Summary of Contents for Electrolux ER 7626 B
- Page 1 - f r e e z e r s INSTRUCTION BOOK ER 7626 B 2222 039-28...
-
Page 2: Important Safety Information
Refer to your local refrigerant to settle. Electrolux Service Force Centre and always insist on genuine spare parts. Child Safety At the end of the •... -
Page 3: Table Of Contents
CONTENTS Instructions for the User Instructions for the Installer Important Safety Information Technical Specification Description of the Appliance Installation Operation Positioning Before use Rear Spacers To start the Appliance Setting the temperature Electrical Connection Use of an air circulation slider control Door Reversal Fresh food refrigeration Movable shelves... -
Page 4: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE COOL FLOW CONTROL 10 - 10 - 10 - 10 - 3 - 4 A- Thermostat control for fridge and freezer compartments B- Dairy compartment C- Movable shelf D- Bottle storage shelf E- Air circulation slider control F- Wire shelves G- Glass shelf H- Salad drawers... -
Page 5: Operation
OPERATION Before using Use of an air circulation slider control - COOL FLOW CONTROL Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of Your appliance has an air circulation slider control soda (5 ml to 0.5 litre of water). situated at the rear of the fridge compartment, which Do not use soap or detergent as the smell may controls the amount of cold air circulated through the... -
Page 6: Movable Shelves
Warning If using the appliance with the salad drawer removed, please ensure the vent in the back wall of the appliance is not obstructed. D756 Movable shelves The walls of the refrigerator have runners so that shelves can be positioned as desired. D040 The door shelves can be easily removed for cleaning. -
Page 7: The Freezer Compartment
The freezer compartment Thawing The four-star freezer compartment is suitable for Frozen food can be thawed in the fridge or at room storage of commercially frozen food and for freezing temperature depending on the time available. Small fresh foods. food items may even be cooked from frozen; in this case cooking will take longer. -
Page 8: Normal Operating Sounds
Normal Operating Sounds The advanced design of today’s frost free appliances means you hear unfamilar noises during everyday operation. The diagram below describes some of the noises you may hear. These are quite normal and your appliance is operating correctly The thermostat control will click when starting or stopping the compressor. -
Page 9: Health And Safety Guidelines
HEALTH AND SAFETY GUIDELINES Because of consumer demand, preservatives have been removed from many pre-prepared foods. This together with the changes in shopping habits to a once-a-week shop, mean that safe handling and storage of food is even more important than ever. The following tips should help you to ensure that the food in your home is in as perfect condition as possible. -
Page 10: Maintenance And Cleaning
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried Changing the light bulb out, DISCONNECT the appliance from the ELECTRICITY supply. Should the interior light fail to work, first switch off the appliance and disconnect from the electricity Internal cleaning supply, then replace the bulb as follows;... -
Page 11: Something Not Working
SOMETHING NOT WORKING Before contacting your local Service Force Centre, check the following points: Important: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee. Symptom Solution No power to the appliance... -
Page 12: Service And Spare Parts
Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. CUSTOMER CARE DEPARTMENT For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.electrolux.co.uk... -
Page 13: Guarantee Conditions
Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. -
Page 14: Technical Specification
TECHNICAL SPECIFICATIONS DIMENSIONS Height Width Depth POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz TOTAL POWER ABSORBED 150 W AVERAGE DAILY UNITS ELECTRICITY * 1.5 kWh GROSS CAPACITY Fridge 135 l Freezer 121 l NET CAPACITY Fridge 134 l Freezer 90 l This figure is based on standard test results in accordance with European Standard EN 153. -
Page 15: Installation
INSTALLATION Depending upon the position which you choose for your appliance, you may wish to reverse the way in Warning which the door opens. To do this, refer to instructions IF YOU ARE DISCARDING AN OLD APPLIANCE on “Door reversal directions” paragraph. THAT HAS A LOCK OR CATCH ON THE DOOR, Important YOU MUST ENSURE THAT IT IS MADE... -
Page 16: Electrical Connection
For replacement, use a 13amp BSI362 fuse. Only Electrical connections ASTA or BSI approved fuses should be used. The plug must not be used if the fuse cover/carrier is Any electrical work required to install this appliance lost. The cover/carrier is indicated by the coloured should be carried out by a qualified electrician or insert at the base of the plug. -
Page 17: Door Reversal
Door reversal directions 1. Disconnect from the electricity supply. 2. Remove all loose items, including food, store food in a cool place. 3. Gently lay the fridge/freezer on its back with the top held away from the floor by 5-8 cm (2-3 inches) of packing. - Page 20 © Electrolux plc 2002...
