Gateway 56-inch RPT TV
Specifications
Specifications are subject to change without notice or obligation.
Display Panel
Screen size
Aspect ratio
Resolution
Brightness
Contrast ratio
Colors
Projection system
Lamp
Lamp life
Viewing angle
Power Source
Input voltage
Input current
Power consumption
Stand-by and Power Save
Video Formats (A/V, S)
Diagonal 56-inch
4:3, 16:9 wide
1280 × 720
400 nits typical
1000:1 typical
16.7 M colors / 8 bits
DLP (Digital light processor)
Philips UHP 100 W/120 W 1.3 E23 lamp driven by Philips 120 W ballast
EUC120P/H11
MTBF 6000 hours
± 50° horizontal, ± 18° vertical
90 ~ 264 Vac, 50 Hz -60 Hz auto-ranging
1.7 A
300 Watts maximum; 250 Watts typical
3 Watts
NTSC
www.gateway.com
Advertisement
Related Manuals for Gateway RPT TV
Summary of Contents for Gateway RPT TV
-
Page 1: Specifications
Gateway 56-inch RPT TV Specifications Specifications are subject to change without notice or obligation. Display Panel Screen size Diagonal 56-inch Aspect ratio 4:3, 16:9 wide Resolution 1280 × 720 Brightness 400 nits typical Contrast ratio 1000:1 typical Colors 16.7 M colors / 8 bits... - Page 2 Gateway 56-inch RPT TV Specifications Connector Types Video Signal, S-Video Type Polarity Amplitude Input impedance Signal (Component) Type Polarity Amplitude Input impedance RGB Signal Type Polarity Amplitude Input impedance Audio Signal RCA jacks for audio, video, and YP 6-pin Din S-terminal for S-Video...
- Page 3 TMDS DATA 4 + DDC CLOCK DDC DATA TMDS DATA 1 – TMDS DATA 1 + TMDS DATA 1/3 SHIELD TMDS DATA 3 – Gateway 56-inch RPT TV Specifications Signal Assignment RED RETURN GREEN RETURN BLUE RETURN +5 V SYNC RETURN...
- Page 4 Gateway 56-inch RPT TV Specifications RGB For VESA Standard Mode Resolution 640 × 350 640 × 400 720 × 400 720 × 400 640 × 480 640 × 480 640 × 480 640 × 480 800 × 600 800 × 600 800 ×...
- Page 5 43.8 in. (1113 mm) Depth 18.9 in. (480 mm) Weight Net weight 130.0 lbs (59.1 kgs) Operating Temperature Relative humidity Pressure Non-Operating Temperature -10~60°C (14~140°F) Relative humidity 5~90% Pressure 0~40,000 feet Gateway 56-inch RPT TV Specifications 5~35°C (41~95°F) 20~90% 0~10,000 feet www.gateway.com...
- Page 6 The MTBF is 50,000 hours under operation at 25±5°C (Half luminosity, motion picture) Emissions Requirement Your RPT TV meets the EMI limits in all screen modes as qualified by FCC class B part 15. Many products for Gateway and its subsidiaries are custom engineered by our suppliers to Gateway specifications and may vary from similarly marketed products.
