ACR Electronics 2800 Product Support Manual

Ship security alert system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ThunderBird SSAS
Ship Security Alert System
OWNER_____________________________
VESSEL_____________________________
RADIO CALL SIGN_____________________
Product Support Manual
5757 Ravenswood Road
Fort Lauderdale, FL 33312
Tel : +1 (954) 981-3333
Fax: +1 (954) 983-5087
www.acrelectronics.com
Email: info@acrelectronics.com
Product No. 2800
RLB-33S
Y1-03-0180
Rev. D
FCC Type Accepted
ACR Electronics, Inc.
Y1-03-0180 Rev. D

Advertisement

Table of Contents
loading

Related Manuals for ACR Electronics 2800

Summary of Contents for ACR Electronics 2800

  • Page 1 OWNER_____________________________ VESSEL_____________________________ RADIO CALL SIGN_____________________ Product Support Manual ThunderBird SSAS Ship Security Alert System Product No. 2800 RLB-33S Y1-03-0180 Rev. D FCC Type Accepted ACR Electronics, Inc. 5757 Ravenswood Road Fort Lauderdale, FL 33312 Tel : +1 (954) 981-3333 Fax: +1 (954) 983-5087 www.acrelectronics.com...
  • Page 2 INCUR A SEVERE PENALTY ***Attention*** This beacon MUST be reprogrammed by an authorized ACR distributor prior to installation and use. Failure to do so will result in incorrect routing of a security alert. To ensure covert nature of the beacon, do not place the proof of registration label onto your SSAS beacon.

  • Page 3: Table Of Contents

    (SSAS). The combination of superior design, high quality raw materials and quality controlled manufacturing produces a product that will perform for years to come. The test facility at ACR can reproduce some of the harshest environmental conditions known to man. This assures that the products we design and manufacture can stand up to the rigors found in a marine environment.

  • Page 4: Section 1 - Registration And Programming Your 406 Mhz Beacons

    Programming This SSAS beacon is programmed with a serialized Unique Identifier Number (UIN). In order for a security alert to be routed properly, this beacon must be reprogrammed by an authorized ACR distributor before installation or use can occur. This beacon must be reprogrammed as follows: With protocol code for SSAS With the country code of the vessel’s flag state...

  • Page 5: Registration Outside Of The United States

    1.4.1 Commercial vessels in the United States In the United States, commercial vessels that are required to have a radio station license are required to modify that license when an SSAS is added to the vessel. Please update FCC FORM 605 to modify your radio station license.

  • Page 6: Section 3 - Installation

    From Any Location USCG Headquarter Command Center Tel: (800) 323-7233 For Canadian Pacific waters: Canadian Coast Guard Rescue Coordination Centre Victoria Tel: (800) 567-5111 For Canadian Atlantic waters: Canadian Coast Guard Rescue Coordination Centre Halifax Tel: (800) 565-1582 For other Canadian waters (Great Lakes, Hudson’s Bay, and Arctic) Canadian Coast Guard Rescue Coordination Centre Trenton Tel: (800) 267-7270 2.2.2...

  • Page 7: Activation Switch Installation

    3.2.2 Mounting location The location selected must be sufficiently rigid to support the weight of the total installation (approx. 2 lbs) and at the same time consider vibration, exposure to surrounding hazards, such as equipment movement, doors openings, personnel traffic, etc. The bracket should only be mounted to a flat surface at least as big as the bracket.
  • Page 8 The recommended wire gauge is a compromise between weight and strength. ACR provides crimp-on terminal lugs for 16 to 22 AWG wire for the connection to the mounting bracket. Other marine grade lugs (Not Supplied) can be used for different gauge wire.

  • Page 9: Cross Dipole Antenna Installation

    3.3.4 Switch installation Cut a 0.638” x 0.638” (16.2 mm x 16.2 mm) square hole in the selected panel. The recommended panel thickness is 0.039” to 0.106” (1.0 mm to 3.2 mm). The switch should be pushed back into the hole from the front. It is recommended to make the wire connections before installing the switch into the panel.
  • Page 10 3.4.2 Mounting guidelines Minimum height above deck: 10 feet (3 m) Allowable obstructions: Obstructions are allowable only below the antenna. There should be no conductive (metallic) objects in the entire hemisphere above the antenna. Coaxial cable length: Maximum: 100 feet (30.5 m) * Contact the factory if longer runs or different coaxial cable is required.
  • Page 11 3.4.5 Connection to beacon Attach male TNC connector (supplied) to marine grade RG-8/U coaxial cable (Not provided) as follows: Strip the coax cable per Figure 13. Solder the connector pin to the center conductor. Slide the ferrule over the cable. Ferrule Knurled Adapter end Coaxial Cable...

  • Page 12: Section 4 - Operation

    Connect the male SMA connector on the cable assembly to the mating female SMA connector on the beacon. For additional protection from corrosion, spray exposed metal surfaces of connectors with Boeshield T-9 or equivalent waterproof lubricant (not provided). ANTENNA INSTALLATION FIGURE 6 3.4.6 Antenna installation verification...

  • Page 13: Indicators

    4.7. Activation An ACR 406 MHz SSAS can be activated by two different methods. 1. With the beacon switch in the ready position and depressing one of the buttons of the remote activation points, or 2.

  • Page 14: Deactivation

    Deactivation The ThunderBird SSAS can be deactivated by returning the thumb switch to the “OFF” position. 4.6.1 4.6.2 If the beacon continues to operate after it has been deactivated, remove the four screws holding the top cap to the bottom case assembly and unplug the battery to disable the unit. Return it to a Service Center for repair.

  • Page 15: Section 5 - Care And Maintenance

    Also carefully inspect the beacon case for any visible cracks. Cracks may admit moisture, which could falsely activate the beacon or otherwise cause a malfunction. Any cracking observed should be immediately referred to ACR for evaluation, (1-800-432-0227 Ext. 112). Y1-03-0180 Rev. D...

  • Page 16: Section 6 - The Search And Rescue System

    These could result in a malfunction of the antenna. Any of the above should be immediately referred to ACR for evaluation. Antenna accessories and rebuild kits are available if the antenna should be damaged. (See page 21 for more details).

  • Page 17: Global Positioning System (Gps)

    carriers followed by a digital message format that provides identification data. The 406 MHz system uses Satellite-borne equipment to measure and store the Doppler-shifted frequency along with the beacons digital data message and time of measurement. This information is transmitted in real time to an earth station called the Local User Terminal (LUT), which may be within the view of the satellite, as well as being stored for later transmission to other LUTs.

  • Page 18: Section 7- Authorizations

    -25°C to +55°C Stowage -25°C TO +70°C Leaves ACR with Serialized U.S. code but must be reprogrammed at an authorized ACR Service center with SSAS protocol code, the vessels Maritime MMSI and country code of the flag state before installing on a ship.
  • Page 19 7.3.3 Accessories Description Part Number Replacement Cross Dipole Antenna 2810 Cross Dipole Rebuild Kit 2811 Marine Grade RG-8/U Cable 2812.1 (10 m) 2812.2 (20 m) 2812.3 (30 m) Activation Switch Cable 2813.1 (5 meters) 2813.2 (10 meters) Additional Activation Switch 2820 Antenna Mount 2821...
  • Page 20 ACR THUNDERBIRD FIGURE 11 Y1-03-0180 Rev. D...
  • Page 21 ANTENNA INSTALLATIONS FIGURE 12 Y1-03-0180 Rev. D...
  • Page 22 INCH (mm) RECOMMENDED CABLE STRIPPING DIMENSIONS FOR TNC CONNECTOR FIGURE 13 INCH (mm) RECOMMENDED CABLE STRIPPING DIMENSIONS FOR SMA CONNECTOR FIGURE 14 Y1-03-0180 Rev. D...
  • Page 23 SSAS SYSTEM BLOCK DIAGRAM FIGURE 15 Y1-03-0180 Rev. D...
  • Page 24 BRACKET DRAWING FIGURE 16 Y1-03-0180 Rev. D...
  • Page 25 BEACON DRAWING FIGURE 17 Y1-03-0180 Rev. D...
  • Page 26 SWITCH DRAWING FIGURE 18 Y1-03-0180 Rev. D...
  • Page 27 ANTENNA DRAWING FIGURE 19 Y1-03-0180 Rev. D...
  • Page 28 ANTENNA MOUNT DRAWING FIGURE 20 Y1-03-0180 Rev. D...

  • Page 29: Declaration Of Conformity

    COSPAS-SARSAT Type Approval Guidelines for 406 MHz Ships Security Alert System (SSAS) beacon – May 2004 RTCM 110-2004/SC110-STD Manufacturer ACR Electronics Inc. Fort Lauderdale, Florida, USA EU Representative : ACR Electronics Inc. (European Office) Lymington, Hampshire, UK. Signed on behalf of ACR Electronics Inc.

  • Page 30: Installation Check List

    INSTALLATION CHECK LIST Please Review to ensure you have properly installed this SSAS beacon:  Installed the beacon and bracket on a flat vertical surface in a discreet location. (Paragraph 3.2)  Installed the activation switches. (Minimum of two.)  One must be on the navigation bridge. ...
