Mophie Juice Pack Air for iPhone 4 User Manual

Product
juice pack air
Compatibility
Made for iPhone 4
Box Contents juice pack air, Micro USB Cable, Manual
The juice pack air
Features
The mophie juice pack air extends the battery
life of your iPhone for hours and provides a
comfortable ergonomic design with the
complete protection of a hard shell case.
Here's a rundown of why the juice pack air
is so fantastic:
1. (Take a breath) Ergonomic, form-fitting, fully
protective impact-resistant case-and-battery-
in-one for iPhone.
2. Integrated power switch allows you to put
the juice pack air in standby mode. Only use
the battery when you need it. In standby mode
(red), the juice pack air still allows charge and
sync capabilities through the micro-USB port
and still offers the complete protection of a case.
3. Uses breakthrough rechargeable lithium
polymer battery. (Much safer than those
troublesome lithium-Ion batteries).
4. State-of-the-art battery technology extends
the life of your iPhone for hours... and you can
even recharge it while it's still connected to the
iPhone! This battery rocks.
5. Track battery power status at a glance with
an integrated 4-light LED status indicator.
Indicates charging mode and current battery
life. Know before you go!
6. It's the included USB micro cable connection
that allows you to charge and sync your iPhone
while refilling your juice pack at the same time
Really, you don't ever have to disconnect the
juice pack, though it's a snap when you do.
7. Rechargeable for over 500 cycles. (These are
FULL cycles. Partial cycles don't count as full.
So, you can charge your juice pack 10% of the
way ten times before you get to a complete
cycle. Don't be afraid to top it off.)
8. Smart battery technology actually instructs
the iPhone to drain out the juice pack first.
When you're done with the juice pack you can
pull it off and still have a fully charged iPhone.
9. The juice pack air offers complete protection
from top to bottom. No more choosing
between protection and power.
10. Built-in short circuit, over-charge and
temperature protection. Safety First!
mophie juice pack air Printable Manual
Made for iPhone 4 User Manual
Compatibility
Though the juice pack air for iPhone 4 comes
with a standard iPod/iPhone connection pin,
this battery is intended solely for use with the
Apple iPhone. 4. Please do not attempt to use
the product with any other device - things
could go haywire, but contact us if they do.
Charging your juice pack air
Connect the juice pack to a power source using
the micro USB cable that came with your juice
pack. The USB cable can be plugged in to your
computer or any "Made for iPhone" wall-plug
style power source with USB out including the
standard iPhone USB wall adaptor. (The LEDs
located on the back of the device will blink
when charging, as the juice pack becomes
more charged the LEDs will indicate how full
it is, but one LED will remain blinking until
completely full.)
Important
The juice pack air comes charged and ready to
go, but after the initial use, normal charging
will take only 2 to 3 hours for maximum power
– AND you can then charge it while the iPhone
is inserted or separately.
Charging your iPhone 4 using the juice pack air
If your iPhone is drained of power or if you want
to extend the battery life of your iPhone, simply
slide the iPhone into the juice pack air. Make
sure that the pin connector is securely inserted
into the bottom of the iPhone and the switch is
turned On (green). When the iPhone recognizes
the juice pack, a battery symbol will appear on
the screen and you will hear a chirp from the
iPhone, this indicates that the iPhone is
charging and/or using the power from the juice
pack rather than from the iPhone itself.
If your iPhone is drained of power, the juice
pack will first charge your iPhone. If your iPhone
is fully charged, the juice pack will act as your
primary battery and no power will be lost from
the iPhone internal battery until the juice pack
is depleted. So you keep on talkin' , rockin' ,
surfin' and sendin'!
Checking the status of the juice pack air
You are always in the KNOW! To check the
battery status of the juice pack, press the
button located on the bottom of the device.
When pressed, the LED lights will illuminate for
several seconds. Four LEDs means that the
juice pack is fully charged, and one LED means
that it is almost empty.
Stand-by mode
If you'd rather use your internal battery and
not the juice pack, use the switch on the
lower-left corner of the juice pack, to put it into
stand-by mode. The dot near the switch will
indicate whether the juice pack is in stand-by
mode (red) or charging mode (green). When
your internal battery is low, simply flick the
switch On and your iPhone will begin charging
immediately.
*Note:
Using the stand-by switch will give you
even more total battery life, as the iPhone uses
additional power to be on a constant charge.
Sync with your computer without removing
While connected to the juice pack air, you can
still sync your iPhone with a computer. Simply
connect the included micro USB cable from the
juice pack air to the computer and sync your
iPhone the same as if it was directly connected.
To keep your juice pack air operating to its
fullest potential, make sure to do the following:
1. Keep your juice pack dry and away from
moisture and corrosive materials.
2. Do not wash the juice pack with harsh
chemicals, soaps or detergents. Just wipe the
case with a soft, water-dampened cloth. Wipe
the pins gently with a soft, dry cloth.
3. Re-charge your juice pack once every three
months when not in use, and remember to
charge it for one hour before putting it away
the first time.
Warranty
At mophie, we are dedicated to making the
best quality products we can. To back this up,
your juice pack is warranted for 1 full year from
the date of purchase. Be sure to register your
product at mophie.com to activate it and check
for the latest product updates as they develop.
Customer Service
Telephone: 888.8mophie
Web Contact: www.mophie.com/cs
Service Hours: 9am to 6pm M-F ET
© mophie 2010 www.mophie.com
