QuickSpecs
Technical Specifications
Cabinet Configuration
System Unit
DA-10392
North America — Version 57 — March 18, 2003
H9A10 M-Series
Dimensions (H x W x D)
67 x 23.6 x 41.5 in/
(Depth includes rear door
170 x 60 x 105.4 cm
extender)
Shipping Dimensions
73 x 36 x 48 in/
185.5 x 91.5 x 122 cm
Weight
Configuration dependent
Shipping Weight
Nominal: 946 lb/430 kg
Maximum: 1,375 lb/625 kg
E
N V I R O N M E N T A L
Temperature
Operating
(Tower, Pedestal, Rackmount)
Non-operating
Storage (60 days)
Rate of change
NOTE: Maximum operating temperature at sea level; reduce by 1.8 F (1 C) for
Humidity
Operating
Non-operating
Storage (60 days)
Rate of change
Maximum Wet Bulb
Operating
Temperature
Storage (60 days)
Maximum Dew Point
Operating
Temperature
Heat Dissipation
Tower and Rack
Pedestal
H9A10/H9A15 Cabinets
Air Flow and Quality
Intake location
Exhaust location
Particle size
Concentration
Altitude (unpressurized)
Operating
Non-operating
NOTE: Higher altitudes are possible if maximum operating temperature is
Compaq AlphaServer ES40
Compaq AlphaStation ES40
H9A15 M-Series
79 x 23.6 x 41.5 in/
200 x 60 x 105.4 cm
85 x 36 x 48 in/
216 x 91.5 x 122 cm
Configuration dependent
Nominal: 1,056 lb/550 kg
Maximum: 1,408 lb/640 kg)
50 to 95 F/10 to 35 C
–40 to 151 F/–40 to 66 C
–40 to 151 F/–40 to 66 C
20 F/hr/11 C/hr
each 2,000 ft (600 m) above sea level.
20% to 80%
20% to 80%
10% to 95%
20% hr
82 F/28 C
115 F/46 C
36 F/2 C
Nominal
900 W, 3,074 BTU/hr 1300 W, 4,440 BTU/hr
1480 W, 5,054
BTU/hr
Configuration
dependent
Front
Rear Tower, Pedestal, Rack; Rear/top
H9A10/H9A15
N/A
N/A
10,000 ft/3,048 m
40,000 ft/12,192 m
reduced (see Temperature); other restrictions may apply such as
maximum permissible altitude for hard drives.
Maximum
2400 W. 8,196 BTU/hr
4800 W, 16,392 BTU/hr
37
