- Page 1 User's Manual Separate Volume Spot Color Guide C941dn ES9541dn...
-
Page 2: Table Of Contents
Contents Contents Setting the Spot Color kit ..............3 Control Panel Explanation ..............7 Standby Screen ...................... 7 Menu table of Spot Color toner ................8 Checking the printer drivers ..............9 Printer driver functions table ............. 11 With white toner mounted ..................11 With clear toner mounted .................. -
Page 3: Setting The Spot Color Kit
Setting the Spot Color kit Setting the Spot Color kit This section explains how to set the Spot Color kit. First "mount the consumables" as described in "Basic" before setting the Spot Color kit. Open the package, and remove the Remove the duct protective tape (x2 duct, toner, and image drum. - Page 4 Setting the Spot Color kit Mount the duct to the printer. Remove the stopper (orange). Align the (red) arrows on the image drum and printer, and insert gently into the slot while taking care not to touch the (green) light sensor on the underside with your hands, and then push in firmly as far as it will go.
- Page 5 Setting the Spot Color kit Close the front cover. Check the position of the slot, and firmly push the toner cartridge in as far as it will go. Remove the toner cartridge from its packaging, and shake it vertically and horizontally.
- Page 6 Setting the Spot Color kit Press and hold the power switch for approx. 1s. Memo z When the Spot Color kit has been set, return to the "Basic", and implement the tasks described from "Setting the Paper" onwards. - 6 -...
-
Page 7: Control Panel Explanation
Control Panel Explanation Control Panel Explanation This section explains the C941dn/ES9541dn control panel. Standby Screen With white toner mounted Displays the printer status. Displays the remaining consumables quantities. With clear toner mounted Displays the printer status. Displays the remaining consumables quantities. - 7 -... -
Page 8: Menu Table Of Spot Color Toner
Control Panel Explanation Menu table of Spot Color toner The printer menus for clear toner and white toner are as described below. Memo z For details of menus other than the Spot Color toner, see the "Basic". Configuration Admin Setup Tray Count Network Setup Supplies Life... -
Page 9: Checking The Printer Drivers
Checking the printer drivers Checking the printer drivers When installation of printer drivers is complete, check that the Spot Color toner that has been mounted is selected in [Spot Color Toner] in the [Device Settings] tab or [Device Options] tab. Memo z For the printer driver installation method, see "Connecting to the PC"... - Page 10 Checking the printer drivers „ Using Windows XPS printer drivers The color of the Spot Color toner that has been mounted is displayed in [Spot color toner] in the [Device Options] tab. If the mounted color is not set, select the relevant Spot color toner color.
-
Page 11: Printer Driver Functions Table
Printer driver functions table Printer driver functions table This section explains the Spot Color toner functions in the printer drivers. Select the Spot Color toner in the [Device Settings] tab or [Device Options] tabs of the printer drivers. The following screen will be displayed. Note z Plain, recycled, and glossy under GSM 52 to 64g/m (ream weight under 45 to 55kg) are incompatible with Spot Color printing... - Page 12 Printer driver functions table „ Using Windows PCL printer drivers Click the [Spot Color] tab to display the window for setting the Spot color toner. Item Explanation Usage methods Do not use Print without using white toner. Full page Using white toner on whole printed pages. Data portion (Excluding white) Using white toner in the data portions excluding the white portions.
- Page 13 Printer driver functions table „ Using Windows XPS printer drivers Click [Spot Color] in the [Color] tab to display the window for setting the Spot color toner. Item Explanation Usage Methods Do not use Print without using white toner. Full page Using white toner on whole printed pages.
- Page 14 Printer driver functions table „ Using Mac OS X PS printer drivers Select the [Spot Color] panel to display the window for setting the Spot Color toner. Item Explanation Usage methods Do not use Print without using white toner. Full page Using white toner on whole printed pages.
-
Page 15: With Clear Toner Mounted
Printer driver functions table With clear toner mounted „ Using Windows PS printer drivers Click [Spot Color] in the [Color] tab to display the window for setting the Spot Color toner. Item Explanation Usage Methods Do not use Print without using clear toner. Full page Using clear toner on whole printed pages. - Page 16 Printer driver functions table „ Using Windows PCL printer drivers Click the [Spot Color] tab to display the window for setting the Spot Color toner. Item Explanation Usage methods Do not use Print without using clear toner. Full page Using clear toner on whole printed pages. Data portion (Excluding white) Using clear toner in the data portions excluding the white portions.
- Page 17 Printer driver functions table „ Using Windows XPS printer drivers Click [Spot Color] in the [Color] tab to display the window for setting the Spot color toner. Item Explanation Usage methods Do not use Print without using clear toner. Full page Using clear toner on whole printed pages.
- Page 18 Printer driver functions table „ Using Mac OS X PS printer drivers Click the [Spot Color] panel to display the window for setting the Spot Color toner. Item Explanation Usage methods Do not use Print without using clear toner. Full page Using clear toner on whole printed pages.
-
Page 19: Printing On Color Paper
Printing on color paper Printing on color paper Color papers that can be Printing using white toner used only Use color paper that satisfies the following Printing text and illustrations using only white conditions. toner on color paper. z Pigments used to color the paper or ink that is Before printing, check that white toner has been mounted to the device, and that white toner has heat-resistant at 230ºC. - Page 20 Printing on color paper Click [Spot Color] in the [Color] tab. „ Using Windows PCL printer drivers Open the file to be printed. Click [Page Setup] in the [File] menu. Select the paper size and print orientation, and click [OK]. Select [Print] in the [File] menu.
- Page 21 Printing on color paper „ Using Windows XPS printer drivers Select [Printing only spot color toner] in [Usage Methods], and click [OK]. Open the file to be printed. Click [Page Setup] in the [File] menu. Select the paper size and print orientation, and click [OK].
-
Page 22: Printing White Under Color (Spot Color Overprint Function)
Printing on color paper „ Using Mac OS X PS printer Printing white under color (Spot drivers Color overprint function) Open the file to be printed. If printing on color paper, print the base using white toner, and then overprint using colors Click [Page Setup] in the [File] menu. - Page 23 Printing on color paper Click [Spot Color] in the [Color] tab. Select [Printing white under the color] in [Order of superposition], and click [OK]. Select [Data portion (Including white)] in [Usage Methods]. Click [OK] to return to the [Print] screen. Click [Print] in the [Print] screen to print.
- Page 24 Printing on color paper „ Using Windows PCL printer drivers Select "Printing white under the color" in [Order of superposition], and click [OK]. Open the file to be printed. Click [Page Setup] in the [File] menu. Select the paper size and print orientation, and click [OK].
- Page 25 Printing on color paper „ Using Windows XPS printer drivers Select [Data portion (Including white)] in [Usage Methods]. Open the file to be printed. Click [Page Setup] in the [File] menu. Select the paper size and print orientation, and click [OK]. Select [Print] in the [File] menu.
- Page 26 Printing on color paper „ Using Mac OS X PS printer Select [Printing white under the color] in [Order of superposition] in the [Spot drivers Color] panel. Open the file to be printed. Click [Page Setup] in the [File] menu. Select the paper size and print orientation using the page setup dialog box, and click [OK].
-
Page 27: Printing On Transparent Film
Printing on transparent film Printing on transparent film Before printing, check that white toner has been mounted to the device, and that white toner has been selected using the printer drivers. Memo z For how to check the Spot Color toner selected using the printer drivers, see "Checking the printer drivers"... -
Page 28: Mirror Reverse Printing
Printing on transparent film Select [Media Type], and press the [OK] Mirror reverse printing button. If printing on transparent film, print in the order color (CMYK) and then white, and print using mirror reverse for correct appearance when turned over. „... - Page 29 Printing on transparent film Click [Spot Color] in the [Color] tab. „ Using Windows PCL printer drivers Open the file to be printed. Click [Page Setup] in the [File] menu. Select the paper size and print orientation, and click [OK]. Select [Print] in the [File] menu.
- Page 30 Printing on transparent film For reverse printing, enable [Mirror „ Using Windows XPS printer drivers Print], and click [OK]. Open the file to be printed. Click [Page Setup] in the [File] menu. Select the paper size and print orientation, and click [OK]. Select [Print] in the [File] menu.
- Page 31 Printing on transparent film Click [Spot Color] in the [Color] tab. „ Using Mac OS X PS printer drivers Open the file to be printed. Click [Page Setup] in the [File] menu. Select the paper size and print orientation using the page setup dialog box, and click [OK].
- Page 32 Printing on transparent film For reverse printing, enable [Mirror Print]. Click [Print] to print. - 32 -...
-
Page 33: Printing By Using Applications To Specify Spot Color Toner (Ps Printer Drivers Only)
Printing by using applications to specify Spot Color toner (PS printer drivers only) Printing by using applications to specify Spot Color toner (PS printer drivers only) Using Illustrator „ Printing If printing Spot Color, make the settings using This explanation uses Illustrator CS6 as an the application print dialog box. -
Page 34: Using Photoshop
Printing by using applications to specify Spot Color toner (PS printer drivers only) ‰ Using Windows Using Photoshop Select Windows PS printer This explanation uses Photoshop CS6 as an drivers, and click [Advanced] (or example. [Properties]). „ Adding Spot Color Channels Click [Spot Color] in the [Color] tab. - Page 35 Printing by using applications to specify Spot Color toner (PS printer drivers only) „ Printing ‰ Using Windows Select Windows PS printer drivers, and click Open the file that has been saved in [Advanced] (or [Properties]). PDF format using Acrobat or Adobe Reader.
-
Page 36: Fine-Tuning White Watermarks
Fine-tuning white watermarks Fine-tuning white watermarks Fine-tune the white using the printer control panel. Press the scroll button Specify the white highlight value, and press the [OK] button. Check that shown to the left of the specified value. Select [Calibration], and press the [OK] button. -
Page 37: Replacing Spot Color Kits
Replacing Spot Color kits Replacing Spot Color kits This section explains the procedure for replacing Spot Color white kits and Spot Color clear kits. This section explains the procedure for replacing Spot Color clear kits from Spot Color white kits. Press and hold the power switch for Remove the white toner. - Page 38 Replacing Spot Color kits Gently lift up the (blue) handle, and Close the front cover. remove the image drum while taking care not to touch the bottom of the drum (i.e., the green cylinder) with your hands. Lift up and remove the white duct. Note z To prevent photodegredation of the image drum, do not leave in direct sunlight or fluorescent light.
- Page 39 Replacing Spot Color kits Remove the duct for the Spot Color Open the front cover. clear kit to be mounted from its box. Mount the clear duct to the printer. Remove the duct protective tape (x2 locations). Pull out the bottom of the clear duct. - 39 -...
- Page 40 Replacing Spot Color kits Close the front cover. Remove the stopper (orange). Remove the clear drum to be mounted Align the (red) arrows on the image from its bag. drum and printer, and insert gently into the slot while taking care not to touch the (green) light sensor on the underside with your hands, and then push in firmly as far as it will go.
- Page 41 Replacing Spot Color kits Close the front cover. Check the position of the slot, and firmly push in the clear toner as far as it will go. Remove the clear toner to be mounted from its bag. Close the toner replacement cover. Open the toner replacement cover.
- Page 42 Replacing Spot Color kits Place the removed white toner, white Press and hold the power switch for duct, and white image drum in the bag approx. 1s. before placing the bag in the box for storage. Memo z See "Test Printing Using the Printer Only" in "Basic", and check that the Spot Color kit has been replaced.
- Page 43 Replacing Spot Color kits „ Memo - 43 -...
- Page 44 Oki Data Corporation 4-11-22 Shibaura, Minato-ku,Tokyo 108-8551, Japan www.okiprintingsolutions.com 45602302EE Rev1...
