Summary of Contents for Wharfedale Pro Q Series
- Page 1 Q Series Equalizers Q Series Equalizers OPERATING MANUAL AND USER GUIDE Q Series Q130 / Q215 / Q230 www.wharfedalepro.com...
-
Page 2: Important Warnings & Safety Instructions
OPERATING MANUAL AND USER GUIDE IMPORTANT WARNINGS & SAFETY INSTRUCTIONS 1. READ ALL INSTRUCTIONS carefully and become familiar with the features and functions of these products before operating them. 2. RETAIN THESE INSTRUCTIONS for future reference. 3. COMPLY WITH ALL WARNINGS – All warnings and instructions for this product should be adhered to. 4. -
Page 3: Table Of Contents
Series TABLE OF CONTENTS 1. Important Warnings & Safety Instructions……………………………..…….…1 2. What about the Q Series Equalizers?………………………………..….…..3 3. Introduction/Overview…………………………….……….........4 4. Features……………………….…………………………………….……………..5 5. Setting up/ Connections/ Wiring……………………………………....7 6. Specifications…………………………………….………………………….……….11 7. Dimensional Drawings……………………………………........12 8. Warranty…………………………..……..…………………………..……....12... -
Page 4: What About The Q Series Equalizers
OPERATING MANUAL AND USER GUIDE WHAT ABOUT THE Q Series Equalizers? The Q Series consists of three models: Q130 is a high quality, constant Q, 1/3 octave, Graphic Equalizer; The Q215 is a high quality constant Q, 2/3 Octave Equalizer and the Q230, dual channel, constant Q, 1/3 Octave Equalizer. -
Page 5: Introduction/Overview
Series INTRODUCTION Wharfedale Q Series Equalizers are the result of many years of experience in the use, design and manufacturing of professional sound reinforcement products. We take great pride in engineering and building every Wharfedale Pro product and wish to thank you for entrusting us with your sound. -
Page 6: Features
OPERATING MANUAL AND USER GUIDE FEATURES ♦ Three models o Q-230: Two Channel 30 band, 1/3 Octave Equalizer o Q-130: Single Channel 30 band, 1/3 Octave Equalizer o Q-215: Two Channel 15 band, 2/3 Octave Equalizer ♦ Constant Q ♦ By-pass switch ♦... -
Page 7: Block Diagram
Series BLOCK DIAGRAM TYPICAL WIRING DIAGRAM FOR THE Q130 CROSSOVER IN SYSTEM SETUP SIGNAL INPUT MIXER OUTPUTS FROM GRAPHIC MIC, CD etc. TO MIXER OUTPUT EQUALISER TO CROSSOVER INPUT TO GRAPHIC EQUALISER SEPARATE HIGH/MID AND LOW OUTPUTS TO INPUTS TO CROSSOVER AMPLIFIER(S) FROM CROSSOVER... -
Page 8: Setting Up/ Connections/ Wiring
The Q Series Equalizers are easy to install and operate. Before plugging in the Q Series Equalizers, or any electrical audio device, be sure that the power switch is in the off position, the volume control is all the way down (at 0 level) and all audio connections are made. - Page 9 Series Gain Stage Adjustments: • Plug the mic in and position the volume control at ´0´ (zero) dB. Keep the main output volume down as well as the other components volume controls. • Whilst watching the meters, speak or sing (it’s always good to warm up your voice) into the mic in the same way as your performance and adjust the GAIN control, usually at the top of the mixer channel near the mic input jack, to the point where the meters spend a lot of time at or near the ´0dB´...
- Page 10 OPERATING MANUAL AND USER GUIDE Tuning the Room: A graphic equalizer is a very valuable tool for the traveling musician. It allows you to get the best sound in a variety of venues. As we know, all rooms are not created equal. They have their own personality.
- Page 11 Series Q Series with connections shown...
-
Page 12: Specifications
OPERATING MANUAL AND USER GUIDE SPECIFICATIONS Q-215 Q-230 Q-130 INPUT/ OUTPUT Connectors: 1/4" TRS, female XLR 1/4" TRS, female XLR 1/4" TRS, female XLR (pin 2 hot) (pin 2 hot) (pin 2 hot) Type: Electronically balanced/ Electronically balanced/ Electronically balanced/ unbalanced, RF filtered unbalanced, RF filtered unbalanced, RF filtered... -
Page 13: Dimensional Drawings
434.00 WHARFEDALE PRO LIMITED WARRANTY Wharfedale Pro products are warranted of manufacturing or material defects for a period of one year from the original date of purchase. In the event of malfunction, contact your authorized Wharfedale Pro dealer or distributor for information. - Page 14 IAG HOUSE Sovereign Court, Ermine Business Park Huntingdon, Cambs, PE29 6XU, England www.wharfedalepro.com Wharfedale Professional reserves the right to alter or improve specifications without notice. All rights reserved © 2008 Wharfedale Pro. Wharfedale Pro is a member of the International Audio Group (IAG).
