Alpine NVD-A211 SMART MAP PRO Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ALPINE ELECTRONICS MARKETING, INC.
Shinagawa-ku, Tokyo 141-0031, Japan
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
Phone 1-800-ALPINE-1 (1-800-257-4631)
1-888-NAV-HELP (1-888-628-4357)
ALPINE ELECTRONICS OF CANADA, INC.
7300 Warden Ave., Suite 203, Markham,
Phone 1-800-ALPINE-1 (1-800-257-4631)
1-888-NAV-HELP (1-888-628-4357)
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
6-8 Fiveways Boulevarde Keysborough,
ALPINE ELECTRONICS GmbH
ALPINE ELECTRONICS OF U.K. LTD.
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue de la Belle Etoile, Z.I. Paris Nord Il,
B.P. 50016, 95945 Roissy Charles de Gaulle Cedex,
Viale C. Colombo 8, 20090 Trezzano
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
© 2002 Navigation Technologies. All Rights Reserved.
Interstate Exit and Service Data provided by
Copyright © 2002, All Rights Reserved.
Certain business data provided by infoUSA, Inc.,
Omaha, Nebraska, Copyright © 2002, All Rights Reserved.
Yamagata Printing Co.,
Designed by ALPINE Japan
Ltd.
2-6-34, Takashima,
Nishi-ku, Yokohama,
Kanagawa, Japan
R
1-1-8 Nishi Gotanda,
Phone 03-5496-8231
California 90501, U.S.A.
Ontario L3R 9Z6, Canada
Victoria 3173, Australia
Phone 03-9769-0000
Kreuzerkamp 7,
40878 Ratingen, Germany
Phone 02102-4550
Alpine House
Fletchamstead Highway,
Coventry CV4 9TW, U.K.
Phone 0870-33 33 763
France
Phone 01-48638989
ALPINE ITALIA S.p.A.
Sul Naviglio (MI), Italy
Phone 02-484781
Phone 945-283588
ZENRIN CO.,LTD.
Printed in Japan (Y)
68P70033Y02-O
NVD-A211
SMART MAP PRO
Prog. Ver. 2.00
OWNER'S MANUAL
Please read before using this DVD-ROM.
R R

Advertisement

Table of Contents
loading

Related Manuals for Alpine NVD-A211 SMART MAP PRO

Summary of Contents for Alpine NVD-A211 SMART MAP PRO

  • Page 1 ALPINE ELECTRONICS OF CANADA, INC. 7300 Warden Ave., Suite 203, Markham, Ontario L3R 9Z6, Canada Phone 1-800-ALPINE-1 (1-800-257-4631) 1-888-NAV-HELP (1-888-628-4357) ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 6-8 Fiveways Boulevarde Keysborough, Victoria 3173, Australia Phone 03-9769-0000 ALPINE ELECTRONICS GmbH Kreuzerkamp 7,...

  • Page 4: Important Information

    The right to use the Disk and Database shall expire either when the user destroys this software, or when any of the terms for use is violated and Aisin AW, Alpine and/ or NavTech exercises the option to revoke the license to use this software.
  • Page 5 If there is anything in the manual about the operation of the navigation system which you are uncertain about, please contact your local Alpine authorized navigation dealer or Alpine at 1-888-NAV-HELP (1-888-628-4357) before using the...
  • Page 6 • Read this manual carefully before using this DVD-ROM. It contains instructions on how to use this product in a safe and effective manner. Alpine cannot be responsible for problems resulting from failure to observe the instructions in this manual.
  • Page 7 Doing so may result in injury or damage to the product. Caution HALT USE IMMEDIATELY IF A PROBLEM APPEARS Failure to do so may cause injury or damages to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service Station for repairing.

  • Page 8: Table Of Contents

    ABLE OF ONTENTS Precautions ....................ii - V Preface System Features, System Enhancements, Navigation Terminology and Remote Control Reference Guide ..............2 - 5 Before Using the System Installing New Navigation System Software ..............6 How to use the Disc ....................7 Operation Basic Operation ....................
  • Page 9 Setting the GPS clock ..................70 - 71 Recalibration for new vehicle or tires .................72 Direction adjustment ....................73 Screen position adjustment ..................74 Information/Guidance Menu Connection check for peripherals ................75 Navigation Simulation ....................76 Viewing GPS Information ..................77 Viewing Trip Information ....................78 Viewing Software Information ..................79 Using the Detour function ..................80 Using the Plan function .....................81...

  • Page 10: Preface

    REFACE System Features Automatic Route Calculation The navigation system displays and tracks your vehicle's position and movement via a moving map display. When you input a destination, the navigation system quickly calculates a route and guides you with pictorial displays and voice prompts. When determining the route, the system can be programmed to minimize the use of toll roads and freeways.
  • Page 11 System Enhancements Overall Improved System Response Time Faster screen transitions and route calculations. Faster Input Using Smart Key Filtering By displaying only the characters necessary to complete your destination input, jumping over unnecessary letters is kept to a minimum. Input Destination by Phone Number By entering a POI by phone number, routing or calling and routing.
  • Page 12 Navigation Terminology Present Vehicle Position Indicator Present vehicle position The present vehicle position is indicated by an arrowhead within a circle. Map Matching Since GPS has an error window of about 100 - 650 feet (30 m - 200 m), the position of the vehicle may be calculated in such a way that it is displayed incorrectly off the road.
  • Page 13 After pressing the MODE button, the Up and North Up orientation. (See following buttons will be pressed page 64.) a The Alpine Head Unit can be while the status indicator is blinking: operated with the remote control. numerals (0-9), DEL.,and OK.

  • Page 14: Before Using The System

    EFORE SING YSTEM Installing New Navigation System Software If a different version of the map disc has been used with your navigation system, the operating system program installed will be rewritten automatically to read this SMART MAP PRO disc. Remove the different version of the map disc from your navigation system.

  • Page 15: How To Use The Disc

    How to use the Disc There are two discs available for NVD-A211: the EAST version, and the WEST version. Phone number/POI (Point of Interest) information, etc., contained in the West area disc cannot be searched by the East disc, and vice versa. Places in the West area, for example, can only be found on the West disc.

  • Page 16: Operation

    PERATION Basic Operation The following example briefly describes how to use the Alpine Advanced Route Guidance Navigation System. The opening screen will appear once the navigation system is turned on. (If a CVA-1003/CVA-1004/CVA-1005/CVA- 1006/IVA-C800/IVA-C801/IVA-D900 type system control monitor is used, you may not see this screen.)
  • Page 17 The Find Point of Interest by menu appears. Use the joystick to select a ENTER method to find the point of interest. (In this example, "Place Type" is being selected. Place Type The place type list appears. Move the joystick up or down to select the desired place type, then press ENTER.
  • Page 18 Basic Operation (continued) The characters selected are displayed in the text window. a. Text window Displays the selected characters. b. AREA Selects areas other than the current-vehicle-position area. c. LIST Displays a list of the candidate names for the selected characters. d.
  • Page 19 The Select City screen appears. Use the joystick to enter a city name and scroll down to select that city. Press ENTER ENTER when finished. LOS ANGELES, CA The Input Place Name screen appears. Once you have entered a few characters, select LIST at the top of the character pallet and press ENTER.

  • Page 20: Basic Operation

    Basic Operation (continued) The navigation system quickly calculates the route to the desired destination. The map screen shows your current vehicle position and a highlighted route. Once you begin to drive on the highlighted route, the system will guide you to the destination using on-screen maneuver directions and voice prompts.

  • Page 21: Switching The Display On/Off

    Try reloading the DVD-ROM correctly. If the message does not disappear, contact your local Alpine navigation dealer. a If the navigation system display is kept on with the engine off for an extended period of time, the vehicle's battery may discharge.

  • Page 22: Switching Between Split Screen Display And Detailed Map Display

    Switching between Split Screen Display and Detailed Map Display Once the route has been calculated and driving begins, the navigation system will guide the driver, turn-by-turn, to the destination. Real time voice directions and map displays aid the driver throughout the entire route. The type of display that appears during your trip can be selected according to your preference.
  • Page 23 During navigation, when your vehicle approaches a major intersection, the Zoomed Major Intersection Map of that intersection is displayed. This enlarged Major Intersection Map gives you additional informa- tion to complement the voice guidance. (This enlarged major intersection map may be displayed even when no turns are necessary.) Zoomed Major Intersection Map Display This shows the remaining distance to...

  • Page 24: Manual Backup

    Manual backup The navigation system will automatically back up (save) your new settings (for example, address book settings etc.) when the ignition switch is turned off and turned on again. If the battery leads should be disconnected from the vehicle's battery, be sure to manually back up your new settings before disconnect- ing the battery leads as described below.
  • Page 25 The disclaimer screen appears. After you have read this important information, press ENTER the ENTER button. The map screen will appear and all of your information will be successfully stored in backup memory.

  • Page 26: Destination Menu

    ESTINATION Entering a destination by Address This section describes how to input your destination in the form of an address. The destination can be input in one of eight different ways: by an address, an intersection, a point of interest, a location's phone number, a recent destination, the personal address book, "Today's Plan"...
  • Page 27 The Input City Name screen is displayed. Use the joystick to select the first character of the city name and press ENTER. The ENTER selected character appears in the text window. When 1 character is input, the candidates for the next character are narrowed down (and the others disappear from the ENTER character pallet).

  • Page 28: Entering A Destination By Address

    Entering a destination by Address (continued) The Select Street Name screen appears. Use the joystick to enter a street name and scroll down to select that street. Press ENTER ENTER when finished. GRAND ENTER The Input Address Number screen appears. Enter the house or building number for the destination by using the ENTER joystick and pressing ENTER after each...

  • Page 29: Entering A Destination Using A Major Intersection

    Entering a destination using a Major Intersection If you know an intersection near where you want to go, you can input two cross streets as your destination. This section describes how to input a destination by entering two cross street names. Press the MENU button to display the main MENU menu bar.
  • Page 30 Entering a destination using a Major Intersection (continued) The Input Street Name screen is displayed. Enter the street name in the same manner ENTER as Step 3. Upon completing character input, select LIST at the top of the character pallet and LIST press ENTER.
  • Page 31 The Confirm Destination screen is OK to Proceed displayed. If the specified cross streets are correct, select OK to Proceed and press ENTER. The system will start to calculate ENTER the route. Note: If you wish to add this entry to Today's Plan, select Add to Today's Plan (see page 37).

  • Page 32: Entering A Point Of Interest By Place Name

    Entering a Point of Interest by Place Name The navigation system allows you to enter a Point of Interest in one of three ways. This can either be by place name, place type or phone number. Press the MENU button to display the main MENU menu bar.
  • Page 33 The Confirm Destination screen appears. OK to Proceed If the destination is correct, select OK to Proceed and press ENTER. The system starts calculating a route to the destination. ENTER Note: If you wish to add this entry to Today's Plan, select Add to Today's Plan (see page 37).

  • Page 34: Entering A Point Of Interest By Place Type

    Entering a Point of Interest by Place Type If you know the type of place you are headed to, you can search for a destination by place type by selecting from a list of categories. The following example shows how to select the shopping center, "Triangle Square"...
  • Page 35 This will display the Find Point of Interest by menu. Select "City Name" from the "Find Point of Interest by" menu and press ENTER ENTER. (In this example, "City Name" is being selected.) City Name When "Sorted by distance" is selected, the list showing the place names for the selected place type is shown in order of ENTER...
  • Page 36 Entering a Point of Interest by Place Type (continued) The Input Place Name screen is displayed. Use the joystick to select the first character of the place name and press ENTER. The ENTER selected character appears in the text window. ENTER The Select Place Name screen appears.

  • Page 37: Entering A Point Of Interest By Phone Number

    Entering a Point of Interest by Phone Number If you know the phone number of the Point of Interest you are headed to, use this function to find the address for the destination. Press the MENU button to display the main MENU menu bar.

  • Page 38: Entering A Point Of Interest By Phone Number

    Entering a Point of Interest by Phone Number (Continued) The Confirm Destination screen appears OK to Proceed showing the address of the selected destination. If it is correct, select OK to Proceed and press ENTER. The system ENTER starts calculating a route to the destination. Note: If you wish to add this entry to Today's Plan, select Add to Today's Plan (see page 37).

  • Page 39: Entering A Point Of Interest By Latitude And Longitude

    Entering a Point of Interest by Latitude and Longitude If you know the latitude and longitude of the desired location, you can display that location by just inputting those numbers. Press the MENU button to display the main MENU menu bar. Select Dest. and press ENTER. The Find Destination by menu appears.

  • Page 40: Entering A Destination By Recent Destination

    Entering a destination by Recent Destination If your destination is one of the twenty most recent route calculations, you can recall that destination using the procedure described in this section. Press the MENU button to display the main MENU menu bar. Select Dest. and press ENTER. The Find Destination by menu Dest.

  • Page 41: Entering A Destination Using The Address Book

    Entering a destination using the Address Book If a location has already been placed into your personal address book, you can recall this location for use as a destination. The Address Book holds up to 99 different addresses and phone numbers. For more information on how to store locations in the address book, see page 36.

  • Page 42: Entering A Destination Directly From The Map Display

    Entering a destination directly from the Map Display This feature allows quick and easy selection of a new destination directly from a street segment or Point of Interest icon on the Detailed Map Display. By selecting a street segment or icon, you can quickly enter a destination without the need to input the city name, street, etc.

  • Page 43: Entering A Destination By Origin Of The Route

    Entering a destination by Origin of the Route The navigation system can guide you to the starting point of your last calculated route. This is very convenient when setting a return route. Press the MENU button to display the main MENU menu bar.

  • Page 44: Saving A Destination Into The Address Book

    Saving a destination into the Address Book Up to 99 addresses can be stored alphabetically in the Address Book. Whenever a destination is selected and Option Menu entered, the system allows you to save the address. Select Option Menu and press ENTER.

  • Page 45: Adding A Destination Into Today's Plan

    Adding a destination into Today's Plan Today's Plan will calculate the most efficient travel order for multiple destinations. Up to 8 destinations can be stored in "Today's Plan." This section describes how to add a destination into "Today's Plan." Whenever a destination is selected and Add to Today's Plan entered by any method, the Confirm Destination screen is displayed.

  • Page 46: Using The Today's Plan Function

    Using the Today's Plan Function Today's Plan will calculate the most efficient travel order for multiple destinations. Up to 8 destinations can be stored in "Today's Plan." This function has two settings, Auto and Manual. Manual will route you to each destination in the order which they were entered. Auto will route you to each destination in the most efficient travel order.
  • Page 47 The system calculates the new destination OK to Proceed order and displays the confirmation screen. If the new destination is acceptable, select OK to Proceed and press ENTER. If you ENTER want to change the destination again, repeat Steps 2 to 3 above. If you would prefer to determine the order of the destinations yourself, you may select Manual from the Today's Plan screen in the Route Options for Today's Plan calculation.

  • Page 48: Setting Waypoints

    Setting Waypoints You can set up to 5 waypoints from your current location to the current destination. Set these points before selecting OK from the Confirm Destination screen. Whenever a destination is selected and Option Menu entered, the system allows you to save the address as a waypoint.

  • Page 49: Searching For Local Places

    Searching for local places The navigation system can display up to eight types of Points of Interest in an area six miles around the cursor position when you scroll the map. These include ATMs, Banks, Gas Stations, Grocery Stores, Hotels, Parking Lots, Restaurants and Highway Exit with IA Data. You can search for such a desired destination using the Find Local Places function.

  • Page 50: Searching For Local Places

    Searching for local places (continued) The address of the selected destination OK to Proceed appears in the Confirm Destination screen. If it is correct, select OK to Pro- ceed and press ENTER. The system starts ENTER calculating a route to the destination. Note: If you wish to add this entry to Today's Plan, select Add to Today's Plan (see page 37).

  • Page 51: Searching For Exit Information Places

    Searching for Exit Information places You can search IA items (facilities) around the highway exit with IA data only by selecting an EXIT icon on the map. To use this function, you have to set the Exit Information to make it effective. For details, refer to “Setting Point of Interest icon options”...

  • Page 52: Setup/Editing Menu Address Book Editing

    ETUP DITING Address Book editing Locations that are saved in the Address Book can be named for easy recall. Destinations saved in the Address Book can be modified to include its phone number and perform special functions called "Beep Points" and "Avoid Points." See the diagram below and the following pages for descriptions of these functions.

  • Page 53: Address Book Editing (Name Editing)

    Address Book editing (Name Editing) See page 44 for steps 1 and 2. Select an entry you would like to modify or delete and press ENTER. (In this example, E MONLACO RD is ENTER chosen.) ENTER Select the name and press ENTER. ENTER ENTER The Input Name for Address Book screen...

  • Page 54: Address Book Editing (Phone Number Editing)

    Address Book editing (Phone Number Editing) See page 44 for steps 1 and 2. Select an entry you would like to modify or delete and press ENTER. (In this example, ALPINE ELECTRONICS, ENTER INC. is chosen.) ENTER Select Tel. and press ENTER.

  • Page 55: Address Book Editing (Special Settings)

    Address Book editing (Special Settings) See page 44 for steps 1 and 2. Select an entry you would like to modify or delete and press ENTER. (In this example, MAY GARDEN is chosen.) ENTER ENTER Select Sp. and press ENTER. ENTER ENTER The Special Setting screen appears.

  • Page 56: Address Book Editing (Special Settings)

    Address Book editing (Special Settings) (continued) The special use setting list is displayed. Press ENTER. ENTER The memory editing list is displayed.

  • Page 57: Recent Route Editing

    Recent Route editing Whenever a route is calculated, the address of the destination is stored into the Recent Route list. The list holds the twenty most recently calculated destinations. Any or all of the twenty previous destinations can be deleted from this list. From any mode, press the MENU button to MENU display the main menu bar.

  • Page 58: Today's Plan Editing

    Today's Plan editing If you wish to delete a destination from Today's Plan, you may use this feature in the Option menu. Press the MENU button to display the main MENU menu bar. Select Setup from the main menu, then press ENTER. The Setup Setup menu appears.

  • Page 59: Route Editing

    Route editing The Edit Route function allows the driver to remove or rearrange specific points along the way. This allows the driver to customize a route to the destination. Press the MENU button to display the main MENU menu bar. Select Route and press ENTER. The Arrange Route menu appears.
  • Page 60 Route editing (continued) Select a point to be edited (the destina- Select the route between the points to tion, a waypoint, or the departure point) be edited (XX.X mi) and press ENTER. and press ENTER. The sub-menu appears as follows. If the route is changed, When destination is selected:...

  • Page 61: Changing Order Of Waypoints

    Changing order of waypoints Press the MENU button to display the main MENU menu bar. Select Route and press ENTER. The Arrange Route Menu appears. Select Edit Route and press ENTER. Route ENTER Edit Route ENTER The Arrange Current Route screen is displayed.

  • Page 62: Setting As Current Position

    Setting as Current Position Use this function to correct the location of the present vehicle position icon on the map screen if it is deviated from the real present location of your vehicle. Move the cursor to the real present vehicle location on the map and press ENTER twice.

  • Page 63: Displaying The Entire Route

    Displaying the entire route The navigation system allows you to view the entire route so that you can verify the navigation system's route calculation. If you select a cross-country route, for example Los Angeles to New York, the naviga- tion system will display the route at a special 256-mile magnification scale setting. Press the MENU button to display the main MENU menu bar.

  • Page 64: Changing The Off-Route Recalculation Option

    Changing the off-route recalculation option If you deviate from the suggested route, the system can recalculate a route to get you back on the way to your destination. You can choose to have the system automatically recalculate the route or await confir- mation before recalculating the route.

  • Page 65: Changing The Route Calculation Method

    Changing the route calculation method Depending upon the time of the day and road conditions, you may want to alter the way the system calculates a route. Press the MENU button to display the main MENU menu bar. Select Route from the menu and press ENTER.

  • Page 66: Setting The Today's Plan Calculation Method

    Setting the Today's Plan Calculation Method When using Today's Plan, there are two methods by which the system will calculate a route. In the Auto mode, the system will calculate the most efficient route for travelling to all the destinations in Today's Plan.

  • Page 67: Recalling The Street List During Guidance

    Recalling the Street List during guidance During route guidance, you may display a list of street names to preview upcoming turns and street names. Press the MENU button to display the main MENU menu bar. Select Route and press ENTER. The Route menu appears.

  • Page 68: Setting The Map Color

    Setting the map color The system allows you to set the display's map color. For most drivers, a dark tone screen is preferred when driving at night. The system can be set to automatically switch to dark tone screen when head- lights are turned on.

  • Page 69: Setting Point Of Interest Icon Options

    Setting Point of Interest icon options The system allows you to display some or all of the eight Point of Interest icons on the Detail Map Display at one time. They will appear only in the 1/2, 1/4, 1/8, 1/16 and 1/32 mile magnification scale settings.
  • Page 70 Setting Point of Interest icon options (continued) Select Gas Station from the place type selection menu to display the list below showing the brand icons (thirteen petrol companies) on the map. <Gas station list> Icon Company's name Icon Company's name Icon Company's name Shell...
  • Page 71 Press the MP/RG button. The system returns to the Detailed Map display. Move the Map Cursor icon to any of the visible P.O.I. icons, press ENTER, and the name and address will appear on the ENTER display for that icon. ENTER To remove the point of interest icons from the map screen, there are 2 choices:...

  • Page 72: Setting The Map Screen Orientation

    Setting the map screen orientation The map display can be positioned so that north is always at the top of the display (North Up). This makes it easy to read your current heading from the map. In addition, the vehicle's icon can be posi- tioned so that its current direction is always pointing to the top of the display (Heading Up).

  • Page 73: Setting The Split Screen

    Setting the Split Screen The Split Screen Display of the Basic Guidance Display or Zoomed Intersection Map Display and Detailed Map Display can be made. Press the MENU button to display the main MENU menu bar. Select Setup and press ENTER. The Setup menu appears.

  • Page 74: Setting The Voice Guide Type/Frequency

    Setting the voice guide type/frequency The system allows you to choose the type or frequency of audible prompts you receive as you are guided along your route. Press the MENU button to display the main MENU menu bar. Select Setup and press ENTER. The Setup menu appears.

  • Page 75: Setting Est. (Estimated) Time Display

    Setting Est. (Estimated) Time display When the system calculates a route, it also estimates the time it will take to arrive at the destination. It will display this estimate as either "AT" or Arrival Time, or "TO GO," the time remaining to reach the destination.

  • Page 76: Setting Assumed Speed

    Setting assumed speed The navigation system allows you to fine-tune the parameters which influence the calculation of travel time. If you are a slower or faster driver, the assumed speed settings can be adjusted accordingly. Press the MENU button to display the main MENU menu bar.

  • Page 77: Setting Audio Interrupt

    The Audio Interrupt function allows the navigation system to mute your radio while voice prompts are being played. This option may require additional parts or labor. Please consult your Alpine dealer for details. Press the MENU button to display the main MENU menu bar.

  • Page 78: Setting The Gps Clock

    Setting the GPS clock The GPS receiver used in this system is synchronized to the time data being transmitted by the GPS satellites. The satellite's clock is Greenwich Mean Time (GMT). This is the world-wide standard for time. This makes the system's clock very accurate, once the appropriate time zone has been set. Press the MENU button to display the main MENU menu bar.
  • Page 79 To change whether Daylight Savings is currently being observed or not, select Daylight Savings Time and press ENTER. ENTER Daylight Savings Time ENTER Select ON or OFF depending upon which is currently being observed. Press ENTER to save. ENTER Press the MP/RG button. The system returns to the Detailed Map display.

  • Page 80: Recalibration For New Vehicle Or Tires

    Recalibration for new vehicle or tires The navigation system measures distance using the vehicle’s speed pulses. The vehicle’s speed pulses vary depending on the manufacturer and tire size. Therefore, whenever you install this system into a different vehicle or replace your tires, the distance coefficient is automatically recalibrated. This done by comparing the speed pulse data to the GPS calculated distance.

  • Page 81: Direction Adjustment

    Direction adjustment If the direction of the present vehicle position icon on the map is different from the actual direction of your vehicle, you can correct the direction of the icon with the following method. Press the MENU button to display the main MENU menu bar.

  • Page 82: Screen Position Adjustment

    Screen position adjustment Some display will appear out of position when connected to the navigation system. The image position can be optimized for a particular monitor being used with the system. Press the MENU button to display the main MENU menu bar.

  • Page 83: Information/Guidance Menu

    NFORMATION UIDANCE Connection check for peripherals Press the MENU button to display the main MENU menu bar. Select Setup and press ENTER. The Setup menu appears. Select Peripher- Setup als and press ENTER. ENTER Peripherals ENTER The peripheral screen appears in the display and it shows the connection state of the Navigation Interface.

  • Page 84: Navigation Simulation

    Navigation Simulation You can watch a demonstration of the navigation system's voice and screen guidance by using this function. The vehicle position icon will automatically move along the desired route showing a simula- tion of how the navigation system functions. If waypoints have been set, the simulation only shows a route to the first waypoint.

  • Page 85: Viewing Gps Information

    Viewing GPS Information The navigation system allows you to view dynamic location information received from GPS satellites. This feature is very useful for off-road users in establishing a starting point before trekking. Press the Menu button to display the main MENU menu bar.

  • Page 86: Viewing Trip Information

    Viewing Trip Information The odometer displays the route distance and time traveled since the power to the navigation system was switched on. Press the Menu button to display the main MENU menu bar. Select Info. and press ENTER. The Info. menu appears. Info.

  • Page 87: Viewing Software Information

    Viewing Software Information You can view information about the DVD-ROM's version. Make note of this information and refer to it whenever you communicate with Alpine Tech Support or your Alpine authorized dealer. Press the MENU button to display the main MENU menu bar.

  • Page 88: Using The Detour Function

    Using the Detour function If during a route you require the system to detour around an obstacle, you may use the DETOUR button to automatically recalculate a new route. Press the DTR (DETOUR) button in the Guidance mode. A window appears con- firming the detour request.

  • Page 89: Using The Plan Function

    Using the Plan function While enroute to your first destination in Today's Plan, you may select to change the first destination. Press the PLAN button while in the route guidance mode. The confirmation screen PLAN asking if you want to execute the clearance procedure or not.

  • Page 90: In Case Of Difficulty/Error Messages

    If you encounter a problem, please review the items in the following checklist. This guide will help you isolate the problem if the unit is at fault. Otherwise, make sure the rest of your system is properly connected or consult your authorized Alpine dealer. Symptom...

  • Page 91: Error Messages

    Error Messages Various messages are displayed on the screen during operation. In addition to the messages telling you the current status or providing guidance for the next maneuver, the following error messages may appear. If one of these error messages is displayed, carefully follow the instructions in the solution column.

  • Page 92: Buttons And Functions Of Remote Controls

    Buttons and functions of remote controls RUE-4119 RUE-4136 (For NVE-N851A) (For NVE-N852A) ENTER ENTER A PROC. MENU VOICE CANC. LIST PLAN MP/RG VOICE LIST DETOUR PLAN & DEL. ON/OFF DEL. DEST DISP " ON/OFF V SEL. DEL DEST.
  • Page 93 Button No. RUE-4119 Description RUE-4136 Selects highlighted items within menus and moves map displays and vehicle position icon. ENTER ENTER Press the ENTER button to select any highlighted function, screen icon or street segment. Changes map magnification ratio upward or downward in 9 steps (1/32, 1/16, 1/8, 1/4, 1/2, 2, 8, 32 and 128 miles).

  • Page 94: Remote Control Reference Guide For Head Unit

    Remote Control Reference Guide for Head Unit When you use the Alpine head unit, you can operate the head unit with the remote control (supplied with NVE-N852A.) Change AUDIO/NAV. Switch, on the side of the remote control, to AUDIO. &...

  • Page 95: Remote Control Reference Guide For Av Head Unit

    Remote Control Reference Guide for AV Head Unit When you use the Alpine head unit with the monitor, you can operate the AV head unit with the remote control (supplied with NVE-N852A.) Change AUDIO/NAV. Switch, on the side of the remote control, to AUDIO.

Table of Contents
