Summary of Contents for Philips 28PT5107/01
-
Page 3: Table Of Contents
Introduction Thank you for purchasing this television set. This handbook has been designed to help you install and operate your TV set. We would strongly recommend that you read it thoroughly. We hope our technology meets entirely with your satisfaction. Table of Contents Installation Installing your television set . -
Page 4: Installation
Installing your television set & “ Positioning the television set Remote control 5 cm 5 cm 5 cm Place your TV on a solid, stable surface, leaving Insert the two R6-type batteries (supplied) a space of at least 5 cm around the appliance. making sure that they are the right way round. -
Page 5: Remote Control Keys
Remote control keys Screen information / permanent no. To display / clear the program number, Radio / TV mode name (if it exists), time, audio mode and To switch the TV set to radio or time remaining for the sleep feature. TV mode (for versions equipped Press the key for 5 seconds to activate with radio). -
Page 6: Quick Installation
Quick installation search and the number of programs found. The first time you switch on the television, a menu appears on the screen and the tuning At the end of the search, the menu disappears. To exit or interrupt the search, press starts automatically. -
Page 7: Manual Store
Manual store This menu is used to store the programmes * Except for France (LL’ standard), you must select choice France. one at a time. ¬ ‘ Search: press & Press the key. .The search starts. Once a é With the cursor, select the Install menu then programme is found, the scanning stops and its name is displayed (when available). -
Page 8: Picture Settings
Picture settings “ Once the adjustments have been made, select ¬ & Press then .The menu is Picture ¬ and press to store them. Press Store displayed: to exit. Description of the adjustments: Picture Mainge • Brightness: this changes picture brilliance. $ Picture Brightness --I------ 39... -
Page 9: Timer Function
Timer function (only available on certain versions) This menu lets you use the TV set as an alarm. ( Start Time: enter the start time. & Press the key. § Stop Time: enter the standby time. é With the cursor, select the Options menu then è... -
Page 10: Teletext
Teletext Teletext is an information system broadcast by certain channels which can be consulted like a newspaper. It also offers access to subtitles for viewers with hearing problems or who are not familiar with the transmission language (cable networks, satellite channels, etc.). Press : You will obtain: Teletext call... -
Page 11: Video Recorder
Connecting peripheral equipment Depending on the versions, the TV set will be equipped with 1 or 2 SCART connectors EXT1 and EXT2 located on the rear. The EXT1 socket has audio, CVBS/RGB inputs and audio, CVBS outputs.The EXT2 socket (if available) has audio, CVBS/S-VHS inputs and audio, CVBS outputs. Video recorder Carry out the connections shown opposite, using a good quality euroconnector cable. -
Page 12: Tips
Tips Poor reception No sound The proximity of mountains or high buildings If on certain channels you receive a picture may be responsible for ghost pictures, echoing but no sound, this means that you do not have or shadows. In this case, try manually adjusting the correct TV system. -
Page 13: Glossary
Glossary RGB Signals: These are 3 Red, Green and Blue video signals which directly drive the red, green and blue emitters in the cathode ray tube. Using these signals provides better picture quality. S-VHS Signals: These are 2 separate Y/C video signals from the S-VHS and Hi-8 recording standards.The luminance signals Y (black and white) and chrominance signals C (colour) are recorded separately on the tape.This provides better picture quality than with standard video (VHS and 8 mm) where the Y/C signals are combined to provide only one video signal. -
Page 14: Information For Users In The Uk
IMPORTANT Information for users in the UK (not applicable outside the UK) Positioning the TV For the best results, choose a position where light does not fall directly on the screen, and at some distance away from radiators or other sources of heat. Leave a space of at least 5 cm all around the TV for ventilation, making sure that curtains, cupboards etc. -
Page 15: Table Of Frequencies
Table of TV frequencies EUROPE EASTERN EUROPE FRANCE ITALY CHANNEL ....FREQ (MHz) CANAL ....FREQ (MHz) CANAL ....FREQ (MHz) CANALE ....FREQ (MHz) E2......48.25 R1 ......49.75 2......55.75 A ......53.75 E3......55.25 R2 ......59.25 3......60.50 B ......62.25 E4......62.25 R3 ......77.25 4......63.75 C ......82.25 E5.......175.25 R4 ......85.25 5......176.0 D ......175.25... - Page 16 ß...
