Page 1 Class H Fitness Product Model No. WETL15131 USER’S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, please call: 08457 089 009 Or write: ICON Health &...
Page 2: Table Of Contents
ORDERING REPLACEMENT PARTS ..........Back Cover Note: An EXPLODED DRAWING and a PART LIST are attached in the centre of this manual. WESLO is a registered trademark of ICON Health & Fitness, Inc.
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 12. Keep the power cord away from heated sur- that all users of this treadmill are adequately faces.
Page 4 DANGER: other than the procedures in this manual Always unplug the power should be performed by an authorised service cord immediately after use, before cleaning representative only. the treadmill, and before performing the main- tenance and adjustment procedures de- 24. This treadmill is intended for in-home use scribed in this manual.
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the WESLO CADENCE ® ing this manual, please call our Customer Service Department at 08457 089 009. To help us assist you, treadmill. The CADENCE 60 treadmill combines ad- vanced technology with innovative design to let you...
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not dispose of the packing materials until assembly is completed. Assembly requires the included hex key and your own phillips screwdriver and adjustable spanners For help identifying the assembly hardware, refer to the drawings below.
Page 7 2. Open part bag B. Press the Right Frame Spacer (13) and the Left Frame Spacer (not shown) onto the sides of the High Frame (55) as shown. Make sure that the high side of side each Spacer is facing forward as shown. With the help of a second person, carefully lift the Frame (55) and hold the Spacers between the plates on the Uprights (89).
Page 8 4. See the inset drawings and identify the two Crossbar Small Bracket Screws (69); be careful not to confuse the Crossbar Screws with the 3/4” Screws (90). Hold the Crossbar (75) on the small brackets on the Handrails (6, 7). Attach the Crossbar to the small brack- ets with the two Crossbar Screws (69).
Page 9 7. Hold the Console (1) near the Console Base (100). Touch the Right Handrail (6) to discharge any static. Find the connector on the end of the Wire Harness (22). Insert the connector into the red socket beneath the Ties Console.
Page 10: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT , a high-performance lubricant. IMPOR- Your treadmill features a walking belt coated with PERFORMANT LUBE TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear.
Page 11 CONSOLE DIAGRAM Displays Note: If there is a thin sheet of Pulse Sensor plastic on the console, remove it. Clip Insert the key fully into the console. After a moment, CAUTION: the displays will light. Test the clip by carefully tak- Before operating the ing a few steps backward until the key is pulled console, read the following precautions.
Page 12 To stop the walking belt, press the Stop button. ton, insert the key into the The elapsed time will begin to flash in the Time console, and continue to display. hold the Stop button for a moment. An “E” (for Note: During the first few minutes that the tread- English) or an “M”...
Page 13 HOW TO CHANGE THE INCLINE OF THE TREAD- MILL Arrow To vary the intensity of your exercise, the incline of the treadmill can be changed. There are four incline levels. Before changing the incline, remove the key and unplug the power cord. Next, fold the treadmill to the storage position (see Housing HOW TO FOLD THE TREADMILL FOR STORAGE on...
Page 14: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill. 1. Hold the treadmill with your hands in the locations shown at the right.
Page 15 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the latch pin.
Page 16: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department. PROBLEM: The power does not turn on SOLUTION: a.
Page 17 PROBLEM: The walking belt slows when walked on SOLUTION: a. If an extension cord is needed, use only a 3-conductor, 1mm (14-gauge) cord that is no longer than 1.5 m (5 ft.). b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- 5–7 cm come damaged.
Page 18: Conditioning Guidelines
CONDITIONING GUIDELINES ergy. Only after the first few minutes does your body WARNING: begin to use stored fat calories for energy. If your goal Before beginning this is to burn fat, adjust the speed and incline of the tread- or any exercise program, consult your physi- mill until your heart rate is near the lowest number in cian.
Page 19 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
Page 20: Ordering Replacement Parts
Fax: 0 (444) 113 387 7125 When ordering parts, please be prepared to give the following information: • the MODEL NUMBER of the product (WETL15131) • the NAME of the product (WESLO CADENCE ® 60 treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
Page 21 REMOVE THIS PART LIST/EXPLODED REMOVE THIS EXPLODED DRAWING AND PART LIST DRAWING FROM THE MANUAL! FROM THE MANUAL. Save this page for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of the User’s Manual.
Page 22 PART LIST—Model No. WETL15131 R1003A Key No. Qty. Description 8” Cable Tie Ferrite Box Console Incline Leg 3” Bolt Incline Leg Housing Key/Clip Incline Leg Screw Left Frame Spacer Roller Adj. Washer Electronics Screw Frame Endcap Right Handrail Endcap Screw Left Handrail Crossbar Screw Battery Cover...
Page 23 EXPLODED DRAWING—Model No. WETL15131 R1003A...
