bATTery driveN, FTP-608 Series
2" HiGH SPeed THerMAL PriNTer
FTP-628MCL053/054
n Overview
The FTP-628 MCL Series are battery driven high-speed
ultracompact printers with a 2-inch paper width equivalent.
Paper can be easily set using our unique platen release
mechanism.
The FTP-628 MCL Series can be used for a variety of
applications, such as portable terminals, POS, ticket issuing
terminals, label printers, banking terminals, and measurement
and medical equipment.
n HiGHLiGHTS
• Ultra compact
Height 5.5 mm, width 69.6 mm, depth 34.3 mm
• High speed printing
It can print at 80 mm/s (640 dotlines/s) maximum by using
Fujitsu's unique head drive control.
• High resolution printing / Kanji supported
8 dots/mm of resolution printing is possible.
• Auto paper loading
Our unique platen release mechanism allows a
wide paper route even if the printer is ultra-compact, so
paper can be easily inserted. Conventional auto loading is
also available.
• Two types of paper routes
Front or bottom feed, depending on the paper route.
• easy mounting
Wiring for the head, motor, sensor are housed within one
flexible cable (053, 054) or in two cables (051, 052). The
mechanism can be secured by one hook and two screws
at two locations, making mounting easy.
• roHS compliant
FTP-628MCL053/054
Advertisement
Related Manuals for Fujitsu FTP-628MCL053
Summary of Contents for Fujitsu FTP-628MCL053
- Page 1 • Ultra compact Height 5.5 mm, width 69.6 mm, depth 34.3 mm • High speed printing It can print at 80 mm/s (640 dotlines/s) maximum by using Fujitsu's unique head drive control. • High resolution printing / Kanji supported 8 dots/mm of resolution printing is possible. • Auto paper loading...
-
Page 2: Part Numbers
Effective printing area Number of columns Paper width Paper thickness Printing Speed Character types Character, dimensions (W×H), number of columns FTP-628MCL053/054 1R (ANK only) (RS232C) Specifications FTP-628MCL053/054 Thermal-line dot method 384 dots/line 0.25 mm (8 dots/mm)—Dot density 0.25 mm (8 dots/mm)—Line feed pitch... - Page 3 69.3 x 34.3 x 5.5mm Approximately 49g (with knob) Approximately 47g Approximately 20g Pulse resistance: 00 million pulse/dot (using Fujitsu's standard driving method) Abrasion resistance: paper traveling distance 50km (at 2.5% print ratio or less) -0ºC to +50ºC 20 to 85% RH (no condensation) -20ºC to +60ºC...
- Page 4 FTP-628MCL053/054 n diMeNSiONS 1. Printer mechanism FTP-628MCL054 FTP-628MCL053 Unit: mm Note: 1. Dimensions are nominal value (tolerance ±5 unless otherwise specified). 2. Platen unit (lever, platen, etc) moves by approximately 0.7mm toward paper insertion direction when platen is open.
- Page 5 FPC connector Remote side (housing site): 52030-3071 (made by Molex) (2) Pin assignment on the mechanical side — — — — — FTP-628MCL053/054 c t i c t i y l l v i t t s i y l l v i t t s i...
- Page 6 250 E. Caribbean Drive Sunnyvale, CA 94089 U.S.A. Tel: (1-408) 745-4900 Fax: (1-408) 745-4970 Email: components@us.fujitsu.com Web: http://us.fujitsu.com/components/ ©2009 Fujitsu Components America, Inc. All rights reserved. All trademarks or registered trademarks are the property of their respective owners. Fujitsu Components America or its affiliates do not warrant that the content of datasheet is error free. In a continuing effort to improve our products Fujitsu Components America, Inc. or its affiliates reserve the right to change specifications/datasheets without prior notice. Rev. February 26, 2009. FTP-628MCL053/054...
