Vauxhall Adam Quick Reference Manual

Vehicle features
Unlocking and opening the load Closing and locking the load Manual transmission:
compartment: compartment: Reverse gear:
Press button c on remote control Use interior handle to close With vehicle stationary, wait
once or twice (depending on tailgate. 3 seconds after depressing clutch
setting) to unlock the load pedal, press release button on the
Do not push the brand emblem on
compartment. selector lever and engage gear.
the tailgate whilst closing as this
Press the bottom half of the brand will unlock the tailgate again. If the gear does not engage, set the
emblem to unlock and open the lever to neutral, release the clutch
e
Press button on remote control to
tailgate. pedal and depress again; then
lock vehicle.
repeat gear selection.
Do not grind the clutch
unnecessarily.
When operating, depress clutch
pedal fully. Do not use the pedal as
a foot rest.
Starting the engine: Stop-Start system: Deactivate the Stop-Start system
Turn key to position 1 When conditions allow, the system manually by pressing the eco
switches off the engine to save fuel button in the centre console.
Move steering wheel slightly to
release steering wheel lock and reduce exhaust emissions if the
The LED in the button extinguishes
vehicle is at a low speed or at a
Depress clutch pedal
to confirm deactivation.
standstill, e.g. at traffic lights or in a
Do not accelerate
traffic jam. It restarts the engine
Turn key to position 3 and
when the clutch pedal is depressed.
release
To activate an Autostop:
An automatic procedure operates
Depress clutch pedal
the starter after a brief delay, until
Shift selector lever to neutral
the engine is running.
Release the clutch pedal
Before restarting, or to switch off
the engine, turn the key back to An Autostop is indicated by the
position 0. needle at the AUTOSTOP position
in the tachometer.
During an Autostop, the engine
can be restarted by depressing the To restart engine, select neutral
clutch pedal. then depress the clutch pedal.
Vehicle features
Parking brake: Opening the bonnet: To open completely, push the
To release parking brake, raise To open the bonnet, pull the safety catch to the right and open
lever slightly, press release button release lever located below the the bonnet.
and lower lever fully. instrument panel on the driver's
side.
Always apply parking brake firmly
without operating the release The bonnet will then be unlocked
button and apply as firmly as and will partially open. Return
possible on an uphill or downhill release lever to its original position.
slope.
To reduce the operating forces of
the parking brake, depress the
brake pedal at the same time.
For refuelling, fully insert the pump
nozzle and switch it on.
After the automatic cut-off, it can
be topped-up with a maximum two
doses of fuel.
Wipe off any overflowing fuel
immediately.
To close, replace fuel filler cap and
turn clockwise until it clicks.
Close the fuel filler flap and
engage.
Pull up bonnet support rod from its Refuelling:
holder and secure it in the hook on Before refuelling, switch off engine.
Fuel for petrol engines:
the underside of the bonnet, on the
Switch off any mobile phones.
Use unleaded fuel meeting
right-hand side.
Fuel filler flap is located at right
specifications of DIN EN 228 or
If the bonnet is opened during an
rear side of vehicle.
E DIN 51626-1.
Autostop, the engine will be
The fuel filler flap can only be
restarted automatically for safety Fuel tank capacity
opened when the vehicle is
reasons.
(all petrol models) - 35 litres.
unlocked.
Release the fuel filler flap by
Closing the bonnet:
pushing the flap, then open.
Replace the bonnet support rod in
its holder.
Turn fuel filler cap slowly
Lower the bonnet and allow it to anticlockwise and remove.
drop into the catch.
The fuel filler cap can be retained in
Check that the bonnet is engaged. the bracket on the fuel filler flap.
Vehicle features
Engine oil:
Check engine oil level manually on a regular basis to prevent damage to engine. Ensure that the correct
specification of oil is used.
Check with vehicle on a level surface. Engine must be at operating temperature and switched off for at least
5 minutes.
Pull out dipstick, wipe clean, insert to stop on the handle, pull out and read engine oil level.
When the engine oil level has dropped to the MIN mark, top up engine oil.
Insert dipstick to stop on handle and make half a turn.
Important:
It is the owner's responsibility to maintain the correct level of an appropriate quality oil in the engine.
Do not allow the engine oil level to drop below the minimum level!
Tyre pressure:
Check tyre pressures, including the spare, every 14 days and prior to any long journey; tyres should be
checked when cold. The tyre pressure data refers to cold tyres. It applies to summer and winter tyres.
Always inflate the spare tyre to the value specified for full load.
Incorrect tyre pressures will impair safety, vehicle handling, comfort and fuel economy and increase tyre
wear.
Warning:
If the pressure is too low, this can result in considerable tyre warm-up and internal damage, leading to tread
separation and even to tyre blow-out at high speeds.
Tyre pressure (psi) Tyre pressure (psi) Tyre pressure (psi)
Comfort setting for upto ECO setting for upto with Full load:
3 people: 3 people:
Engine Tyres Front Rear Engine Tyres Front Rear Engine Tyres
A12XEL 175/70 R14 29 26 A12XEL 175/70 R14 42 39 A12XEL 175/70 R14
185/65 R15 29 26 185/65 R15 39 36 185/65 R15
195/55 R16 29 26 195/55 R16 42 42 195/55 R16
215/45 R17 29 26 215/45 R17 39 36 215/45 R17
225/35 R18 29 26 225/35 R18 39 36 225/35 R18
A14XEL 175/70 R14 32 29 A14XEL 175/70 R14 42 39 A14XEL 175/70 R14
185/65 R15 32 29 185/65 R15 39 36 185/65 R15
195/55 R16 32 29 195/55 R16 42 42 195/55 R16
215/45 R17 32 29 215/45 R17 39 36 215/45 R17
225/35 R18 32 29 225/35 R18 39 36 225/35 R18
A14XER 175/70 R14 32 29 A14XER 175/70 R14 42 39 A14XER 175/70 R14
185/65 R15 32 29 185/65 R15 39 36 185/65 R15
195/55 R16 32 29 195/55 R16 42 42 195/55 R16
215/45 R17 32 29 215/45 R17 39 36 215/45 R17
225/35 R18 32 29 225/35 R18 39 36 225/35 R18
*KTA-2746*
Adam
Quick Reference Guide
Refer to Owner's Manual for detailed information. Depending on the model variant, special equipment
Illustrations may depict left-hand drive vehicles. and accessories, the scope of equipment on your
Operation is similar for right-hand drive vehicles. vehicle may differ from the descriptions in this guide.
10. Central locking system,
1. Power windows
Front Rear
2. Exterior mirrors fuel selector, seat heating,
3. Cruise control, speed limiter heated steering wheel,
38 46
4. Side air vents parking assist, Eco button for
38 46
stop-start system
5. Turn and lane-change signals,
38 46
headlight flash, 11. Info-Display
38 46 low beam, high beam, 12. Hazard warning flashers,
exit lighting, parking lights, control indicators for airbag
38 46
Driver Information Centre deactivation and front
buttons passenger seat belt
38 46
6. Instruments 13. Anti-theft alarm system LED
38 46
14. Centre air vents
7. Steering wheel controls
38 46 8. Driver Information Centre 15. Side air vents (passenger side)
9. Wipers and washers 16. Glovebox, fusebox
38 46
38 46
38 46
38 46
38 46
38 46
38 46
Locking the vehicle:
Unlocking the vehicle:
Press button c on remote control Close doors, load compartment
- or - turn key in driver's door lock and fuel filler flap.
towards the front of the vehicle to e
Press button on remote control
unlock the doors, load
- or - turn key in driver's door lock
compartment and fuel filler flap.
towards the rear to lock the vehicle.
KTA 2746
17. Climate control system
18. Power outlet
19. AUX input, USB input
20. Selector lever
21. Parking brake
22. Ignition switch
with steering wheel lock
23. Horn, driver airbag
24. Bonnet release lever
25. Steering wheel adjustment
26. Light switch,
headlight range adjustment,
rear fog light,
instrument illumination
Anti-theft alarm system:
The anti-theft alarm system is
combined with the central locking
system and monitors doors,
tailgate, bonnet and ignition.
Anti-theft locking system:
e
Press button twice on remote
control within 15 seconds to
deadlock all doors.
Do not use the system if there are
people in the vehicle! The doors
cannot be unlocked from the
inside.
Electronic immobiliser:
Activated automatically when key
is removed from ignition switch.
October 2012
