- Page 1 DGE-510T Gigabit Ethernet Adapter for PCI Bus User’s Guide First Edition (October 2002) 6DGE510T..01 Printed in Taiwan RECYCLABLE...
-
Page 2: Copyright Statement
Trademarks Copyright 2001 D-Link Corporation. Contents subject to change without prior notice. D-Link is a registered trademark of D-Link Corporation/D-Link Systems, Inc. All other trademarks belong to their respective proprietors. Copyright Statement No part of this publication may be reproduced in any... -
Page 3: Limited Warranty
This Warranty applies on the condition that the product Registration Card is filled out and returned to a D-Link office within ninety (90) days of purchase. A list of D-Link offices is provided at the back of this manual, together with a copy of the Registration Card. - Page 4 Registration Card. If a Registration Card for the product in question has not been returned to a D-Link office, then a proof of purchase (such as a copy of the dated purchase invoice) must be provided when requesting warranty service.
-
Page 5: Limitation Of Liability
LIGHTNING OR OTHER HAZARD. LIMITATION OF LIABILITY IN NO EVENT WILL D-LINK BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, LOSS OF PROFITS, COST OF COVER OR OTHER INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES ARISING OUT THE INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE OR INTERRUPTION OF A D- LINK PRODUCT, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY. -
Page 6: Table Of Contents
Table of Contents INTRODUCTION ............. 1 Features..............2 INSTALLATION............... 5 Unpack and Inspect ..........5 Installing the Adapter ..........5 Connecting the Network Cable ........ 6 Software Installation..........7 TROUBLESHOOTING ............ 8 SPECIFICATIONS............9... -
Page 7: Introduction
DGE-510T 10/100/1000 PCI Adapter Introduction Thank you for choosing D-Link DGE-510T, the value leader among dual-speed adapters for PCI Bus personal computers. This introduction gives a general description of the newer networking technologies found on the DGE-510T. The DGE-510T provides the bandwidth capability to support high-end servers and workstations. -
Page 8: Features
DGE-510T 10/100/1000 PCI Adapter the switch will transmit one standard Ethernet packet that causes the DGE-510T to pause for a period, thus avoiding internal buffer overflow and packet loss. The NIC enables simple, scalable network migration, providing the benefit of Gigabit Ethernet networking with the familiarity of Ethernet. - Page 9 DGE-510T 10/100/1000 PCI Adapter • One built-in RJ-45 connector • Support for Gigabit Ethernet over standard Category 5 and 5e UTP wiring for distances up to 100 meters • Auto-negotiation to the highest available speed • Four LED indicators: Link/Activity, Full Duplex, 1000Mbps, 100Mbps •...
-
Page 11: Installation
1. Shut down the computer, unplug its power cord, and remove the chassis cover. 2. Insert the contact edge of the DGE-510T card into the connector of any available PCI Bus Master expansion slot. Press the card firmly into the connector such that the card’s contacts are fully... -
Page 12: Connecting The Network Cable
DGE-510T 10/100/1000 PCI Adapter 3. Install the bracket screw that secures the card to the computer chassis. 4. Replace the computer’s chassis cover. 5. Reconnect the computer’s power cord, and switch computer power on. If the BIOS section of your computer’s... -
Page 13: Software Installation
Simply follow the directions in the Wizard, and your DGE-510T will be installed successfully in just a few minutes, allowing you to enjoy the many advantages of joining an Ethernet LAN. -
Page 14: Troubleshooting
Mbps device is connected to the adapter. • 100M The LED indicator lights green when a 100 Mbps device is connected to the adapter. • Link/Activity Steady green indicates good linkage between the DGE-510T and its supporting server or switch. Flashing green indicates activity (transmitting or receiving) within the adapter. -
Page 15: Specifications
DGE-510T 10/100/1000 PCI Adapter Specifications Jumperless Hardware LAN Chip Set: • Gigabit Media Access controller: DL2001 • Physical interface: 88E 1000T EMI Certifications: • FCC Class B • CE Class B • BSMI Class B • VCCI Class B •... - Page 16 78330 Fontenay le Fleury, France TEL: 33-1-3023-8688 FAX: 33-1-3023-8689 URL: www.dlink-france.fr E-MAIL: info@dlink-france.fr GERMANY D-Link Cent. Europe/D-Link Deutschland GmbH Schwalbacher Strasse 74, 65760 Eschborn, Germany TEL: 49-(0) 6196-7799-0 FAX: 49-(0) 6196-7799-300 URL: www.dlink.de BBS: 49-(0) 6192-971199 (analog) BBS: 49-(0) 6192-971198 (ISDN)
- Page 17 URL: www.dlink.it E-MAIL: info@dlink.it JAPAN D-Link Japan 10F, 8-8-15 Nishi-Gotanda, Shinagawa-ku, Tokyo 141, Japan TEL: 81-3-5434-9678 FAX: 81-3-5434-9868 URL: www.d-link.co.jp E-MAIL: kida@d-link.co.jp RUSSIA D-Link Russia Michurinski Prospekt 49, 117607 Moscow, Russia TEL: 7-095-737-3389 & 7-095-737-3492 FAX: 7-095-737-3390 URL: www.dlink.ru E-MAIL: vl@dlink.ru...
- Page 18 8. What category best describes your company? Aerospace Engineering Education Finance Hospital Legal Insurance/Real Estate Manufacturing Retail/Chainstore/Wholesale Government Transportation/Utilities/Communication Systemhouse/company Other_____________ 9. Would you recommend your D-Link product to a friend? No (why?) ______________________ I don’t know yet 10. Your comments on this product: Installation...
- Page 19 Installation...
