PYLE Audio PYM1298 Owner's Manual

Part Number
Comments
Re
Le
QM
QE
QT
Xmax
Pmax
Bl
Coil Diameter
Gap Height
Efficiency
*Please note : Customer assumes responsibility for power testing each design per application. Eminence Speaker LLC does not power test samples. The ratings above
are a general guideline based upon known thermal capacity of voice coil diameters/materials. True power handling depends on many driver and system factors, thus
our guidelines are conservative in nature.
Parameter Date 8/3/2004 1:58:36 PM
PYM1298BLK
0431E PRODUCTION RUN
5.16 Ohms
0.54 mH
6.76
0.31
0.30
3.18 mm
300 Watts
14.15 Tm
3.00 Inches
0.375 Inches
3.01 %
Reference Number
121961A
fs
Mms
Mmd
Cms
Rms
Vas
SD
VD
EBP
Magnet Weight
Winding Width
SPL
44.2 Hz
43.1 grams
36.4 grams
0.301 mm/N
1.770
N*sec/m
111.2 liters
509.9 cm^2
161.9 cm^3
143.5
80 ounces
0.625 inches
96.8
dB 1W-1m
