- Page 1 Universal Remote Control User’s Guide (North America Edition) v2.56 for URC 4...
- Page 2 For Customer Support please call: 650.572.7000 Entone, Inc. 20863 Stevens, Creek Blvd Suite 300, Cupertino, CA 95014 U.S.A. Tel: 650.572.7000 v2.56 for URC 4...
-
Page 3: Table Of Contents
Auto Search Procedures ..............................13 Appendix A – Device Code ..............................15 Appendix B – Other Features ............................... 25 Showing URC 4 Firmware Version..........................25 Showing Programmed Device Code ..........................25 Copyright © © © © Entone, Inc. All rights reserved 2012 v2.5 for URC 4... - Page 4 The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. Copyright © © © © 2012 Entone, Inc. All rights reserved v2.5 for URC 4...
-
Page 5: Loading Batteries
A/V devices such as TV, DVD player and audio equipment using IR. There are two types of Entone URC 4: IR only (IR URC) and IR+RF (RF URC). IR URC is included in the package of Janus/Amulet while RF URC is included in Entone Second Stream Kit. -
Page 6: Controlling Stb Using Rf Urc
One RF URC 4 can only be registered to one output. However, you can register at most 3 RF URC 4 to an output. After registration, you need to use the corresponding RF URC 4 to control the outputs. - Page 7 The registration list is maintained in order. If the secondly registered RF URC 4 is removed from the list, the third entry will move forth to the second and the third will be blank for a new RF URC 4 to be registered.
- Page 8 URC 4 User’s Guide Connect the Entone STB to the TV coax network wall outlet according to whether you are using an Entone Janus or Amulet STB. The rear panel of actual product may vary. 1. Janus without Tuner Connection: Connect the Janus “MATV” or “TV OUT” output to the TV coax network as shown.
-
Page 9: Rf Urc Registration
“Toggle Power Key Punch-through Functionality” in Chapter 4 for details. The Volume +/- and MUTE key can be configured to control both the STB and TV while the URC 4 is in “STB” mode, please refer to the section “Toggle Volume Key Punch-through Functionality” in Chapter 4 for details. - Page 10 2. On the URC 4, press “STB” once again. Both the “STB” and “AUX” button backlight will illuminate. 3. Press “0” to set RF URC 4 to IR mode only. The RF URC 4 will not send any RF signal.
-
Page 11: Ir Reception Range
IR signals travel only short distances (40 feet or less), and cannot go through walls or other solid objects. You must point the URC 4 to the STB, with no objects blocking the line of sight. Figure 3-4 IR Reception Range Copyright ©... -
Page 12: Toggle Power Key Punch-Through Functionality
“Toggle Power Key Punch-through Functionality” in Chapter 4 for details. The Volume +/- and MUTE key can be configured to control both the STB and TV while the URC 4 is in “STB” mode, please refer to the section “Toggle Volume Key Punch-through Functionality” in Chapter 4 for details. -
Page 13: Auto Search Procedures
1. Press and Hold STB for 5 seconds, then STB led will switch on. 2. Press STB key once again, then both STB and AUX led will switch on. 3. Press 0 Copyright © © © © 2012 Entone, Inc. All rights reserved v2.5 for URC 4... -
Page 14: Toggle Channel Up/Down Keys For Tv/Aux
NOTE: In this search mode, the remote control will send IR codes from the library starting from the lowest code set number to the end of code set for that device; OR Copyright © © © © 2012 Entone, Inc. All rights reserved v2.5 for URC 4... - Page 15 NOTE: In the programming mode if no key is received within 30s, the device mode key backlight will blink rapidly for 7 times to indicate an error and then extinguish, and the programming mode will end. Copyright © © © © 2012 Entone, Inc. All rights reserved v2.5 for URC 4...
-
Page 16: Device Code
URC 4 User’s Guide Your URC 4 can control many brands and models of television, VCR, DVD and other types of audio-visual equipment. The following pages list device codes for many categories and brands of equipment. Many brands list more than one code, and you may need to test several codes to find the best match for your equipment. - Page 17 0097 Vision TV - Plasma TV Monitor Action Dimensia 0017 Akai 0170 Amtron 0182 Dumont 0286, 0308 Fujitsu 0252, 0049, 0260, Anam 0097 0186, 0257 Copyright © © © © 2012 Entone, Inc. All rights reserved v2.5 for URC 4...
- Page 18 JC Penney 0017, 0239, 0221, 0196, 0190, 0176, Signature 0223 0308 0029, 0075 Sony 0153, 0243, 0072, 0153 Penney 0245, 0030 0154, 0302, 0305, Jensen 0308 0037, 0169 Copyright © © © © 2012 Entone, Inc. All rights reserved v2.5 for URC 4...
- Page 19 TV - TV/DVD/Tuner Combo Audio 3024 Apex 0264 Panasonic 0176 Dynamics Audiovox 0150 Sony 0126 Audiovox 3043 Broksonic 0046, 0199 Beaumark 3052 Coby 0306 Cytron 0220 Copyright © © © © 2012 Entone, Inc. All rights reserved v2.5 for URC 4...
- Page 20 3052 Harley 3062, 3091 Technology Ricoh 3026 Davidson Microsoft 3053 Runco 3073 Harman/Kar 3024 Mind 3053 Samsung 3052, 3048, 3012 Mitsubishi 3031, 3019 Sanky 3073 Copyright © © © © 2012 Entone, Inc. All rights reserved v2.5 for URC 4...
- Page 21 3072, 3029 Sony 3091 Voodoo 3053 Sylvania 3063, 3032 Symphonic 3091 Wards 3052, 3043, 3021, Symphonic 3063 Thomas 3091 3062 Toshiba 3006, 3045 Zenith 3091, 3022 Copyright © © © © 2012 Entone, Inc. All rights reserved v2.5 for URC 4...
- Page 22 Funai 4049, 4181, 4208 Techwood 4137 4081, 4222, 4091, 4224, 4111 4200, 4038, 4143, Theta Digital 4117 Go Video 4072 4080, 4044, 4013 Goldstar 4162 Copyright © © © © 2012 Entone, Inc. All rights reserved v2.5 for URC 4...
- Page 23 Panasonic 4080 Denon 4047 Zenith 4018, 4122, 4170 Polaroid 4102 Emerson 4079 DVD - DVD-DVR 4185 Insignia 4121 4004, 4113, 4128, Samsung 4241 4221 4196 Copyright © © © © 2012 Entone, Inc. All rights reserved v2.5 for URC 4...
- Page 24 BOSE 2032 Pioneer 2070 2007, 2051, 2066 CambridgeS 2053 AUDIO - LCD TV/Tuner Combo Philips 2085, 2096, 2047 oundWorks Polaroid 2028 Classic 2009 Coby 2045 Copyright © © © © 2012 Entone, Inc. All rights reserved v2.5 for URC 4...
- Page 25 2071 McIntosh 4265 BOSE 4269 Sharp 2001 Nakamichi 4271 Sherwood 2015 Panasonic 4254 Onkyo 4257, 4278 Sony 2101, 2025, 2025, 2025, 2005 Panasonic 4254, 4264 Copyright © © © © 2012 Entone, Inc. All rights reserved v2.5 for URC 4...
- Page 26 URC 4 User’s Guide The URC 4 firmware version is in the format of x.y.z, where x, y and z is digit 0-9. Use the following procedures to show the URC 4 firmware version: 1. Press “STB” and hold for 5s. The “STB” backlight will illuminate.
