Quantel Digital Intermediate products provide full support for all the
advanced operating modes found in HDCAM-SR™ VTRs. The iQ on-line
finishing system, the Pablo color correction system and Sid, the Stereoscopic
3D finishing system all share the same features to support streamlined
workflows with HDCAM-SR. Real-time dual-link input and output is
standard and all the systems store and process non-compressed signals
for the highest possible quality. Double speed ingest delivers the quickest
possible conforms. Support for 1080/60p and 1080/50p ensures that
whatever the format Quantel owners can handle it and in real time.
Stereo3D is a massive opportunity for everyone and the HDCAM-SR/Quantel
combination delivers a high quality real-time Stereo3D workflow.
iQ 2K, iQ 4K, Pablo 2K, Pablo 4K, Sid V4.0 or later system software.
Stereo 3D ingest requires Stereo3D option on iQ and Pablo
Supported Workflow
Double-speed transfer
Stereoscopic 3D
1080/50p and 1080/60p
To capture material recorded at double-speed:
1. Ensure that the HDCAM-SR VTR is connected to the iQ/Pablo using a dual-link.
2. Set the HDCAM-SR VTR to 422DBL.
3. From the I/O menu box, select the Edit Setups and make sure the correct HDCAM-SR VTR Dual port is selected.
4. From the input format box, select 'dual x2'.
5. Capture the clip.
To capture material recorded at 1080/60p or 1080/50p:
1. Ensure that the HDCAM-SR VTR is connected to the iQ/Pablo using a dual-link.
2. Set the HDCAM-SR VTR to 1080P mode.
3. From the I/O menu box, select the Edit Setups and make sure the correct HDCAM-SR VTR Dual port is selected.
4. From the input format box, select 'dual P'.
5. Capture the clip.
HDCAM-SR Workflow Guide
Applicable HDCAM-SR VTR
SRW-5800 with HKSR-5803HQ
SRW-5100 with HKSR-5103
