Viking RVCH330SS Quick Reference Manual

Settings and Functions

Dimmer knob
LIGHTS
PUSH ON/OFF PUSH ON/OFF
LOW HIGH
Light switch ON/OFF switch
ALWAYS turn on your hood before you Light switch—Controls the 50-watt
begin cooking to establish airflow in the halogen lights located in the front of
kitchen. Also let the blower run for a few the hood.
minutes to clear the air after you turn off
your cooking appliance. This will help Dimmer knob—Turn the knob
keep the kitchen air cleaner. clockwise to brighten the lights and
counterclockwise to dim.
ON/OFF switch—Starts and stops the
blower. When turned on, the blower will
operate at the previous setting of the
speed control.
Blower speed knob—Turn
counterclockwise to decrease the blower
speed and clockwise to increase the
speed. The type of cooking you are
doing will dictate the speed of the
blower you use.

Cleaning and Maintenance

Cleaning Mesh Filters
Blower speed knob
As air passes through the filter, grease
particles collect on the stainless steel
screen inside the filter. The filters should
FAN
be examined periodically to assure that
all surfaces and parts are clean. This unit
is equipped with an alarm. Once the unit
has been in operation for 48 hours, the
LOW HIGH
letters "FILT" will appear on the display.
The filters can then be washed in a
dishwasher or in a sink with hot, soapy
water. Simple periodic cleaning will
ensure maximum effectiveness. DO NOT
use caustic detergent to clean the filters.
An abrasive or corrosive cleaner may
damage the finish. DO NOT take the
filters apart to clean them. It is not
necessary and will void the filter warranty.
Once the filters have been cleaned and
placed back in the hood, the display is
canceled by holding the scroll up (+) and
the scroll down (-) buttons for 5 seconds.
C A U T I O N
1
Slide filter front over front lip. Push filter
rear up, then slide back over rear lip.
Replacing the Light Bulbs
When removing bulbs, use an oven mitt
2
to protect your hand in case the bulb
breaks.
Slide filter front over front lip. Push filter
rear up, then slide back over rear lip.
Maintaining Charcoal Filter
(Recirculating Hoods Only)
Replace the charcoal filters every 6 months
to 1 year depending on the amount and
type of cooking you do.
To replace, remove the mesh/charcoal filter
assembly and slide the charcoal filter out of
the channel and replace with a new one.
DO NOT put the charcoal filters in the
dishwasher.
Replacement filters are available through
your local Viking Range dealer, or you can
call the Viking Online Store at
Replace the bulb with a 120 volt, 50-watt
1-877-834-8222 or visit vikingrange.com
Cleaning Hood Canopy
Finishes in enamel or stainless steel are
highly resistant to damage or discoloration
due to grease, steam, and heat—provided
that reasonable care is given to the
equipment. The following suggestions will
help keep your hood looking new.
1. DO NOT allow an excessive
accumulation of grease. For best results,
you should wipe your hood clean with a
cloth dipped in warm, soapy water.
DO NOT USE ABRASIVE CLEANSERS,
STEEL WOOL PADS, OR ABRASIVE
CLOTHS. DO NOT use cleansers that
contain chlorides; the chlorides in the
cleaner could damage the stainless steel
finish. If you need to scrape stainless
steel to remove encrusted materials, first
1
soak the area with hot towels to loosen
1
the material, then use a wooden or
nylon spatula or scraper. DO NOT use a
metal knife, spatula, or any other metal
2
tool to scrape stainless steel.
2. Every 3 months give your hood a
thorough cleaning. On painted surfaces,
use a new coat of wax. A good wax
cleaner—available at either a grocery or
hardware store—will do both jobs at
once. On stainless steel surfaces, use a
good stainless steel cleaner and polish.
Unscrew halogen bulb.
Renewing Enamel Finish
If discoloration occurs, you should
2
thoroughly polish the finish on your hood
to renew its gloss and luster and to
1
remove any grease residue which may
1
have a yellowing effect. Use any good
enamel polish, refrigerator polish, or
automotive polish.
2
C A U T I O N
halogen bulb.
Renewing Stainless Steel Finish
Regular cleaning is the best way to assure
that your stainless steel finish stays bright
and unscratched. Use lemon oil or stainless
steel polish to coat and protect stainless
steel.
C A U T I O N
