Disassembly Procedure

Please follow the information provided in this section to perform the complete
disassembly procedure of the notebook. Be sure to use proper tools
described before.
A
SUS Z9200K Series Notebook consists of various modules. This chapter describes the
procedures for the complete notebook disassembly. In addition, in between procedures,
the detailed disassembly procedure of individual modules will be provided for your
service needs.
The disassembly procedure consists of the following steps:
• Battery Module
• Memory Module
• Wireless LAN Module
• HDD Module
• ODD Module
• Keyboard
• LCD Module
• Top Case Module
• Main Board Module
• Modem Module
• CPU/Heat Sink Module
Disassembly Procedure
2 – 1
2
C apter

Advertisement

Table of Contents
loading

Related Manuals for Asus Z9200K Series

Summary of Contents for Asus Z9200K Series

  • Page 1: Disassembly Procedure

    Be sure to use proper tools described before. SUS Z9200K Series Notebook consists of various modules. This chapter describes the procedures for the complete notebook disassembly. In addition, in between procedures, the detailed disassembly procedure of individual modules will be provided for your service needs.

  • Page 2: Battery Module

    Memory Module S E C O N D The Z9200K Series Notebook do not have onboard RAM. There are two SO-DIMM M E M O R Y sockets for installing SO-DIMM RAM. It can upgrade the total memory size up to 2GB M O D U L E with a 512MB module on each socket.

  • Page 3: Wireless Lan Module

    Disassembly Procedure 2. Take the memory DIMM cover away as the picture shows. Wireless Lan Module W I R E L E S S L A N M O D U L E The illustration below show show how to remove the Wireless LAN module Disassembling Wireless Lan board R E M O V A L 1.

  • Page 4: Hdd Module

    Disassembly Procedure HDD Module H D D The illustrations below show how to remove the HDD module from the notebook. M O D U L E Removing HDD Module H D D 1. Remove 1 screw and lift the HDD cover away. M O D U L E R E M O V A L 2.

  • Page 5: Odd Module

    Disassembly Procedure ODD Module O P T I C A L 1. Remove 2 screws. D R I V E R E M O V A L 2. Remove the Mylar. 3. Push the metal plate with a screw driver and pull the ODD out. 2 - 5...

  • Page 6: Cpu Module

    Disassembly Procedure CPU Module C P U M O D U L E The illustrations below show how to remove the CPU module from the notebook. R E M O V A L Removing CPU C P U 1. Remove the rubber. R E M O V A L 2.

  • Page 7: Lcd Module

    Disassembly Procedure LCD Module L C D The illustrations below show how to disassemble the LCD module. The module M O D U L E contains LCD panel, Inverter board, LCD Hinge bracket, Hinge cover, LCD front cover, LCD back cover Disassembling LCD Module L C D 1.
  • Page 8 Disassembly Procedure 4. Remove 1 screw and disconnect the connector. 5. Remove 1 screw and disconnect the connector. 6. Remove 2 screws on both ends. 2 - 8...
  • Page 9 Disassembly Procedure 7. Remove the LCD module from system. Disassembling LCD Module L C D 1. Remove 5 rubber pads and 5 screws(M2.5 x 8L) from LCD module. D I S A S S E M B L Y 2. Prying the inside edges of the bezel, then separate it from LCD back cover and take LCD front bezel away.
  • Page 10 Disassembly Procedure Disassembling inverter board 3. Remove 1tape and disconnect 2 cables. 4. Take away the inverter board. Disassembling LCD panel 1. Remove 10 screws and take away the LCD panel. 2 - 10...
  • Page 11 Disassembly Procedure 2. Finally, Remove 4 screws on the right LCD bracket , and 4 screws on the left side to disassemble LCD brackets. 3. Remove one tape and disconnect the cable. 2 - 11...
  • Page 12 Disassembly Procedure Disassembling speaker 1. Tear of the tape and disconnect the cable from Video Camera module. 2. Disconnect the cable. 3. Remove all tapes. 4. Remove 4 screws and take away the both cable. 2 - 12...

  • Page 13: Keyboard Module

    Disassembly Procedure 5. Take away the both cable. Keyboard Module K E Y B O A R D The illustration of below shows how to remove the keyboard Removing Keyboard Cover D I S A S S E M B L Y 1.

  • Page 14: Main Board Module

    Disassembly Procedure Main Board Module The illustrations below show how to disassemble and remove the Main Board module of the notebook. Removing Top Case Disconnect the Touchpad cable. Turn over the NB and remove all screws on bottom case. Remove 2 screws here. 2 - 14...
  • Page 15 Disassembly Procedure Remove 1 screw on Top case. Separate the Top Case and Bottom case. Removing Touchpad bracket 1. Disconnect the Touchpad cable. 2 - 15...
  • Page 16 Disassembly Procedure 2. Remove All screws and take away the bracket 3. Take away the Touchpad. Disassembling Speaker Module 1. Disconnect the speaker cable. 2 - 16...
  • Page 17 Disassembly Procedure 2. Remove right side and left side 2 screws then take away the both speaker. Removing Main Board 1. Remove 4 screws on the M/B and remove the M/B from the bottom case. Removing Modem board 1. Remove 2 screws and disconnect the cable. 2 - 17...

  • Page 18: Heat Sink Module

    Disassembly Procedure 2. Take away the modem board. 3. Disconnect the cable. Heat Sink Module H E A T S I N K M O D U L E The illustrations below show how to remove the CPU module from the notebook. R E M O V A L Removing Heat sink H E A T...
