Page 1: Operation Manual
DAIKIN ROOM AIR CONDITIONER OPERATION MANUAL MODELS FVXS60HVMA FVXS71HVMA... -
Page 2: Table Of Contents
CONTENTS READ BEFORE OPERATION Safety Precautions ..............2 Name of Parts ................4 Preparation before Operation ..........8 OPERATION AUTO · DRY · COOL · HEAT · FAN Operation ...... 10 Adjusting the Airfl ow Direction ..........12 POWERFUL Operation ............14 OUTDOOR UNIT QUIET Operation ........ -
Page 3: Safety Precautions
Safety Precautions • Keep this manual where the operator can easily fi nd them. • Read the precautions in this manual carefully before operating the unit. • The precautions described herein are classifi ed as WARNING and CAUTION. They both contain important information regarding safety. - Page 4 CAUTION • Do not block air inlets nor outlets. Impaired airfl ow may result in insuffi cient performance or trouble. • Do not sit on the indoor or outdoor unit, put things on the units, or pull the units. Doing so may cause accidents, such as falling or toppling down, thus resulting in injury, product malfunctioning, or product damage.
-
Page 5: Name Of Parts
Name of Parts Indoor Unit Flap (horizontal blade) Page 12 Air outlet Front panel Titanium apatite photocatalytic Air-purifying fi lter • These fi lters are attached to the inside of the air fi lters. Air fi lter Air inlet Louvers (vertical blade) Page 12 •... -
Page 6: Refrigerant Piping
Open the front panel • How to open the front panel: Page 25 Air outlet selection switch Page 13 • This setting blows air from upper outlet only. • This setting automatically decides a blow pattern depending on mode and conditions. •... -
Page 7: Front Cover
Name of Parts Remote Controller: ARC452A2 Signal transmitter Receiver Display (LCD) • It displays the current settings. • To use the remote controller, aim the (In this illustration, each section is transmitter at the indoor unit. If there shown with its displays ON for the is anything to block signals between purpose of explanation.) the unit and the remote controller,... -
Page 8: Quiet Button
Open the front cover MODE selector button ECONO button • It selects the operation mode. • ECONO operation Page 16 (AUTO/DRY/COOL/HEAT/FAN) Page 10 SWING button • Adjusting the Airfl ow Direction Page 12 QUIET button • OUTDOOR UNIT QUIET operation Page 15 OFF TIMER button : WEEKLY button... -
Page 9: Preparation Before Operation
Preparation before Operation To set the batteries Position Slide the front cover to take it off. – correctly! Set 2 dry batteries AAA.LR03 (alkaline). Set the front cover as before. To fi x the remote controller holder on the wall Set. -
Page 10: To Set The Clock
To set the clock Press “ ” is displayed. “ ” and “ ” blinks. Press to set the current day of the week. Press “ ” blinks. Press to set the clock to the present time. • Holding down button rapidly increases or decreases the time display. Press •... -
Page 11: Auto · Dry · Cool · Heat · Fan Operation
AUTO · DRY · COOL · HEAT · FAN Operation The air conditioner operates with the operation mode of your choice. From the next time on, the air conditioner will operate with the same operation mode. To start operation Press and select a operation mode. - Page 12 To change the airfl ow rate setting Press DRY mode AUTO or COOL or HEAT or FAN mode Five levels of airfl ow rate setting from The airfl ow rate setting is not variable. “ ” to “ ” plus “ ”...
-
Page 13: Adjusting The Airfl Ow Direction
Adjusting the Airfl ow Direction You can adjust the airfl ow direction to increase your comfort. Adjusting the upper and lower airfl ow direction To adjust the fl ap (horizontal blade) Press “ • ” is displayed on the LCD and the fl ap will begin to swing. When the fl... -
Page 14: Air Outlet Selection
Air outlet selection • Make air outlet selection according to what suits you. Page 5 When setting the air outlet selection switch to • Air conditioner automatically decides the appropriate blowing pattern depending on the operating mode/situation. Operating mode Situation Blowing pattern •... -
Page 15: Powerful Operation
POWERFUL Operation POWERFUL operation quickly maximizes the cooling (heating) effect in any operation mode. You can get the maximum capacity. To start POWERFUL operation Press during operation. • POWERFUL operation ends in 20 minutes. Then the system automatically operates again with the previous settings which were used before POWERFUL operation. -
Page 16: Outdoor Unit Quiet Operation
OUTDOOR UNIT QUIET Operation OUTDOOR UNIT QUIET operation lowers the noise level of the outdoor unit by changing the frequency and fan speed on the outdoor unit. This function is convenient during night. To start OUTDOOR UNIT QUIET operation Press “... -
Page 17: Econo Operation
ECONO Operation ECONO operation is a function which enables effi cient operation by limiting the maximum power consumption value. This function is useful for cases in which attention should be paid to ensure a circuit breaker will not trip when the product runs alongside other appliances. To start ECONO operation Press during operation... -
Page 18: Timer Operation
TIMER Operation Timer functions are useful for automatically switching the air conditioner on or off at night or in the morning. You can also use OFF TIMER and ON TIMER in combination. To use OFF TIMER operation • Check that the clock is correct. If not, set the clock to the present time. - Page 19 TIMER Operation To use ON TIMER operation • Check that the clock is correct. If not, set the clock to the present time. Page 9 Press “ ” is displayed. “ ” blinks. “ • ” and day of the week disappear from the LCD. Press until the time setting reaches the point you like.
-
Page 20: Weekly Timer Operation
WEEKLY TIMER Operation Up to 4 timer settings can be saved for each day of the week. It is convenient if the WEEKLY TIMER is set according to the family’s life style. Using in these cases of WEEKLY TIMER An example of WEEKLY TIMER settings is shown below. Example: The same timer settings are made for the week from Monday through Friday while different timer settings are made for the weekend. - Page 21 WEEKLY TIMER Operation To use WEEKLY TIMER operation Setting mode • Make sure the day of the week and time are set. If not, set the day of the week and time. Page 9 Program 1 Program 2 Program 3 Program 4 [Monday] 25°C...
- Page 22 Press to select the desired time. • The time can be set between 0:00 and 23:50 in 10 minute intervals. • To return to the mode setting, press • Go to STEP when setting the OFF TIMER. Press • The time will be set. “...
- Page 23 WEEKLY TIMER Operation Copy mode • A reservation made once can be copied another day of the week. The whole reservation of the selected day of the week will be copied. Program 1 Program 2 Program 3 Program 4 [Monday] 25°C 27°C 6:00...
- Page 24 Confi rming a reservation • The reservation can be confi rmed. Setting Displays Normal display Confi rmation display Press • The day of the week and the reservation number of the current day will be displayed. Press to select the day of the week and the reservation number to be confi...
- Page 25 WEEKLY TIMER Operation To deactivate WEEKLY TIMER operation Press while “ ” is displayed on the LCD. • The “ ” will disappear from the LCD. • The TIMER lamp goes off. • To reactivate the WEEKLY TIMER operation, press again.
- Page 26 The reservations for each day of the week • This function can be used for deleting reservations for each day of the week. Press to select the day of the week to be deleted. Hold for 5 seconds. • The reservation of the selected day of the week will be deleted. All reservations Hold for 5 seconds.
-
Page 27: Care And Cleaning
Care and Cleaning CAUTION Before cleaning, be sure to stop the operation and turn the breaker OFF. Units Indoor unit, Outdoor unit and Remote controller Wipe them with dry soft cloth. Front panel Open the front panel. • Slide the 2 stoppers on the left and right sides inward until they click. - Page 28 Filters Open the front panel. Page 25 Remove the air fi lter. • Press the claws on the right and left of the air fi lter down slightly, then pull upward. Take off the Titanium Apatite Photocatalytic Air-Purifying Filter. • Hold the tabs of the frame, and remove the claws in 4 places.
- Page 29 Care and Cleaning Air Filter Wash the air fi lters with water or clean them with vacuum cleaner. • If the dust does not come off easily, wash them with neutral detergent thinned with lukewarm water, then dry them up in the shade.
- Page 30 NOTE • Operation with dirty fi lters: cannot deodorize the air. cannot clean the air. results in poor heating or cooling. may cause odour. • To order Titanium Apatite Photocatalytic Air-Purifying Filter contact to the service shop there you bought the air conditioner. •...
-
Page 31: Trouble Shooting
Trouble Shooting These cases are not troubles. The following cases are not air conditioner troubles but have some reasons. You may just continue using it. Case Explanation Operation does not start soon. • • When ON/OFF button was pressed soon This is to protect the air conditioner. - Page 32 Check again. Please check again before calling a repair person. Case Check • Hasn’t a breaker turned OFF or a fuse blown? • The air conditioner does not operate. Isn’t it a power failure? (OPERATION lamp is off.) • Are batteries set in the remote controller? •...
- Page 33 Trouble Shooting Call the service shop immediately. WARNING When an abnormality (such as a burning smell) occurs, stop operation and turn the breaker OFF. Continued operation in an abnormal condition may result in troubles, electric shocks or fi re. Consult the service shop where you bought the air conditioner. Do not attempt to repair or modify the air conditioner by yourself.
- Page 34 Two-dimensional bar code is a code for manufacturing. 3P191290-3K M07B245A (0903) HT...
