Page 1: Table Of Contents
The Controls on Your Microwave Time Cooking Automatic Cooking Other Features Oven Shelf Helpful Information Microwave Terms Care and Cleaning If Something Goes Wrong Before You Call For Service GE Service Numbers Warranty GEAppliances.com 950 Watts Models: JVM1410 JVM1420 JVM1421 JVM1430 JVM1440...
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION READ ALL SAFETY INFORMATION BEFORE USING FOR YOUR SAFETY PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY For your safety the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury or loss of life.
Page 3 Welcome Welcome to the GE family. We’re proud of our quality products and we believe in dependable service. Start Here!…Before using your Microwave Need Help? Before you call for service, there are a few things you can do to help us serve you better.
Page 4: Safety Precautions
INFORMATION BEFORE USING WARNING When using electrical appliances, basic safety precautions should be followed, including the following: SAFETY PRECAUTIONS This microwave oven is UL listed for installation over electric and gas ranges. This microwave oven is not approved or tested for marine use.
Page 5: Save These Instructions
• As with any appliance, close supervision is necessary when used by children. • Do not store anything directly on top of the microwave oven surface when the microwave oven is in operation.
Page 6: Special Notes About Microwaving
Such use of the microwave oven could result in injury. • Do not boil eggs in a microwave oven. Pressure...
Page 7 — Do not use straight- sided containers with narrow necks. — After heating, allow the container to stand in the microwave oven for a short time before removing the container. — Use extreme care when inserting a spoon or other utensil into the container.
Page 8 IMPORTANT SAFETY INFORMATION SPECIAL NOTES ABOUT MICROWAVING MICROWAVE- SAFE COOKWARE Make sure all cookware used in your microwave oven is suitable for microwaving. Most glass casseroles, cooking dishes, measuring cups, custard cups, pottery or china dinnerware which does not have metallic trim or glaze with a metallic sheen can be used.
Page 9 3/4″ high; remove the top foil cover and return the tray to the box. When using foil in the microwave oven, keep the foil at least 1″ away from the sides of the oven. THE VENT The fan will operate...
Page 10: Grounding Instructions
Filter Kits JX81A—Recirculating Charcoal Filter Kit Filter kits are used when the microwave oven cannot be vented to the outside. Available at extra cost from your GE supplier.
Page 11: Operating Instructions
8 Convenience Guide. NOTE: Rating plate, oven vent(s) and oven light are located on the inside walls of the microwave oven. 9 Shelf (on some models). Lets you microwave several foods at once. Food microwaves best when placed directly...
Page 12: The Controls On Your Microwave
Quick Start The Controls on Your Microwave Oven (Throughout this manual, features and appearance may vary from your model.) You can microwave by time, temperature, or with the convenience features. Time Features Time Cooking Press TIME COOK I & II (Press once or twice)
Page 13: Convenience Features
HELP (on some models) Press this pad and any feature pad for usage instructions and tips. Convenience Features Press POPCORN BEVERAGE REHEAT DEFROST AUTO/TIME (Press once) GUIDE ON MICROWAVE Before you begin, check the guide located on the inside front of the oven when you open the door.
Page 14: Changing Power Levels
1–10. 5 Press START. Variable power levels add flexibility to microwave cooking. The power levels on the microwave oven can be compared to the surface units on a range. High (power level 10) or full power is the fastest way to cook and gives you 100% power.
Page 15: Time Cooking
Time Features Time Cook 1 Press TIME COOK. 2 Enter cooking time. 3 Change power level if you don’t want full power. (Press POWER LEVEL. Select a desired power level 1–10.) 4 Press START. Time Cook I Allows you to microwave for any time up to 99 minutes and 99 seconds.
Page 16 Operating Instructions Cooking Guide for Time Cook I & II NOTE: Use power level High (10) unless otherwise noted. Vegetable Amount Asparagus (fresh spears) 1 lb. (frozen spears) 10-oz. package Beans (fresh green) 1 lb. cut in half (frozen green) 10-oz. package (frozen lima) 10-oz.
Page 17 Vegetable Amount Corn (frozen kernel) 10-oz. package Corn on the cob (fresh) 1 to 5 ears (frozen) 1 ear 2 to 6 ears Mixed vegetables (frozen) 10-oz. package Peas (fresh, shelled) 2 lbs. unshelled 9 to 12 min. (frozen) 10-oz. package Potatoes (fresh, cubed, 4 potatoes...
Page 18: Time Defrost
Operating Instructions Time Features Time Defrost 1 Press DEFROST AUTO/TIME twice. 2 Enter defrosting time. 3 Press START. 4 Turn food over when the oven signals. 5 Press START. (Auto Defrost explained in the section on Convenience Features.) Allows you to defrost for the length of time you select.
Page 19: Defrosting Guide
Defrosting Guide Food Breads, Cakes Bread, buns or rolls (1 piece) Sweet rolls (approx. 12 oz.) Fish and Seafood Fillets, frozen (1 lb.) Shellfish, small pieces (1 lb.) Fruit Plastic pouch—1 to 2 (10-oz. package) Meat Bacon (1 lb.) Franks (1 lb.) Ground meat (1 lb.) Roast: beef, lamb, veal, pork Steaks, chops and cutlets...
Page 20: Express Cook
Operating Instructions Time Features Express Cook Add 30 Seconds This is a quick way to set cooking time for 1–6 minutes. Press one of the Express Cook pads (from 1 to 6) for 1 to 6 minutes of cooking at power level 10. For example, press the 2 pad for 2 minutes of cooking time.
Page 21: Automatic Cooking
Convenience Features Popcorn NOTE: Do not use the metal shelf when cooking popcorn. How to Use the Popcorn Feature 1 Follow package instructions, using Time Cook if the package is less than 1.75 ounces or larger than 3.5 ounces. Place the package of popcorn in the center of the microwave.
Page 22 Operating Instructions Convenience Features Reheat NOTE: Do not use the metal shelf when using the Reheat feature. Reheat Guide Food Type 1 Pasta 2 Meats, casseroles, pizza 3 Fruits and vegetables 4 Beverages, 8–10 oz. 5 Sauces and gravies 6 Plate of leftovers (2 to 3 foods, 4 oz.
Page 23 Beverage The Beverage feature heats servings of any beverage. Press BEVERAGE. The oven starts immediately. On some models, the serving size is automatically set at 1, but can be changed by pressing 2 or 3 right after pressing BEVERAGE. On model JVM1430 only, the serving size is automatically set at 4 ounces, but can be changed by tapping...
Page 24: Auto Defrost
Operating Instructions Convenience Features Auto Defrost 1 Press DEFROST AUTO/TIME once. 2 Using the Conversion Guide at right, enter food weight. For example, press pads 1 and 2 for 1.2 pounds (1 pound, 3 ounces). 3 Press START. (Time Defrost is explained in the Time Features section.) The Defrost Auto/Time...
Page 25: Other Features
Other Features Your Model May Have Help Cooking Complete Reminder Clock (On some models) The HELP pad displays feature information and helpful hints. Press HELP, then select a feature pad. To remind you that you have food in the oven, the oven will display “FOOD IS READY”...
Page 26: Scroll Speed
Operating Instructions Other Features Your Model May Have Scroll Speed Display On/Off Delay Start (On some models) The scroll speed of the display can be changed. Press and hold the AM/PM pad about 3 seconds to bring up the display. Select 1–5 for slow to fast scroll speed.
Page 27 Timer On/Off Start/Pause Reminder Timer On/Off operates as a minute timer and can be used at any time, even when the oven is operating. 1 Press TIMER ON/OFF. 2 Enter time you want to count down. 3 Press TIMER ON/OFF to start.
Page 28 Operating Instructions Other Features Your Model May Have Child Lock-Out Turntable Automatic Fan You may lock the control panel to prevent the microwave from being accidentally started or used by children. (On some models) For best cooking results, leave the turntable on. It can be turned off for large dishes.
Page 29: Beeper Volume
Surface Light Beeper Volume Vent Fan Press to turn the surface light on or off. (On some models) The beeper sound level can be adjusted. Press BEEPER VOLUME. Choose 0–3 for mute to loud. The vent fan removes steam and other vapors from surface cooking.
Page 30: Oven Shelf
Operating Instructions Other Features Your Model May Have Shelf (on some models) How to Use the Shelf When Microwaving • Make sure the shelf is positioned properly inside the microwave to prevent damage to the oven from arcing. • Do not use a microwave browning dish on the shelf.
Page 31 Shelf and Reheating • To reheat on 2 levels • To reheat 2 dishes on the lower level: 1 Multiply reheat time by 1 2 Switch places after 1/2 the time.
Page 32: Helpful Information
Helpful Information Microwave Terms Term Definition Arcing Arcing is the microwave term for sparks in the oven. Arcing is caused by: Covering Covers hold in moisture, allow for more even heating and reduce cooking time. Venting plastic wrap or covering with wax paper allows excess steam to escape.
Page 33: Care And Cleaning
Care and Cleaning Helpful Hints How to Clean the Inside An occasional thorough wiping with a solution of baking soda and water keeps the inside fresh. Walls, Floor, Inside Window, Metal and Plastic Parts on the Door Some spatters can be removed with a paper towel, others may require a damp cloth.
Page 34: How To Clean
We recommend against using cleaners with ammonia or alcohol, as they can damage the appearance of the microwave oven. If you choose to use a common household cleaner, first apply the cleaner directly to a clean cloth, then wipe the soiled area.
Page 35: Light Bulb Replacement
Light Bulb Replacement Cooktop Light/ Night Light Replace the burned-out bulb with a 40-watt incandescent bulb (WB36X10003), available from your GE supplier. Oven Light Replace the burned-out bulb with a 40-watt incandescent bulb (WB36X10003), available from your GE supplier. 1 To replace the bulb(s),...
Page 36: The Exhaust Feature
Helpful Information The Exhaust Feature The Vent Fan Reusable Grease Filters Removing and Cleaning the Filter The vent fan has 2 metal reusable grease filters. The metal filters trap grease released by foods on the cooktop. They also prevent flames from foods on the cooktop from damaging the inside of the microwave.
Page 37: Charcoal Filter
Charcoal Filter (on some models) The charcoal filter cannot be cleaned. It must be replaced. Order Part No. WB2X9883 from your GE supplier. To Remove Charcoal Filter To Install Charcoal Filter If the model is not vented to the outside, the air will...
Page 38: If Something Goes Wrong
What to Do • Replace fuse or reset circuit breaker. • Unplug the microwave oven, then plug it back in. • Make sure the 3-prong plug on the oven is fully inserted into wall outlet.
Page 39 Things That Are Normal • Steam or vapor escaping from around the door. • Light reflection around door or outer case. • Dimming oven light and change in the blower sound at power levels other than high. • Dull thumping sound while oven is operating.
Page 40 Notes...
Page 41 Notes...
Page 42: Ge Service Numbers
Try the GE Appliances Website 24 hours a day, any day of the year! Expert GE repair service is only one step away from your door. Get on-line and schedule your service at your convenience 24 hours...
Page 43 Parts and Accessories www.GEAppliances.com 800.626.2002 Register Your Appliance www.GEAppliances.com Individuals qualified to service their own appliances can have parts or accessories sent directly to their home. (VISA, MasterCard and Discover cards are accepted.) Order on-line today, 24 hours every day or by phone at 800.626.2002 during normal business hours.
Page 44: Warranty
Should your appliance need service, during warranty period or beyond, call 800.GE.CARES (800.432.2737). Warrantor is not responsible for consequential damages. • Replacement of the cooktop light bulbs. • Failure of the product if it is misused, or used for other than the intended purpose or used commercially.
