Summary of Contents for Boss Audio Systems 754DI
-
Page 2: Troubleshooting
Specifications Trouble Shooting Supply voltage : 12V DC(11V-15V) Current consumption : Less than 10A Before going through the check list, check wiring connection. If any of the problems persist after check Audio Signal Output : 2ch line out list has been made, consult your nearest service dealer. Characteristics : (1) Frequency Response: 20Hz-20KHz... -
Page 3: Setting Mode
General and Radio Controls Setting Mode You can make changes to the system setting in the following area: Radio Frequency Range + Enable/Disable AUX In+ Clock Format To enter setting mode, input the following command by pressing remote keys" 8, DOWN DIRECTION KEY, 9, ENTER " MENU The display will show "TEST MOD "... -
Page 4: Installation
3. MODE (Input Select) Installation Press this button repeatedly to cycle through the audio input sources: dashboard attachment surface support strap CARD> AUX >TUNER > USB > IPOD Please note: 5mm nut ipod Mode can only be selected if an ipod is present in the dock. support screw 4. -
Page 5: Wiring Connection Diagram
Wiring connection diagram USB/SD Card (MP3 Playback) Controls BLUE (ANT) MENU 0.5A FUSE RED (ACC.12 volts) RED R RCA LINE OUT BLACK (GROUND) MODE 10A FUSE WHITE L YELLOW (CONSTANT 12 volts) ENTER AUX IN LEFT FRONT RIGHT FRONT WHITE GRAY SPEAKER SPEAKER... - Page 6 7.TA In Radio mode, press this button to activated as TA mode on or off. 8.RDM (Random Play Mode) When TA mode is on(TA is displayed on LCD), it will begin to seek TA station Press this button for playback of all the files in the current folder in a random and TA SEEK will be displayed on LCD for a while.
