- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Short Throw Wall Mount PRJ-WALLKIT-13...
-
Page 2: Important Safety Instructions
(collectively "InFocus"), intend to make this manual accurate and complete. However, InFocus makes no claim that the IMPORTANT ! : The PRJ-WALLKIT-13 short throw projector information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in mount is designed to be mounted to: connection with the installation or use of this product. - Page 3 Installation Instructions PRJ-WALLKIT-13 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz 上紧紧固件 铅笔标记 Befestigungsteil festziehen Stiftmarkierung 旋緊扣件 鉛筆標記 Serrez les fixations Marquage au crayon Serrare il fissaggio 패스너 조이기 Segno a matita 연필 표시 ดึ ง สายรั ด ให ้แน่ น...
-
Page 4: Tools Required For Installation
PRJ-WALLKIT-13 Installation Instructions TOOLS REQUIRED FOR INSTALLATION Hardware required, NOT INCLUDED: Steel Stud Install • 4 - Toggler® 1/4-20 (BB) Snap-Toggle 5/32" • 4 - Grade 2 or better 1/4-20 x 1-3/4" Phillips (included) pan head screws 1/2" • 4 - Grade 2 or better 1/4" washer Concrete Install •... -
Page 5: Site Requirements
Installation Instructions PRJ-WALLKIT-13 Site Requirements WARNING: IMPROPER INSTALLATION CAN LEAD TO EQUIPMENT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! The figure below identifies the minimum requirements for installation of mount onto a steel stud structure. If the structure or its components do not meet these requirements contact the mount manufacturer for specific instructions before attempting installation. -
Page 6: Assembly And Installation
PRJ-WALLKIT-13 Installation Instructions ASSEMBLY AND INSTALLATION The PRJ-WALLKIT-13 short throw projector mount is designed to be mounted to solid concrete, hollow concrete block, 2" x 4" x 4 (dual stud) wood studs (16" on center), or steel studs (16" on center). - Page 7 Installation Instructions PRJ-WALLKIT-13 Wood Studs Steel Studs Using a stud finder and wall plate/bracket assembly, mark IMPORTANT ! : See Site Requirements section before four preliminary mounting holes (dual stud) over center of proceeding with Steel Studs installation to ensure installation...
- Page 8 PRJ-WALLKIT-13 Installation Instructions Holding plastic straps on anchor, pull anchor away from wall until channel rests flush behind wall making sure anchor Steel channel is positioned vertically on stud. (See Figure 6) stud Drywall Slide plastic cap on anchor towards wall until flange of cap is flush with wall.
- Page 9 Installation Instructions PRJ-WALLKIT-13 Wall plate hook Projector arm slots Figure 11 Fasten short throw arm (A) to wall plate (B) using two 1/4-20 x 3/4" button head cap screws (HD). (See Figure 12) (HD) x 2 Figure 9 Installing Short Throw Projector Arm to Bracket Attach arm adjust plate (C) to wall plate ensuring that adjust plate tabs fit into notches on wall plate.
-
Page 10: Projector Installation
PRJ-WALLKIT-13 Installation Instructions Projector Installation WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the weight of the projector does not exceed 25 lbs (11.3 kg). -
Page 11: Pitch Adjustment
Installation Instructions PRJ-WALLKIT-13 Adjustments Height Adjustment Loosen two Phillips screws (one on left, one on right). (See Figure 17) (lower) (raise) Turn the button head cap screw on top of mount clockwise to raise the mount (counterclockwise to lower the mount). -
Page 12: Cable Management (Optional)
PRJ-WALLKIT-13 Installation Instructions Cable Management (Optional) Add end cap (D) to end of short throw projector arm. (See Figure 20) Route cables/cords from projector through opening on projector arm and route to wall. (See Figure 18) Guide cables/cords from wall end of projector arm upward or downward through slots in wall plate. - Page 13 Installation Instructions PRJ-WALLKIT-13 Visit the InFocus support site at www.infocus.com/support...
- Page 14 PRJ-WALLKIT-13 Installation Instructions Visit the InFocus support site at www.infocus.com/support...
- Page 15 Installation Instructions PRJ-WALLKIT-13 Visit the InFocus support site at www.infocus.com/support...
- Page 16 Installation Instructions InFocus Corporation 13190 SW 68th Parkway, Ste 200 Portland, OR 97223 8800-002462 Rev00 ©2013 InFocus Corporation www.infocus.com 09/13...
