Specifications; Recommended Enclosures - Orion H2 10.2 Specifications

S P E C I F I C AT I O N S
Nominal Impedance
RE (DC resistance)
Levc (coil inductance)
Sensitivity @ 1w/1m
Fs (free air resonance)
Qms (mechanical Q)
Qes (electrical Q)
Qts (totalQ)
BL (force factor)
Sd (piston area)
Vas (volume acoustic suspension)
Xmax (linear excursion)
Power (continuous thermal power handling)
Power (peak thermal power handling)
Outside Diameter
Mounting Diameter
Mounting Depth
Basket Displacement
Voice Coil Diameter
E N C L O S U R E R E C O M M E N D AT I O N S
1500 Watt Sealed Enclosure
2500 Watt Sealed Enclosure
1500 Watt Vented Enclosure
Port Tuning Frequency
Port Diameter (inside diameter)
Equivalent Square Port (in.)
Port Length
2500 Watt Vented Enclosure
Port Tuning Frequency
Port Diameter (inside diameter)
Equivalent Square Port (in.)
Port Length
1. Parameters listed are for conventional applications only, further assist please call Tech Audio Support
2. Enclosure volumes are gross air space and include port and speaker displacement
3. Please call Technical Audio support for further specifications and information: 1-800-876-0800 ext. 2032
Specifications subject to change without notice
H2 10.2 H2 10.4
4 ohm 8 ohm
3.11 7.05
1.42 mH 2.6 mH
85.2 dB 82 dB
37.96 Hz 39.06 Hz
8.72 6.73
0.63 0.68
0.58 0.62
16.1 TM 21.51 TM
0.029 sq. m 0.029 sq. m
44.95 sq. in. 44.95 sq. in.
9.68 liters 10.71 liters
0.34 cu. ft. 0.38 cu. ft.
29 mm 29 mm
1.14 in. 1.14 in.
2000 watts 2000 watts
2500 watts 2500 watts
11 in. 11 in.
9.25 in. 9.25 in.
7.5 in. 7.5 in.
0.28 cu. ft. 0.28 cu. ft.
.0098 liters .0098 liters
3.0 in. 3.0 in.
76.2 mm 76.2 mm
0.5 cu. ft. 0.66 cu. ft.
0.33 cu. ft. 0.33 cu. ft.
0.75 cu. ft. 0.65 cu. ft.
26 Hz 30 Hz
3 in. 3 in.
2.65 x 2.65 2.65 x 2.65
29.8 in. 24.7 in.
0.6 cu. ft. 0.5 cu. ft.
29 Hz 34 Hz
3 in. 3 in.
2.65 x 2.65 2.65 x 2.65
32.6 in. 27.5 in.
H2 12.2 H2 12.4 H2 15.2
4 ohm 8 ohm
3.2 7.39
1.5 mH 2.65 mH 1.38 mH
87.8 dB 84.5 dB 90.4 dB
30.54 Hz 33.88 Hz 29.99 Hz
8.56 7.19
0.62 0.66
0.58 0.61
16.68 TM 21.58 TM 15.76 TM
0.044 sq. m 0.044 sq. m 0.078 sq. m
68.2 sq. in. 68.2 sq. in. 120.9 sq. in.
30.18 liters 28.35 liters 79.52 liters
1.1 cu. ft. 1.0 cu. ft. 2.8 cu. ft.
29 mm 29 mm 29 mm
1.14 in. 1.14 in. 1.14 in.
2000 watts 2000 watts 2000 watts
2500 watts 2500 watts 2500 watts
13 in. 13 in. 15.75 in.
11.25 in. 11.25 in.
8 in. 8 in. 9.25 in.
0.39 cu. ft. 0.39 cu. ft. 0.48 cu. ft.
.013 liters .013 liters .016 liters
3.0 in. 3.0 in.
76.2 mm 76.2 mm 76.2 mm
1 cu. ft. 1 cu. ft. 2.4 cu. ft.
0.5 cu. ft. 0.55 cu. ft. 1.7 cu. ft.
1.25 cu. ft. 1.5 cu. ft. 2.25 cu. ft.
28 Hz 28 Hz
4 in. 4 in.
3.54 x 3.54 3.54 x 3.54 4.43 x 4.43
15.8 in. 22.3 in.
1 cu. ft. 1 cu. ft. 2.25 cu. ft.
31 Hz 33 Hz
4 in. 4 in.
3.54 x 3.54 3.54 x 3.54 4.43 x 4.43
32 in. 26.5 in.
H2 15.4
4 ohm 8 ohm
3.3 7
2.55 mH
87.1 dB
30.54 Hz
7.86 6.88
0.85 0.81
0.77 0.73
21.57 TM
0.078 sq. m
120.9 sq. in.
83.77 liters
3 cu. ft.
29 mm
1.14 in.
2000 watts
2500 watts
15.75 in
14 in. 14 in.
9.25 in.
0.48 cu. ft.
.016 liters
3.0 in. 3.0 in.
76.2 mm
2.2 cu. ft.
1.7 cu. ft.
2.5 cu. ft.
33 Hz 32 Hz
5 in. 5 in.
4.43 x 4.43
19 in. 16.8 in.
2.5 cu. ft.
33 Hz 32 Hz
5 in. 5 in.
4.43 x 4.43
19 in. 18.2 in.
