Sockets
Name/Model No.
• Socket, HC 2-pin
• The difference between the HC2 and HC4 sockets is
only the number of the pins. Their appearances and
sizes are the same.
HC2-SS-K
• Socket, HC 4-pin
HC4-SS-K
• Sockets for PC board
HC2-Socket for PC board: HC2-PS-K
HC4-Socket for PC board: HC4-PS-K
Dimensions
4.06
.160
1
2
3
4
5
6
7
8
29.4
6.35
1.157
.250
9 10
11
12
25.2
6.35
.992
.250
1.27
13
14
.050
2.3
.091
16.55
.652
7.65
.301
General tolerance: ±0.5
4.06
.160
1
2
3
4
5
6
7
8
29.4
6.35
1.157
.250
9
10
11
12
25.2
6.35
.250
.992
1.27
13
14
.050
2.3
.091
16.55
.652
7.65
.301
All Rights Reserved © COPYRIGHT Panasonic Electric Works Co., Ltd.
S1DXM-A/M/S1DX COMMON OPTIONS
Mounting hole dimensions
• The thickness of applicable chassis plates ranges
from 1.0 to 2.0 mm
• To install the socket easily, insert the socket top
surface into the drilled holes and press the two points
4.45 4.45
.175 .175
on the fastening plate indicated by arrows as shown in
4.45
the fig. below.
.175
7.06
.278
25.5
1.004
21.2
.835
±.020
4.45 4.45
.175
.175
4.45
.175
25.8
7.06
.278
1.016
25.5
1.004
The interval size between
the sockets which are
parallel installed.
21.2
Dimensional tolerance of machining: ±0.1
.835
.039 to .079
inch.
5.9
21.6
.232
.850
±.004
Applicable timers
S1DX(2c)
S1DX(4c)
S1DXM(2c)
S1DXM(4c)
Not
Available
available
Available
Available
