PRODUCT SPECIFICATIONS

Table 2 lists product specifications for the Cisco Catalyst 3750 Series.
Table 2. Descriptions and Specifications
Description Specification
Performance ● 32-Gbps switching fabric
● Stack-forwarding rate of 38.7 mpps for 64-byte packets
● Forwarding rate: 6.5 mpps (Cisco Catalyst 3750-24TS, 3750-24FS, and 3750-24PS), 13.1
mpps (Cisco Catalyst 3750-48TS and 3750-48PS), 17.8 mpps (Cisco Catalyst 3750G-12S),
35.7 mpps (Cisco Catalyst 3750G-24T), 38.7 mpps (Cisco Catalyst 3750G-24TS and 3750G-
24WS), 35.7 mpps (Cisco Catalyst 3750G-16TD), 38.7 mpps (Cisco Catalyst 3750G-24TS-
1U), 38.7 mpps (Cisco Catalyst 3750G-24PS), 38.7 mpps (Cisco Catalyst 3750G-48TS), 38.7
mpps (Cisco Catalyst 3750G-48PS)
● 128 MB DRAM and 16 MB Flash memory (Cisco Catalyst 3750G-24TS, 3750G-24WS,
3750G-24T, 3750G-12S, 3750-24TS, 3750-24PS, 3750-48TS, 3750-48PS, and 3750G-
16TD)
● 128 MB DRAM and 32 MB Flash memory (Cisco Catalyst 3750G-24TS-1U, 3750G-24WS,
3750G-24PS, 3750G-48TS, 3750G-48PS, and 3750-24FS)
● Configurable up to 12,000 MAC addresses (Cisco Catalyst 3750G-24TS, 3750G-24WS,
3750G-24T, 3750G-12S, 3750-24TS, 3750-24FS, 3750-24PS, 3750-48TS, 3750-48PS,
3750G-24TS-1U, 3750G-24PS, 3750G-48TS, 3750G-48PS, and 3750G-16TD)
● Configurable up to 20,000 unicast routes (Cisco Catalyst 3750G-12S) and up to 11,000
unicast routes (Catalyst 3750G-24TS, 3750G-24WS, 3750G-24T, 3750-24TS, 3750-24FS,
3750-24PS, 3750-48TS, 3750-48PS, 3750G-24TS-1U, 3750G-24PS, 3750G-48TS, 3750G-
48PS, and 3750G-16TD)
● Configurable up to 1000 IGMP groups and multicast routes (Cisco Catalyst 3750G-24TS,
3750G-24WS, 3750G-24T, 3750G-12S, 3750-24TS, 3750-24FS, 3750-24PS, 3750-48TS,
3750-48PS, 3750G-24TS-1U, 3750G-24PS, 3750G-48TS, 3750G-48PS, and 3750G-16TD)
● Configurable maximum transmission unit (MTU) of up to 9000 bytes, with a maximum
Ethernet frame size of 9018 bytes (jumbo frames) for bridging on Gigabit Ethernet ports, and
up to 1546 bytes for bridging and routing on Fast Ethernet ports
● 10BASE-T ports: RJ-45 connectors, 2-pair Category 3 (Cat-3), 4, or 5 unshielded twisted-pair
Connectors
and Cabling (UTP) cabling
● 100BASE-TX ports: RJ-45 connectors, 2-pair Cat-5 UTP cabling
● 100BASE-FX ports: MT-RJ connectors, 50/125 or 62.5/125 micron multimode fiber
● 1000BASE-T ports: RJ-45 connectors, 2-pair Cat-5 UTP cabling
● 1000BASE-T SFP-based ports: RJ-45 connectors, 2-pair Cat-5 UTP cabling
● 1000BASE-SX, -LX/LH, -ZX, and CWDM SFP-based ports: LC fiber connectors (single-
mode, or multimode fiber)
● 10GBASE-ER XENPAK-based port (single-mode)
● 10GBASE-LR XENPAK-based port (single-mode)
● Cisco StackWise stacking ports: copper-based Cisco StackWise cabling that is also
compatible with the StackWise Plus technology in the Cisco Catalyst 3750-E Series
Switches.
● Management console port: RJ-45-to-DB9 cable for PC connections
● Customers can provide power to a switch by using either the internal power supply or a
Power Connectors
redundant power system (Cisco RPS 2300 or the Cisco RPS 675). The connectors are
located at the back of the switch.
● Internal power supply connector
● The internal power supply is an autoranging unit.
● The internal power supply supports input voltages between 100 and 240VAC.
● Use the supplied AC power cord to connect the AC power connector to an AC power outlet.
● Cisco RPS Connector
● The connector offers connection for an optional Cisco RPS 2300 or RPS 675 that uses AC
input and supplies DC output to the switch.
● The connector automatically senses when the internal power supply of a connected device
fails and provides power to the failed device, preventing loss of network traffic.
● Only the Cisco RPS 2300 (model PWR-RPS2300) or the Cisco RPS 675 (PWR675-AC-RPS-
N1=) should be attached to the redundant-power-supply receptacle.
Indicators ● Per-port status LEDs: link integrity, disabled, activity, speed, and full-duplex indications
● System-status LEDs: system, RPS, and bandwidth-utilization indications
