TIME LAPSE VIDEO CASSETTE RECORDER
MODEL
ADV096HD
INSTALLATION AND OPERATION MANUAL
Super VHS ET (Expansion Technology)
Only video cassette tapes with the
The included power cord is used for 120 V, 60 Hz. Never connect any outlet or power
supply having a different voltage or frequency.
This instruction manual is important to you.
Please read it before using your video cassette recorder.
IMPORTANT! Due to the new method for recording tapes in super resolution mode, tapes
recorded in the ADV096HD VCR cannot be reviewed using other models of American
Dynamics VCRs. In addition, tapes recorded on other American Dynamics VCRs cannot be
reviewed using the ADV096HD VCR.
mark or the
mark may be used with this model.
8200-0206-02
