OEM Manual
Hard Disk Drive Specifications
Ultrastar 10K300 – 300/ 147/ 73/ 36
Read and follow all instructions and cautions for safety described
in this document before using the drive.
It is recommended that this manual is kept at a proper location
for quick reference.
Hitachi Global Storage Technologies
© 2003, Hitachi Global Storage Technologies. All Rights Reserved.
(SCSI Interface)
Models HUS103030FL3600 :(300GB/68pin)
Models HUS103014FL3600 :(147GB/68pin)
Models HUS103073FL3600 :( 73GB/68pin)
Models HUS103036FL3600 :( 36GB/68pin)
Models HUS103030FL3800 :(300GB/80pin)
Models HUS103014FL3800 :(147GB/80pin)
Models HUS103073FL3800 :( 73GB/80pin)
Models HUS103036FL3800 :( 36GB/80pin)
Drawing No. Sheet No. Revision
K6610091
1/43
2005/2/23
Advertisement
Table of Contents
Related Manuals for Hitachi Ultrastar SCSI Interface HUS103014FL3600
Summary of Contents for Hitachi Ultrastar SCSI Interface HUS103014FL3600
-
Page 1: Hard Disk Drive Specifications
It is recommended that this manual is kept at a proper location for quick reference. Hitachi Global Storage Technologies © 2003, Hitachi Global Storage Technologies. All Rights Reserved. Drawing No. Sheet No. Revision K6610091 1/43... - Page 2 REVISION CONTROL Remarks AD: Addition , CH: Change ,CR: Correction ,DL: Deletion Rev. Date Signature Page Description Remarks 2003/8/5 DWN : O,Suzuki First Issuance CHKD: T,Nakazawa APPD: T,Nakazawa 2003/12/1 DWN : O,Suzuki It updated to new information CHKD: T,Nakazawa Table 3.1 Seek time (average) APPD: T,Nakazawa Table 3.1 Power requirement Table 3.3...
-
Page 3: To Use This Product Safely
(2) Disturbance caused by other product, such as cabling, to operations of other products or equipment. Do not change the condition of the drive, excluding the change admitted by Hitachi. Violating above-mentioned precautions will void any warranties of the HDD. - Page 4 To use this product safely (Continued) Followings are the cautions and contents described in this manual. Caution Items of indicating - Safety cautions for this product Page 4 Caution Items of indicating - Safety cautions for this product Page 4-5 - Spindle Start and Stop Page 16 - Mounting of the drive...
- Page 5 Hitachi GST liability may be further limited in accordance with its sales contact. In general, Hitachi GST shall not be responsible for product damages caused by natural disasters, fire, static discharge, misuse, abuse, neglect, improper handling or installation, unauthorized repair, alteration, or accident.
-
Page 6: Table Of Contents
TABLE OF CONTENTS Chapter Page To use this product safely............... 3 Features....................8 Standards and Related Documents ............9 Description....................10 Characteristics ................10 Environmental conditions and reliability ........11 DC power Interface .................. 15 DC Power Requirement .............. 15 Power Supply Current .............. - Page 7 11 Pin assignment ..................33 11.1 SCSI Bus Connector C1 ............. 33 11.2 Other connectors ................ 37 12 Jumper Socket setting ................38 12.1 Jumper connector layout............. 38 12.2 Jumper socket setting ..............39 12.3 Jumper socket part number ............43 12.4 Extension connector (for remote cable) ........
-
Page 8: Features
(SCSI Primary Commands-3) X3T10/1365D Rev 4 (SCSI Parallel Interface-4) Interface specifications for the Ultrastar 10K300 are found in the companion manual: " Hitachi 3.5 inch Magnetic Disk Drive Reference Manual for Ultrastar 10K300 (SCSI Interface Specification) ". Table 1.1 Models Product name... -
Page 9: Standards And Related Documents
CNS13438,C6357 class B (BSMI) AS/NZS 3548 class B (C-Tick) RRL mark for Korean EMC (c) Related Documents (1) Hitachi 3.5 inch Magnetic Disk Drive Reference Manual for Ultrastar 10K300 (SCSI Interface Specification) K6610095 (2) Packing Specification (3) Ultrastar 10K300-300 (SCSI) Design Verification Test Reports... -
Page 10: Description
Description 3.1 Characteristics Table 3.1 Characteristics Item Specifications unit Ultrastar Ultrastar Ultrastar Ultrastar 10K300-300 10K300-147 10K300-73 10K300-36 Configuration Storage capacity (formatted) (see Note 1,2,13) Bytes/sector (see Note 3) 512, 514, 516, 520, 522, 524, 528 Bytes Number of disks Number of heads Gb/inch 2 Areal density Recording method... -
Page 11: Environmental Conditions And Reliability
3.2 Environmental conditions and reliability Table 3.2 Environmental conditions and reliability Item Ultrastar Ultrastar Ultrastar Ultrastar 10K300-300 10K300-147 10K300-73 10K300-36 Environmental 5 to 55°C operating conditions -40 to 70°C Temperature non-operating storage/shipping -40 to 70°C 20°C per hour maximum Temperature gradient 5 to 90%RH Humidity operating... - Page 12 Note 1. Storage capacity does not include spare sector and spare cylinder. Note 2. This is the value in the case that the drive is formatted to 512 Bytes/sector. (1 gigabyte shows 1x10 bytes on this document.) Note 3. Ultrastar 10K300 is formatted to 512 Bytes/sector as the default. If non-512 Bytes/sector is required, customer can change it by re-format of the drive.
- Page 13 Hitachi's standard procedures. Hitachi does not warrant that the predicted MTBF is representative of any particular unit or group of units comprising a customer base. The actual failure rates will vary from unit to unit. Surface temperature of HDA is 50°C or less.
- Page 14 Note 13. When the Ultrastar 10K300-300 is formatted to 512 Bytes/sector, the maximum Logical Block Address is (22ECB25B)h. When the Ultrastar 10K300-147 is formatted to 512 Bytes/sector, the maximum Logical Block Address is (111D69B4)h. When the Ultrastar 10K300-73 is formatted to 512 Bytes/sector, the maximum Logical Block Address is (88BB9D4)h.
-
Page 15: Dc Power Interface
DC power Interface 4.1 DC Power Requirement The drives are operated on DC power (+5V, +12V) only. No power sequencing is required. The +5 and +12 Volts can be applied in any order. Table 4.1 DC Power Requirement Power supply Voltage tolerance Allowed ripple and noise +5V DC... -
Page 16: Power Supply Current
4.2 Power supply current +12V Current Time[S] T2 T3 T0-T1: Power up T0: Power on T1-T2: Spin-up T1: Accept start unit command or Auto Spin-up T2-T3: Servo initialize T2: Ready T3-T4: Upload Code etc T1-T4: Start up Fig 4.1 Current transition for +12V Note: A retry Spin-up operation may be attempted during the Start up process. - Page 17 4.3.2 Spindle Start Selection When multiple disk drives are connected to the same power supply and turned on simultaneously, a large current will be required at power up. In the above case, it is recommended to turn the motors on one by one at intervals in order to minimize 12V line current.
-
Page 18: Connecting Methods
Connecting Methods 5.1 Interface Cable (Daisy Chain) Terminator SCSI interface cable Terminator SCSI bus Ultrastar Ultrastar Ultrastar 10K300 10K300 10K300 DC power power supply cable Figure 5.1 Cabling layout (WIDE LVD drive) Note 1. The SCSI bus can accommodate a maximum of 16 units on a WIDE (16-bit) bus, including the host processor, Ultrastar 10K300 units, and other SCSI devices. - Page 19 5.2 Low voltage differential (LVD) mode The NW and NC drives have two different transceivers to allow customer to use it in traditional systems which may use single-ended drivers and receivers, or to use it in low voltage differential (LVD) systems which use LVD drivers and receivers. Their I/O circuits are selectable using the I/O "DIFFSENS"...
-
Page 20: Scsi Interface
SCSI Interface 6.1 Summary of SCSI Controller The Ultrastar 10K300 SCSI controller interfaces between the drive and the host computer with the Small Computer System Interface (SCSI). (1) ANSI standard The controller supports the SCSI interface that conforms to the ANSI specifications shown in section 2. - Page 21 (8) Tagged Command Queuing A maximum of 128 commands can be enqueued to this drive. The drive does not have to connect and disconnect to the host controller even if the SCSI command has been issued successively, so the overhead time of the SCSI bus can be reduced. (9) S.M.A.R.T.
-
Page 22: Summary Of Scsi Commands
6.2 Summary of SCSI Commands The SCSI controller supports the group 0,1, and 2 commands listed in Table 6.1 Table 6.1 SCSI Commands Supported Operation Code Group 0 Command Name TEST UNIT READY REZERO UNIT REQUEST SENSE FORMAT UNIT REASSIGN BLOCKS READ WRITE SEEK... -
Page 23: Mounting And Handling
Table 6.1 SCSI Commands Supported (Continued) Operation Code Group 2 Command Name WRITE SAME LOG SELECT LOG SENSE MODE SELECT (10) RESERVE (10) RELEASE (10) MODE SENSE (10) PERSISTENT RESERVE IN PERSISTENT RESERVE OUT Operation Code Group 5 Command Name READ DEFECT DATA (12) REPORT LUNS Mounting and Handling... -
Page 24: Mounting Of The Drive
Caution 7.2 Mounting of the drive 1. Mount the drive with four 6-32 UNC screws. (Screw's torque : 0.588 to 0.784 N·m) 2. Mounting holes (A1,A2,B1,B2,B3) are available for mounting.(See figure 8.3) It is recommended that the 4 holes, (A1,A2 or B1,B3 on figure 8.3), be used for mounting to keep the proper space between mounting holes. -
Page 25: Mounting Dimensions
7.3 Mounting dimensions Dimension 101.6±0.25 95.25±0.25 3.18±0.25 41.28±0.5 44.45±0.25 147 max. 101.6±0.25 28.5±0.5 41.6±0.25 26.1 max. 6.35±0.25 Figure 7.3 Layout of Mounting holes Drawing No. Sheet No. Revision K6610091 25/43 2005/2/23... -
Page 26: Precautions On The Off-Line Test Or Bench Test
7.4 Precautions on the off-line test or bench test When the off-line test or bench test is performed the drive should be tightly fixed and cooled. The set-up should be similar to the actual system configuration. 7.5 Cooling of the drive Keep the drive (HDA and PCB) cool by using a FAN. -
Page 27: Precautions For Handling
Caution Precautions for handling The drive is sensitive to shock, vibration, over voltage, temperature, humidity, corrosive gas, magnetic force and electrostatic discharge. If these forces contact the electrical or mechanical components (magnetic heads, magnetic disks), the drive will break down, degrade, or storage data will be lost. The following handling guidelines are mandatory. -
Page 28: Other Precautions
8.4 Other Precautions 8.4.1 Do not loosen the screws or disassemble the drive. 8.4.2 Do not remove the PCB from the drive or swap the PCB with other drives. 8.4.3 Do not solder the wire or other parts on the PCB, or reconstruct the PCB. 8.4.4 Do not remove the sealing tape or label on the HDA. -
Page 29: Physical Interface
10 Physical interface 10.1 Connector Specifications Use the mating connectors which are electrically and mechanically compatible. The following part numbers indicate the mating connectors. Table 10.1 Interface connectors Interface Name Part number Manufacturer WIDE LVD SCSI interface connector 786090-7 DHJ-PAC68-2AN DC power connector Pin:61314-4 Housing:1-480424-0... - Page 30 (2) DC Power Supply Cable The DC power cable should be as short as possible to minimize voltage drop. Table 10.2 Interface cable (WIDE, Single-ended mode) Cable Type Maximum cable length Fast-5 Fast-10 Ultra (Fast 20) SCSI interface Flat Ribbon or 3m (4 units max.) or Twisted Pair (16 units max.)
-
Page 31: Connector Layout
10.3 Connector Layout WIDE LVD drive SCSI Bus Connector Auxiliary Connector Power Connector Figure 10.1 Connector Layout (WIDE LVD drive) C2-1 : 12V C2-2 : GND (12V Return) C2-3 : GND (5V Return) C2-4 : 5V Figure 10.2 Connector view Note: The SCSI ID setting is to be set via the C3 connector (not by C4) normally. - Page 32 SCA-2 LVD drive Dimension Dimension 26.1 max. 101.6±0.25 6.35±0.25 (58) 50.8±0.5 4.6±0.5 Figure 10.3 Connector Layout (SCA-2 LVD drive) PCB parts side Figure 10.4 Connector view Drawing No. Sheet No. Revision K6610091 32/43 2005/2/23...
-
Page 33: Pin Assignment
Pin assignment 11.1 SCSI Bus Connector C1 Table 11.1 Pin assignment of SCSI Bus Connector C1 (WIDE, Single-ended mode) Signal Name Connector Signal Name Cable Connector contact conductor contact -DB(12) -DB(13) -DB(14) -DB(15) -DB(P1) -DB(0) -DB(1) -DB(2) -DB(3) -DB(4) -DB(5) -DB(6) -DB(7) -DB(P0) - Page 34 Table 11.2 Pin assignment of SCSI Bus Connector C1 (WIDE, LVD mode) Signal Name Connector Cable Connector Signal Name contact conductor contact +DB(12) -DB(12) +DB(13) -DB(13) +DB(14) -DB(14) +DB(15) -DB(15) +DB(P1) -DB(P1) +DB(0) -DB(0) +DB(1) -DB(1) +DB(2) -DB(2) +DB(3) -DB(3) +DB(4) -DB(4) +DB(5)
- Page 35 Table 11.3 Pin assignment of SCSI Bus Connector C1 (SCA-2, Single-ended mode) Signal Name Connector contact No. Signal Name GND(12V Return) GND(12V Return) GND(12V Return) MATED1 (Note 2) Open Open Open DIFFSENS -DB(11) -DB(10) -DB(9) -DB(8) -I/O -REQ -C/D -SEL -MSG -RST -ACK...
- Page 36 Table 11.4 Pin assignment of SCSI Bus Connector C1 (SCA-2, LVD mode) Signal Name Connector contact No. Signal Name GND(12V Return) GND(12V Return) GND(12V Return) MATED1 (Note 2) Open Open Open DIFFSENS -DB(11) +DB(11) -DB(10) +DB(10) -DB(9) +DB(9) -DB(8) +DB(8) -I/O +I/O -REQ...
-
Page 37: Other Connectors
11.2 Other connectors Table 11.5 Pin assignment of Auxiliary Connector C4 (WIDE LVD drive) Pin No. Signal Name Pin No. Signal Name Note -ID0 Reserved -ID1 Reserved -ID2 Reserved -ID3 LED(with 150 ohm) See Figure 12.1 N.C. -WRITE PROTECT Table 11.6 Pin assignment of Option Jumper Connector C3 (WIDE LVD drive) Pin No. -
Page 38: Jumper Socket Setting
12 Jumper Socket setting 12.1 Jumper connector layout WIDE LVD drive Option Jumper Connector (C3) Force Single-Ended bus mode (11) Enable Delayed Start (13) Disable Auto Start (9) Write Protect (15) ID0 (7) Reserved (17) ID1 (5) Reserved (19) ID2 (3) LED(with 0ohm) (21) ID3 (1) Term. -
Page 39: Jumper Socket Setting
12.2 Jumper socket setting The Jumper sockets should be set only when the power is off. 12.2.1 SCSI ID WIDE LVD Option Jumper Connector (C3) SCSI ID # Remove all Jumper Sockets (Default) Install the Jumper Socket for C3-7,8 Install the Jumper Socket for C3-5,6 Install the Jumper Sockets for C3-5,6 &... - Page 40 12.2.2 Disable Auto Start WIDE LVD Option Jumper Connector (C3) Meaning Spindle motor automatically Remove the Jumper Socket starts when the power is for C3-9,10 (Default) applied or in sequence via ID number x 10 seconds from the time power is applied if C3-13,14 is jumpered.
- Page 41 12.2.4 Enable Delayed Start WIDE LVD Option Jumper Connector (C3) Meaning Spindle motor automatically Remove the Jumper Socket starts when the power is on. for C3-13,14 (Default) Spindle motor starts in Install the Jumper Socket sequence via ID number x 10 for C3-13,14 seconds from the time power is applied...
- Page 42 12.2.5 SCSI bus Terminator Power WIDE LVD Option Jumper Connector (C3) Meaning Terminator power not supplied Remove the Jumper Socket to SCSI TERMPWR line for C3-23,24 (Default) Terminator power supplied Install the Jumper Socket to SCSI TERMPWR line for C3-23,24 (To SCSI bus cable) Note 1.
-
Page 43: Jumper Socket Part Number
12.3 Jumper socket part number Part numbers of jumper sockets are as follows: Table 12.1 Jumper socket Connector Name Part number Manufacturer Option Jumper Connector MINITEK 86730-001 FCI Japan K.K. JUMPER (C3) 12.4 Extension connector Part numbers of extension connectors for remote cable are as follows: Table 12.2 Extension connector Connector Name...
