PLASMA MONITOR (DISPLAY)
WALL HANGER UNIT
Thank you for purchasing the Daewoo Electronic Plasma Display Wall Hanger Unit. This
wall unit is specifically designed for use with the Daewoo Plasma Display (DSP-4210GM).
To ensure the safe operation of the unit, please read these instructions before installing.
INSTRUCTION MANUAL
DSP-HG10
H W
A A
N L
G L
E
R
U
N
I
T
Advertisement
Related Manuals for Daewoo DSP-HG10
Summary of Contents for Daewoo DSP-HG10
-
Page 1: Instruction Manual
PLASMA MONITOR (DISPLAY) WALL HANGER UNIT Thank you for purchasing the Daewoo Electronic Plasma Display Wall Hanger Unit. This wall unit is specifically designed for use with the Daewoo Plasma Display (DSP-4210GM). To ensure the safe operation of the unit, please read these instructions before installing. - Page 2 TABLE OF CONTENTS 1. Check for enclosed parts ......2 2. Important Safety Instructions ......3 3. Assembly Instructions ........6 4. Adjusting angles after installation ....12 To install the wall hanger unit, Please consult an Authorized service center first.
- Page 3 PLASMA DISPLAY HANGER UNIT 1. PLEASE CHECK THE ITEMS SHOWN BELOW FRAME SET A FRAME SET B CONNECTING FRAME CONCRETE WALL ANCHOR M5 SCREWS (20 MM) WALL SCREWS (12) PAPER PATTERN PLAN M5 SCREWS (30MM) Paper pattern plan...
-
Page 4: Important Safety Instructions
Do not use the wall hanger unit with other products. This wall hanger unit (HSP-HG10) is specifically designed to fit the Daewoo Plasma Display (DSP-4210GM). (Failing to do so may cause the unit to fall and break) (Failing to do so may cause the unit to fall and break) - Page 5 PLASMA DISPLAY HANGER UNIT PLEASE FOLLOW THESE SAFETY PRECAUTIONS WHEN INSTALLING OR HANDLING Special care is needed when installing onto the When installing, please wear working gloves. wall due to its weight (35Kg) When installing on a concrete wall Please be sure to use the enclosed concrete anchors.
- Page 6 PLEASE FOLLOW THESE SAFETY PRECAUTIONS WHEN INSTALLING OR HANDLING When installing, please use the size referenced below to choose a place, and attach the paper pattern plan to the wall. 527.5 527.5 Paper pattern plan Measurement unit : mm It is important to use the paper pattern plan to choose the proper place; otherwise, it can result in damage to the wall and you will not be able to install the unit When installing, please allow at least 15 cm at the top, bottom, left and right on the wall, and clear all items away from where the unit will be.
-
Page 7: Assembling Instructions
PLASMA DISPLAY HANGER UNIT 3. ASSEMBLING INSTRUCTIONS PREPARATION WHEN THE PLASMA DISPLAY IS ATTACHED TO THE STAND TO DETACH THE STAND FROM THE PLASMA DISPLAY To avoid unwanted marks on the unit, place Unscrew the secured 2 screws completely a protective covering over the surface you and Pull the stand away from the plasma will be working on and lay the plasma display to detach. - Page 8 INSTALLING THE WALL FRAME SET A ON THE PLASMA DISPLAY HOW TO DISPOSE OF THE PLASMA MONITOR WRAPPER First discard the wrapping band and Afterwards, dispose of the Styrofoam raise the top box to open. and remove the vinyl covering. HOW TO INSTALL FRAME SET A ON THE UNIT To avoid unwanted marks on the unit, place Place frame set A on the left and right...
- Page 9 PLASMA DISPLAY HANGER UNIT INSTALLING WALL FRAME SET B AND CONNECTING FRAME INSTALLING WALL FRAME SET B AND CONNECTING FRAME. Frame set B Place frame set B on the left and right side of Connecting Frame the unit and use the enclosed screws (M5) to secure them tightly.
- Page 10 INSTALL THE WALL FRAME SET ON THE WALL Install the wall frame set on the wall by matching the concrete anchors with the holes, then use the wall screws (8) to secure tightly. INSTALLING ON THE WALL HELD BY SUPPORTING WOODEN STRUCTURE If it is not feasible to attach frame set B firmly and completely, due to the distance between the two supporting woods;...
- Page 11 PLASMA DISPLAY HANGER UNIT INSTALLING PLASMA DISPLAY ON THE WALL CONNECTING UPPER PART OF FRAME SET A AND FRAME SET B Insert the upper part of frame set A (X) to frame set B (Y) as indicated below. Frame set B Frame set A At least two people are needed to put these frames together.
- Page 12 TO PROVIDE THE SECUREST FIT After installing plasma display and wall frame sets, for a more secure fit, secure M5 screws (M5x30) on the (Z) part so that (Z) will not move up and down as shown in the picture below.
- Page 13 PLASMA DISPLAY HANGER UNIT 4. ADJUSTING ANGLES AFTER INSTALLATION (10˚, 15˚, 20˚) HOW TO ADJUST VIEWING ANGLES Take out the screws from the upper part of the frame. Insert the upper part of the frame set B angle adjustment lever to its gap.
