Page 1 VAUXHALL Astra 0 - 1 VAUXHALL Astra Owner’s Manual Model Year 2012.5 Edition: January 2012 TS 1680-B-12...
Page 2: Table Of Contents
Contents Introduction ........2 In brief ..........6 Keys, doors and windows .... 19 Seats, restraints ......35 Storage ........53 Instruments and controls ..... 91 Lighting ........126 Climate control ......137 Driving and operating ....145 Vehicle care ....... 181 Service and maintenance ..
Page 3: Introduction
Introduction Introduction...
Page 4: Using This Manual
Operation is reasonable prices. Experienced Introduction similar for right-hand drive vehicles. mechanics trained by Vauxhall work ■ The Owner's Manual uses the Your vehicle is a designed according to specific Vauxhall factory engine designations. The combination of advanced technology, instructions.
Page 5 Symbols Cautions Page references are indicated with 3. 3 means "see page". 9 Danger Thank you for choosing a Vauxhall. We wish you many hours of Text marked 9 Danger provides pleasurable driving. information on risk of fatal injury. Your Vauxhall Team Disregarding this information may endanger life.
Page 6 Introduction...
Page 7: In Brief
In brief In brief Vehicle unlocking Seat adjustment Seat positioning Initial drive information Press button c to unlock the doors and load compartment. Open the Pull handle, slide seat, release doors by pulling the handles. To open handle. the tailgate, push the touchpad switch below the handle.
Page 8 In brief Seat backrests Seat height Seat inclination Pull lever, adjust inclination and Lever pumping motion Lever pumping motion release lever. Allow the seat to = seat higher = front end higher engage audibly. down = seat lower down = front end lower Seat position 3 37, Seat adjustment Seat position 3 37, Seat adjustment Seat position 3 37, Seat adjustment...
Page 9: Head Restraint Adjustment
In brief Head restraint adjustment Seat belt Mirror adjustment Interior mirror Press the button, adjust height and Pull out the seat belt and engage in engage. belt buckle. The seat belt must not be twisted and must fit close against the To reduce dazzle, adjust the lever on Head restraints 3 35.
Page 10: Steering Wheel Adjustment
In brief Steering wheel adjustment Exterior mirrors Select the relevant exterior mirror and Unlock the lever, adjust the steering adjust it. wheel, then engage the lever and Convex exterior mirrors 3 28, ensure it is fully locked. Electric adjustment 3 28, Folding Do not adjust the steering wheel exterior mirrors 3 28, Heated unless the vehicle is stationary and...
Page 11 In brief Instrument panel overview...
Page 12 In brief Power windows ..... 30 Control indicator for front 19 Selector lever, manual passenger seat belt ... 103 transmission ....... 155 Exterior mirrors ..... 28 Cruise control ..... 162 Fuel selector ......99 Automatic transmission ..152 Side air vents ...... 143 11 Info-Display ......
Page 13: Exterior Lighting
In brief Exterior lighting Headlight flash, high beam and low beam Automatic light control AUTO = automatic light control: Turn light switch: Headlights are switched headlight flash = pull lever on and off automatically = lights off high beam = push lever = activation or deactivation 8 = sidelights low beam...
Page 14 In brief Horn Turn and lane-change signals Hazard warning flashers Operated with the ¨ button. lever up = right turn signal Press j. lever down = left turn signal Hazard warning flashers 3 131. Turn and lane-change signals 3 131, Parking lights 3 132.
Page 15: Washer And Wiper Systems
In brief Washer and wiper systems Windscreen and headlight Rear window wiper and washer washer systems systems Windscreen wiper Pull lever. Press the rocker switch to activate the = fast rear window wiper: Windscreen and headlight washer = slow system 3 93, Washer fluid 3 185. upper = continuous P = timed interval wiping or...
Page 16: Climate Control
In brief Climate control Demisting and defrosting the windows Heated rear window, heated exterior mirrors Push lever. Washer fluid is sprayed on the rear window and the wiper wipes a few Press button V. times. Set the temperature control to the The heating is operated by pressing highest level.
Page 17: Starting Off
In brief Transmission Starting off Automatic transmission Manual transmission Check before starting off ■ Tyre pressure and condition 3 206, 3 247. ■ Engine oil level and fluid levels 3 183. ■ All windows, mirrors, exterior lighting and number plates are free from dirt, snow and ice and are operational.
Page 18 In brief Parking Starting the engine Stop-start system ■ Always apply the parking brake. Activate the manual parking brake without pressing the release button. Apply as firmly as possible on a downhill slope or uphill slope. Depress foot brake at the same time to reduce operating force.
Page 19 In brief selector lever to P before switching off the ignition. Turn the front wheels towards the kerb. ■ Lock the vehicle with button e on the radio remote control. Activate the anti-theft alarm system 3 25. ■ Do not park the vehicle on an easily ignitable surface.
Page 20: Keys, Doors And Windows
Keys, doors and windows Keys, doors and Keys, locks Key with foldaway key section windows Keys Replacement keys Keys, locks ........19 The key number is specified in the Car Pass or on a detachable tag. Doors ........... 24 The key number must be quoted Vehicle security ......
Page 21: Radio Remote Control
Keys, doors and windows Radio remote control Handle with care, protect from Radio remote control battery moisture and high temperatures and replacement avoid unnecessary operation. Replace the battery as soon as the range reduces. Fault If the central locking system cannot be operated with the radio remote control, it may be due to the following: ■...
Page 22: Central Locking System
Keys, doors and windows Memorised settings Central locking system Key with foldaway key section Whenever the key is removed from Unlocks and locks doors, load the ignition switch, the following compartment and fuel filler flap. settings are automatically memorised A pull on an interior door handle by the key: unlocks the respective door.
Page 23 Keys, doors and windows Unlocking The setting can be saved for the key being used. Memorised settings 3 21. Locking Close doors, load compartment and fuel filler flap. Press the e button to lock. Press the c button to unlock. Press button c.
Page 24: Automatic Locking
Keys, doors and windows Fault in radio remote control Fault in central locking system the ignition key is removed (manual transmission) or the selector lever is system Unlocking moved to P position (automatic transmission). Manually unlock the driver's door by Unlocking turning the key in the lock.
Page 25: Doors
Keys, doors and windows Doors Closing 9 Warning Load compartment Use the child locks whenever children are occupying the rear Tailgate seats. Opening Using a key or suitable screwdriver, turn the child lock in the rear door to the horizontal position. The door cannot be opened from the inside.
Page 26: Vehicle Security
Keys, doors and windows Vehicle security General hints for operating Activating tailgate Anti-theft locking system 9 Warning 9 Warning Do not drive with the tailgate open or ajar, e.g. when transporting Do not use the system if there are bulky objects, since toxic exhaust people in the vehicle! The doors gases, which can not be seen or cannot be unlocked from the...
Page 27 Keys, doors and windows Activation Activation without monitoring of 1. Close tailgate, bonnet, windows and sunroof. passenger compartment and ■ Self-activated 30 seconds after locking the vehicle (initialisation of vehicle inclination 2. Press button o. LED in the the system) button o illuminates for a maximum of 10 minutes.
Page 28 Keys, doors and windows Immobiliser Status during the first 30 seconds of The alarm can be silenced by anti-theft alarm system activation: pressing any button on the radio The system is part of the ignition remote control or by switching on the = test, arming delay.
Page 29: Exterior Mirrors
Keys, doors and windows Exterior mirrors In position 0 no mirror is selected. Electric folding Convex shape Folding The convex exterior mirror contains an aspherical area and reduces blind spots. The shape of the mirror makes objects appear smaller, which will affect the ability to estimate distances.
Page 30: Interior Mirrors
Keys, doors and windows Interior mirrors Heated Automatic anti-dazzle Manual anti-dazzle Dazzle from following vehicles at Operated by pressing the Ü button. night is automatically reduced. Heating works with the engine To reduce dazzle, adjust the lever on running and is switched off the underside of the mirror housing.
Page 31: Windows
Keys, doors and windows Windows payment must be attached in these areas. Otherwise data recording malfunctions may occur. Windscreen Manual windows Heat-reflecting windscreen The heat-reflecting windscreen has The door windows can be opened or a coating which reflects solar closed with the window winders. radiation.
Page 32 Keys, doors and windows Safety function Child safety system for rear windows If the window glass encounters resistance above the middle of the window during automatic closing, it is immediately stopped and opened again. Override safety function In the event of closing difficulties due to frost or the like, switch on the ignition, then pull the switch to the first detent and hold.
Page 33: Heated Rear Window
Keys, doors and windows Heated rear window Initialising the power windows If the sun visors have integral mirrors, the mirror covers should be closed If the windows cannot be closed when driving. automatically (e.g. after disconnecting the vehicle battery), A ticket holder is located on the a warning message or a warning code backside of the sun visor.
Page 34: Roof
Keys, doors and windows Roof Raise or close Press q or r: sunroof is raised or Sunroof closed automatically with safety function enabled. 9 Warning If the sunroof is raised, it can be opened in one step by pressing p. Take care when operating the Sunblind sunroof.
Page 35 Keys, doors and windows Closing sunroof from outside The sunroof can be closed remotely from outside the vehicle. Press and hold e button to close the sunroof. Release the button to stop the movement. Initialising after a power failure After a power failure, it may only be possible to operate the sunroof to a limited extent.
Page 36: Seats, Restraints
Seats, restraints Seats, restraints Head restraints Adjustment Head restraints on front seats Position Head restraints ......35 9 Warning Front seats ........37 Rear seats ........40 Only drive with the head restraint Seat belts ........41 set to the proper position. Airbag system ......
Page 37: Active Head Restraints
Seats, restraints Horizontal adjustment Head restraints on rear seats forwards. Thus the head is supported so that the risk of whiplash injury is reduced. Note Approved accessories may only be attached if the seat is not in use. To adjust horizontally, pull the head Height adjustment restraint forwards.
Page 38: Front Seats
Seats, restraints Front seats ■ Sit with shoulders as far back ■ Adjust the lumbar support so that it against the backrest as possible. supports the natural shape of the Set the backrest rake so that it is spine. Seat position possible to easily reach the steering wheel with arms slightly Seat adjustment...
Page 39 Seats, restraints Seat positioning Seat backrests Seat height Pull handle, slide seat, release Pull lever, adjust inclination and Lever pumping motion handle. release lever. Allow the backrest to = seat higher engage audibly. down = seat lower...
Page 40 Seats, restraints Seat inclination Lumbar support Adjustable thigh support Lever pumping motion Adjust lumbar support using the four- Pull the lever and slide the thigh way switch to suit personal support. = front end higher requirements. down = front end lower Moving support up and down: push switch up or down.
Page 41: Rear Seats
Seats, restraints Rear seats Armrest Heating Armrest The armrest can be slid forwards by Adjust heating to the desired setting 10 cm. Under the armrest there is by pressing the ß button for the a storage compartment. respective seat one or more times. Fold armrest down.
Page 42: Seat Belts
Seats, restraints Seat belts Seat belts are designed to be used by Belt force limiters only one person at a time. They are On the front seats, stress on the body not suitable for people smaller than is reduced by the gradual release of 150 cm.
Page 43: Three-Point Seat Belt
Seats, restraints Note buckle. Tighten the lap belt regularly Height adjustment Do not affix or install accessories or whilst driving by pulling the shoulder other objects that may interfere with belt. the operation of the belt pretensioners. Do not make any modifications to belt pretensioner components as this will invalidate the vehicle type approval.
Page 44 Seats, restraints Removing Using the seat belt while pregnant Adjust the height so that the belt lies across the shoulder. It must not lie To release belt, press red button on across the throat or upper arm. belt buckle. Do not adjust while driving. 9 Warning Seat belts on the rear seats The lap belt must be positioned as...
Page 45: Airbag System
Seats, restraints Airbag system Each airbag is triggered only once. Have deployed airbags replaced by a workshop. Furthermore, it might be The airbag system consists of necessary to have the steering a number of individual systems wheel, the instrument panel, parts of depending on the scope of the panelling, the door seals, equipment.
Page 46: Side Airbag System
Seats, restraints Fit the seat belt correctly and engage securely. Only then the airbag is able to protect. Side airbag system The inflated airbags cushion the The inflated airbags cushion the impact, thereby reducing the risk of impact, thereby reducing the risk of injury to the upper body and head of injury to the upper body and pelvis in the front seat occupants...
Page 47: Curtain Airbag System
Seats, restraints Curtain airbag system 9 Warning The curtain airbag system consists of an airbag in the roof frame on each Keep the area in which the airbag side. This can be identified by the inflates clear of obstructions. word AIRBAG on the roof pillars. The hooks on the handles in the roof frame are only suitable for The curtain airbag system is triggered...
Page 48 Seats, restraints Use the ignition key to choose the Change status only when the vehicle Risk of fatal injury for an adult position: is stopped with the ignition off. person on a seat with deactivated *OFF = front passenger airbag is Status remains until the next change.
Page 49: Child Restraints
Child restraint systems used on the front passenger seat. Ensure that the mounting location of We recommend the Vauxhall child the child restraint system within the Selecting the right system restraint system which is tailored vehicle is correct.
Page 50: Child Restraint Installation Locations
Seats, restraints Child restraint installation locations Permissible options for fitting a child restraint system On front passenger seat Weight and age class activated airbag deactivated airbag On rear outboard seats On rear centre seat Group 0: up to 10 kg or approx.
Page 51 Seats, restraints Permissible options for fitting an ISOFIX child restraint system Weight class Size class Fixture On front passenger seat On rear outboard seats On rear centre seat Group 0: up to 10 kg ISO/R1 Group 0+: up to 13 kg ISO/R1 ISO/R2 ISO/R3...
Page 52 Seats, restraints ISOFIX size class and seat device A – ISO/F3 = Forward-facing child restraint system for children of maximum size in the weight class 9 to 18 kg. B – ISO/F2 = Forward-facing child restraint system for smaller children in the weight class 9 to 18 kg. B1 –...
Page 53: Top-Tether Fastening Eyes
Seats, restraints ISOFIX child restraint Top-tether fastening eyes systems Top-Tether fastening eyes are marked with the symbol : for a child seat. Fasten vehicle-approved ISOFIX child restraint systems to the ISOFIX mounting brackets. Specific vehicle In addition to the ISOFIX mounting ISOFIX child restraint system fasten the Top-Tether strap to the positions are marked in the table by...
Page 54: Storage
Storage Storage Storage compartments Cupholders Glovebox Storage compartments ....53 Load compartment ....... 74 Roof rack system ......88 Loading information ..... 89 Cupholders are located in the centre console. The glovebox features a pen holder, a credit card holder and a coin holder. The glovebox should be closed whilst driving.
Page 55: Front Storage
Storage Front storage Sunglasses storage Depending on the version, cupholders are located under a cover in the centre console. Slide cover backwards. Bottles can be stowed after folding up the intermediate shelf 3 56. A storage compartment is located Fold down and open. next to the steering wheel.
Page 56: Underseat Storage
Storage Underseat storage Armrest storage Storage in the rear armrest Storage under the front armrest Fold down armrest and open cover. Press button in the recess and pull out drawer. Maximum load: 3 kg. To Close cover before folding the Press button to fold up the armrest.
Page 57: Centre Console Storage
Storage Centre console storage A further storage compartment is located under the intermediate shelf. Fold up the intermediate shelf and fix Front console it in the vertical position. The frame of the cupholder can be reintegrated to stow bottles. Rear console Press button to remove the frame of the cupholder.
Page 58: Rear Carrier System
Storage Rear carrier system There must not be any objects on the bicycles that could become loose during transportation. Rear carrier system for two bicycles Caution Do not attach bicycles with carbon pedal cranks to bicycle carriers. The bicycles might get damaged. Extending Open the tailgate.
Page 59 Storage Completely pull out the rear carrier Install the tail lamps Open out the lamp support on the system until you hear it engage. back of the tail lamp completely. Ensure that it is not possible to push in the rear carrier system without pulling the release lever again 9 Warning It is only permissible to fit objects...
Page 60 Storage Lock the rear carrier system Check the cable and lamp position to The rear carrier system is locked make sure these are correctly when the clamping levers are Swivel the right clamping lever (1) installed and are securely located. swivelled by approx.
Page 61 Storage Unfold pedal crank recesses Adapting the rear carrier system to a bicycle Remove the pedal crank mounts from the pedal crank recesses. Fold one or both pedal crank Press the release lever and withdraw recesses upwards until the diagonal the wheel recesses.
Page 62 Storage Push the release lever on the strap The rear bicycle must have its front retainer and remove the strap wheel facing right. retainer. Attaching a bicycle to the rear carrier Prepare the bicycle for attachment system If the bicycle has curved pedal cranks, screw in the pedal crank unit all the way (position 1).
Page 63 Storage Put on the bicycle. The pedal crank Place the wheel recesses such that here must be placed in the pedal the bicycle is more or less horizontal. crank recess opening as shown in the Here, the distance between the illustration.
Page 64 Storage If the two bicycles obstruct one Check the bicycle to make sure it is It is recommended to attach another, the relative positions of the secure. a warning sign at the rearmost bicycle bicycles can be adapted by adjusting to increase visibility.
Page 65 Storage Retracting the rear carrier system Insert the strap retainer and pull tightly downwards as far as possible. Disengage the locking lever on the diagonal support and fold both pedal Push the pedal crank mounts into the crank recesses down. pedal crank recess like shown in the Press release lever and slide in wheel graphic.
Page 66 Storage Push the clamping lever down and pull both lamp supports out of the recesses. Open the tailgate. Swivel first the left clamping lever (1), Pull the release lever up and push the followed by the right clamping lever system into the bumper until it (2), until they stop.
Page 67 Storage Rear carrier system for four powered bicycles to the pull-out 9 Warning carrier. The maximum load per bicycles bicycle on the adapter is 20 kg. No-one should be in the extension If not in use, the carrier system must zone of the rear carrier system, be slid back into the vehicle floor.
Page 68 Storage Unfold number plate holder Fold out tail lamps Completely pull out the rear carrier system until you hear it engage. Fold out both tail lamps. Lift the number plate holder and fold Ensure that it is not possible to push it backwards.
Page 69 Storage Swivel both clamping levers Assembling the bicycle rack sidewards as far as they will go. Otherwise safe functionality is not guaranteed. Fold out wheel recesses Push down the rack (1) and swivel handle (2) backwards to engage. Lift the rack at the rear (1) and pull it backwards.
Page 70 Storage 1. Rotate the pedals into position as shown in the illustration and put the bicycle on the foremost wheel recess. Make sure that the bicycle stands centrally on the wheel recesses. 3. Secure both bicycle wheels to the 1. Apply the adapter to the rear wheel recesses using the strap carrier system as shown in the retainers.
Page 71 Storage 2. Turn the lever (1) forwards and 1. Before putting on the bicycle, mounting brackets should be hold, then lower the adapter (2) at always unfold the wheel recesses fixed in parallel. the rear. for the next bicycle if necessary. Use the long mounting bracket to 3.
Page 72 Storage It is recommended to attach ■ With attached adapter: a warning sign at the rearmost bicycle to increase visibility. 9 Warning Fold the rear carrier system Take care when disengaging the backwards rear carrier system as it will tilt The rear carrier system can be folded backwards.
Page 73 Storage 3. Turn the lever (1) forwards and 9 Warning hold. 4. Lift the adapter (2) at the rear and When folding the rear carrier remove. system forwards again, take care that the system is engaged Disassembling the bicycle rack securely.
Page 74 Storage Swivel both clamping levers inwards as far as they will go. Fold in tail lamps Swivel in both tail lamps. Fold in number plate holder Lift the number plate holder and fold it forwards. Retracting the rear carrier system Caution Fold the rack backwards, then push Stow the strap retainers accurately.
Page 75: Load Compartment
Storage Load compartment Guide the seat belts through side supports to protect them against damage. When folding the backrests, The rear seat backrest is divided into pull the seat belts along with them. two parts. Both parts can be folded Pull the release lever on one or both down.
Page 76 Storage Ensure that the seat belts of the Load compartment extension, 9 Warning outboard seats are placed in the Sports tourer corresponding belt guides. When folding up, ensure that Folding down rear backrests backrests are securely locked in Remove the load compartment cover position before driving.
Page 77 Storage Pull the release lever on one or both To fold up, raise the backrests and 9 Warning sides and fold down the backrests guide them into an upright position onto the seat cushion. until they engage audibly. Take care when operating the On vehicles with electric seat folding, Ensure that the seat belts of the electric foldable rear seats.
Page 78 Storage Raise the seat cushion and fold the Remove the seat cushion 9 Warning backrest Only drive the vehicle if the backrests are securely locked into position. Otherwise there is a risk of personal injury or damage to the load or vehicle in the event of heavy braking or a collision.
Page 79: Load Compartment Cover
Storage Pull the grip and open the cover. The closed cover can be secured To attach, apply seat cushion as from the side of the load shown in the illustration and engage Suitable for loading long, narrow compartment. Turn the knob 90°: both levers.
Page 80 Storage 5-door hatchback Lift cover at the rear and push it Opening cover upwards at the front. Removing Remove the cover. If the height adjustable cover is mounted in the middle or upper position, the load compartment cover can be stowed below it. Height adjustable cover 3 81.
Page 81 Storage Cover in upper position Removing cover The removed cover can be stored under the rear floor cover like shown Push the handle at the end of the Open the load compartment cover. in the graphic. cover downwards. The rear of the Pull the release lever on the right side Rear floor storage cover 3 81.
Page 82: Rear Floor Storage Cover
Storage Rear floor storage cover Height adjustable cover, 5-door Lifting hatchback Rear floor cover, 5-door hatchback To lift the cover to a higher level, pull the loop backwards and lift the rear The height adjustable cover can be edge of the cover onto the mounted in three positions: corresponding supports.
Page 83 Storage Lowering Note Rear floor cover, Sports tourer ■ If mounted in position 2 or 3, the space between the rear floor cover and the height adjustable cover can be used as a stowage compartment. ■ The height adjustable cover can be lifted and hooked in with the strap when it is mounted in position 1 or 2.
Page 84: Lashing Eyes
Storage Lashing eyes ■ hooks, ■ service box, ■ strap set. The components are fitted in rails on both side panels using adapters and hooks. Installation of adapters in the rails Insert the bar into the recesses at the sidewalls. The lashing eyes are designed to secure items against slippage, e.g.
Page 85 Storage plate upwards to lock the adapter. To Net pocket Installation of hooks in the rails remove, turn the handle plate down and move out of the rail. Variable partition net Insert adapters into the required Insert the hook in the desired position position in the rails.
Page 86: Safety Net
Storage Service box Strap set Alternatively install both hooks in the lower rail. Plug in the lower brackets Insert the adapters of the strap set in Install two hooks in the upper rail. of the box from above into the lower a rail.
Page 87 Storage Passengers must not be transported Behind the front seats Installation of the rod behind the safety net. Installation Behind the rear seats Attach strap to eyes underneath the There are two installation openings in rear seat cushion. the roof frame: suspend and engage rod of net at one side, compress rod Fold backrests forward.
Page 88: Warning Triangle
Storage Warning triangle First aid kit Sports tourer 5-door hatchback 5-door hatchback Fold down straps. Stow the warning triangle in the space behind the straps on the inside of the tailgate. Stow the first aid kit in the stowage Stow the warning triangle in the space compartment behind the warning behind the strap on the right side of triangle.
Page 89: Roof Rack System
Storage Roof rack system Sports tourer Detach the cover from each mounting point by using a coin. Roof rack Sports tourer with roof railing For safety reasons and to avoid damage to the roof, the vehicle approved roof rack system is recommended.
Page 90: Loading Information
Storage Loading information ■ Use the four hooks at the sidewalls ■ Do not allow the load to protrude of the load compartment for above the upper edge of the hanging up carrier bags. Maximum backrests. load: 5 kg per hook. ■...
Page 91 Storage vehicle weight (see identification 100 kg for the Sports tourer. The plate 3 229) and the EC kerb roof load is the combined weight of the roof rack and the load. weight. To calculate the payload, enter the data for your vehicle in the Weights table at the front of this manual.
Page 92: Instruments And Controls
Instruments and controls Instruments and Controls Steering wheel controls controls Steering wheel adjustment Controls ........91 Warning lights, gauges and indicators ........98 Information displays ....109 Vehicle messages ...... 114 Trip computer ......118 Vehicle personalisation ....121 The Infotainment system, the cruise control and a connected mobile phone can be operated via the Unlock lever, adjust steering wheel,...
Page 93: Horn
Instruments and controls Heated steering wheel Horn The recommended grip areas of the steering wheel are heated quicker Activate heating by pressing * and to a higher temperature than the Press j. other areas. button. Activation is indicated by the LED in the button.
Page 94: Windscreen Wiper/Washer
Instruments and controls Windscreen wiper/washer Adjustable wiper interval Automatic wiping with rain sensor Windscreen wiper Wiper lever in position P. P = automatic wiping with rain sensor Turn the adjuster wheel to adjust the = fast desired wipe interval: The rain sensor detects the amount of = slow short = turn adjuster wheel...
Page 95 Instruments and controls Adjustable sensitivity of the rain Windscreen and headlight sensor washer Keep the sensor free from dust, dirt and ice. Turn the adjuster wheel to adjust the Pull lever. Washer fluid is sprayed sensitivity: onto the windscreen and the wiper = turn adjuster wheel wipes a few times.
Page 96: Outside Temperature
Instruments and controls Rear window wiper/washer The rear window washer system is deactivated when the fluid level is low. Outside temperature Push lever. Washer fluid is sprayed onto the rear window and the wiper Press the rocker switch to activate the wipes a few times.
Page 97 Instruments and controls Set date and time ■ Set date format: Changes indication of date between MM/DD/ Press the CONFIG button. The menu YYYY and DD.MM.YYYY. Settings is displayed. ■ Display digital clock: Switches on/ Select Time & Date. off indication of time on the display. ■...
Page 98: Power Outlet
Instruments and controls Power outlets Cigarette lighter A further 12 Volt power outlet is located in the rear console. Fold the cover downwards. Sports tourer: A 12 Volt power outlet is located at the left sidewall in the load compartment. Do not exceed the maximum power consumption of 120 watts.
Page 99: Warning Lights, Gauges And
Instruments and controls Warning lights, gauges Odometer and indicators Instrument cluster In some versions, the needles of the instruments briefly rotate to the end position when the ignition is switched Speedometer The portable ashtray can be placed in the cupholders. The bottom line displays the recorded distance in miles.
Page 100: Fuel Selector
Instruments and controls Tachometer Fuel gauge Because of the fuel remaining in the tank, the top-up quantity may be less than the specified tank capacity. Fuel selector Displays the engine speed. Displays the fuel level or gas level in the tank depending on the operation Drive in a low engine speed range for mode.
Page 101: Engine Coolant Temperature Gauge
Instruments and controls As soon as the liquid gas tanks are In the Uplevel-Display or Uplevel- Caution empty, petrol operation is Combi-Display, the remaining oil life automatically engaged until the duration is displayed in the Vehicle If engine coolant temperature is ignition is switched off.
Page 102: Control Indicators
Instruments and controls Press the MENU button to select the versions. Depending on the Vehicle Information Menu. equipment, the position of the control indicators may vary. When the Turn the adjuster wheel to select ignition is switched on, most control Remaining Oil Life.
Page 103 Instruments and controls Control indicators in the instrument cluster...
Page 104: Seat Belt Reminder
Instruments and controls Control indicators in the centre Bulb replacement 3 189, Fuses When the ignition is switched on, the control indicator illuminates for 3 198. console approx. 4 seconds. If it does not Turn signals 3 131. illuminate, does not go out after 4 seconds or illuminates whilst Seat belt reminder driving, there is a fault in the airbag...
Page 105: Malfunction Indicator Light
Instruments and controls Malfunction indicator light * illuminates yellow. Seek the assistance of a workshop. The front passenger airbag is Vehicle messages 3 114. Z illuminates or flashes yellow. deactivated 3 46. Illuminates when the ignition is Brake and clutch system switched on and extinguishes shortly 9 Danger after the engine starts.
Page 106: Electrical Parking Brake
Instruments and controls Electrical parking brake Illuminates If the control indicator does not go out after a few seconds, or if it illuminates Brake pedal needs to be operated to fault while driving, there is a fault in the release the electrical parking brake ABS.
Page 107: Electronic Stability Control Off
Instruments and controls Stop-start system 3 148. Interference due to external sources Have the cause of the fault remedied of ultrasound. Once the source of by a workshop. Illuminates with power steering interference is removed, the system Flashes disabled will operate normally. The system is actively engaged.
Page 108: Engine Oil Pressure
Instruments and controls Continue driving until % Flashes 3. Move out of the flow of traffic as quickly as possible without extinguishes. If possible, do not allow Fault in system or tyre without impeding other vehicles. engine speed to drop below pressure sensor mounted (e.g.
Page 109: Fog Light
Instruments and controls Fog light Flashes Illuminated when high beam is on or during headlight flash 3 127, or when Fuel used up. Refuel immediately. > illuminates green. high beam is on with high beam Never run the tank dry. The front fog lights are on 3 132.
Page 110: Driver Information Centre
Instruments and controls Information displays Door open h illuminates red. Driver Information Centre A door or the tailgate is open. The following main menus, depending on the vehicle configuration, can be selected: ■ Vehicle Information Menu The Driver Information Centre (DIC) ■...
Page 111 Instruments and controls Selecting menus and functions The menus and functions can be selected via the buttons on the turn signal lever. In the Uplevel-Combi-Display, the Turn the adjuster wheel to highlight menus can be selected by the a menu option or to set a numeric MENU button, indicated by symbols value.
Page 112 Instruments and controls Press the SET/CLR button to select Possible submenus: a function or to confirm a message. ■ Unit: Displayed units can be changed Vehicle Information Menu ■ Tire Pressure: 3 207 Press the MENU button to select the ■...
Page 113: Info-Display
Instruments and controls Graphic-Info-Display, Colour-Info-Display Colour-Info-Display Depending on the vehicle configuration the vehicle has a Graphic- or Colour-Info-Display. The Info-Display is located in the instrument panel above the Infotainment system. Graphic-Info-Display Graphic-Info-Display indicates: ■ time 3 96 The Colour-Information-Display ■ outside temperature 3 95 indicates in colour: ■...
Page 114: Instruments And Controls
Instruments and controls ■ vehicle messages 3 114 Selecting with the Infotainment Press (the outer ring) system ■ settings for vehicle personalisation ■ To select or activate the marked 3 121 option ■ To confirm a set value The type of information and how it is displayed depends on the equipment ■...
Page 115: Vehicle Messages
Instruments and controls Vehicle messages Vehicle messages on the No. Vehicle message Midlevel-Display Depress brake pedal to release Messages are indicated mainly in the electrical parking brake Driver Information Centre (DIC), in some cases together with a warning Turn steering wheel, switch and signal buzzer.
Page 116 Instruments and controls No. Vehicle message No. Vehicle message No. Vehicle message 24 Number plate light failure 54 Water in diesel fuel filter 68 Service power steering 25 Left front turn signal failure 55 Diesel particle filter is full 69 Service suspension system 3 150 26 Left rear turn signal failure 70 Service level control system...
Page 117 Instruments and controls Vehicle messages on the ■ Cruise control No. Vehicle message Uplevel-Display or Uplevel- ■ Object detection systems 95 Service airbag Combi-Display ■ Lighting, bulb replacement 128 Bonnet open ■ Wiper/washer system 134 Park assist fault, clean bumper ■...
Page 118: Warning Chimes
Instruments and controls Warning chimes When the vehicle is parked and/ If the battery cannot be recharged, have the cause of the fault remedied or the driver's door is opened by a workshop. When starting the engine or ■ When the key is in the ignition whilst driving switch.
Page 119: Trip Computer
Instruments and controls Trip computer ■ Trip odometer 1 ■ Trip odometer 2 The menus and functions can be ■ Range selected via the buttons on the turn ■ Average consumption signal lever. ■ Instantaneous consumption ■ Average speed ■ Digital speed ■...
Page 120 Instruments and controls ■ Trip odometer 2 ■ Average consumption 2 ■ Average speed 2 ■ ECO drive assistant ■ Trip odometer 1 ■ Route guidance ■ Average consumption 1 ■ Average speed 1 Trip computer 1 and 2 ■ Digital speed The information of two trip computers ■...
Page 121 Instruments and controls When the tank has to be refuelled Digital speed immediately, a warning code or Digital display of the instantaneous warning message is displayed on speed. vehicles with Midlevel- and Uplevel- Display or Uplevel-Combi-Display. Traffic sign assistant Additionally the control indicator i in Indicates detected traffic signs for the the fuel gauge illuminates or flashes current route section 3 165.
Page 122: Vehicle Personalisation
Instruments and controls Vehicle personalisation Personal settings in the Graphic-Info-Display The vehicle's behaviour can be personalised via changing the settings in the Info-Display. Some of the personal settings for different drivers can be memorised individually for each vehicle key. Memorised settings 3 21. Depending on vehicle equipment and country-specific regulations some of the functions described below might...
Page 123 Instruments and controls Sport mode settings Phone settings Auto demist: Supports windscreen dehumidification by automatically The driver can select the functions See description for Infotainment selecting the necessary settings which will be activated in Sport mode system in the Infotainment system and auto air conditioning mode.
Page 124 Instruments and controls rear window wiper when reverse Delayed door lock: Activates or Personal settings in the gear is engaged. deactivates the delayed door Colour-Info-Display locking function. ■ Park assist / Collision detection ■ Remote locking, unlocking, starting Park assist: Activates or deactivates the ultrasonic parking Remote unlock feedback: Activates assist.
Page 125 Instruments and controls Sport mode settings Phone settings The driver can select the functions See description for Infotainment which will be activated in Sport mode system in the Infotainment system 3 160. manual. ■ Sport suspension: Damping Navigation settings becomes harder. See description for Infotainment ■...
Page 126 Instruments and controls Climate control mode: Activates or Rear auto wipe in reverse: automatic door locking function deactivates cooling when switching Activates or deactivates while a door is open. on the ignition or uses the last automatically switching on of the ■...
Page 127: Lighting
Lighting Lighting Exterior lighting Light switch with Automatic light control Light switch Exterior lighting ......126 Interior lighting ......133 Lighting features ......134 Turn light switch: AUTO = automatic light control: Turn light switch: Headlights are switched = lights off on and off automatically 8 = sidelights depending on external...
Page 128: Automatic Light Control
Lighting In the Driver Information Centre with When the automatic light control Tunnel detection Uplevel-Display or Uplevel-Combi- function is switched on and the When a tunnel is entered the Display, the current status of the engine is running, the system headlights are switched on without automatic light control is displayed.
Page 129: Headlight Range Adjustment
Lighting Headlight flash 2 = all seats occupied and load Vehicles with Xenon headlight compartment laden system To activate the headlight flash, pull 3 = driver's seat occupied and load lever. compartment laden. Dynamic automatic headlight Headlight range levelling 3 129. adjustment Headlights when driving Manual headlight range...
Page 130: Adaptive Forward Lighting
Lighting For deactivation operate the same Playstreet lighting Adverse weather lighting procedure as described above. f will Activated automatically at low speed Activated automatically up to a speed not flash when function is up to approx. 20 mph. The light beam of approx.
Page 131 Lighting Corner lighting High Beam Assist Activation This feature allows high beam as main driving light by night and when vehicle speed is faster than 25 mph. It switches to low beam when: ■ the camera in the windscreen detects the lights of oncoming or preceding vehicles On tight bends or when turning off, ■...
Page 132: Hazard Warning Flashers
Lighting If a headlight flash is activated when Fault in Adaptive forward In the event of an accident with airbag the high beam is on, the high beam deployment the hazard warning lighting system assist will be deactivated. flashers are activated automatically. When the system detects a failure in If a headlight flash is activated when the Adaptive forward lighting system,...
Page 133: Parking Lights
Lighting Parking lights For three flashes, e.g. when changing Light switch in position AUTO: lanes, press the lever until resistance switching on front fog lights will switch is felt and then release. headlights on automatically. When a trailer is connected, turn Rear fog lights signal flashes six times when pressing the lever until resistance is...
Page 134: Interior Lighting
Lighting Interior lighting Reversing lights On vehicles with light sensor, the brightness can only be adjusted when The reversing light comes on when the exterior lights are on and the light Instrument panel the ignition is on and reverse gear is sensor detects night conditions.
Page 135: Lighting Features
Lighting Lighting features Reading lights Operate rocker switch: = automatic switching on Centre console lighting and off. press u = on. Spotlight incorporated in the interior press v = off. lighting comes on when headlights are switched on. Rear courtesy lights Entry lighting Welcome lighting Following lights are switched on for...
Page 136: Exit Lighting
Lighting Activation or deactivation of this Headlights, tail lights, reversing lights Exit lighting is switched off function can be changed in the menu and number plate lights illuminate the immediately if the turn signal lever is Settings in the Info-Display. Vehicle surrounding area for an adjustable pulled while the driver's door is open.
Page 137 Lighting In the second stage a message which confirms the activation of the battery discharge protection will be displayed in the Driver Information Centre. Switching off electric lights To prevent discharge of the battery when the ignition is switched off, some interior lights are switched off automatically after some time.
Page 138: Climate Control
Climate control Climate control Climate control systems Heating will not be fully effective until the engine has reached normal operating temperature. Heating and ventilation system Air distribution Climate control systems ..... 137 s = to windscreen and front door Air vents ........143 windows Maintenance ......
Page 139: Air Conditioning System
Climate control Air conditioning system The air conditioning system cools and In warm and very humid ambient air dehumidifies (dries) as soon as the conditions, the windscreen might mist outside temperature is slightly above up from outside, when cold air is the freezing point.
Page 140: Electronic Climate Control
Climate control Demisting and defrosting the Note Controls for: If the settings for demisting and windows V ■ Temperature on driver side defrosting are selected, an Autostop ■ Air distribution will be inhibited. ■ Fan speed If the settings for demisting and ■...
Page 141 Climate control Automatic mode AUTO The fan speed regulation in automatic mode can be changed in the menu Settings. Vehicle personalisation 3 121. All air vents are actuated automatically in automatic mode. The air vents should therefore always be open. Temperature preselection Temperatures can be set to the desired value.
Page 142 Climate control If the maximum temperature is set, Note Press lower button to decrease or the climate control system runs at If the V button is pressed while the upper button to increase fan speed as maximum heating. engine is running, an Autostop will shown in the illustration.
Page 143: Air Recirculation Mode
Climate control Cooling n Air recirculation mode 4 Activate or deactivate with the n 9 Warning button. The air conditioning system cools and The exchange of fresh air is dehumidifies (dries) when outside reduced in air recirculation mode. temperature is above a specific level. In operation without cooling the air Therefore condensation may form humidity increases, so the...
Page 144: Air Vents
Climate control Air vents Auxiliary heater Air heater Adjustable air vents Quickheat is an electric auxiliary air At least one air vent must be open heater which automatically warms up while the cooling is on. the passenger compartment more quickly. Direct the flow of air by tilting and swivelling the slats.
Page 145: Pollen Filter
Climate control Maintenance Air conditioning regular operation Air intake In order to ensure continuously efficient performance, cooling must be operated for a few minutes once a month, irrespective of the weather and time of year. Operation with cooling is not possible when the outside temperature is too low.
Page 146: Driving And Operating
Driving and operating Driving and operating Driving hints Pedals To ensure the pedal travel is Control of the vehicle uninhibited, there must be no mats in the area of the pedals. Driving hints ....... 145 Never coast with engine not Starting and operating ....
Page 147: Starting And Operating
Driving and operating Starting and operating Ignition switch positions ■ Power windows ■ Sunroof New vehicle running-in ■ Power outlets Do not brake unnecessarily hard for Power to the Infotainment system will the first few journeys. continue to operate for 30 minutes or until the key is removed from the During the first drive, smoke may ignition switch, regardless of whether...
Page 148: Overrun Cut-Off
Driving and operating Do not operate the accelerator pedal. Starting the vehicle at low Possible reasons for a non-starting engine: temperatures Diesel engine: turn the key to position 2 for preheating until control ■ Clutch pedal not operated (manual The start of the engine without indicator ! extinguishes.
Page 149 Driving and operating Stop-start system Deactivation The stop-start system helps to save fuel and to reduce the exhaust emissions. When conditions allow, it switches off the engine as soon as the vehicle is at a low speed or at a standstill, e.g. at a traffic light or in a traffic jam.
Page 150 Driving and operating Conditions for an Autostop ■ the self-cleaning function of the Restart of the engine by the diesel particle filter is not active The stop-start system checks if each driver of the following conditions is fulfilled. ■ the vehicle has moved since the Depress the clutch pedal to restart the Otherwise an Autostop will be last Autostop...
Page 151: Engine Exhaust
Driving and operating Engine exhaust ■ the driver's seat belt is unfastened firmly as possible on downhill or and the driver's door is opened uphill slopes. Depress the foot brake at the same time to reduce ■ the engine temperature is too low operating force.
Page 152: Catalytic Converter
Driving and operating take up to 25 minutes. Typically it full continue driving or warning Cleaning takes place quickest at high needs between 7 and 12 minutes. code 55 appears in the Driver engine speeds and loads. Autostop is not available and fuel Information Centre.
Page 153: Automatic Transmission
Driving and operating Automatic transmission Selector lever rectified by a workshop as soon as possible. In an emergency, driving can be continued for a short period, The automatic transmission permits keeping vehicle speed and engine automatic gearshifting (automatic speed low. mode) or manual gearshifting (manual mode).
Page 154: Manual Mode
Driving and operating Manual mode Do not accelerate while engaging a gear. Never depress the accelerator pedal and brake pedal at the same time. When a gear is engaged, the vehicle slowly begins to creep when the brake is released. Engine braking To utilise the engine braking effect, select a lower gear in good time when...
Page 155 Driving and operating Interruption of power In manual mode no automatic shifting Kickdown to a higher gear takes place at high If the accelerator pedal is pressed supply engine revolutions. down completely in automatic mode, In the event of an interruption of the transmission shifts to a lower gear power supply, the selector lever Electronic driving...
Page 156: Manual Transmission
Driving and operating Manual transmission 2. Release the selector lever trim Caution from the centre console at the front, fold it upwards and rotate it It is not advisable to drive with the to the left. hand resting on the selector lever. To engage reverse, with the vehicle stationary wait 3 seconds after 3.
Page 157: Brakes
Driving and operating Brakes ABS starts to regulate brake pressure Fault as soon as a wheel shows a tendency to lock. The vehicle remains 9 Warning The brake system comprises two steerable, even during hard braking. independent brake circuits. If there is a fault in the ABS, the ABS control is made apparent If a brake circuit fails, the vehicle can wheels may be liable to lock due...
Page 158: Parking Brake
Driving and operating Parking brake Electrical parking brake Do not operate electrical parking brake system too often without engine running because this will Manual parking brake discharge the battery. Before leaving the vehicle, check the electrical parking brake status. Control indicator m 3 105. Releasing Switch on ignition.
Page 159: Brake Assist
Driving and operating Dynamic braking when vehicle is Control indicator m flashes: electrical The hill start assist is not active during moving an Autostop. parking brake is not fully applied or released. When continuously When the vehicle is moving and the flashing, release electrical parking switch m is kept pulled, the electrical brake and retry applying.
Page 160: Traction Control System
Driving and operating Ride control systems TC is reactivated by pressing the b 9 Warning button again. Traction Control system TC is also reactivated the next time Do not let this special safety the ignition is switched on. feature tempt you into taking risks The Traction Control system (TC) is when driving.
Page 161: Sport Mode
Driving and operating ESC is reactivated by pressing the In each driving mode Flex Ride 9 Warning b button again. If the TC system was networks the following electronic systems: previously disabled, both TC and Do not let this special safety ESC are reactivated.
Page 162 Driving and operating SPORT mode ■ Shift points of automatic into sporty settings. The DMC transmission occur in a comfort changes to SPORT mode in case of The settings of the systems are mode. very sporty driving behaviour. adapted to a sportier driving style: ■...
Page 163: Driver Assistance Systems
Driving and operating Driver assistance maintained. Control indicator m illuminates green. Accelerator pedal systems can be released. Vehicle speed can be increased by depressing the accelerator pedal. 9 Warning When the accelerator pedal is released, the previously stored speed Driver assistance systems are is resumed.
Page 164: Parking Assist
Driving and operating Deactivation Switching off The warning chime regarding unfastened seat belts has priority Press button y, control indicator m in Press button m, control indicator m in over any other acoustic signal 3 117. instrument cluster extinguishes. The instrument cluster illuminates white.
Page 165 Driving and operating Activation vehicle gets closer to the obstacle. Additionally, r illuminates or When the distance is less than a vehicle message is displayed in the 30 cm, the buzzing is continuous. Driver Information Centre if a malfunction of the system due to Depending on the version, the temporary conditions like snow distance to a front obstacle is...
Page 166: Traffic Sign Assistant
Driving and operating Note Caution The parking assist system automatically detects factory-fitted Performance of the sensor can be towing equipment. It is deactivated reduced when sensors are when the connector is plugged in. covered, e.g. by ice or snow. The sensor may detect a non- Performance of the parking assist existing object (echo disturbance) systems can be reduced due to...
Page 167 Driving and operating An exclamation mark in a frame Display indication If the system is deactivated, the indicates that there is an content of the traffic sign page is supplementary sign detected which cleared, indicated by the following cannot be recognised by the system. symbol: The system is active at an indicated speed above 9 mph and is active up...
Page 168 Driving and operating Pop-up function Speed limits and no passing signs are Once setting page is displayed, select displayed as pop-up on each page of Off to deactivate pop-up function. The pop-up function can be the menu. Reactivate by selecting On. When deactivated on the traffic sign page by switching on the ignition, pop-up pressing the SET/CLR button on the...
Page 169: Lane Departure Warning
Driving and operating Fault changes and warns the driver in the Caution event of an unintended lane change The traffic sign assistant system may via visual and acoustic signals. not operate correctly when: The system is intended to help the Criteria for the detection of an ■...
Page 170: Fuel
Driving and operating Fuel The lane departure warning system is Deactivation activated by pressing the ) button. The system is deactivated by The illuminated LED in the button Fuel for petrol engines pressing ) button, the LED in the indicates that the system is switched button extinguishes.
Page 171: Fuel For Diesel Engines
Driving and operating The boiling point depends on the Caution Caution pressure and mixing ratio. At ambient pressure, it is between -42 °C (pure Use of fuel that does not comply to Use of fuel that does not comply to propane) and -0.5 °C (pure butane).
Page 172 Driving and operating Pressing the LPG button switches Fill the tank completely at regular Caution between petrol and liquid gas intervals to prevent corrosion in the operation as soon as the required tank. Repairs and adjustments may only parameters (coolant temperature, be made by trained specialists in Faults and remedies gas temperature and minimum...
Page 173 Driving and operating Refuelling 9 Danger Fuel is flammable and explosive. No smoking. No naked flames or sparks. If you can smell fuel in your vehicle, have the cause of this remedied immediately by a workshop. Caution Turn the thumb wheel clockwise. In case of misfuelling, do not If no further gas odour is perceptible switch on ignition.
Page 174 Driving and operating Fuel filler cap Only use genuine fuel filler caps. Diesel-engined vehicles have special fuel filler caps. Liquid gas refuelling Follow the operating and safety instructions of the filling station when refuelling. The filling valve for the liquid gas is behind the fuel filler cap.
Page 175 Fit protective cap to prevent the required which are available from penetration of foreign bodies into the Vauxhall Distributors and from filler opening and the system. Vauxhall Authorised Repairers. ACME Adapter: Screw the nut of the filling nozzle onto the adapter.
Page 176: Fuel Consumption - Co
Emissions Petrol The fuel consumption (combined) of ACME adapter: Belgium, Germany, EURO adapter: Spain the model Vauxhall Astra is within Ireland, Luxembourg, Switzerland a range of 38 to 72 mpg. The CO emission (combined) is within a range of 99 to 177 g/km.
Page 177: General Information
Driving and operating Towing The CO emission (combined) was For trailers with low driving stability and caravan trailers with a permitted not available at time of printing. gross vehicle weight of more than General information General information 1300 kg the use of a stabiliser is Only use towing equipment that has strongly recommended when driving The official fuel consumption and...
Page 178: Towing Equipment
Driving and operating The permissible trailer loads are The maximum permissible vertical Stowage of coupling ball bar specified in the vehicle documents. In coupling load (75 kg) is specified on general, they are valid for gradients the towing equipment identification up to max.
Page 179 Driving and operating Fitting the coupling ball bar Disengage and fold down the socket. Otherwise, the coupling ball bar must Remove the sealing plug from the be tensioned before being inserted: opening for the coupling ball bar and ■ Unlock coupling ball bar by turning stow it.
Page 180 Driving and operating Inserting the coupling ball bar Eye for break-away stopping cable ■ The coupling ball bar must be firmly engaged in the opening. ■ The coupling ball bar must be locked and the key removed. 9 Warning Towing a trailer is permitted only when a coupling ball bar is fitted correctly.
Page 181: Trailer Stability Assist
Driving and operating Open the protective flap and turn the key to position c to unlock the coupling ball bar. Pull out rotary handle and turn clockwise as far as it will go. Pull out coupling ball bar downwards. Insert sealing plug in opening. Fold away socket.
Page 182: Vehicle Care
Vehicle care Vehicle care General Information Vehicle storage Accessories and vehicle Storage for a long period of time If the vehicle is to be stored for several modifications General Information ....181 months: We recommend the use of genuine Vehicle checks ......182 ■...
Page 183: Vehicle Checks
Vehicle care Vehicle checks ■ Disconnect the clamp from the Gas vehicles must be recycled by negative terminal of the vehicle a service centre authorised for gas battery. Beware that all systems are vehicles. Performing work not functional, e.g. anti-theft alarm system.
Page 184: Engine Oil
Vehicle care If the bonnet is opened during an 9 Danger Autostop, the engine will be restarted automatically for safety reasons. The ignition system and Xenon headlights use extremely high Closing voltage. Do not touch. Before closing the bonnet, press the support into the holder.
Page 185: Engine Coolant
Vehicle care We recommend the use of the same Caution grade of engine oil that was used at last change. It is the owner's responsibility to The engine oil level must not exceed maintain the proper level of an the MAX mark on the dipstick. appropriate quality oil in the engine.
Page 186: Washer Fluid
Vehicle care Washer fluid Coolant level 9 Warning Caution Allow the engine to cool before opening the cap. Carefully open Too low a coolant level can cause the cap, relieving the pressure engine damage. slowly. To top up use a 1:1 mixture of released coolant concentrate mixed with clean tap water.
Page 187: Brake Fluid
Vehicle care Brakes Battery In the event of minimum thickness of The vehicle battery is maintenance- the brake lining, a squealing noise free provided that the driving profile sounds during braking. allows sufficient charging of the battery. Short-distance-driving and Continued driving is possible but frequent engine starts can discharge have the brake lining replaced as the battery.
Page 188 Using an AGM battery different from off with a dummy cap, and the the original Vauxhall battery might ventilation in the vicinity of the result in a lower performance of the negative terminal must be opened.
Page 189: Wiper Blade Replacement
Vehicle care Diesel fuel system Meaning of symbols: Lift the wiper arm until it stays in the raised position, press button to ■ No sparks, naked flames or bleeding disengage the wiper blade and smoking. remove. If the tank has been run dry, the diesel ■...
Page 190: Bulb Replacement
Vehicle care Bulb replacement Lower wiper arm carefully. Headlights have separate systems for low beam 1 (outer bulbs) and high beam 2 (inner bulbs). Switch off the ignition and switch off the relevant switch or close the doors. Low beam Only hold a new bulb at the base! Do not touch the bulb glass with bare hands.
Page 191 Vehicle care 3. Detach the bulb from the bulb 3. Detach the bulb from the bulb holder and replace the bulb. holder and replace the bulb. 4. Insert the bulb holder, engaging 4. Insert the bulb holder, engaging the two lugs into the reflector and the two lugs into the reflector and rotate clockwise to secure.
Page 192 Vehicle care 3. Remove the bulb from the socket and replace the bulb. 4. Insert the bulb holder into the reflector. Fit the cap and rotate clockwise. Front turn signal 2. Press latches together and 1. Disengage the spring clip and withdraw the bulb holder from the then swivel it backwards.
Page 193: Fog Lights
Vehicle care Fog lights 3. Disengage the bulb holder from 1. Turn the bulb holder anti- the plug connector by pressing clockwise and remove it from the the retaining lug. reflector. 4. Remove and replace the bulb holder with bulb. 5.
Page 194: Tail Lights
Vehicle care Tail lights 2. Unscrew the plastic securing nut from the inside by hand. Saloon/Hatchback 6. Unscrew the three screws with a coin and remove the bulb carrier. 3. Carefully withdraw the light assembly from retaining pins and 1. Release the cover and remove it. remove.
Page 195 Vehicle care Tail lights (1) 1. Open the tailgate and remove the three covers. Brake light (2) 2. Unscrew the three screws and Turn signal light (3) remove. 8. Insert the bulb carrier into the tail 3. Remove the tail light assembly. light assembly and screw into Make sure that the cable duct place.
Page 196 Vehicle care Sports tourer 2. Remove cover. 4. Carefully remove tail light assembly. Take care that the cable duct remains in position. Detach wiring plug from bulb holder. 3. Unscrew two plastic securing nuts 1. On left-hand side, fold down the from the inside by hand.
Page 197 Vehicle care Tail light in the tailgate When assembling press the blind 4. Remove and replace the bulb. into the rubber grommets to reach 1. Open the tailgate and remove the 5. Install the tail light assembly in the full retention force. covers.
Page 198: Number Plate Light
Vehicle care Rear fog light / reverse light in the 2. Remove and replace the bulb of 2. Remove the bulb holder tailgate rear fog light. downwards, taking care not to pull on the cable. 3. Close cover. For replacing reverse light bulb on the right side of the tailgate, proceed in the same way.
Page 199: Electrical System
Vehicle care Electrical system Interior lights Courtesy light, reading lights Fuses Have bulbs replaced by a workshop. Data on the replacement fuse must match the data on the defective fuse. Load compartment light There are three fuse boxes in the Have bulbs replaced by a workshop.
Page 200: Engine Compartment Fuse
Vehicle care Engine compartment fuse Place the fuse extractor on the various types of fuse from the top or side, and withdraw fuse. The fuse box is in the front left of the engine compartment. Disengage the cover and fold it upwards until it stops.
Page 201 Vehicle care No. Circuit No. Circuit Engine control module 17 Transmission control module Lambda probe 18 Heated rear window Fuel injection, ignition system 19 Front power windows Fuel injection, ignition system 20 Rear power windows – 21 ABS Mirror heating 22 Left high beam (Halogen) Fan control 23 Headlamp washer system...
Page 202: Instrument Panel Fuse Box
Vehicle care Instrument panel fuse box No. Circuit No. Circuit 34 – 50 Headlamp levelling 35 Power windows 51 Air shutter 36 – 52 Auxiliary heater, diesel engine 37 Canister vent solenoid 53 Transmission control module, Engine control module 38 Vacuum pump 54 Wiring monitoring 39 Fuel system control module After having changed defective fuses...
Page 203 Vehicle care No. Circuit No. Circuit Displays 17 Air conditioning system Exterior lights 18 Prefuse: radio, Infotainment, displays Exterior lights 19 Brake lights, tail lights, interior Radio lights Infotainment system, 20 – instrument 21 – Power outlet front 22 Ignition switch Power outlet rear seat In right-hand drive vehicles, the fuse 23 Body control unit...
Page 204 Vehicle care Fuse assignments Remove the cover. Fold down the blind and remove. Sports tourer The fuse box is on the left side of the load compartment behind a cover. Remove the cover.
Page 205 Vehicle care No. Circuit No. Circuit Trailer module 18 – Trailer outlet 19 Steering wheel heating Parking assist 20 Sunroof – 21 Seat heating – 22 – – 23 – – 24 – When assembling press the blind into Anti-theft alarm system 25 –...
Page 206: Vehicle Tools
Vehicle care Vehicle tools Wheels and tyres Vehicles with spare wheel, variant 1 Tools The jack, the tools and a strap for Tyre condition, wheel condition securing a damaged wheel are in Drive over edges slowly and at right Vehicles with tyre repair kit a storage compartment below the angles if possible.
Page 207: Tyre Pressure
Vehicle care Tyres of size 235/40 R 19 and Speed code letter: 235/45 R 18 and 225/45 R 18 must Q = up to 100 mph not be used as winter tyres. S = up to 112 mph T = up to 118 mph Tyres of size 215/60 R 16 must not H = up to 130 mph...
Page 208: Tyre Pressure Monitoring
Vehicle care Incorrect tyre pressures will impair The current tyre pressures can be safety, vehicle handling, comfort and shown in the Vehicle Information fuel economy and will increase tyre Menu in the Driver Information wear. Centre. The menu can be selected by the 9 Warning buttons on the turn signal lever.
Page 209: Tread Depth
Vehicle care Control indicator w 3 107. The tyre pressure monitoring system Temperature compensation valve cores and sealing rings must be Cold tyres decrease the tyre Vehicle messages 3 114. replaced each time the tyres are pressure, warm tyres increase the If the tyre pressure shall be reduced changed.
Page 210: Wheel Covers
Vehicle care Changing tyre and wheel If the wheel covers and tyres used are not factory approved, the tyres must size not have a rim protection ridge. If tyres of a different size than those Wheel covers must not impair brake fitted at the factory are used, it may be cooling.
Page 211: Tyre Repair Kit
Vehicle care Tyre chains are only permitted on the Tyre damage exceeding 4 mm or that The tyre repair kit is in a compartment front wheels. is at tyre's sidewall cannot be repaired under the floor cover in the load with the tyre repair kit.
Page 212 Vehicle care 10. Set the rocker switch on the 4. Screw the compressor air hose to 6. Unscrew valve cap from defective compressor to I. The tyre is filled the connection on the sealant tyre. with sealant. bottle. 7. Screw the filler hose to the tyre 11.
Page 213 Vehicle care 14. Detach the tyre repair kit. Push catch on bracket to remove sealant bottle from bracket. Screw the tyre inflation hose to the free connection of the sealant bottle. This prevents sealant from escaping. Stow tyre repair kit in load compartment.
Page 214: Wheel Changing
Vehicle care Wheel changing Note ■ Never crawl under a jacked-up The driving characteristics of the vehicle. Some vehicles are equipped with repaired tyre are severely affected, ■ Do not start the vehicle when it is a tyre repair kit instead of a spare therefore have this tyre replaced.
Page 215 Vehicle care the wheel cover with the hook. 3. Ensure the jack is correctly Vehicle tools 3 205. positioned under the relevant vehicle jacking point. Alloy wheels: Disengage wheel nut caps with a screwdriver and 4. Variant 1: remove. To protect the wheel, place a soft cloth between the screwdriver and the alloy wheel.
Page 216 Vehicle care Attach wheel wrench and with the jack correctly aligned rotate wheel wrench until wheel is clear of the ground. 5. Unscrew the wheel nuts. 6. Change the wheel. 7. Screw on the wheel nuts. 8. Lower vehicle. 9. Install the wheel wrench ensuring that it locates securely and tighten each nut in a crosswise Set the jack to the necessary...
Page 217: Spare Wheel
Vehicle care Jacking position for lifting Caution platform The use of a spare wheel that is smaller than the other wheels or in combination with winter tyres could affect driveability. Have the defective tyre replaced as soon as possible. Front arm position of the lifting platform at the underbody.
Page 218 Vehicle care compartment after having changed 3. Place the hook end of the strap ■ Turn the wing nut anticlockwise and wheels, it needs to be secured with through the loop and pull it until remove temporary spare wheel and a strap, or, in the Sports tourer, with the strap is fastened securely to tool box.
Page 219 Vehicle care The floor cover can be placed on the Temporary spare wheel The following applies to tyres fitted projecting wheel. opposing the rolling direction: Caution Replace the long bolt before fitting the ■ Driveability may be affected. Have spare wheel in the well after renewing the defective tyre renewed or The use of a spare wheel that is or repairing the defective wheel.
Page 220: Jump Starting
Vehicle care Jump starting ■ A discharged battery can already ■ The vehicles must not come into freeze at a temperature of 0 °C. contact with each other during the Defrost the frozen battery before jump starting process. Do not start with quick charger. connecting jump leads.
Page 221: Towing
Vehicle care Towing 3. Connect the black lead to the 4. Switch on electrical consumers negative terminal of the booster (e.g. headlights, heated rear battery. window) of the vehicle receiving Towing the vehicle the jump start. 4. Connect the other end of the black lead to a vehicle grounding point, 5.
Page 222: Towing Another Vehicle
Vehicle care Towing another vehicle Caution Drive slowly. Do not drive jerkily. Excessive tractive force can damage the vehicle. When the engine is not running, considerably more force is needed to brake and steer. To prevent the entry of exhaust gases from the towing vehicle, switch on the air recirculation and close the Screw in the towing eye as far as it will...
Page 223: Appearance Care
Vehicle care Appearance care Caution Exterior care Drive slowly. Do not drive jerkily. Excessive tractive force can Locks damage the vehicle. The locks are lubricated at the factory After towing, unscrew the towing eye. using a high quality lock cylinder grease.
Page 224: Exterior Lights
Vehicle care If using a vehicle wash, comply with Thoroughly rinse and leather-off the Windows and windscreen wiper the vehicle wash manufacturer's vehicle. Rinse leather frequently. Use blades instructions. The windscreen wiper separate leathers for painted and Use a soft lint-free cloth or chamois and rear window wiper must be glass surfaces: remnants of wax on leather together with window cleaner...
Page 225: Interior Care
Vehicle care Clean rims with a pH-neutral wheel Liquid gas system Air shutter cleaner. Clean the shutter system in the front 9 Danger bumper to maintain correct Rims are painted and can be treated functionality. with the same agents as the body. Liquid gas is heavier than air and Paintwork damage can collect in sink points.
Page 226 Vehicle care Caution Close Velcro fasteners as open Velcro fasteners on clothing could damage seat upholstery. The same applies to clothing with sharp-edged objects, like zips or belts or studded jeans. Plastic and rubber parts Plastic and rubber parts can be cleaned with the same cleaner as used to clean the body.
Page 227: Service And Maintenance
Service and maintenance Service and General information Iceland, Ireland, Israel, Italy, Latvia, Lithuania, Luxembourg, Macedonia, maintenance Malta, Montenegro, Netherlands, Service information Norway, Poland, Portugal, Romania, In order to ensure economical and Slovakia, Slovenia, Spain, Sweden, safe vehicle operation and to Switzerland, United Kingdom.
Page 228: Recommended Fluids
Service and maintenance Recommended fluids, Make sure that the Service and aging control, whereas viscosity Warranty Booklet is completed grade gives information on the oil's lubricants and parts correctly as continuous proof of thickness over a temperature range. service is essential if any warranty or Dexos is the newest engine oil quality Recommended fluids and goodwill claims are to be met, and is...
Page 229 Service and maintenance Select the appropriate engine oil Coolant and antifreeze Over time, brake fluid absorbs based on its quality and on the moisture which will reduce braking Use only silicate-free long life coolant minimum ambient temperature effectiveness. The brake fluid should (LLC) antifreeze.
Page 230: Technical Data
Technical data Technical data Vehicle identification Identification plate Vehicle Identification Number Vehicle identification ....229 Vehicle data ....... 231 The identification plate is located on the front left door frame. The Vehicle Identification Number is visible through the windscreen.
Page 231 Technical data Information on identification label: Specifications in the vehicle documents always have priority over 1 = Manufacturer those given in this manual. 2 = Type approval number 3 = Vehicle Identification Number 4 = Permissible gross vehicle weight rating in kg 5 = Permissible gross train weight in kg 6 = Maximum permissible front axle...
Page 232: Vehicle Data
Technical data Vehicle data Recommended fluids and lubricants European service schedule Required engine oil quality All European countries (except Belarus, Moldova, Russia, Serbia, Turkey) Only Israel Engine oil quality Petrol engines Diesel engines Petrol engines Diesel engines (including CNG, LPG, E85) (including CNG, LPG, E85) dexos 1 –...
Page 233 Technical data International service schedule Required engine oil quality All countries outside Europe except Israel Only Belarus, Moldova, Russia, Serbia, Turkey Engine oil quality Petrol engines Diesel engines Petrol engines Diesel engines (including CNG, LPG, E85) (including CNG, LPG, E85) dexos 1 ✔...
Page 234 Technical data All countries outside Europe except Israel Only Belarus, Moldova, Russia, Serbia, Turkey Engine oil quality Petrol engines Diesel engines Petrol engines Diesel engines (including CNG, LPG, E85) (including CNG, LPG, E85) ACEA A3/B3 ✔ – ✔ – ACEA A3/B4 ✔...
Page 235: Engine Data
Technical data Engine data Sales designation 1.4 Engine identifier A14XEL A14XER A14NEL A14NET A16XER A16LET code Number of cylinders Piston 1398 1398 1364 1364 1598 1598 displacement [cm Engine power [kW] 64 at rpm 6000 6000 4200-6000 4900-6000 6000 5500 Torque [Nm] at rpm 4000...
Page 236 Technical data Sales designation 1.4 Engine identifier A14XEL A14XER A14NEL A14NET A16XER A16LET code possible Super Plus Super Plus Super Plus Super Plus Super Plus Super Plus schwefelfrei schwefelfrei schwefelfrei schwefelfrei schwefelfrei schwefelfrei (98) (98) (98) (98) (98) (98) possible Benzin Benzin Benzin...
Page 237 Technical data Sales designation Engine identifier code A13DTE A17DTE A17DTC A17DTF A17DTS at rpm 1750-3250 1750-2500 1750-2500 2000-2500 2000-2500 Fuel type Diesel Diesel Diesel Diesel Diesel Oil consumption [l/1000 km] Sales designation 2.0 Turbo Engine identifier code A17DTJ A17DTR A20DTH Number of cylinders Piston displacement [cm 1686...
Page 238 Technical data Performance 5-door hatchback Engine A14XEL A14XER A14NEL A14NET A16LET A16XER Maximum speed [mph] Manual transmission Automatic transmission – – – Engine A13DTE A17DTE A17DTC A17DTF A17DTS Maximum speed [mph] Manual transmission Automatic transmission – – – – – The maximum speed indicated is achievable at kerb weight (without driver) plus 200 kg payload.
Page 239 Technical data Engine A17DTJ A17DTR A20DTH Maximum speed [mph] Manual transmission Automatic transmission – – Sports tourer Engine A14XER A14NEL A14NET A16LET A16XER Maximum speed [mph] Manual transmission Automatic transmission – – Engine A13DTE A17DTJ A17DTR A20DTH Maximum speed [mph] Manual transmission Automatic transmission –...
Page 240: Vehicle Weight
Technical data Vehicle weight Kerb weight, basic model without any optional equipment 5-door hatchback Engine Manual transmission Automatic transmission without/with air conditioning A14XEL 1373/1388 – [kg] A14XER 1373/1388 – A14NEL 1393/1408 – A14NET 1393/1408 –/1453 A16LET –/1490 –/1503 A16XER 1393/1408 –/1443 A13DTE 1393/1408...
Page 241 Technical data 5-door hatchback Engine Manual transmission Automatic transmission without/with air conditioning A17DTE 1503/1518 – [kg] A17DTF 1503/1518 – A17DTJ 1503/1518 – A17DTR 1503/1518 – A17DTS 1503/1518 – A20DTH 1503/1518 –/1590 1503/1518 – A20DTH With stop-start function.
Page 242 Technical data Kerb weight, basic model with all optional equipment 5-door hatchback Engine Manual transmission Automatic transmission without/with air conditioning A14XEL –/1545 – [kg] A14XER –/1545 – A14NEL –/1611 – A14NET –/1611 –/1613 A16LET –/1613 –/1665 A16XER –/1578 –/1613 A13DTE –/1571 –...
Page 243 Technical data 5-door hatchback Engine Manual transmission Automatic transmission without/with air conditioning A17DTE –/1664 – [kg] A17DTF –/1664 – A17DTJ –/1684 – A17DTR –/1689 – A17 DTS –/1664 A20DTH –/1711 –/1731 –/1701 – A20DTH With stop-start function.
Page 244 Technical data Kerb weight, basic model without any optional equipment Sports tourer Engine Manual transmission Automatic transmission without/with air conditioning A14XER 1393/1408 – [kg] A14NEL 1471/1486 –/1503 A14NET 1437/1452 –/1503 A16LET –/1503 –/1550 A16XER 1437/1452 –/1503 A13DTE 1471/1486 – A17DTJ 1503/1518 –...
Page 245 Technical data Kerb weight, basic model with all optional equipment Sports tourer Engine Manual transmission Automatic transmission without/with air conditioning A14XER –/1571 – [kg] A14NEL –/1664 –/1664 A14NET –/1664 –/1664 A16LET –/1664 –/1701 A16XER –/1613 –/1664 A13DTE –/1664 – A17DTJ –/1733 –...
Page 246: Vehicle Dimensions
Technical data Vehicle dimensions 5-door hatchback Sports tourer Length [mm] 4419 4698 Width without exterior mirrors [mm] 1814 1814 Width with two exterior mirrors [mm] 2013 2013 Height (without antenna) [mm] 1510 1535 Length of load compartment floor [mm] 1069 Length of load compartment with folded rear seats [mm] 1549 1835...
Page 247 Technical data Capacities Engine oil Engine A14XEL, A14NEL, A16LET, A13DTE A14XER A14NET A16XER ecoFlex including Filter [l] between MIN and MAX [l] Engine A17DTE, A17DTF, A17DTJ, A20DTH A17DTC A17DTS A17DTR including Filter [l] between MIN and MAX [l] Fuel tank Petrol/diesel, nominal capacity [l] LPG, nominal capacity [l] –...
Page 248: Tyre Pressures
Technical data Tyre pressures Comfort with up to 3 people ECO with up to 3 people With full load Engine Tyres front rear front rear front rear [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] ([psi]) ([psi]) ([psi]) ([psi]) ([psi]) ([psi]) A14XER, 205/55 R16, 220/2.2 (32) 220/2.2 (32) 270/2.7 (39) 270/2.7 (39) 230/2.3 (33) 270/2.7 (39) A14XEL...
Page 249 Technical data Comfort with up to 3 people ECO with up to 3 people With full load Engine Tyres front rear front rear front rear [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] ([psi]) ([psi]) ([psi]) ([psi]) ([psi]) ([psi]) A16LET 205/65 R16, 230/2.3 (33) 230/2.3 (33) 270/2.7 (39) 270/2.7 (39) 240/2.4 (35) 280/2.8 (41) 10)9) 215/60 R16,...
Page 250 Technical data Comfort with up to 3 people ECO with up to 3 people With full load Engine Tyres front rear front rear front rear [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] ([psi]) ([psi]) ([psi]) ([psi]) ([psi]) ([psi]) A17DTE, 230/2.3 (33) 230/2.3 (33) 270/2.7 (39) 270/2.7 (39) 240/2.4 (35) 280/2.8 (41) 205/65 R16, 10)11) A17DTC,...
Page 251 Technical data Comfort with up to 3 people ECO with up to 3 people With full load Engine Tyres front rear front rear front rear [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] ([psi]) ([psi]) ([psi]) ([psi]) ([psi]) ([psi]) A17DTJ 205/65 R16, 230/2.3 (33) 230/2.3 (33) 270/2.7 (39) 270/2.7 (39) 240/2.4 (35) 280/2.8 (41) 10)9) 215/60 R16,...
Page 252 Technical data Comfort with up to 3 people ECO with up to 3 people With full load Engine Tyres front rear front rear front rear [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] ([psi]) ([psi]) ([psi]) ([psi]) ([psi]) ([psi]) A17DTR 205/65 R16, 230/2.3 (33) 230/2.3 (33) 270/2.7 (39) 270/2.7 (39) 240/2.4 (35) 280/2.8 (41) 10)9) 215/60 R16,...
Page 253 Technical data Comfort with up to 3 people ECO with up to 3 people With full load Engine Tyres front rear front rear front rear [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] [kPa/bar] ([psi]) ([psi]) ([psi]) ([psi]) ([psi]) ([psi]) A20DTH 205/65 R16, 230/2.3 (33) 230/2.3 (33) 270/2.7 (39) 270/2.7 (39) 240/2.4 (35) 280/2.8 (41) 10)9) 215/60 R16,...
Page 254 Technical data Towing hitch installation dimensions 5-door Hatchback...
Page 255 Technical data Sports Tourer...
Page 256: Customer Information
To read this data, special equipment and access to the vehicle is required. Some diagnostic data is electronically fed into Vauxhall global systems when the vehicle is serviced in a workshop, in order to document the...
Page 257 ■ to share summary data which is not vehicle transmitters for garage door tied to a specific vehicle with other openers. RFID technology in organisations for research Vauxhall vehicles does not use or purposes record personal information or link with any other Vauxhall system containing personal information.
Page 258 Customer information...
Page 259: Index
Index Accessories and vehicle Battery ........186 modifications ......181 Battery discharge protection ..135 Active head restraints....36 Battery voltage ......117 Adaptive forward lighting ... 108, 129 Bicycle rack........57 Adjustable air vents ....143 Bonnet ........183 Airbag and belt tensioners ..
Page 260 Climate control ......15 Electrical parking brake fault..105 Fixed air vents ......143 Climate control systems..... 137 Electrical system......198 Flex-Fix system......57 Clock..........96 Electronic climate control Fog light ........108 Code........... 114 system ........139 Fog lights ........192 Control indicators......
Page 261 Headlight flash ......128 Interior care ....... 224 Headlight range adjustment ..128 Interior lighting......133 Malfunction indicator light ..104 Headlights........126 Interior lights ...... 133, 198 Manual anti-dazzle ...... 29 Headlights when driving abroad 128 Interior mirrors......29 Manual mode ......
Page 262 Power outlets ....... 97 Sun visors ........32 Power steering......105 Symbols ......... 4 Safety net ........85 Power windows ......30 Seat adjustment ....... 6, 37 Preheating ......... 106 Seat belt ........8 Tachometer ......... 99 Puncture........213 Seat belt reminder ..... 103 Tail lights ........
Page 263 Tyre pressure ......206 Tyre pressure monitoring Warning chimes ......117 system......107, 207 Warning lights....... 98 Tyre pressures ......247 Warning triangle ......87 Tyre repair kit ......210 Washer and wiper systems ..14 Washer fluid ....... 185 Wheel changing ......

This manual is also suitable for:

2012 astra

Vauxhall Astra Owner's Manual

Vauxhall Astra

In Brief 11

Windows

Seats, Restraints 35 Seats, Restraints Head Restraints

Instruments and Controls Steering Wheel Controls Controls

Driving and Operating Driving Hints

Modifications

Quick Links

Chapters

Related Manuals for Vauxhall Astra

Summary of Contents for Vauxhall Astra
