RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE. INSTALLER – LEAVE THESE
Specifications
YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS SO PLEASE READ THESE INSTRUCTIONS
GENERAL HAZARD WARNING:
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION. SERVICE, OR MAINTENANCE CAN CAUSE
INJURY OR PROPERTY DAMAGE. READ THE INSTALLATION, OPERATING AND MAINTENANCE
INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.
WARNING: FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID COMBUSTIBLES, SUCH
AS BUILDING MATERIALS, PAPER OR CARDBOARD, A SAFE DISTANCE AWAY FROM THE HEATER AS
RECOMMENDED BY THE INSTRUCTIONS. NEVER USE THE HEATER IN SPACES WHICH DO OR MAY
CONTAIN VOLATILE OR AIRBORNE COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE, PAINT
THINNER, DUST PARTICLES OR UNKNOWN CHEMICALS.
0253700 - 0296656
Page 1 of 11
INSTRUCTIONS AND PARTS LIST
INSTRUCTIONS WITH THE CONSUMER
PATIO HEATER
MODELS: MH40PH
LP GAS-FIRED OUTDOOR PATIO HEATER
40,000 BTU/HR
BEFORE YOU OPERATE THIS HEATER.
ENERCO / MR. HEATER
th
4560 W. 160
TEL: 1-800-251-0001
Type of Gas
Input rating
Manifold Pressure
Regulator Pressure
Orifice Size
Maximum Supply Pressure
Minimum inlet supply pressure
St., CLEVELAND, OHIO 44135
FAX: 1-800-321-0552
For use with Propane Only
40,000 Btu/Hr
10.7" Water Column
11.0" Water Column
1.95mm
150psig
5psig
06/08 Rev A
