- Page 1 Product Manual Seagate 600 SSD ® Standard 2.5” 7mm Standard 2.5” 5mm Usage Based models Usage Based models ST480HM001 ST480HM000 ST240HM001 ST240HM000 ST120HM001 ST120HM000 100722309 Rev. A April 2013...
- Page 2 Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Seagate 600 SSD and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.All other trademarks or registered trademarks are the property of...
-
Page 3: Table Of Contents
Seagate Technology Support Services ........ - Page 4 IGURES Figure 1. Typical 5V Startup and Operation Current Profile ........10 Figure 2.
-
Page 5: Seagate Technology Support Services
• Authorized Service Centers Warranty terms will vary based on type of warranty chosen: “Managed Life” or “Usage Based”. Consult your Seagate sales representative for warranty terms and conditions. For information regarding data recovery services, visit http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit: http://www.seagate.com/partners/... -
Page 6: Introduction
NTRODUCTION ® This manual describes the functional, mechanical and interface specifications for the following Seagate 600 SSD model drives: 2.5" Usage Based 7mm Model 2.5" Usage Based 5mm Model ST480HM000 ST480HM001 ST240HM000 ST240HM001 ST120HM000 ST120HM001 These drives provide the following key features: •... -
Page 7: Drive Specifications
If you are designing a system which will use one of the models listed or future generation products and need further assistance, please contact your Customer Technical Support Engineer or our global support services group as shown in See “Seagate Technology Support Services” on page 1. -
Page 8: Formatted Capacity
*One GB equals one billion bytes when referring to drive capacity. Accessible capacity may vary depending on operating environment and formatting. **Warranty terms are “Usage Based”, see Warranty information in Section 2.10.2 or consult your Seagate sales representative for warranty terms and conditions. -
Page 9: Performance, Recording And Interface Technology
ERFORMANCE ECORDING AND INTERFACE TECHNOLOGY 2.4.1 Interface technology 480GB models 240GB models 120GB models Interface Serial ATA (SATA-II) Interface Speeds Supported 6Gb/s, 3Gb/s, 1.5Gb/s Maximum Burst Transfer Rate 600MB/s Hot Plug Support Native Command Queuing Support Trim Support 2.4.2 Recording technology Flash Memory Type NAND MLC Emulated LBA Size (Bytes) -
Page 10: Physical Characteristics
HYSICAL CHARACTERISTICS ST480HM000, ST240HM000 ST480HM001, ST240HM001 & ST120HM000 & ST120HM001 Maximum height 7.00 mm (0.276 in) 5.00 mm (0.197 in) Maximum width 70.10 mm (2.760 in) Maximum length 100.45 mm (3.955 in) Max weight 77 g (0.170lb) 67 g (0.148 lb) -
Page 11: Power Specifications
OWER SPECIFICATIONS The drive receives DC power (+5V) through a native SATA power connector. See 2 on page 16. 2.7.1 Power consumption Power requirements for the drives are listed in the table on page 9. Typical power measurements are based on an average of drives tested, under nominal conditions, at 35°C ambient temperature. - Page 12 Table 3 240GB DC power requirements Parameter ST240HM000, ST240HM001 (6.0Gb) Voltage Power Regulation +/- 5% (watts) Average Idle Current 0.22 1.10 Average Sleep Current 0.10 0.50 Maximum Start Current 0.95 DC (Peak DC) 0.52 AC (Peak AC) 0.38 Peak Operating Current (random read): Typical DC 0.32 1.57...
- Page 13 Table 4 120GB DC power requirements Parameter ST120HM000, ST120HM001 (6.0Gb) Voltage Power Regulation +/- 5% (watts) Average Idle Current 0.22 1.10 Average Sleep Current 0.10 0.50 Maximum Start Current 0.95 DC (Peak DC) 0.54 AC (Peak AC) 0.70 Peak Operating Current (random read): Typical DC 0.34...
-
Page 14: Figure 1. Typical 5V Startup And Operation Current Profile
2.7.2.1 Typical current profiles Figure 1. Typical 5V Startup and Operation Current Profile 600 SSD P EAGATE RODUCT ANUAL... -
Page 15: Environmental Specifications
NVIRONMENTAL SPECIFICATIONS 2.8.1 Temperature Temperature is defined as the drive's internal temperature as reported by SMART attribute 194 for operation or the drive case temperature for non-operating. Above 1000 feet (305 meters), the maximum temperature is derated linearly to 112°F (44°C) at 10,000 feet (3048 meters). Operating: 0°... -
Page 16: Electromagnetic Immunity
2.8.6.1 Operating vibration The maximum random vibration levels that the drive may experience while meeting the performance standards specified in this document are specified below. This specification does not cover connection issues that may result from testing at this level. 20–2000 Hz 11.08 Grms 2.8.6.2... -
Page 17: Reliability
(at nominal voltage and temperature, with 60 cycles per hour and a 50% duty cycle) Warranty Warranty terms are “Usage Based” Consult your Seagate sales representative for warranty terms and conditions. Preventive maintenance None required. Typical Data Retention with Power removed (at 40°C) -
Page 18: Agency Certification
As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate Technology LLC has tested this device in enclosures as described above to ensure that the total assembly (enclosure, drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. -
Page 19: Environmental Protection
The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. -
Page 20: Configuring And Mounting The Drive
For installations which require cables, you can connect the drive as illustrated in 2. Signal connector Power connector Signal cable Power cable Figure 2. Attaching SATA cabling Each cable is keyed to ensure correct orientation. Seagate 600 SSD drives support latching SATA connectors. 600 SSD P EAGATE RODUCT ANUAL... -
Page 21: Drive Mounting
RIVE MOUNTING You can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom- mounting holes. Follow these important mounting precautions when mounting the drive: • Allow a minimum clearance of 0.030 in (0.76 mm) around the entire perimeter of the drive for cooling as a guideline. Please refer to Section 3.5 for final cooling requirements. -
Page 22: Figure 4. Mounting Configuration Dimensions (5Mm Models)
Note. These dimensions conform to the Small Form Factor Standard documented in SFF-8120 and SFF-8146 found at www.sffcommittee.org. Figure 4. Mounting configuration dimensions (5mm models) 600 SSD P EAGATE RODUCT ANUAL... -
Page 23: Cooling
OOLING Cabinet cooling must be designed by the customer so that the ambient temperature immediately surrounding the drive will not exceed temperature conditions specified in Section 2.8.1, "Temperature." The rack, cabinet, or drawer environment for the drive must provide heat removal. You should confirm that adequate heat removal is provided using the temperature measurement guidelines described in Section 2.8.1. -
Page 24: Serial Ata (Sata) Interface
For detailed information about the Serial ATA interface, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. LUG COMPATIBILITY Seagate 600 SSD drives incorporate connectors which enable you to hot plug these drives in accordance with the Serial ATA II: Extension to Serial ATA 1.0a specification. This specification can be downloaded from www.serialata.org. ERIAL DEVICE PLUG CONNECTOR PIN DEFINITIONS Table 6 summarizes the 2.5”... - Page 25 Power 5V power to Drive LED Signal Activity LED: Driven low to light Keyway Optional Reserved for Seagate use. Leave unconnected. Optional Notes: Ground pins 3 and 4 mate first on micro SATA backplane connectors The two V pins are unused but connected together on the drive. They can be used for a drive-in-place detection.
-
Page 26: Supported Ata Commands
UPPORTED COMMANDS The following table lists Serial ATA standard commands that the drive supports. For a detailed description of the ATA commands, refer to the Serial ATA: High Speed Serialized AT Attachment specification. See “S.M.A.R.T. commands” on page 31for details and subcommands used in the S.M.A.R.T. implementation. Table 8 Supported ATA commands OMMAND NAME OMMAND CODE... - Page 27 OMMAND NAME OMMAND CODE IN HEX Set Multiple Mode Sleep S.M.A.R.T. Disable Operations / D9 S.M.A.R.T. Enable Operations / D8 S.M.A.R.T. Execute Offline / D4 S.M.A.R.T. Read Data / D0 S.M.A.R.T. Read Log Sector / D5 S.M.A.R.T. Return Status / DA S.M.A.R.T.
-
Page 28: Identify Device Command
4.3.1 Identify Device command The Identify Device command (command code EC ) transfers information about the drive to the host following power up. The data is organized as a single 512-byte block of data, whose contents are shown in Table 8 on page 22. All reserved bits or words should be set to zero. - Page 29 ESCRIPTION ALUE Minimum PIO transfer cycle time without flow control (120ns) 0078 Minimum PIO transfer cycle time with IORDY flow control (120ns) 0078 Additional Features and Commands supported. 0100 Trim Features supported, DMA commands supported Reserved 0000 71–74 Reserved for ATAPI 0000 Queue depth 001F...
- Page 30 ESCRIPTION ALUE Obsolete 0000 Security status 0001 129–159 Vendor specific xxxx 160–167 Reserved for the CompactFlash Association 0000 Device Nominal Form Factor 0003 DATA SET MANAGEMENT features supported 0001 170–173 Additional Product Identifier (ATA String) 0000 174–175 Reserved 0000 176–197 Reserved 0000 198–199...
- Page 31 Word 69 Read zero after Trim is supported Optional ATA 28-bit commands supported Download Microcode DMA supported Set Max Password DMA and Set Max Unlock DMA supported Write Buffer DMA Supported Read Buffer DMA Supported DEVICE CONFIGURATION IDENTIFY DMA and DEVICE CONFIGURATION SET DMA are supported Long Physical Sector Alignment Error Reporting Control is supported Deterministic read after Trim is supported...
- Page 32 Word 83 DOWNLOAD MICROCODE command is supported Obsolete CFA feature set is supported APM feature set is supported Obsolete PUIS feature set is supported SET FEATURES subcommand is required to spin-up after power-up Reserved SET MAX security extension is supported AAM feature set is supported 48-bit Address feature set is supported DCO feature set is supported...
- Page 33 Word 87 SMART error logging is supported SMART self-test supported The Media Card Pass Through Command feature set is supported The GPL feature set is supported WRITE DMA FUA EXT and WRITE MULTIPLE FUA EXT commands are supported The 64-bit World wide name is supported The IDLE IMMEDIATE command with UNLOAD FEATURE is supported Shall be set to one Shall be cleared to zero...
-
Page 34: Set Features Command
4.3.2 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted. -
Page 35: Commands
SSD Percentage Endurance Remaining Indicator An application can interrogate the drive through the host to determine an estimate of the percentage of device life that is remaining. Seagate SeaTools diagnostic software has the capability to report the indicator value. 600 SSD P... - Page 36 NDEX ACA 14 FCC verification 14 acceleration 12 features 2 Agency certification 14 Federal Communications Commission 14 air flow Flush Cache 22 illustrated 19 Flush Cache Extended 22 altitude 11 Formatted capacity 4 ambient temperature 7 Annualized Failure Rate (AFR) 13 ATA commands 22 geometry 4 Australia/New Zealand Standard AS/NZ CISPR22 14...
- Page 37 Nonoperating vibration 12 Sanitize Freeze Lock Ext 22 NOP 22 Sanitize Status Ext 22 SATA 20 screws 11 Seagate Technology Support Services 1 Operating shock 11 Sectors per track 4 Operating vibration 12 Security Disable Password 22 Security Erase Prepare 22...
- Page 38 NDEX Write Multiple Extended 23 Write Multiple FUA Extended 23 Write Sectors 23 Write Sectors Extended 23 write uncorrectable 23 600 SSD P EAGATE RODUCT ANUAL...
- Page 39 Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100722309, Rev.
