Read the instructions carefully and follow the rules for safe
operation.
Failure to do so could result in serious injury.
ECHO, INCORPORATED
400 Oakwood Road, Lake Zurich, Illinois 60047-1564
Phone : 847-540-8400
INSTRUCTION MANUAL
CHAIN SAW
WARNING
Printed in Japan 1308Am 0347 ES
CS-680
X750-012 20 6
X750 316-510 6
