Page 1: Getting Started
Getting Started © 1998, 1999 Hitachi Koki Imaging Solutions, Inc. 1757 Tapo Canyon Rd. Simi Valley, CA 93063 March 1999 335841-002 Revision B... - Page 2 40, DDS 32/40, ScanCenter, and their associated logo marks, are trademarks of Hitachi Koki Imaging Solutions, Inc. Hitachi and the Hitachi logo are trademarks of Hitachi, Ltd. All rights reserved. NOTICE TO USER In an effort to meet the demands of a rapidly changing technology, the manufacturer is continually developing new features and functions to meet your changing printing or printer needs.
-
Page 3: Related Documentation
Preface What This Manual Contains Chapter 1 (Unpacking and Setup) shows how to unpack the ScanCenter, how to attach the necessary cables and power cord, and provides power up instructions. Appendix A (Safety Information) provides safety, certification, and environmental information. Related Documentation ScanCenter User’s Guide ScanCenter Quick Reference Guide... - Page 4 Preface...
-
Page 5: Table Of Contents
Contents What This Manual Contains ......... . i Related Documentation . - Page 6 Contents iv...
-
Page 7: Chapter 1. Unpacking And Setup
Chapter 1 Unpacking and Setup Before You Begin Set up of the printer must be complete before you begin to set up the scanner. Selecting a Location The scanner must be located on a flat, stable surface near the printer. This can be a table or desk, or it can be the optional ScanCenter Stand. -
Page 8: Unpacking The Scanner
Unpacking the Scanner Follow these instructions for unpacking the scanner. The packing arrangement is illustrated in the figure below. Left and Right Packaging Foam Shipaway Kit Packaging Front Packaging Foam Bottom Packaging Foam 1. Open the box. 2. Lift up and remove the left, right, and front packaging foam. 3. -
Page 9: Shipaway Kit Contents
Shipaway Kit Contents You will need the following items from the shipaway kit to set up the scanner: Shroud Standoffs (2 ea.) Tie Wrap (1 ea.) Printer Cable Power Cord (USA and Europe only) Unpacking and Setup... -
Page 10: Scanner Components
Scanner Components ADF Cover Document Table Document Guides Document Support Wire Indicator Lamps Power Switch Cable Cover Exit Table Exit Table Extension Scanner Indicator Lamps Rear View Without Shroud Printer Connector Image Processing Board OCP Cable SCSI Connectors (Do Not Use) Power Plug Inlet Reset Switch DIP Switches... -
Page 11: Installation Instructions
Installation Instructions Perform the following steps to install the scanner: 1. Place the scanner on a table or desktop not more than 6 feet from the printer. Place the scanner on the optional ScanCenter Stand with the two left feet of the scanner in the cutouts on the left side of the tray. WARNING! When using the optional ScanCenter Stand, do not place the scanner on the stand until the printer is in place and the entire unit is in the desired... - Page 12 3. Plug in the power cord as shown below. Power Cord Printer Cable Connector OCP Connector Printer Cable OCP Cable Unpacking and Setup...
-
Page 13: Attaching The Shroud
Attaching the Shroud A shroud is attached to the scanner to protect the cables from coming loose and to provide a clean, finished appearance to the unit. To attach the shroud: 1. Unscrew the thumbscrews from the I/O plate and set them aside for later use. - Page 14 3. The power cord and the printer cable will be routed through an opening in the side of the shroud as it is installed. To ensure the printer cable stays connected, use the tie wrap to fasten the cable to the left standoff.
-
Page 15: Attaching The Cables And Power Cord To The Printer
Attaching the Cables and Power Cord to the Printer 1. If you are using the ScanCenter Stand, route the power cord and the printer cable down the back of the stand and secure them with the cable clamp. 2. Connect the printer cable to the printer interface where indicated below. -
Page 16: Power Up
Power Up To turn the power on, press the switch on the front of the scanner. A green LED will light on the front of the scanner and the touch panel will display a screen indicating the diagnostics are being run. When the diagnostics are complete (about 2 minutes), the touch panel will display the Job Status Screen. -
Page 17: Appendix A. Safety Information
Appendix A Safety Information General For the safety of the personnel and the product, operate the equipment according to the instructions in this user’s guide. The manufacturer will not be responsible for any problems or damage that arise from improper use. Certifications FCC Notice This equipment has been tested and found to comply with the limits for a... -
Page 18: Canadian Certification
Application of Council Directive(s): 73/23/EEC, 89/336/EEC Standard(s) to which the Conformity is Declared: EN60950, EN55022 Class A, EN50082-1 Manufacturer’s Name: Hitachi Koki Imaging Solutions, Inc. 1757 Tapo Canyon Rd., Manufacturer’s Address: Simi Valley, CA 93063 Type of Equipment: Scanner Model No.: The equipment specified above conforms to the Directives and to the Standards referenced above. -
Page 19: Ce Notice
CE Notice This equipment has been tested and found to comply with the limits for a class A Information Technology Equipment in accordance with the Euro- pean Standard EN55022. These limits are designed to provide reasonable protection against unacceptable interference in either commercial or industrial environments. This equipment generates, uses, and can radiate radio signals and if it is not installed and used in accordance with the instructions detailed in this user’s guide, it may cause unacceptable interference to radio communication... -
Page 20: Precautions
Precautions Read all of these instructions and keep them for later use. Follow all warnings and instructions marked on the device. Unplug this device from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Do not use this device near water. Do not place this device on an unstable cart, stand, or table. - Page 21 Never push objects of any kind into this device through cabinet slots as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product. Except as specifically explained in the user’s manual, do not attempt to service this device yourself.
-
Page 22: Environmental Limit
Use the standard cable attached provided with the scanner. Other- wise, use cables that meet the following requirements:. Area Rating Plug Cable Connector SVT or SJT 18/3 IEC320 type North 120V NEMA 5-15P AWG Less than America 1.6 m long 230V Use the required H05VV-F or...
