ASROCK H81M-ITX Quick Installation Manual

Quick installation guide
Hide thumbs Also See for H81M-ITX:
Table of Contents

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 1

Quick Links

Download this manual See also: User Manual, Installation Manual
Version 1.0
Published August 2013
Copyright©2013 ASRock INC. All rights reserved.

Copyright Notice:

No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identification or explanation and to the owners' benefit, without intent to
infringe.
Disclaimer:
Specifications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or fitness for a particular
purpose.
In no event shall ASRock, its directors, officers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of profits, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.
The terms HDMI™ and HDMI High-Definition Multimedia Interface, and the HDMI
logo are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
"Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate"
ASRock Website: http://www.asrock.com

Advertisement

Table of Contents
loading

Related Manuals for ASROCK H81M-ITX

Summary of Contents for ASROCK H81M-ITX

  • Page 1: Copyright Notice

    (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.

  • Page 2: Motherboard Layout

    H81M-ITX Motherboard Layout USB 2.0 T: USB2 B: USB3 Fast RAM RoHS USB 3.0 T: USB1 B: USB2 USB 3.0 CMOS USB 2.0 Battery Top: T: USB0 Intel RJ-45 B: USB1 32Mb BIOS H81M-ITX AUDIO CODEC USB_10_11 PANEL1 PCIE1...
  • Page 3 No. Description ATX 12V Power Connector (ATX12V1) 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1) Clear CMOS Jumper (CLRCMOS1) Chassis Intrusion Header (CI1) ATX Power Connector (ATXPWR1) CPU Fan Connector (CPU_FAN1) USB 2.0 Header (USB10_11) System Panel Header (PANEL1) SATA3 Connector (SATA3_0) SATA3 Connector (SATA3_1) Chassis Fan Connector (CHA_FAN1) TPM Header (TPMS1)
  • Page 4 H81M-ITX I/O Panel No. Description No. Description USB 2.0 Ports (USB_23) Microphone (Pink) VGA Port Optical SPDIF Out Port eSATA Connector*** USB 2.0 Ports (USB_01) LAN RJ-45 Port* USB 3.0 Ports (USB3_12) Central / Bass (Orange) HDMI Port Rear Speaker (Black)
  • Page 5 * There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port Activity / Link LED Speed LED Status Description Status Description No Link 10Mbps connection Blinking Data Activity Orange...

  • Page 6: Chapter 1 Introduction

    If you require technical support related to this mother- board, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 7: Specifications

    1.2 Specifications Platform • Mini-ITX Form Factor • All Solid Capacitor design • Home Cloud A-Style • Supports 4th Generation Intel® CoreTM i7 / i5 / i3 / Xeon® / Pentium® / Celeron® in LGA1150 Package • 4 Power Phase Design ®...
  • Page 8 H81M-ITX • Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz • Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI (Compliant HDMI monitor is required) • Supports HDCP function with DVI-D and HDMI ports • Supports Full HD 1080p Blu-ray (BD) playback with DVI-D...
  • Page 9 Storage • 2 x SATA3 6.0 Gb/s connectors, support NCQ, AHCI and Hot Plug • 1 x eSATA connector, supports NCQ, AHCI and Hot Plug Connector • 1 x Chassis Intrusion header • 1 x TPM header • 1 x CPU Fan connector (4-pin) • 1 x Chassis Fan connector (4-pin) • 1 x 24 pin ATX power connector • 1 x 4 pin 12V power connector...
  • Page 10 Due to limitation, the actual memory size may be less than 4GB for the reservation for sys- tem usage under Windows® 32-bit operating systems. Windows® 64-bit operating systems do not have such limitations. You can use ASRock XFast RAM to utilize the memory that Windows® cannot use.

  • Page 11: Unique Features

    LED, FAN-Tastic Tuning, OC Tweaker and a whole lot more. ASRock Instant Flash ASRock Instant Flash is a BIOS flash utility embedded in Flash ROM. This conve- nient BIOS update tool allows you to update the system BIOS in a few clicks without preparing an additional floppy diskette or other complicated flash utility.
  • Page 12 And it also boosts the speed of Adobe Photoshop 5 times faster. Another advantage of ASRock XFast RAM is that it reduces the frequency of accessing your SSDs or HDDs in order to extend their lifespan.
  • Page 13 Windows® 8 brings the ultimate boot up experience. The lightning boot up speed makes it hard to access the UEFI setup. ASRock Restart to UEFI allows users to enter the UEFI automatically when turning on the PC. By enabling this function, the PC will enter the UEFI directly after you restart.

  • Page 14: Chapter 2 Installation

    H81M-ITX Chapter 2 Installation This is an Mini-ITX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 15: Installing The Cpu

    2.1 Installing the CPU 1. Before you insert the 1150-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 16 H81M-ITX...
  • Page 17 Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.
  • Page 18 H81M-ITX 2.2 Installing the CPU Fan and Heatsink...

  • Page 19: Installing Memory Modules (Dimm)

    2.3 Installing Memory Modules (DIMM) This motherboard provides two 240-pin DDR3 (Double Data Rate 3) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR3 DIMM pairs. 2.
  • Page 20 H81M-ITX...
  • Page 21 2.4 Expansion Slots (PCI and PCI Express Slots) There is 1 PCI Express slot on this motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 22: Jumpers Setup

    H81M-ITX 2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”...

  • Page 23: Onboard Headers And Connectors

    2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header Connect the power (9-pin PANEL1) switch, reset switch and...
  • Page 24 H81M-ITX Serial ATA3 Connectors These two SATA3 (SATA3_0: connectors support SATA see p.1, No. 9) data cables for internal (SATA3_1: storage devices with up to see p.1, No. 10) 6.0 Gb/s data transfer rate. USB 2.0 Headers Besides two USB 2.0 ports...
  • Page 25 Chassis Fan Connector Please connect fan cable (4-pin CHA_FAN1) +12V to the fan connector and CHA_FAN_SPEED (see p.1, No. 11) match the black wire to FAN_SPEED_CONTROL the ground pin. CPU Fan Connectors This motherboard pro- GN D (4-pin CPU_FAN1) vides a 4-Pin CPU fan + 12V CPU_ FAN_SPEED (see p.1, No.
  • Page 26 H81M-ITX TPM Header This connector supports Trusted F_CLKRUN# (17-pin TPMS1) Platform Module (TPM) system, SERIRQ# +3VSB S_PWRDWN# (see p.1, No. 12) which can securely store keys, LAD0_L LAD1_L digital certificates, passwords, LAD2_L LAD3_L and data. A TPM system also SMB_DATA_MAIN...
  • Page 27 1 Einleitung Vielen Dank, dass Sie sich für das H81M-ITX von ASRock entschieden haben – ein zuverlässiges Motherboard, das konsequent unter der strengen Qualitätskontrolle von ASRock hergestellt wurde. Es liefert ausgezeichnete Leistung mit robustem Design, das ASRocks Streben nach Qualität und Beständigkeit erfüllt.

  • Page 28: Technische Daten

    H81M-ITX 1.2 Technische Daten Plattform • Mini-ITX-Formfaktor • Vollständig solides Kondensatordesign • Unterstützt Intel® CoreTM i7 / i5 / i3 / Xeon® / Pentium® / Prozessor Celeron® der 4. Generation im LGA1150-Paket • 4-Leistungsphasendesign ® • Unterstützt Intel Turbo Boost 2.0-Technologie ®...
  • Page 29 • Unterstützt D-Sub mit maximaler Auflösung von 1920 x 1200 bei 60 Hz • Unterstützt Auto-Lippensynchronizität, hohe Farbtiefe (12 bpc), xvYCC und HBR (Audio mit hoher Bitrate) mit HDMI (konformer HDMI-Monitor erforderlich) • Unterstützt HDCP-Funktion mit DVI-D- und HDMI-Ports • Unterstützt Blu-ray- (BD) Wiedergabe (Full HD/1080p) mit DVI-D- und HDMI-Ports Audio • 7.1-Kanal-HD-Audio mit Inhaltsschutz (Realtek ALC892-...
  • Page 30 H81M-ITX Speicher • 2 x SATA-III-6,0-Gb/s-Anschlüsse, unterstützt NCQ, AHCI und Hot-Plugging • 1 x eSATA-Anschluss, unterstützt NCQ, AHCI und Hot- Plugging Anschluss • 1 x Gehäuseeingriff-Stiftleiste • 1 x TPM-Stiftleiste • 1 x CPU-Lüfteranschluss (4-polig) • 1 x Gehäuselüfteranschluss (4-polig) • 1 x 24-poliger ATX-Netzanschluss...
  • Page 31 Aufgrund von Beschränkungen kann die Größe des tatsächlich für die Systemnutzung reservierten Speichers unter Windows®-Betriebssystemen mit 32 Bit weniger als 4 GB betragen. Windows®-Betriebssysteme mit 64 Bit haben keine derartigen Beschränkungen. Mit ASRock XFast RAM können Sie den Speicher einsetzen, den Windows® nicht nutzen kann.
  • Page 32 H81M-ITX 1.3 Jumpereinstellung Die Abbildung zeigt, wie die Jumper eingestellt werden. Wenn die Jumper-Kappe auf den Kontakten angebracht ist, ist der Jumper „kurzgeschlossen“. Wenn keine Jumper- Kappe auf den Kontakten angebracht ist, ist der Jumper „offen“. Die Abbildung zeigt einen 3-poligen Jumper, dessen Kontakt 1 und Kontakt 2 „kurzgeschlossen“ sind, wenn eine Jumper-Kappe auf diesen 2 Kontakten angebracht ist.
  • Page 33 1.4 Integrierte Stiftleisten und Anschlüsse Integrierte Stiftleisten und Anschlüsse sind KEINE Jumper. Bringen Sie KEINE Jumper- Kappen an diesen Stiftleisten und Anschlüssen an. Durch Anbringen von Jumper- Kappen an diesen Stiftleisten und Anschlüssen können Sie das Motherboard dauerhaft beschädigen. Systemblende-Stiftleiste Verbinden Sie (9-polig, PANEL1) Netzschalter, Reset-Taste...
  • Page 34 H81M-ITX Serial-ATA-III-Anschlüsse Diese zwei SATA-III- (SATA3_0: Anschlüsse unterstützen siehe S. 1, Nr. 9) SATA-Datenkabel für (SATA3_1: interne Speichergeräte mit siehe S. 1, Nr. 10) einer Datenübertragungsge schwindigkeit bis 6,0 Gb/s. USB 2.0-Stiftleisten Neben zwei USB 2.0-Ports DUMMY (9-polig, USB10_11) an der E/A-Blende befindet (siehe S.
  • Page 35 Gehäuselüfteranschluss Bitte verbinden Sie das (4-polig, CHA_FAN1) Lüfterkabel mit dem +12V (siehe S. 1, Nr. 11) Lüfteranschluss; der CHA_FAN_SPEED FAN_SPEED_CONTROL schwarze Draht gehört zum Erdungskontakt. CPU-Lüfteranschlüsse Dieses Motherboard bietet GN D (4-polig, CPU_FAN1) einen 4-poligen CPU- + 12V CPU_ FAN_SPEED (siehe S.
  • Page 36 H81M-ITX Gehäuseeingriff- Dieses Motherboard Stiftleiste(2-polig, CI1) unterstützt die Gehäuse- Signal (siehe S. 1, Nr. 4) offen-Erkennung, die erkennt, wenn die Gehäuseabdeckung entfernt wurde. Diese Funktion setzt ein Gehäuse mit Gehäuseeingrifferkennungsdesign voraus. TPM-Stiftleiste Dieser Anschluss unterstützt das F_CLKRUN# (17-polig, TPMS1) Trusted Platform Module- (TPM)
  • Page 37 à modification sans préavis. En cas de modifications du présent document, la version mise à jour sera disponible sur le site Internet ASRock sans notification préalable. Si vous avez besoin d’une assistance technique pour votre carte mère, veuillez visiter notre site Internet pour plus de détails sur le modèle que vous utilisez.
  • Page 38 H81M-ITX Spécifications Plateforme • Facteur de forme Mini-ITX • Conception à condensateurs solides Processeur • Prend en charge les processeurs de 4ème Génération Intel® CoreTM i7 / i5 / i3 / Xeon® / Pentium® / Celeron® en package LGA1150 • Alimentation à 4 phases ®...
  • Page 39 • Prend en charge le mode D-Sub avec une résolution maximale de 1920x1200 @ 60Hz • Prend en charge les technologies Auto Lip Sync, Deep Color (12bpc), xvYCC et HBR (High Bit Rate Audio) avec HDMI (un écran compatible HDMI est requis) • Prend en charge la fonction HDCP via ports DVI-D et HDMI • Prend en charge la lecture Blu-ray (BD) Full HD 1080p via ports DVI-D et HDMI...
  • Page 40 H81M-ITX Stockage • 2 x connecteurs SATA3 6,0 Go/s, compatible avec les fonctions NCQ, AHCI et Hot Plug  • 1 x connecteur eSATA, compatible avec les fonctions NCQ, AHCI et Hot Plug  Connectique • 1 x embase d’intrusion châssis • 1 x embase TPM • 1 x connecteur pour ventilateur de CPU (4 broches)
  • Page 41 • FCC, CE, WHQL • ErP/EuP Ready (alimentation ErP/EuP ready requise) * pour des informations détaillées de nos produits, veuillez visiter notre site : http://www.asrock.com En raison de limitations dues au système d'exploitation, la capacité de mémoire utilisée sous Windows® 32-bit peut être inférieure à 4 Go. Cette limitation ne concerne pas les systèmes d'exploitation Windows®...
  • Page 42 H81M-ITX 1.3 Configuration des cavaliers (jumpers) L’illustration ci-dessous vous renseigne sur la configuration des cavaliers (jumpers). Lorsque le capuchon du cavalier est installé sur les broches, le cavalier est ‘court-circuité’ . Si le capuchon du cavalier n’ e st pas installé sur les broches, le cavalier est ‘ouvert’ .
  • Page 43 1.4 Embases et connecteurs de la carte mère Les embases et connecteurs situés sur la carte NE SONT PAS des cavaliers. Ne placez JAMAIS de capuchons de cavaliers sur ces embases ou connecteurs. Placer un capuchon de cavalier sur ces embases ou connecteurs endommagera irrémédiablement votre carte mère. Embase du panneau sys- Branchez le bouton de tème...
  • Page 44 H81M-ITX Connecteurs Serial ATA3 Ces deux connecteurs (SATA3_0: SATA3 sont compatibles voir p.1, No. 9) avec les câbles de données (SATA3_1: SATA pour les appareils de voir p.1, No. 10) stockage internes avec un taux de transfert maximal de 6,0 Go/s.
  • Page 45 Connecteur du ventilateur Veuillez brancher les du châssis +12V câbles du ventilateur sur le CHA_FAN_SPEED (CHA_FAN1 à 4 broches) connecteur du ventilateur, FAN_SPEED_CONTROL (voir p.1, No. 11) puis reliez le fil noir à la broche de mise à terre. Connecteurs du Cette carte mère est GN D ventilateur du processeur...
  • Page 46 H81M-ITX Embase d’intrusion Cette carte mère prend en charge châssis( CI1 à 2 broches) la fonction de détection CHASSIS Signal (voir p.1, No. 4) OUVERT qui alerte l’utilisateur en cas de retrait du boîtier du châssis. Cette fonction requiert un châssis à...
  • Page 47 Web per informazioni specifiche relative al modello attualmente in uso. È possibile trovare l'elenco di schede VGA più recenti e di supporto di CPU anche sul sito Web di ASRock. Sito Web di ASRock http://www.asrock.com.
  • Page 48 H81M-ITX 1.2 Specifiche Piattaforma • Fattore di forma Mini-ITX • Design di condensatore solido • Supporta Intel® CoreTM i7 / i5 / i3 di 4^ generazione / Xeon® / Pentium® / Celeron® in LGA1150 Package • 4 Power Phase Design ®...
  • Page 49 • Supporta D-Sub con una risoluzione max. fino a 1920 x 1200 a 60 Hz • Supporta Auto Lip Sync, Deep Color (12 bpc), xvYCC e HBR (High Bit Rate Audio) con HDMI (è necessario un monitor conforme ad HDMI) • Supporta la funzione HDCP con porte DVI-D e HDMI • Supporta Blu-ray (BD) Full HD 1080p, riproduzione con porte DVI-D e HDMI...
  • Page 50 H81M-ITX Archiviazione • 2 x connettori SATA3 6,0 Gb/s, supporta le funzioni NCQ, AHCI e Hot Plug • 1 x connettore eSATA, supporta le funzioni NCQ, AHCI e Hot Plug Connettore • 1 x header di intrusione nello chassis • 1 x header TPM • 1 x connettore ventola CPU (4 pin)
  • Page 51 * Per informazioni dettagliate sul prodotto, visitare il nostro sito Web: http://www.asrock.com A causa della limitazione, l'effettiva dimensione della memoria può essere inferiore a 4 GB per riservare l'uso del sistema ai sistemi operativi di Windows® a 32 bit. I sistemi ope- rativi Windows®...
  • Page 52 H81M-ITX 1.3 Impostazione jumper L'illustrazione mostra in che modo vengono impostati i jumper. Quando il cappuccio del jumper è posizionato sui pin, il jumper è "cortocircuitato". Se sui pin non è posizionato alcun cappuccio del jumper, il jumper è "aperto". L'illustrazione mostra un jumper a 3 pin i cui pin1 e pin2 sono "cortocircuitati"...
  • Page 53 1.4 Header e connettori sulla scheda Gli header e i connettori sulla scheda NON sono jumper. NON posizionare cappucci del jumper su questi header e connettori. Il posizionamento di cappucci del jumper su header e connettori provocherà danni permanenti alla scheda madre. Header sul pannello del Collegare l'interruttore sistema...
  • Page 54 H81M-ITX Connettori Serial ATA3 Questi due connettori (SATA3_0: SATA3 supportano cavi vedere pag.1, n. 9) dati SATA per dispositivi (SATA3_1: di archiviazione interna, vedere pag.1, n. 10) con una velocità di trasferimento dati fino a 6,0 Gb/s. Header USB 2.0...
  • Page 55 Connettore della ventola Collegare il cavo della dello chassis +12V ventola al connettore della CHA_FAN_SPEED (CHA_FAN1 a 4 pin) ventola e far corrispondere FAN_SPEED_CONTROL (vedere pag. 1, n. 11) il filo nero al pin di terra. Connettori della ventola Questa scheda madre è GN D della CPU dotata di un connettore...
  • Page 56 H81M-ITX Header TPM Questo connettore supporta il F_CLKRUN# (TPMS1 a 17 pin) sistema Trusted Platform Module SERIRQ# +3VSB S_PWRDWN# (vedere pag. 1, n. 12) (TPM), che può archiviare in LAD0_L LAD1_L modo sicuro chiavi, certificati LAD2_L LAD3_L digitali, password e dati. Un...

  • Page 57: Contenido Del Paquete

    Podrá encontrar las últimas tarjetas VGA, así como la lista de compatibilidad de la CPU, en el sitio web de ASRock. Sitio web de ASRock http://www.asrock.com.
  • Page 58 H81M-ITX 1.2 Especificaciones Plataforma • Factor de forma Mini-ITX • Diseño de los Condensadores: All Solid • Compatible con 4.ª Generación de Intel® CoreTM i7 / i5 / i3 / Xeon® / Pentium® / Celeron® en Paquete LGA1150 • Diseño de 4 fases de alimentación ®...
  • Page 59 • Compatible con D-Sub con máxima resolución hasta 1920x1200 @ 60Hz • Compatible con Auto Lip Sync, Deep Color (12bpc), xvYCC y HBR (audio de alta velocidad de bits) con HDMI (requiere un monitor compatible con HDMI) • Compatible con función HDCP con puertos DVI-D y HDMI • Compatible con reproducción Blu-ray (BD) Full HD de 1080p con puertos DVI-D y HDMI Audio...
  • Page 60 H81M-ITX • 1 cabezal de intrusión de chasis Conectores • 1 cabezal TPM • 1 conector de ventilador de la CPU (de 4 pines) • 1 conector de ventilador de chasis (de 4 pines) • 1 conector de alimentación ATX de 24 pines • 1 conector de alimentación de 12V de 4 pines...
  • Page 61 * Para obtener más información acerca del producto, visite nuestro sitio web: http://www.asrock.com Debido a las limitaciones, el tamaño real de la memoria podrá ser inferior a 4GB para reservar espacio para el uso del sistema en sistemas operativos Windows® de 32 bits. Los sitemas operativos Windows®...
  • Page 62 H81M-ITX 1.3 Instalación de los puentes La instalación muestra cómo deben instalarse los puentes. Cuando la tapa de puente se coloca en los pines, el puente queda “Corto”. Si no coloca la tapa de puente en los pines, el puente queda “Abierto”. La ilustración muestra un puente de 3 pines cuyo pin 1 y pin 2 son “Cortos”...
  • Page 63 1.4 Conectores y cabezales incorporados Los cabezales y conectores incorporados NO son puentes. NO coloque tapas de puente sobre estos cabezales y conectores. Si coloca tapas de puente sobre los cabezales y conectores dañará de forma permanente la placa base. Cabezal del panel del siste- Conecte el interruptor de alimentación, restablezca el...
  • Page 64 H81M-ITX Conectores Serie ATA3 Estos dos conectores (SATA3_0: SATA3 son compatibles consulte la pág.1, N.º 9) con cables de datos SATA (SATA3_1: para dispositivos de consulte la pág.1, N.º 10) almacenamiento interno con una velocidad de transferencia de datos de hasta 6,0 Gb/s.
  • Page 65 Conector del ventilador Conecte el cable del +12V del chasis ventilador al conector del CHA_FAN_SPEED (CHA_FAN1 de 4 pines) ventilador y haga coincidir FAN_SPEED_CONTROL (consulte la pág.1, N.º 14) el cable negro con el pin de conexión a tierra. Conectores del ventilador Esta placa base contiene GN D de la CPU...
  • Page 66 H81M-ITX Cabezal TPM Este conector es compatible con F_CLKRUN# (TPMS1 de 17 pines) el sistema Módulo de Plataforma SERIRQ# +3VSB S_PWRDWN# (consulte la pág.1, N.º 15) Segura (TPM, en inglés), que LAD0_L puede almacenar de forma segura LAD1_L LAD2_L LAD3_L...
  • Page 67 1 Введение Благодарим вас за приобретение надежной материнской платы ASRock H81M- ITX, выпускаемой под постоянным строгим контролем компании ASRock. Эта материнская плата обеспечивает великолепную производительность и характеризуется прочной конструкцией в соответствии с требованиями компании ASRock в отношении качества и долговечности.
  • Page 68 H81M-ITX 1.2 Спецификация Платформа • Форм-фактор Mini-ITX • Использование только твердотельных конденсаторов ЦП • Поддержка процессоров 4-го поколения Intel® CoreTM i7 / i5 / i3 / Xeon® / Pentium® / Celeron® в исполнении LGA1150 • Система питания 4 ® • Поддержка технологии Intel Turbo Boost 2.0...
  • Page 69 • Поддержка D-Sub с максимальным разрешением до 1920x1200 при 60 Гц • Поддержка Auto Lip Sync, Deep Color (12bpc), xvYCC и HBR (High Bit Rate Audio) по HDMI (необходим HDMI- совместимый монитор) • Поддержка функции HDCP через порты DVI-I и HDMI • Поддержка...
  • Page 70 H81M-ITX Разъемы • 1 x колодка для датчика вскрытия корпуса • 1 x колодка ТРМ • 1 x разъем для вентилятора ЦП (4-контактный) • 1 x разъем для вентилятора корпуса (4-контактный) • 1 х разъем питания АТХ (24-контактный) • 1 x 4-контактный разъем питания 12 В...
  • Page 71 В связи с ограничением при работе под 32-разрядной ОС Windows® фактический объем памяти может быть меньше 4 Гбайт. Для 64-разрядных ОС Windows® таких ограничений нет. Для использования той памяти, которую ОС Windows® не может использовать, используйте ASRock XFast RAM.
  • Page 72 H81M-ITX 1.3 Установка перемычек Установка перемычек показана на рисунке. При установке колпачковой перемычки на контакты перемычка «замкнута». Если колпачковая перемычка на контакты не установлена, перемычка «разомкнута». На рисунке показана 3-контактная перемычка с замкнутыми контактами 1 и 2 при установке на них...
  • Page 73 1.4 Колодки и разъемы, расположенные на материнской плате Расположенные на материнской плате колодки и разъемы перемычками НЕ являются. НЕ устанавливайте на эти колодки и разъемы колпачковые перемычки. Установка колпачковых перемычек на эти колодки и разъемы может вызвать неустранимое повреждение материнской платы. Подключите...
  • Page 74 H81M-ITX Разъемы Serial ATA3 Эти два разъема SATA3 (SATA3_0: предназначены для см. стр.1, № 9) подключения кабелей (SATA3_1: SATA внутренних см. стр.1, № 10) запоминающих устройств для передачи данных со скоростью до 6,0 Гб/с. Колодки USB 2.0. Кроме двух портов USB DUMMY (9-контактная,...
  • Page 75 Разъем вентилятора Предназначен для подключения кабеля корпуса +12V CHA_FAN_SPEED разъема вентилятора и (4-контактный, FAN_SPEED_CONTROL подключения черного CHA_FAN1) провода к заземлению. (См. стр. 1, № 14) Разъемы Эта материнская GN D плата снабжена вентиляторов ЦП + 12V CPU_ FAN_SPEED 4-контактным разъемом (4-контактный, FAN_SPEED_CONTROL для...
  • Page 76 H81M-ITX Колодка для датчика Эта материнская плата поддерживает технологию вскрытия корпуса Signal определения вскрытия корпуса (2-контактная, CI1) по снятию верхней части (См. стр. 1, № 4) корпуса. Для этой технологии необходим корпус с функцией определения вскрытия. Колодка ТРМ Этот разъем обеспечивает...
  • Page 77 Caso ocorram modificações a esta documentação, a versão actualizada estará disponível no Web site da ASRock sem aviso prévio. Se necessitar de assistência técnica relacionada com esta placa principal, visite o nosso Web site para obter informações específicas acerca do modelo que está...
  • Page 78 H81M-ITX 1.2 Especificações Plataforma • Formato Mini-ITX • Design de condensador sólido • Suporta processadores Intel® CoreTM i7 / i5 / i3 / Xeon® / Pentium® / Celeron® de 4ª geração em socket LGA1150 • Design com 4 fases de alimentação ®...
  • Page 79 • Suporta D-Sub com resolução máxima de até 1920x1200 @ 60Hz • Suporta Auto sincronização labial, Deep Color (12bpc), xvYCC e HBR (High Bit Rate Audio) com HDMI (É necessário um monitor compatível com HDMI) • Suporta a função HDCP com portas DVI-D e HDMI • Suporta reprodução Blu-ray (BD) Full HD a 1080p com portas DVI-D e HDMI Áudio...
  • Page 80 H81M-ITX Armazena- • 2 x conectores SATA3 a 6,0 Gb/s, com suporte para as funções NCQ, AHCI e Hot Plug mento • 1 x conector eSATA, com suporte para as funções NCQ, AHCI e Hot Plug Conector • 1 x Terminal de intrusão no chassis • 1 x Terminal TPM...
  • Page 81 * Para obter informações detalhadas acerca do produto, visite o nosso Web site: http://www.asrock.com Devido às limitações, o tamanho real da memória de 4GB reservada para utilização em sistemas operativos Windows® 32-bits poderá ser inferior. Os sistemas operativos Windows® 64-bits não possuem essas limitações. Pode utilizar o ASRock XFast RAM...
  • Page 82 H81M-ITX 1.3 Configuração dos jumpers A imagem abaixo ilustra como os jumpers são configurados. Quando a tampa do jumper é colocada nos pinos, o jumper é "Curto". Se não for colocada uma tampa de jumper nos pinos, o jumper é "Aberto". A imagem ilustra um jumper de 3 pinos cujos pino1 e pino2 estão "Curtos"...
  • Page 83 1.4 Terminais e conectores integrados Os terminais e conectores integrados NÃO são jumpers. NÃO coloque tampas de jumpers sobre estes terminais e conectores. Colocar tampas de jumpers sobre os terminais e conectores irá causar danos permanentes à placa principal. Terminal do painel de Ligue o botão de sistema alimentação, o botão de...
  • Page 84 H81M-ITX Conectores ATA3 de série Estes dois conectores (SATA3_0: SATA3 suportam consultar p.1, Nº. 9) cabos de dados SATA (SATA3_1: para dispositivos de consultar p.1, Nº. 10) armazenamento interno com uma velocidade de transferência de dados de até 6,0 Gb/s.
  • Page 85 Conector da ventoinha do Ligue o cabos da +12V chassis ventoinha aos conectores CHA_FAN_SPEED FAN_SPEED_CONTROL (CHA_FAN1 de 4 pinos) da ventoinha colocando (consultar p.1, N.º 11) o cabo preto no pino de ligação à terra. Conectores da ventoinha Esta placa principal inclui GN D da CPU + 12V...
  • Page 86 H81M-ITX Terminal de intrusão do Esta placa principal suporta chassis(CI1 de 2 pinos) a função de detecção de Signal (consultar p.1, N.º 4) ABERTURA da CAIXA que detecta se a tampa do chassis foi removida. Esta função requer um chassis com design de detecção de intrusão.
  • Page 87 ASRock'ın web sitesinde yer alacaktır.. Bu anakart ile ilgili olarak teknik destek almak istiyorsanız, lütfen kullandığınız model hakkında özel bilgiler için web sitemizi ziyaret edin. En güncel VGA kartları ve CPU destek listelerini de ASRock'ın web sitesinden bulabilirsiniz. ASRock web sitesi http://www.asrock.com.
  • Page 88 H81M-ITX 1.2 Özellikler Platform • Mini-ITX Form Faktörü • Tam Katı Bağlayıcı tasarımı • 4ncü Nesil Intel® CoreTM i7 / i5 / i3 / Xeon® / Pentium® / Celeron®, LGA1150 Paketinde desteklemektedir • 4 Güç Safhası Tasarımı ® • Intel Turbo Boost 2.0 Teknolojisini destekler...
  • Page 89 • 1920x1200 @ 60Hz'ye kadar çözünürlükle D-Sub işlevini destekler • HDMI ile Otomatik Dudak Senkronizasyonu (12bpc, xvYCC ve HBR (Yüksek Bit Hızında Ses) özelliklerini destekler (Uyumlu bir HDMI monitörü kullanılmalıdır) • DVI-D ve HDMI bağlantı noktaları ile HDCP işlevini destekler • DVI-D, ve HDMI bağlantı...
  • Page 90 H81M-ITX Depolama • 2 x SATA3 6,0 Gb/s bağlayıcıları, NCQ, AHCI ve Hot Plug işlevlerini destekler • 1 x eSATA bağlayıcısı, NCQ, AHCI ve Hot Plug işlevlerini destekler Bağlayıcı • 1 x Kasa Yetkisiz Erişim bağlantısı • 1 x TPM bağlantısı...
  • Page 91 * Detaylı ürün bilgisi için, lütfen web sitemizi ziyaret edin: http://www.asrock.com Sınırlamalar nedeniyle, gerçek bellek boyutu Windows® 32-bit işletim sistemleri çerçevesinde sistem kullanımına ayrıldığı için 4GB'den az olabilir. Windows® 64-bit işletim sistemlerinde bu tür sınırlamalar yoktur. Windows® tarafından kullanılmayan bellekten faydalanmak için ASRock XFast RAM'i kullanabilirsiniz.
  • Page 92 H81M-ITX 1.3 Bağlantı Teli Kurulumu Çizim, bağlantı tellerinin kurulumunu göstermektedir. Tel kapağı, pimlerin üzerine yerleştirildiğinde, tel "Kısa" olur. Pimlerin üzerinde tel kapağı bulunmadığında, tel "Kısa" olur. Çizim, pin1 ve pin2 alanları "Kısa" olan ve bu iki pim üzerinde bir bağlantı...
  • Page 93 1.4 Ekli Bağlantılar ve Bağlayıcılar Ekli bağlantılar ve bağlayıcılar bağlantı teli değildir. Bağlantı teli kapaklarını bu bağlantı ve bağlayıcılar üzerine yerleştirmeyin. Bağlantı teli kapaklarının bağlantılar ile bağlayıcılar üzerine yerleştirilmesi, anakarta kalıcı hasar verebilir. Sistem Paneli Bağlantısı Güç anahtarını bağlayın, (9-pin PANEL1) kasa üzerindeki anahtar ile RESET# PWRBTN#...
  • Page 94 H81M-ITX Seri ATA3 Bağlayıcıları Bu iki SATA3 bağlayıcısı, (SATA3_0: veri aktarım hızı 6,0 Gb/ bkz. s.1, No. 9) sn'ye kadar olan dahili (SATA3_1: depolama aygıtları için bkz. s.1, No. 10) tasarlanmış SATA veri kablolarını destekler. USB 2.0 Bağlantıları Bu anakart üzerinde, I/O...
  • Page 95 Kasa Fanı Konektörü Lütfen fan kablosunu fan +12V (4-pin CHA_FAN1) konektörüne takın ve siyah CHA_FAN_SPEED (bkz sf.1, No. 11) teli topraklama pinine FAN_SPEED_CONTROL bağlayın. CPU Fan Bağlayıcıları Bu anakart, 4-Pin CPU GN D (4-pin CPU_FAN1) fan (Sessiz Fan) bağlayıcısı + 12V CPU_ FAN_SPEED (bkz sf.1, No.
  • Page 96 H81M-ITX TPM Bağlantısı Bu bağlayıcı, anahtarlar, dijital F_CLKRUN# (17-pin TPMS1) sertifikalar, parolalar ve verileri SERIRQ# +3VSB (bkz. sf.1, No. 12) S_PWRDWN# güvenli bir şekilde saklama LAD0_L özelliği bulunan Güvenilir LAD1_L LAD2_L LAD3_L Platform Modülü (TPM) sistemini SMB_DATA_MAIN TPM_RST# destekler. TPM sistemleri,...
  • Page 97 ASRock H81M-ITX 마더보드를 구입해 주셔서 감사합니다 . 이 마더보드는 ASRock 의 일관되고 엄격한 품질관리 하에 생산되어 신뢰성이 우수하며 , 품질 과 내구성에 대한 ASRock 의 기준에 부합하는 우수한 성능과 견고한 설계를 제 공합니다 . 마더보드 규격과 BIOS 소프트웨어를 업데이트할 수도 있기 때문에 , 이 문서의 내...
  • Page 98 H81M-ITX 1.2 규격 • Mini-ITX 폼 팩터 플랫폼 • 모든 솔리드 콘덴서 구조 • LGA1150 패키지로 제공되는 4 세대 Intel® CoreTM i7 / i5 / i3 / Xeon® / Pentium® / Celeron® 지원 • 4 개 전원 위상 구조 ®...
  • Page 99 • Intel® HD 그래픽스 빌트 - 인 비주얼과 VGA 출력은 GPU 그래픽 통합 프로세서로만 지원할 수 있습니다 . • Intel® HD 그래픽스 빌트 - 인 비주얼 지원 : AVC, MVC (S3D) 및 MPEG-2 풀 HW Encode1 지원 Intel® Quick Sync Video, Intel®...
  • Page 100 H81M-ITX • 1 개 PS/2 마우스 / 키보드 포트 후면 패널 I/O • D-Sub 포트 1 개 • DVI-D 포트 1 개 • HDMI 포트 1 개 • 광학 SPDIF 출력 포트 1 개 • eSATA 커넥터 1 개 • USB 2.0 포트 4 개...
  • Page 101 제한 때문에 실제 메모리 크기는 Windows® 32 비트 운영체제 하의 시스템 사용 을 위한 예비 메모리용 4GB 보다 더 적을 수 있습니다 . Windows® 64 비트 운영체 제에는 그러한 제한이 없습니다 . ASRock XFast RAM 을 사용하여 Windows® 가 사용할 수 없는 메모리를 이용할 수 있습니다 .
  • Page 102 H81M-ITX 1.3 점퍼 설정 그림은 점퍼를 어떻게 설정하는지 보여줍니다 . 점퍼 캡을 핀에 씌우면 점퍼가 “단락”됩니다 . 점퍼 캡을 핀에 씌우지 않으면 점퍼가 “단선”됩니다 . 그림은 3 핀 점퍼를 보여주며 핀 1 과 핀 2 는 점퍼 캡을 씌울 때 “단락”됩니다 .
  • Page 103 1.4 온보드 헤더 및 커넥터 온보드 헤더와 커넥터는 점퍼가 아닙니다 . 점퍼 캡을 온보드 헤더와 커넥터에 씌 우지 마십시오 . 점퍼 캡을 온보드 헤더와 커넥터에 씌우면 마더보드가 영구적으 로 손상됩니다 . 섀시의 전원 스위치 , 시스템 패널 헤더 (9 핀 PANEL1) 리셋...
  • Page 104 H81M-ITX 시리얼 ATA3 커넥터 이들 두 SATA3 커넥터 (SATA3_0: 는 최대 6.0 Gb/s 데이 1 페이지 , 9 번 항목 참조 ) 터 전송 속도를 제공하 (SATA3_1: 는 내부 저장 장치용 1 페이지 , 10 번 항목 참조 ) SATA 데이터 케이블을...
  • Page 105 섀시 팬 커넥터 팬 케이블을 팬 커넥 +12V (4 핀 CHA_FAN1) 터에 연결하고 검은색 CHA_FAN_SPEED (1 페이지 , 11 번 항목 참조 ) FAN_SPEED_CONTROL 와이어를 접지핀에 연 결하십시오 . CPU 팬 커넥터 이 마더보드에는 4 핀 GN D (4 핀 CPU_FAN1) CPU 팬...
  • Page 106 H81M-ITX TPM 헤더 이 커넥터는 키 , 디지털 F_CLKRUN# (17 핀 TPMS1) 인증서 , 암호 및 데이터 SERIRQ# +3VSB S_PWRDWN# (1 페이지 , 12 번 항목 참조 ) 를 안전하게 보관할 수 있 LAD0_L LAD1_L 는 TPM(Trusted Platform LAD2_L LAD3_L Module) 시스템을...
  • Page 107 H81M-ITX BIOS http://www.asrock.com. 1.1 パッケージの内容 • H81M-ITX • H81M-ITX • H81M-ITX • 2 x ATA SATA • 1 x I/O...
  • Page 108 H81M-ITX 1.2 仕様 • • • LGA1150 Intel® Core i7 / i5 / i3 / Xeon® / Pentium® / Celeron® • 4 ® • Intel ® • Intel • DDR3 • 2 x DDR3 DIMM • DDR3 1600/1333/1066 ECC •...
  • Page 109 • D-Sub 1920x1200 @60Hz • HDMI HDMI 12bpc xvYCC HBR • DVI-D HDMI HDCP • DVI-D HDMI HD 1080p (BD) • 7.1 CH HD Realtek ALC892 • • PCIE x1 LAN 10/100/1000 Mb/ • ® ® AR8171 • ® ® •...
  • Page 110 H81M-ITX • 2 x SATA3 6.0 Gb/ NCQ AHCI • 1 x eSATA NCQ AHCI • 1 x • 1 x TPM • 1 x CPU • 1 x • 1 x 24 • 1 x 4 • 1 x • 1 x USB 2.0...
  • Page 111 Windows® 32 Windows® 64 Windows® XFast RAM...
  • Page 112 H81M-ITX 1.3 ジャンパー設定 CMOS (CLRCMOS1) CMOS p.1 No. 3 CLRCMOS1 CMOS CLRCMOS1 BIOS CMOS BIOS CMOS CMOS CMOS CMOS BIOS Clear Status...
  • Page 113 1.4 オンボードのヘッダーとコネクター RESET# PWRBTN# p.1 No. 8 HDLED- PLED- PLED+ HDLED+ PWRBTN RESET PLED S1/S3 HDLED...

  • Page 114: Table Of Contents

    H81M-ITX ATA3 SATA3 6.0 Gb/ SATA3_0 p.1 No. 9 SATA3_1 SATA p.1 No. 10 USB 2.0 DUMMY USB10_11 p.1 No. 8 USB_PWR USB_PWR USB 2.0 GN D OUT2_L J_SENSE PRESENCE# OUT2_R HD_AUDIO1 MIC_RET MIC2_R OUT_RET MIC2_L p.1 No. 16 2. AC 97...
  • Page 115 +12V CHA_FAN1 CHA_FAN_SPEED p.1 No. 11 FAN_SPEED_CONTROL GN D CPU_FAN1 + 12V CPU_ FAN_SPEED p.1 No. 6 FAN_SPEED_CONTROL ATXPWR1 p.1 No. 5 ATX12V ATX12V1 ATX12V p.1 No. 1 Signal p.1 No. 4...
  • Page 116 H81M-ITX F_CLKRUN# TPMS1 +3VSB SERIRQ# S_PWRDWN# p.1 No. 12 LAD0_L LAD1_L LAD2_L LAD3_L SMB_DATA_MAIN TPM_RST# SMB_CLK_MAIN LFRAME#_L CK_33M_TPM...
  • Page 117 1 简介 感谢您购买 ASRock H81M-ITX 主板，这是按照 ASRock 一贯严格质量控制标准 生产的性能可靠的主板。它提供符合 ASRock 质量和耐久性承诺的精良设计和 卓越性能。 由于主板规格和 BIOS 软件可能已更新，因此，本文档的内容可能会随时更改， 恕不另行通知。 如果本文档有任何修改， 则更新的版本将发布在 ASRock 网站上， 我们不会另外进行通知。如果您需要与此主板相关的技术支持，请访问我们的网 站以具体了解所用型号的信息。您也可以在 ASRock 网站上找到最新 VGA 卡和 CPU 支持列表。ASRock 网站 http://www.asrock.com。 1.1 包装清单 • ASRock H81M-ITX 主板（Mini-ITX 规格尺寸） • ASRock H81M-ITX 快速安装指南...
  • Page 118 H81M-ITX 1.2 规格 • Mini-ITX 规格尺寸 平台 • 全固态电容器设计 • 支持 LGA1150 封装第 4 代 Intel® CoreTM i7 / i5 / i3 / Xeon® / Pentium® / Celeron® • 4 电源相设计 ® • 支持 Intel Turbo Boost 2.0 技术 ®...
  • Page 119 • 支持 D-Sub，60Hz 时最大分辨率达 1920x1200 • 通过 HDMI（需要符合规格的 HDMI 监视器）支持 Auto Lip Sync、Deep Color (12bpc), xvYCC 和 HBR（高位速率音 频） • 通过 DVI-D and HDMI 端口支持 HDCP 功能 • 通过 DVI-D 和 HDMI 端口支持全高清 1080p Blu-ray (BD) 播放。 • 具有内容保护功能的 7.1 CH 高清音频（Realtek ALC892 音 音频...
  • Page 120 H81M-ITX • 1 x 机箱侵入接脚 接口 • 1 x TPM 接脚 • 1 x CPU 风扇接口 (4 针 ) • 1 x 机箱风扇接口 (4 针 ) • 1 x 24 针 ATX 电源接口 • 1 x 4 针 12V 电源接口...
  • Page 121 * 有关详细产品信息，请访问我们的网站：http://www.asrock.com 由于限制原因，实际内存容量可能会小于 4GB，以保留给 Windows® 32-bit 操 作系统下的系统使用。Windows® 64-bit 操作系统没有此类限制。您可以使用 ASRock XFast RAM 来利用 Windows® 不能使用的内存。...
  • Page 122 H81M-ITX 1.3 跳线设置 此图显示如何设置跳线。将跳线帽装到这些针脚上时，跳线 “短接”。如果这 些针脚上没有装跳线帽，跳线 “开路”。此图显示 3 针跳线，当跳线帽装在针 脚 1 和针脚 2 上，它们“短接”。 清除 CMOS 跳线 (CLRCMOS1) 清除 CMOS 默认 ( 见第 1 页，第 3 个） CLRCMOS1 允许您清除 CMOS 中的数据。要清除和重置系统参数到默认设 置，请关闭计算机，从电源上拔下电源线插头。等候 15 秒后，使用跳线帽将 CLRCMOS1 上的针脚 2 和针脚 3 短接 5 秒。但是，请勿在更新 BIOS 后立即...
  • Page 123 1.4 板载接脚和接口 板载接脚和接口不是跳线。不要将跳线帽装到这些接脚和接口上。将跳线帽装到 这些接脚和接口上将会对主板造成永久性损坏。 系统面板接脚 按照下面的针脚分配， (9 针 PANEL1) RESET# 将机箱上的电源开关、 PWRBTN# ( 见第 1 页， 第 8 个） 重置开关和系统状态指 HDLED- PLED- 示灯连接到此接脚。在 PLED+ HDLED+ 连接线缆前请记下正负 针脚。 PWRBTN（电源开关）: 连接到机箱前面板上的电源开关。您可以配置使用电源开关关闭系统的方式。 RESET（重置开关）: 连接到机箱前面板上的重置开关。如果计算机死机，无法执行正常重新启动，按 重置开关重新启动计算机。 PLED（系统电源 LED）: 连接到机箱前面板上的电源状态指示灯。系统操作操作时，此 LED 亮起。系统 处在 S1/S3 睡眠状态时，此 LED 闪烁。系统处在 S4 睡眠状态或关机 (S5) 时，此 LED 熄灭。...

  • Page 124: Mic_Ret

    H81M-ITX 串行 ATA3 接口 这 2 个 SATA3 接口支持 (SATA3_0: 最高 6.0 Gb/s 数据传输 见第 1 页 , 第 9 个） 速率的内部存储设备的 (SATA3_1: SATA 数据线。 见第 1 页 , 第 10 个） USB 2.0 接脚 除 I/O 面板上的两个 USB DUMMY (9 针...
  • Page 125 机箱风扇接口 请将风扇线连接到风扇 +12V (4 针 CHA_FAN1) 接口并使黑线匹配接地 CHA_FAN_SPEED FAN_SPEED_CONTROL ( 见第 1 页， 第 11 个 ) 针脚。 CPU 风扇接口 此主板提供 4 针 CPU 风 GN D + 12V (4 针 CPU_FAN1) 扇（静音风扇）接口。如 CPU_ FAN_SPEED FAN_SPEED_CONTROL ( 见第 1 页， 第 6 个 ) 果您打算连接...
  • Page 126 H81M-ITX 電子信息產品污染控制標示 依據中國發布的「電子信息產品污染控制管理辦法」及 SJ/T 11364-2006「電 子信息產品污染控制標示要求」，電子信息產品應進行標示，藉以向消費者揭 露產品中含有的有毒有害物質或元素不致發生外洩或突變從而對環境造成污染 或對人身、財產造成嚴重損害的期限。依上述規定，您可于本產品之印刷電路 板上看見圖一之標示。圖一中之數字為產品之環保使用期限。由此可知此主板 之環保使用期限為 10 年。 圖一 有毒有害物質或元素的名稱及含量說明 若您慾了解此產品的有毒有害物質或元素的名稱及含量說明，請參照以下表格 及說明。 有害物質或元素 部件名稱 鉛 (Pb) 鎘 (Cd) 汞 (Hg) 六价鉻 (Cr(VI)) 多溴聯苯 (PBB) 多溴二苯醚 (PBDE) 印刷電路板 及電子組件 外部信號連 接頭及線材 O : 表示該有毒有害物質在該部件所有均質材料中的含量均在 SJ/T 11363-2006 標準規定...
  • Page 127 通知。如本文件有任何修改，可至 ASRock 網站逕行取得更新版本，不另外通知。 若您需要與本主機板相關的技術支援，請上我們的網站瞭解有關您使用機型的特 定資訊。您也可以在 ASRock 網站找到最新的 VGA 卡及 CPU 支援清單。ASRock 網站 http://www.asrock.com 1.1 包裝內容 • ASRock H81M-ITX 主機板 (Mini-ITX 尺寸 ) • ASRock H81M-ITX 快速安裝指南 • ASRock H81M-ITX 支援光碟 • 2 x Serial ATA (SATA) 資料纜線（選用） • 1 x I/O 面板外罩...
  • Page 128 H81M-ITX 1.2 規格 • Mini-ITX 尺寸 平台 • 全固態電容設計 • 支援第 4 代 Intel® CoreTM i7 / i5 / i3 / Xeon® / Pentium® / Celeron® (LGA1150 封裝 ) • 4 電源相位設計 ® • 支援 Intel Turbo Boost 2.0 技術...
  • Page 129 • 支援最高達 1920x1200 @ 60Hz 解析度的 D-Sub • 支援使用 HDMI（需相容於 HDMI 監視器）的 Auto Lip Sync、 Deep Color (12bpc)、 xvYCC 及 HBR （高位元率音訊） • 支援含 DVI-D 及 HDMI 連接埠的 HDCP 功能 • 支援透過 DVI-D 及 HDMI 連接埠的 Full HD 1080p Blu-ray (BD) 播放...
  • Page 130 H81M-ITX • 1 x 機殼防護標頭 接頭 • 1 x TPM 標頭 • 1 x CPU 風扇接頭 (4-pin) • 1 x 機殼風扇接頭 (4-pin) • 1 x 24 pin ATX 電源接頭 • 1 x 4 pin 12V 電源接頭 • 1 x 前面板音訊接頭...
  • Page 131 * 如需產品詳細資訊，請上我們的網站：http://www.asrock.com 在 Windows® 32 位元作業系統下，因有保留供系統使用記憶體的限制，所以實 際記憶體大小可能低於 4GB。Windows® 64 位元作業系統則沒有此類限制。您 可使用 ASRock XFast RAM 運用 Windows® 無法使用的記憶體。...
  • Page 132 H81M-ITX 1.3 跳線設定 圖例顯示設定跳線的方式。當跳線帽套在針腳上時，該跳線為「短路」。若沒 有跳線帽套在針腳上，該跳線為「開啟」。圖例顯示當 3-pin 跳線的跳線蓋套 在 pin1 及 pin2 時，這兩個針腳皆為「短路」。 清除 CMOS 跳線 (CLRCMOS1) 清除 CMOS 預設 ( 請參閱第 1 頁，編號 3) 您可利用 CLRCMOS1 清除 CMOS 中的資料。若要清除及重設系統參數為預 設設定，請先關閉電腦電源，再拔下電源供應器的電源線。在等待 15 秒後， 請使用跳線帽讓 CLRCMOS1 上的 pin2 及 pin3 短路約 5 秒。不過，請不要在...
  • Page 133 1.4 板載排針及接頭 板載排針及接頭都不是跳線。請勿將跳線帽套在這些排針及接頭上。將跳線帽套 在排針及接頭上，將造成主機板永久性的受損。 系統面板排針 請依照以下的針腳排 (9-pin PANEL1) RESET# 列將機殼上的電源開 PWRBTN# ( 請參閱第 1 頁， 編號 8) 關、重設開關及系統 HDLED- PLED- 狀態指示燈連接至此 PLED+ HDLED+ 排針。在連接纜線之 前請注意正負針腳。 PWRBTN ( 電源開關 )： 連接至機殼前面板上的電源開關。您可設定使用電源開關關閉系統電源的方式。 RESET ( 重設開關 )： 連接至機殼前面板上的重設開關。若電腦凍結且無法執行正常重新啟動，按下重 設開關即可重新啟動電腦。 PLED ( 系統電源 LED)： 連接至機殼前面板上的電源狀態指示燈。系統正在運作時，此...

  • Page 134: Out_Ret

    H81M-ITX Serial ATA3 接頭 這兩組 SATA3 接頭皆 (SATA3_0： 支援內部儲存裝置的 請參閱第 1 頁，編號 9) SATA 資料纜線，最 (SATA3_1: 高可達 6.0 Gb/s 資料 請參閱第 1 頁，編號 10) 傳輸率。 USB 2.0 排針 除了 I/O 面板上的兩 DUMMY (9-pin USB10_11) 個 USB 2.0 連接埠外， ( 請參閱第 1 頁，編號 8) 在本主機板上還有另...
  • Page 135 機殼風扇接頭 請將風扇纜線連接至 +12V (4-pin CHA_FAN1) 風扇接頭，並比對黑 CHA_FAN_SPEED ( 請參閱第 1 頁， 編號 11) FAN_SPEED_CONTROL 線及接地針腳。 CPU 風扇接頭 本主機板配備 4-Pin GN D + 12V (4-pin CPU_FAN1) CPU 風扇 ( 靜音風扇 ) CPU_ FAN_SPEED FAN_SPEED_CONTROL ( 請參閱第 1 頁， 編號 6) 接頭。若您計畫連接 3-Pin CPU 風扇，請...
  • Page 136 1 Pendahuluan Terima kasih telah membeli motherboard ASRock H81M-ITX, yakni motherboard andal yang diproduksi di bawah kendali mutu ketat yang sejalan dengan ASRock. Motherboard ini memberikan performa luar biasa dengan desain canggih yang meneguhkan komitmen ASRock terhadap kualitas dan ketahanan.
  • Page 137 1.2 Spesifikasi Platform • Bentuk dan Ukuran Mini-ITX • Desain Kapasitor Solid • Mendukung Intel® CoreTM i7 / i5 / i3 Generasi Ke-4 / Xeon® / Pentium® / Celeron® dalam Paket LGA1150 • Desain 4 Fase Daya ® • Mendukung Teknologi Intel Turbo Boost 2.0 ®...
  • Page 138 H81M-ITX • Mendukung D-Sub dengan resolusi maksimum hingga 1920x1200 @ 60Hz • Mendukung Auto Lip Sync, Deep Color (12bpc), xvYCC, dan HBR (High Bit Rate Audio) dengan HDMI (memerlukan monitor HDMI yang kompatibel) • Mendukung fungsi HDCP dengan port DVI-D dan HDMI • Mendukung pemutaran Full HD 1080p Blu-ray (BD) dengan...
  • Page 139 Penyimpanan • 2 x Konektor SATA3 6,0 Gb/s, mendukung fungsi NCQ, AHCI, dan Hot Plug • 1 x Konektor eSATA, mendukung fungsi NCQ, AHCI, dan Hot Plug Konektor • 1 x Header Intrusi Chassis • 1 x Header TPM • 1 x Konektor kipas CPU (4-pin) • 1 x Konektor kipas chassis (4-pin) • 1 x Konektor daya ATX 24 pin • 1 x Konektor daya 12V 4 pin...
  • Page 140 H81M-ITX * Untuk informasi tentang produk rinci, kunjungi situs web kami: http://www.asrock.com Karena keterbatasan, ukuran memori sebenarnya mungkin kurang dari 4GB karena akan digunakan sistem berdasarkan sistem operasi Windows® 32-bit. Sistem operasi Windows® 64-bit tidak memiliki keterbatasan tersebut. Anda dapat menggunakan ASRock XFast RAM untuk memanfaatkan memori yang tidak dapat digunakan Windows®...
  • Page 141 1.3 Konfigurasi Jumper Gambar menunjukkan cara mengkonfigurasi jumper. Bila penutup jumper diletakkan pada pin, maka jumper akan “Pendek”. Jika tidak ada penutup jumper yang diletakkan pada pin, maka jumper akan “Terbuka”. Gambar menunjukkan jumper 3-pin, yakni pin1 dan pin2 menjadi "Pendek" bila penutup jumper diletakkan pada 2 pin tersebut. Clear CMOS Jumper (CLRCMOS1) Default...
  • Page 142 H81M-ITX 1.4 Header dan Konektor Onboard Header dan konektor terpasang BUKANLAH jumper. JANGAN letakkan penutup jumper pada header dan konektor tersebut. Meletakkan penutup jumper pada header dan konektor akan mengakibatkan kerusakan permanen pada motherboard. Header Panel Sistem Sambungkan switch daya,...
  • Page 143 Konektor Serial ATA3 Dua konektor SATA3 ini (SATA3_0: mendukung kabel data lihat hal. 1, No. 9) SATA untuk perangkat (SATA3_1: penyimpanan internal lihat hal. 1, No. 10) dengan kecepatan transfer data hingga 6,0 Gb/s. Header USB 2.0 Selain dua port USB DUMMY (USB10_11 9-pin) 2.0 pada panel I/O,...
  • Page 144 H81M-ITX Konektor Kipas Chassis Sambungkan kabel kipas +12V (CHA_FAN1 4-pin) ke konektor kipas, lalu CHA_FAN_SPEED (lihat hal. 1, No. 11) cocokkan kabel hitam FAN_SPEED_CONTROL dengan pin ground. Konektor Kipas CPU Motherboard ini GN D + 12V (CPU_FAN1 4-pin) memberikan konektor CPU_ FAN_SPEED (lihat hal.
  • Page 145 Header TPM Konektor ini mendukung sistem F_CLKRUN# (TPMS1 17-pin) TPM (Trusted Platform Module), SERIRQ# +3VSB S_PWRDWN# (lihat hal. 1, No. 12) yang dapat menyimpan kode LAD0_L kunci, sertifikat digital, sandi, dan LAD1_L LAD2_L LAD3_L data secara aman. Sistem TPM TPM_RST# SMB_DATA_MAIN juga membantu meningkatkan SMB_CLK_MAIN...

  • Page 146: Contact Information

    Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at http://www.asrock.com/support/tsd.asp...

Table of Contents
