Panasonic PT-DZ12000 Specifications

3-chip dlp projector
Hide thumbs Also See for PT-DZ12000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Instructions
P ro d u c t N u m b e r :
P ro d u c t N a m e :
As of July 2008. Appearance and specifications are subject to change without notice.
S
P
E
C
PT-DZ12000
3-Chip DLP™ Projector
F
I
L
E
< 1 >

Advertisement

Table of Contents
loading

Related Manuals for Panasonic PT-DZ12000

Summary of Contents for Panasonic PT-DZ12000

  • Page 1 PT-DZ12000 P ro d u c t N u m b e r : 3-Chip DLP™ Projector P ro d u c t N a m e : As of July 2008. Appearance and specifications are subject to change without notice.

  • Page 2: Specifications

    PT-DZ12000 3-Chip DLP™ Projector Specifications Main Unit Power supply: North America: 120–240 V AC, 16 – 9.0 A, 50/60 Hz (3-wire single-phase) Europe, Asia 220–240 V AC, 9.5 A, 50/60 Hz (3-wire single-phase) Power consumption: North America: 1,600–1,500 W (10-15 W in standby mode with fan stopped)
  • Page 3 PT-DZ12000 3-Chip DLP™ Projector RGB2 IN: D-sub HD 15-pin x 1 R, G, B: 0.7 Vp-p (1.0 Vp-p for sync on G), 75 ohms HD, VD, SYNC: TTL, high impedance, positive/negative automatic VD: 1.4–5.0 Vp-p, positive/negative automatic, 75 ohms Y, P Y: 1.0 p-p, 75 ohms (incl.
  • Page 4 PT-DZ12000 3-Chip DLP™ Projector Operating temperature* 0°C–45°C (32°F–113°F) Operating humidity: 10%–80% (no condensation) Remote Control Unit Number of functions: 35 keys, 39 functions Power supply: 3 V DC (AA battery x 2) Operation range* Approx. 30 m (98.4´) when operated from directly signal receptor Dimensions (W x H x D): 51 x 22.7 x 176 mm (2˝...
  • Page 5 (NEMA 5-20R) (NEMA 6-15R) Note: Be sure to use the power plug adaptor cord supplied with the projector. The supplied power plug adaptor can be used with the PT-DZ12000 only. Dimensions unit : mm (inch) NOTE: This illustration is not drawn to scale.

  • Page 6: Standard Setting-Up Positions

    PT-DZ12000 3-Chip DLP™ Projector Standard setting-up positions *1 When the lens protrudes to the maximum. 414 mm (16-5/16˝) with the ET-D75LE6 316.5 mm (12-15/32˝) with ET-D75LE1 Upper edge of projected image 301 mm (11-27/32˝) with the ET-D75LE2 304.5 mm (12˝) with the ET-D75LE3 328.4 mm (12-15/16˝) with the ET-D75LE4...

  • Page 7: Calculation Of The Projection Distance

    PT-DZ12000 3-Chip DLP™ Projector Projection distance (screen aspect ratio 16:9) Distance to screen Height from the edge of screen to Zoom Fixed-focus center of lens (H) Lens ET-D75LE6 ET-D75LE1 ET-D75LE2 ET-D75LE3 ET-D75LE4 ET-D75LE8 ET-D75LE5 Zoom lenses Fixed- (Throw ratio) Zoom lens...
  • Page 8 PT-DZ12000 3-Chip DLP™ Projector Installable Angle Install the projector at an angle within the range shown below. • Vertical direction • Horizontal direction The projector may be installed at a vertical The projector may be installed at a horizontal angle of 360°.

  • Page 9: List Of Compatible Signals

    PT-DZ12000 3-Chip DLP™ Projector List of compatible signals This projector supports RGB signals with horizontal frequencies of 15 to 100 kHz, vertical frequencies of 24 to 120 Hz and dot clock frequencies of 20 MHz to 162 MHz. NOTE: The native resolution of this projector is 1,920 x 1,200 pixels. If the display resolution of the input signal is different from the native resolution, image compression or expansion will be used to convert the input signal to a level within the native resolution.
  • Page 10 PT-DZ12000 3-Chip DLP™ Projector Serial connector The serial connector complies with RS-232C. To control the projector from a personal computer, com- mands must be input through communication software, based on the format and satisfying the commu- nication conditions shown below.
  • Page 11 PT-DZ12000 3-Chip DLP™ Projector Cable specifications Projector PC (DTE) Control commands Command : Parameter Function Callback Standby power on POWER (STANDBY) Standby power off RGB 1 IIS:RG1 IIS:RG1 INPUT SELECT IIS:RG2 RGB 2 IIS:RG2 IIS:VID Video IIS:VID S-Video IIS:SVD IIS:SVD...

  • Page 12: Status Asking Commands

    PT-DZ12000 3-Chip DLP™ Projector Status asking commands Command : Parameter Function Callback Description Main power status Shutter function status Input signal status RGB 1 RGB 2 Video S-Video On-screen display status Projector run time 00000h –99999h 00000-99999 Lamp 1 run time Q$L:p1 0000h –9999h...
  • Page 13 PT-DZ12000 3-Chip DLP™ Projector Notes on Projector Placement and Operation The projector uses a high-wattage lamp that becomes very hot during operation. Please observe the following precautions. Never place objects on top of the projector while it is operating. Make sure there is an unobstructed space of 500 mm (19-11/16˝) or more around the projector’s exhaust openings.
