NTRODUCTION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
OBJECT AND LIQUID ENTRY - Never push objects of any kind into this TV through openings as they may touch dangerous voltage points or short out parts that could result in a fi re or electric shock. Never spill liquid of any kind on the TV. SERVICING - Do not attempt to service this TV yourself as opening or removing covers may expose you to dangerous voltage or other hazards.
NTRODUCTION LOCATION For safe operation and satisfactory performance of the unit, keep the following in mind when selecting a place for its installation: • Shield it from direct sunlight and keep it away from sources of intense heat. • Avoid dusty or humid places. •...
All rights reserved. No part of this manual may be reproduced, copied, transmitted, disseminated, transcribed, downloaded or stored in any storage medium, in any form or for any purpose without the express prior written consent of Funai. Furthermore, any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited.
NTRODUCTION Remote Control Function Installing the Batteries Install the batteries (AA x 2) matching the polarity indicated inside battery compartment of the remote control. Battery Precautions: • Be sure to follow the correct polarity as indicated in the battery compartment. Reversed batteries may cause damage to the device. •...
Control Panel SETUP VOLUME CHANNEL INPUT top of the unit Rear Panel rear of this unit VIDEO 2 COMPONENT AUDIO VIDEO 1 AUDIO S-VIDEO VIDEO COAXIAL SETUP button (p12) Press to display the main menu. VOLUME X / Y buttons (p13) Press to adjust the volume or move right( X )/left( Y ) through the main menu items.
ONNECTION Cables not included. Please purchase the necessary cables at your local store. Basic Connection This section describes how to connect the unit to an antenna, cable/satellite box, etc. Note: • Be sure your antenna or other device is connected properly before plugging in the power cord. [Antenna Cable Connection] When connecting the unit to an antenna or cable TV company (without cable/satellite box) Connect the RF coaxial cable on your home outlet to the antenna input jack of this unit.
Cables not included. Please purchase the necessary cables at your local store. External Device Connection [Component Video Cable Connection] Component video connection offers better picture quality for video devices connected to the unit. Use a component video cable to connect the unit to external video devices equipped with component video output jacks.
ONNECTION Cables not included. Please purchase the necessary cables at your local store. [Video Connection] Video connection offers standard picture quality for video devices connected to the unit. If you connect to the unit’s video input jack, connect RCA audio cables to the audio L/R jacks of VIDEO1. When the audio jack of the video device is monaural, connect the RCA audio cable to the audio L input jack.
NITIAL SETTING These operations are accessible by remote control. Some may also be accessible by controls on the main unit. Initial Setup This section will guide you through the unit’s initial setting which includes selecting a language for your on-screen menu and “AUTO PRESET CH”, which automatically scans and memorizes viewable channels.
NITIAL SETTING • BACK LIGHT You can set the desired brightness mode. (Refer to “Back Light Setting” on page 21.) • COLOR TEMP. You can adjust color temperature (“NORMAL”, “WARM”, “COOL”). (Refer to “Color Temperature” on page 21.) • DTVCC In addition to the basic closed caption described on page 18, DTV has its own closed caption called DTVCC.
ATCHING TV Channel Selection Select channels by pressing [CH. K /L] or [the Number buttons]. • To select the memorized channels, use [CH. K /L] or [the Number buttons]. • To select the non-memorized channels, use [the Number buttons]. To Use [the Number buttons] - When selecting analog channel 12 - When selecting digital channel 12-1 Be sure to press [–/ENT.] before entering the minor...
ATCHING TV Switching Each Mode You can easily switch with the remote control to the DTV (ATSC) and TV (NTSC) or to access an external device when they are connected to the unit. Press [INPUT] repeatedly to cycle through the input mode.
Screen Information You can display the currently selected channel or other information such as the audio mode on the TV screen. In the analog mode, the current channel number is displayed. Press [DISPLAY ]. • The current channel number is displayed at the top- right corner of the TV screen.
ATCHING TV TV Screen Display Mode 2 types of display modes can be selected in the digital mode when the broadcasting station is sending 16:9 video signal. Press [SCREEN MODE ] repeatedly to switch the TV aspect ratio. LETTERBOX [LETTERBOX] Display the digital-supported program in full-screen.
PTIONAL SETTING Channel Add/Delete The channel add/delete function lets you add the channel that was not added by the auto channel scan due to the reception status at the initial setting. You can also delete the unnecessary channels. Press [SETUP] to display the main menu. Use [Cursor K/L] to select “CHANNEL SETUP”, then press [ENTER].
PTIONAL SETTING Picture Adjustment You can adjust brightness, contrast, color, tint and sharpness. Press [SETUP] to display the main menu. Use [Cursor K /L] to select “PICTURE”, then press [ENTER]. e.g.) digital TV mode - TV SETUP - PICTURE CHANNEL SETUP V-CHIP SETUP LANGUAGE CAPTION...
Press [SETUP] to exit. Note: • To show the closed caption on your TV screen, broadcast signal must contain the closed caption data. • Not all TV programs and commercials have the closed caption or all types of the closed caption. •...
PTIONAL SETTING DTVCC Style You can change the style of DTV CC such as font, color or size, etc. Press [SETUP] to display the main menu. Use [Cursor K /L] to select “DTVCC“, then press [ENTER]. e.g.) digital TV mode - TV SETUP - PICTURE CHANNEL SETUP...
Back Light Setting You can set the desired brightness mode. Press [SETUP] to display the main menu. Use [Cursor K /L] to select “BACK LIGHT”, then press [ENTER] repeatedly to change the setting. e.g.) digital TV mode - TV SETUP - PICTURE CHANNEL SETUP V-CHIP SETUP...
PTIONAL SETTING V-chip V-chip reads the ratings for programs, then denies access to the programs which exceed the rating level you set. With this function, you can block certain programming inappropriate for children. Press [SETUP] to display the main menu. Use [Cursor K /L] to select “V-CHIP SETUP“, then press [ENTER].
Page 23
[To Set the Sub Ratings] As for TV-Y7, TV-PG, TV-14 or TV-MA, you can further set the sub ratings to block specific elements of programming. To set the sub ratings, follow the steps below. Use [Cursor K /L ] to select the desired main rating, then press [ENTER] twice to show its sub ratings.
PTIONAL SETTING C. Change Password C. Change Password Although the default code “0000” is supplied with the unit, you can set your own password. Use [Cursor K /L] to select “CHANGE PASSWORD”, then press [ENTER]. e.g.) digital TV mode - V - CHIP SETUP - TV RATING MPAA RATING DOWNLOADABLE RATING...
ROUBLESHOOTING Troubleshooting Guide If the unit does not perform properly when operated as instructed in this owner's manual, check the following chart once before calling for service. Symptom Remedy No power • Be sure the power cord is plugged in. •...
ROUBLESHOOTING Symptom The entered channel number changes automatically Remote control does not work Misspelled captions are displayed. Captions are not entirely displayed, or captions are delayed behind the dialogue. Captions are displayed as a white box. No caption is displayed in the closed caption-supported program.
NFORMATION Glossary ATSC Acronym that stands for Advanced Television Systems Committee and the name of the digital broadcasting standards. Aspect Ratio The width of a TV screen relative to its height. Conventional TVs are 4:3 (in other words, the TV screen is almost square); widescreen models are 16:9 (the TV screen is almost twice as wide as its height).
FUNAI CORP. will repair this product, free of charge in the USA in the event of defect in materials or workmanship as follows: DURATION: PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date of original retail purchase.
