Page 1 This manual deals with the operation and care of your Volvo. Welcome to the worldwide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/ recommendations in this manual.
Page 2 2002 VOLVO V70 Rockleigh, New Jersey 07647-0914 800-663-8255 800-458-1552 We also invite you to visit our Home Page on the Internet at: http://www.volvocars.com Contents Contents Chapter 1 - Safety Chapter 2 - Instruments, switches and controls Chapter 3 - Climate control system...
Page 3 2002 VOLVO V70 When your car is parked, the gear selector is locked in the (P)ark position. To release the selector from this position, turn the ignition key to position II (or start the engine), depress the brake pedal, press the button on the front of the gear selector knob and move the selector from (P)ark.
Page 4 Volvo and the environment Volvo is committed to the well being of our customers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environmental impact.
Page 5 In addition to continuous environmental refinement of conventional gasoline-powered internal combustion engines, Volvo is actively looking at advanced technology alternative-fuel vehicles. When you drive a Volvo, you become our partner in the work to lessen the car's impact on the environment.
Page 6: Table Of Contents
1 Safety Not wearing a seat belt is like believing "It'll never happen to me!" Volvo, the inventor of the three-point seat belt, urges you and all adult occupants of your car to wear seat belts and ensure that children are properly restrained, using an infant, car or booster seat determined by age, weight and height.
Page 7: Seat Belts
2002 VOLVO V70 Stability Traction Control (STC) 20 Dynamic Stability Traction Control (DSTC) pg. 2 Seat belts Seat belts Always fasten the seat belts before you drive or ride. A chime will sound several times if the driver's seat belt is not fastened.
Page 8 2002 VOLVO V70 Child seats: Please refer to page 14 for information on securing child seats with the seat belts. During pregnancy Pregnant women should always wear seat belts. Remember that the belt should always be positioned in such a way as to avoid any possible pressure on the abdomen. The lap portion of the belt should be located low, as shown in the above illustration.
Page 9: Center Head Restraint
Never repair the belt on your own; have this work done by an authorized Volvo retailer only. Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision.
Page 10 As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS). The Volvo SRS consists of an airbag (2) on both the driver's and passenger's sides and seat belt tensioners in both front door pillars (4). The system is designed to supplement the protection provided by the three-point seat belt system.
Page 11 When installing any optional equipment, make sure that the SRS system is not damaged. Do not attempt to service any component of the SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car to the nearest authorized Volvo retailer for inspection as soon as possible.
Page 12 If the SRS warning light stays on after the engine has started or if it comes on while you are driving, drive the car to the nearest authorized Volvo retailer for inspection as soon as possible. There is no maintenance to perform on the SRS yourself. The month and year shown on the decal on the door pillar indicate when you should contact your Volvo retailer for specific servicing or replacement of airbags and seat belt tensioners.
Page 13 2002 VOLVO V70 P.O. Box 914 Willowdale, Ontario M2H 2N7 Rockleigh, New Jersey 07647-0914 800-663-8255 800-458-1552 pg. 6 Front airbags - SRS file:///K|/ownersdocs/2002/2002_V70/02v70_01a.htm (8 of 16)12/30/2006 3:58:52 PM...
Page 14 Collisions can occur where only one of the airbags deploys. NOTE: Volvo's dual-stage air bags:If the impact is less severe, but severe enough to present a clear injury risk, the dual-stage airbags are triggered at just 70% of its total capacity. If the impact is more severe, the dual-stage airbags are triggered with full capacity.
Page 15 2002 VOLVO V70 WARNING! Children must never be allowed in the front passenger seat. Volvo recommends that ALL occupants (adults and children) shorter than 4 feet 7 inches (140 cm) be seated in the back seat of any vehicle with a passenger-side front airbag. See page 14 for guidelines.
Page 16 Seat belts - the heart of the Volvo safety system The heart of the Volvo safety system is the three-point seat belt (a Volvo invention)! In order for the SRS system to provide the protection intended, seat belts must be worn at all times by everyone in the car.
Page 17: Side Impact Airbags (Sips)
Never try to open or repair any components of the SIPS airbag system. This should be done only by an authorized Volvo service technician. In order for the SIPS airbag to provide its best protection, both front seat occupants should sit in an upright position with the seat belt properly fastened.
Page 18 This may cause airbag deployment which could result in personal injury. Have the car towed to an authorized Volvo retailer for repairs.
Page 19: Volvo Inflatable Curtain (Vic)
2002 VOLVO V70 Volvo Inflatable Curtain (VIC) This system consists of inflatable curtains located along the sides of the roof liners, stretching from the center of both front side windows to the rear edge of the rear side door windows. It is designed to help protect the heads of the occupant of the front seat and the occupant of the outboard rear seat position in certain side impact collisions.
Page 20 2002 VOLVO V70 WARNING! The IC system is a supplement to the Side Impact Protection System. It is not designed to deploy during collisions from the front or rear of the car or in most rollover situations. Never try to open or repair any components of the IC system. This should be done only by an authorized Volvo service technician.
Page 21 If your car has been involved in a collision, the front seat backrests must be inspected by an authorized Volvo retailer even if the seats appear to be undamaged. Certain components in the WHIPS system may need to be replaced. Do not attempt to service any component in the WHIPS system yourself.
Page 22 2002 VOLVO V70 pg. 11 Child safety If all the seats are occupied, a rear-facing auxiliary seat in the cargo area can be used. This seat is designed for two children, each weighing between 50 - 88 lbs. (23 - 40 kg) with a total seat capacity of 176 lbs.
Page 23 12 Child safety Integrated booster cushions, outboard positions (optional) Volvo's own integrated booster cushions have been specially designed to help safeguard a child seated in the rear seat. When using an integrated booster cushion, the child must be secured with the vehicle's three-point seat belt.
Page 24 2002 VOLVO V70 1. Pull the handle at the front of the cushion forward. 2. With both hands push the cushion rearward. 3. Push the cushion until it locks in place. Outboard integrated booster cushions - Lowering 1. Pull the handle at the front of the cushion forward. 2. Push the cushion forward/ downward.
Page 25 The booster cushion should also be replaced if it is badly worn or damaged in any way. This work should be performed by an authorized Volvo retailer only. The booster cushion should be cleaned while in place in the vehicle if possible. If not, please consult your Volvo retailer.
Page 26 2002 VOLVO V70 Why Volvo believes no child should sit in the front seat of a car. It's quite simple really. A front air bag is a very powerful device designed, by law, to help protect an adult. Because of the size of the air bag and its speed of inflation, a child should never be placed in the front seat, even if he or she is properly belted or strapped into a child safety seat.
Page 27: Child Restraint Anchorages
2002 VOLVO V70 Child Restraint Anchorages Volvo cars are fitted with child restraint top tether anchorages in the rear seat. Refer to the child seat manufacturer's instruction for information on securing the child seat. WARNING! Child Restraint Anchorages are designed to withstand only those loads imposed by correctly fitted Child Restraints.
Page 28: Child Safety
2002 VOLVO V70 Isofix fasteners and Seat guide The Isofix fasteners are installed in the outboard rear seat positions. Consult your Volvo retailer for more information on child safety accessories. pg. 16 Child safety Child safety Volvo recommends the proper use of restraint systems for all occupants including children. Remember that, regardless of age and size, a child should always be properly restrained in a car.
Page 29: Seat Belt Maintenance
A specially designed and tested booster cushion (not available in Canada ) for children between 50 - 80 lbs (22.7 - 36 kg) and 46 -54" (117 - 137 cm) can be obtained from your Volvo retailer. If necessary, an auxiliary seat for children is available for use in the luggage compartment of station wagon models.
Page 30: Brake System
However, NHTSA cannot become involved in individual problems between you, your retailer, or Volvo Cars of North America. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393 (or 202-366-0123 in Washington, D.C. area) or write to: NHTSA, U.
Page 31 WARNING! If the fluid level is below the MIN mark in the reservoir: DO NOT DRIVE. Tow the car to a Volvo retailer and have the brake system inspected. NOTE: When the car is at a standstill and the engine is idling, e.g. at a traffic light and the brake pedal is depressed, the pedal may go down slightly.
Page 32: Anti-Lock Brake System (Abs)
If the warning lamp lights up there is a malfunction of the ABS system (the standard braking system will however function) and the vehicle should be driven cautiously to a Volvo retailer for inspection. The Anti-lock Braking System (ABS) helps to improve vehicle control (stopping and steering) during severe braking conditions by limiting brake lockup.
Page 33 2002 VOLVO V70 If the brake fluid level is above the MIN mark, drive carefully to an authorized Volvo retailer and have the brake system inspected. Stability Traction Control (STC)* The STC system is designed to help reduce wheel spin by limiting power to the drive wheels if they begin to lose traction.
Page 34 DSTC has been temporarily switched off due to high brake temperature. The system will automatically switch on again when the brakes have cooled. If the system has been switched off due to a fault. An authorized Volvo retailer should check the system. Emergency Brake Assistance (EBA) The EBA function is an integrated part of the DSTC system.
Page 35 2002 VOLVO V70 When the EBA system is activated, the brake pedal will go down and pressure in the brake system immediately increases to the maximum level. Maintain full pressure on the brake pedal in order to utilize the system completely. EBA is automatically deactivated when the brake pedal is released.
Page 36: Instruments, Switches And Controls
2002 VOLVO V70 2 0 0 2 VOLVO Chapter 2 - Instruments, switches and controls pg. 21 Instruments, switches and controls Interior 22 Exterior 23 Instruments 24 Instrument panel 25 Indicator and warning lights 26 Text information window 28 Switches in the center console 29...
Page 37 2002 VOLVO V70 Rearview/sideview mirrors 39 Sun roof 40 pg. 22 Instruments, switches and controls pg. 23 Instruments, switches and controls file:///K|/ownersdocs/2002/2002_V70/02v70_02a.htm (2 of 14)12/30/2006 3:58:56 PM...
Page 38 2002 VOLVO V70 pg. 24 Instruments, switches and controls file:///K|/ownersdocs/2002/2002_V70/02v70_02a.htm (3 of 14)12/30/2006 3:58:56 PM...
Page 39 2002 VOLVO V70 pg. 25 Instruments, switches and controls 1 Turn signals 2 Text window 3 Temperature gauge The pointer should be approximately midway on the gauge when driving. file:///K|/ownersdocs/2002/2002_V70/02v70_02a.htm (4 of 14)12/30/2006 3:58:56 PM...
Page 40 2002 VOLVO V70 Do not drive the car if the warning light is on. The text window will provide you with additional information. If the engine temperature remains high, check coolant level - see page 129. 4 Trip odometer/reset button The trip odometer is used for measuring shorter distances.
Page 41: Indicator And Warning Lights
1.8 US gal. (8 liters) of fuel remaining. 14 Indicator and warning lights * 18.5 US gals (70 liters) on V70 AWD, V70 XC and V70 with non-turbo engine. pg. 26 Instruments, switches and controls The indicator and warning lights described on pages 26 and 27 should never stay on when driving* When the ignition key is turned, all of the warning lights in the lower right-hand side of the instrument panel should go on to test the function of the bulbs.
Page 42: Oil Pressure Warning Light
If the light comes on (or stays on after the vehicle has started), the SRS diagnostic system has detected a fault. Drive to an authorized Volvo retailer for an inspection of the system. See the SRS section for more information.
Page 43: Rear Fog Light
When this happens, please have your car checked by a Volvo retailer as soon as possible. A CHECK ENGINE light may have many causes. Sometimes, you may not notice a change in your car's behavior.
Page 44: Seat Belt Reminder
Anti-lock Brake System ABS If the warning light comes on, there is a malfunction of the ABS system (the standard braking system will still function). The vehicle should be driven to a Volvo retailer for inspection. See page 19 additional information.
Page 45 STOP ENGINE: Stop and switch off the engine - to help prevent serious risk of damage. SERVICE URGENT: Take your car to an authorized Volvo retailer for inspection as soon as possible. SEE MANUAL: Refer to your owner's manual. For additional information, please contact your Volvo retailer.
Page 46 2002 VOLVO V70 FIX NEXT SERVICE: Have the system affected inspected at the next scheduled maintenance service. TIME FOR REGULAR SERVICE: This light will come on at 7,500 mile (12,000 km) intervals, after 750 hours of driving or after 12 months, whichever occurs first, to remind the driver that the service interval has been exceeded.
Page 47 This 12 volt socket can be used to plug in certain accessories such as cellular telephones, etc. The ignition key must be in position 1 (or higher) for the auxiliary socket to function. NOTE: The auxiliary sockets can also be used for cigarette lighters, which are available at your Volvo retailer.
Page 48: Trip Computer
2002 VOLVO V70 Trip computer The trip computer stores information gathered from several systems in your car and has four menus that can be displayed in the text window. Driving distance on current fuel reserve Average fuel consumption Current fuel consumption...
Page 49 2002 VOLVO V70 3. Current fuel consumption This value indicates the current fuel consumption, based on readings taken once per second. When the car is not moving, "----" will be displayed. 4. Average speed This value indicates average speed since the last time the trip computer was reset (by pressing RESET, button C).
Page 50: Cruise Control
2002 VOLVO V70 pg. 31 Cruise control Cruise control The cruise control panel is located on the left side of the steering wheel hub. Engaging cruise control/setting speed Press the CRUISE button Press + or - to set the current speed Increase or decrease speed as desired NOTE: Cruise control will not function at speeds below 22 mph (35 km/h).
Page 51: Light Switch Panel
II. Front and rear parking lights and license plate lights will also be on. Volvo recommends the use of daytime running lights. If, however, you would prefer to have these lights turned off (USA only), please consult your Volvo retailer. Please note that the use of daytime running lights is mandatory in Canada.
Page 52 2002 VOLVO V70 ignition key is in position II. If the headlight switch is in position all lights will go out when the ignition is switched off. The headlight switch must be in this position before the high beams will function.
Page 53: Steering Wheel Adjustment
2002 VOLVO V70 conditions such as fog, rain, snow, smoke or dust reduce visibility for other vehicles to less than 500 ft (150 meters). An LED in the switch indicates when the rear fog light is on. The rear fog light will only function in combination with the high/low beam head-lights.
Page 54: Steering Wheel Lock
2002 VOLVO V70 A chime will sound if the key is left in the ignition and the driver's door is opened. * The gear selector must be in the (P)ark position. Steering wheel lock The steering wheel lock might be under tension when the car is parked. Turn the steering wheel slightly to free the ignition key.
Page 55: Windshield Wipers/Washers
2002 VOLVO V70 1 Lane change position. In maneuvers such as lane changing, the driver can flash the turn signals by moving the turn signal lever to the first stop and holding it there. The lever will return to the neutral position when released.
Page 56 2002 VOLVO V70 The rain sensor replaces the intermittent wiper function. The windshield wiper interval increases or decreases according to the amount of rain. The sensitivity of the sensor can be adjusted by twisting control A upward or downward. Normal wiper speed High wiper speed 3 Windshield wiper/washer, headlight wiper/washer (certain models).
Page 57: Hazard Warning Flashers
If the tailgate wiper is already in normal wiping function, the normal wiping function will continue. * Ask your Volvo-retailer, if you would like to turn off this function. pg. 36 Warning flashers, Heated mirrors/rear window, Heated front seats Hazard warning flashers The four-way flasher should be used to indicate that the vehicle has become a traffic hazard.
Page 58: Parking Brake, Auxiliary Socket/Ashtrays
2002 VOLVO V70 Heated sideview mirrors/rear window Press the switch to start heating the rear window and sideview mirrors to remove ice or condensation. An LED in the switch will light up. A timer automatically switches off the heating to the sideview mirrors after approximately 6 minutes and to the rear window after approximately 12 minutes.
Page 59 2002 VOLVO V70 Parking brake (hand brake) The lever is situated between the front seats. The brake is applied to the rear wheels. The indicator light in the instrument panel will light up to indicate when the parking brake is applied. Apply the parking brake by pulling up firmly on the lever.
Page 60 NOTE: The cover should be kept on when the auxiliary socket is not in use. Ashtrays Volvo cars in North America do not have an ashtray in the front seat as standard equipment. If you want to have an ashtray in the front seat, please contact your Volvo retailer.
Page 61: Electrically Operated Windows
2002 VOLVO V70 Electrically operated windows The electrically operated windows are controlled by buttons in the arm rests. The ignition switch must be ON * (ignition key in position I, II or the engine running) for the electrically operated windows to function.
Page 62: Rearview Mirror
2002 VOLVO V70 Cutout switch for rear windows The electrically operated rear door windows can be disabled by a switch located on the driver's door (see illustration). If the LED in the switch is OFF: The rear door windows can be raised or lowered with the buttons on the rear door armrests or with the buttons on the driver's door armrest.
Page 63 2002 VOLVO V70 A Normal position B Night position, reduces glare from following headlights Autodim function (option) The autodim function reacts to headlights from following traffic and automatically reduces glare. NOTE: This function is automatically switched off when the gear selector is placed in the Reverse position.
Page 64 2002 VOLVO V70 This feature will not function if you lock your car with the key. WARNING! The mirrors should always be adjusted prior to driving. Objects seen in the wide-angle sideview mirror are closer than they appear to be.
Page 65 2002 VOLVO V70 To close the sun roof: Push the switch forward to the first detent ("stop") and hold it until the sun roof has closed completely. AUTO close:Push the switch forward as far as possible and release it to automatically close the sun roof.
Page 66 2002 VOLVO V70 * A position where the sun roof is not quite fully open which helps alleviate rumbling wind noise. Contents Top of Page file:///K|/ownersdocs/2002/2002_V70/02v70_02b.htm (17 of 17)12/30/2006 3:58:58 PM...
Page 67: Climate Control System
2002 VOLVO V70 2 0 0 2 VOLVO Chapter 3 - Climate control system pg. 41 Climate control system Ventilation 42 Climate control system - general information 43 Electronic Climate Control (ECC) 44 pg. 42 Ventilation Air vents (dash) A Open...
Page 68: Air Flow
2002 VOLVO V70 D Vertical air flow Direct the outer air vents toward the side windows to demist. In cold weather, close the air vents in the center of the dash to direct as much air as possible toward the windows.
Page 69: Cabin Air Filter
2002 VOLVO V70 B Closed C Horizontal air flow D Vertical air flow Direct the air vents toward the rear side windows to demist. Direct the air vents toward the rear seat for the best heating/cooling effect. pg. 43 Climate control system - general information...
Page 70 Acceleration The air conditioning is momentarily disengaged during full-throttle acceleration. ECC maintenance All maintenance on the climate control systems should be carried out by an authorized Volvo service technician only. Refrigerant Volvo cares about the environment. The air conditioning system in your car contains a CFC-free refrigerant - R134a.
Page 71 2002 VOLVO V70 pg. 45 Electronic Climate Control (ECC) AUTO This function automatically regulates the Electronic Climate Control system so that the selected temperatures are maintained. The blower, heating, air distribution (air flow) and air conditioning are controlled. If you prefer to manually set any of these functions, the remaining functions will still be controlled automatically.
Page 72 2002 VOLVO V70 lower than necessary. Set the control to the temperature you prefer. Defroster This function demists/de-ices the windshield and front side windows. The LED in the switch will light up to indicate that the defrost function is engaged. Blower speed increases automatically and the air in the passenger compartment is dehumidified.
Page 73: Interior
2002 VOLVO V70 Recirculation should not be used for more than 15 minutes. If your windows begin to fog or mist, make sure that the recirculation function is switched off. Selecting Defroster automatically switches recirculation off. Timer mode activation: (Cars with Interior Air Quality system have no timer mode) Press and hold the recirculation button for at least 3 seconds to activate a recirculation timer mode.
Page 74 2002 VOLVO V70 Air conditioning ON/OFF Press the switch to turn the air conditioning on or off. The "ON" or "OFF" LED will light up to indicate if the system is switched on or off. Other functions will still be regulated automatically (if the AUTO switch is on).
Page 75 2002 VOLVO V70 Operation: Press to activate the Air quality sensor (normal setting). Or select one of three functions by pressing 1. Press : the LED AUT comes on. The Air quality sensor is now activated. 2. Press 3. Press : the LED MAN comes on.
Page 76 2002 VOLVO V70 pg. 49 Manual climate control with air conditioning, A/C A/C - ON/OFF The air conditioning function is engaged by pressing ON and disengaged by pressing OFF. When you select Defroster , the air conditioning is automatically engaged if the fan is not set to position 0.
Page 77 2002 VOLVO V70 to indicate that the heating function is engaged. See page 36 for additional information on this function. CAUTION: Never use ice scrapers made of metal as they can easily scratch the mirror surface. Recirculation Recirculation can be used to shut out stale air, exhaust, etc. from the passenger compartment. The air in the passenger compartment is then recirculated, i.
Page 78: Air Distribution
2002 VOLVO V70 Temperature Turn the control to set the temperature for the driver's and passenger's sides of the car. For cooler air, the air conditioning function must be engaged. Air distribution Use the air distribution control positions (marked with dots) between the different symbols to fine-tune air distribution for the maximum comfort.
Page 79 2002 VOLVO V70 Contents Top of Page file:///K|/ownersdocs/2002/2002_V70/02v70_03.htm (13 of 13)12/30/2006 3:59:00 PM...
Page 80 2002 VOLVO V70 2 0 0 2 VOLVO Chapter 4 - Interior pg. 51 Interior Front seats 52 Interior lighting 54 Storage compartments 55 Storage compartment, front/Vanity mirrors 57 Rear seat and cargo area 59 Spare tire 68 Auxiliary seat in cargo area, Extra handgrip - Cross...
Page 81 2002 VOLVO V70 Electrically operated front seats From the time the driver's door is unlocked, the driver's seat can be adjusted with the ignition off during a 10 minute period, if the door remains opened. If the door is closed, the seat can be adjusted for 40 seconds.
Page 82: Front Seats
2002 VOLVO V70 WARNING! Because the driver's seat can be adjusted with the ignition off, children should never be left unattended in the car. Movement of the seat can be STOPPED at any time by pressing any button on the power seat control panel.
Page 83 2002 VOLVO V70 Adjusting the front seats: The passenger's seat can only be adjusted if the ignition key is in position I or II. Driver's seat: The driver's seat can be adjusted if the ignition key is in position I or II (see page 52).
Page 84 2002 VOLVO V70 The passenger seat backrest can be folded down to the horizontal position for carrying long loads. To fold down the backrest: Move the seat as far rearward as possible Adjust the backrest tilt to the most upright position...
Page 85: Storage Compartments
2002 VOLVO V70 pg. 55 Storage compartments file:///K|/ownersdocs/2002/2002_V70/02v70_04a.htm (6 of 12)12/30/2006 3:59:01 PM...
Page 86: Cup Holders
2002 VOLVO V70 Ashtray (option) To empty the ashtrays: Front seat, open the ashtray, pull out the insert. Rear seat, as above. Cup holders Some models are equipped with cup holders for the front and rear seat occupants. You can also use the center console's storage compartment for cassette tapes, CD's etc.
Page 87: Storage Compartment, Front/Vanity Mirrors
2002 VOLVO V70 Inside the armrest there is a storage compartment which you may use for different personal accessories. The armrest's lid is twofold. To open only the upper lid: press the locking mechanism underneath the upper lid and fold the lid backwards to desired position. To open the upper and lower lid: lift the lid from underneath upwards and fold to desired position.
Page 88 2002 VOLVO V70 To use the cup holder, open the cover on the center console and fold it rearward. The cup holder and the cover open together. The cup holder and the cover can be closed separately. NOTE: If the cup holder is subjected to weights above approximately 12 lbs (5 kg), it will fold down slightly to help prevent damage to the hinges.
Page 89: Coat Hanger
The side panel on the passenger side of your car has an opening for various accessories. You must pry off its cover before you can use it. You can fit a hook for a handbag, waste bin, tray for personal effects etc. Consult your Volvo retailer. Coat hanger Use the coat hanger for clothes of normal weight.
Page 90 2002 VOLVO V70 Waste bin / bottle holder in rear seat To change the waste bag: Open the holder. Using both hands, press out the lower part of the holder. Fit the bag around the lower part. Press the lower part back onto the upper part.
Page 91 2002 VOLVO V70 Pull the tab and fold the table section forward. Fold the armrest in the backrest forward. Fold out the table so that it rests on the armrest. Press to release the cup holder. You do not have to fold the backrest forward, if you only want to use the cup holder.
Page 92: Rear Seat And Cargo Area
2002 VOLVO V70 pg. 59 Rear seat and cargo area Extension of cargo area The rear seat is in two sections and each section can be folded forward separately. Tip the front seat backrests into a more upright position if they are excessively reclined. Pull the seat cushion tab and fold the cushion forward against the front seat backrests.
Page 93 2002 VOLVO V70 Models with 2 or 3-section rear seat Press the backrest catch to the rear and tip the backrest forward. See the illustration in the right-hand column. A - Catch in closed position. B - Catch in open position.
Page 94 2002 VOLVO V70 Folding down the center section of the backrest Cross Country with 3-section rear seat To fold down the center section of the backrest (without folding down either of the outboard sections): Lower the head restraint. Press the center section backrest catch to the rear and tip the backrest forward.
Page 95 Cross Country with 3-section rear seat A partition with storage pockets is available as an accessory on V70 models with a 3-section rear seat. This partition can help prevent objects in the cargo area from being thrown forward when the center section of the backrest is not in the upright position.
Page 96 Replace the backrest by pressing the bottom section onto the retaining bar until the backrest clicks into place. Please consult your Volvo retailer for information about accessory equipment that can be placed in the center section of the backrest. WARNING! For safety reasons, the center section of the backrest or seat cushion should not be left in the car after they have been removed.
Page 97: Center Armrest
2002 VOLVO V70 Center armrest Cross Country with 3-section rear seat The center backrest can be reversed and used as an armrest. Remove the center backrest as described in the left-hand column. Turn the backrest so that the front side faces up (see illustration above).
Page 98 2002 VOLVO V70 Removing the seat cushion Models with 2 or 3-section rear seat Pull up the seat by the handle. Unlock the two red locking tabs. Lift out the seat. When replacing, do everything in reverse order. Make sure the red locking tabs are in a locked position.
Page 99: Rear Seat Backrest
2002 VOLVO V70 Rear seat backrest You can adjust the angle of the rear seat backrests. To adjust a backrest to a more upright position: Press the catch until the red mark is visible. Pull the backrest forward to a new locked position.
Page 100: Securing Cargo
2002 VOLVO V70 Open the tailgate. Hang or secure your grocery bags by means of tensioning straps or holders. To remove the plastic tray (option), turn the two knobs at the sides. Auxiliary 12 Volt socket in cargo area This feature is standard equipment on the Cross Country and optional on other models. Fold down the cover when you want to use the electric socket.
Page 101 WARNING! The eyelets are not to be used as passenger restraints or as anchorages for child restraints. Unless the car is equipped with an optional Volvo auxiliary seat for children, passengers should not ride in the rear cargo area. Remember that a 44 lbs object produces a force of 2,200 lbs in a head-on collision at 30 mph! Auxiliary seat If an auxiliary seat is installed in the vehicle, store the seat before loading cargo.
Page 102 2002 VOLVO V70 Load the cargo against the backrest. Load heavy cargo as low as possible. Load wide cargo on either side of the rear seat split. If no one is sitting in the rear seat, reinforce the backrest by fastening the rear seat belts.
Page 103 Green mark - locked position. Red mark - unlocked position. Cargo net (option on V70) Models with 2-section rear seat Your car can be equipped with a cargo net made of strong nylon fabric that can be unrolled from the rear seat backrest.
Page 104 Nylon cargo net (option on Cross Country) The Volvo Cross Country can be equipped with a cargo net made of strong nylon fabric that can be installed with the rear seat backrests in the upright position or folded down. The upper and lower rods of the cargo net are hinged.
Page 105 2002 VOLVO V70 WARNING! The nylon cargo net must not be used when the optional rear-facing auxiliary child seat in the cargo area is in use. When not in use, the cargo net should not be stored unattached in the car to prevent it from being thrown forward in the event of a sudden stop, etc.
Page 106: Vanity Mirrors
2002 VOLVO V70 Withdraw the cargo area cover, pull it over the luggage compartment and hook it in the holes in the rear cargo area pillars. Removing the cargo area cover: Press the end pieces of the cargo area cover inward, pull up and remove.
Page 107: Country
2002 VOLVO V70 Unstrap and lift out the jack and tool kit. Unscrew the securing bracket and remove the spare tire from the storage well. When putting the tire back into the well, perform these steps in reverse order. Make sure the spare tire, jack and tool kit are properly secured.
Page 108 2002 VOLVO V70 Auxiliary seat (option) If all the seats are occupied, a rear-facing auxiliary seat in the cargo area can be used. This seat is designed for two children, each weighing between 50 - 88 lbs. (23 - 40 kg) with a total seat capacity of 176 lbs.
Page 109: Interior Lighting
Extra handgrip The Volvo Cross Country is equipped with an extra handgrip on the front passenger's side. This handgrip can be used for added support when travelling on unpaved roads, etc. pg. 70 Interior lighting Courtesy light The courtesy light can be turned on or off by pressing the button.
Page 110 When switched on with the engine running, the light will stay on indefinitely. The light may be switched off at any time by pressing the center button a second time. The courtesy light timer periods can be changed. Consult your Volvo retailer. Overriding the Interior Courtesy Lights Normally if a car door is left open with the engine turned off, the interior courtesy light will stay on for 10 minutes.
Page 111 2002 VOLVO V70 Reading lights - front/rear The reading lights can be switched on or off by pressing the respective buttons. These lights switch off automatically after 10 minutes if the engine is not running. If the engine is running, the lights stay on indefinitely.
Page 112: Keys, Locks, Alarm
2002 VOLVO V70 2 0 0 2 VOLVO Chapter 5 - Keys, Locks, Alarm pg.71 Keys, Locks, Alarm Keys, Exterior courtesy lights, Locking and unlocking the car 72 Remote keyless entry system 73 Unlocking the tailgate, Central locking buttons, "Trunk lock"...
Page 113 The car will start only with a properly coded key. If you misplace a key, take the other keys to an authorized Volvo retailer for reprogramming as an antitheft measure. *This key operates only driver's door and ignition switch/steering wheel lock.
Page 114: Remote Keyless Entry System
2002 VOLVO V70 Exterior courtesy lights Home Safe System When you leave your car at night, you can make use of the courtesy lighting function: Remove the key from the ignition switch. Pull the direction indicator lever towards the steering wheel (as when activating the high beams).
Page 115: Using The Remote Control
The car can also be locked/unlocked with the key. As an extra security precaution in certain situations (valet parking, etc.), Volvo recommends that the transmitter not be included when the keys are given to anyone. The service key can be used instead. If one of the transmitters is misplaced, contact your nearest authorized Volvo retailer for assistance.
Page 116 Avoid touching the contact surfaces of the battery with your fingers. Reinstall the cover and tighten the screw to help protect the transmitter. NOTE: The old battery should be disposed of properly at a recycling center or at your Volvo retailer. WARNING! Volvo does not recommend using the transmitter to lock the doors from inside the car.
Page 117: Central Locking Buttons
2002 VOLVO V70 Unlocking the tailgate The tailgate lock is incorporated in the central locking system and is locked or unlocked when the driver's door is locked/unlocked. The tailgate can be unlocked by: Pressing UNLOCK on the remote control twice.
Page 118: Arming The Alarm
2002 VOLVO V70 tailgate and set the alarm. The rear passenger doors can also be locked and unlocked with the individual lock buttons on each door. pg. 76 Alarm Alarm The alarm is automatically armed whenever you lock your car. When armed, the alarm continuously monitors a number of points on the car.
Page 119 2002 VOLVO V70 An audible alarm signal is given by a battery powered siren. One alarm cycle lasts for 25 seconds. "Panic" button In an emergency situation, this feature can be used to attract attention. Activate the "panic" function by...
Page 120: Child Safety Locks - Rear Doors
LED flashes rapidly before the ignition is switched on - the alarm has been triggered Fault in the alarm system: If a fault has been detected in the alarm system, a message will be displayed in the text window. Contact a Volvo retailer. Automatic re-lock/re-arm system If the car is unlocked with the remote, the car will re-lock and the alarm will re-arm after 2 minutes unless a door or the tailgate has been opened.
Page 121 2002 VOLVO V70 A The door cannot be opened from the inside. Normal operation from the outside. B The door lock functions normally. WARNING! Remember, in the event of an accident, the rear seat passengers cannot open the doors from the inside with the buttons in position A.
Page 122: Starting And Driving
2002 VOLVO V70 2 0 0 2 VOLVO Chapter 6 - Starting and driving pg. 79 Starting and driving Fuel requirements 80 Fuel Formulations 81 Refueling 82 Starting the engine 83 Manual transmission 84 Automatic transmission (AW5) 85 Automatic transmission...
Page 123: Fuel Requirements
New Vehicle Limited Warranty. Unleaded fuel Each Volvo has a three-way catalytic converter and must use only unleaded gasoline. U.S. and Canadian regulations require that pumps delivering unleaded gasoline be labelled "UNLEADED". Only these pumps have nozzles which fit your car's filler inlet.
Page 124: Fuel Formulations
(MMT). If such fuels are used, your Emission Control System performance may be affected, and the Check Engine light (malfunction indicator lamp) located on your instrument panel may light. If this occurs, please return your vehicle to an authorized Volvo retailer for service.
Page 125: Refueling
2002 VOLVO V70 Use of Additives With the exception of gas line antifreeze during winter months, do not add solvents, thickeners, or other store-bought additives to your car's fuel, cooling, or lubricating systems. Overuse may damage your engine, and some of these additives contain organically volatile chemicals. Do not needlessly expose yourself to these chemicals.
Page 126: Starting The Engine
126 for additional information. * 18.5 US gals (70 liters) on V70 AWD, V70 XC and V70 with non-turbo engine. CAUTION: Do not refuel with the engine running *. Turn the ignition off or to position I. If the ignition is on, an incorrect reading could occur in the fuel gauge.
Page 127 2002 VOLVO V70 starter to operate for up to 10 seconds. Release the key as soon as the engine starts. If the engine fails to start, repeat this step. For cold starts at altitudes above 6000 ft (1800 meters), depress the accelerator pedal halfway and turn the key to the starting position.
Page 128: Manual Transmission
2002 VOLVO V70 * Your car is equipped with an electronic start inhibitor (immobilizer). The keys you received with your car are specially coded. The code in the key is transmitted to an antenna in the ignition switch where it is compared to the code stored in the start inhibitor module.
Page 129: Engaging Reverse Gear
2002 VOLVO V70 Engaging reverse gear Reverse gear should only be engaged from a complete stop. CAUTION: Be careful that you do not inadvertently engage reverse while moving forward. * Clutch interlock The clutch must be fully depressed before you can start your car. If the clutch is not depressed, it will not be possible to start the engine.
Page 130 2002 VOLVO V70 P (Park) Use this position when starting the engine or parking the car. Never use P while the car is in motion. The parking brake should be set whenever the car is parked. The gear selector is mechanically locked in the P position (SHIFTLOCK). To release the gear selector from this position, the engine must be running (or the ignition key must be in position II) and the brake pedal must be depressed.
Page 131 2002 VOLVO V70 D is the normal driving position and should be used as often as possible to help improve fuel economy. The car should not be moving when shifting from R to the D position. 4 (Intermediate gear) The transmission will shift automatically between gears 4, 3, 2 or 1 from this position. The transmission cannot shift up to (D)rive from fourth gear.
Page 132 2002 VOLVO V70 Automatic transmission -shift gate positions The gear selector can be moved freely between N and D. Depressing the button on the front of the gear selector knob enables you to move the gear selector to positions P, R, N, D, 4, 3 and L.
Page 133: Automatic Transmission (Geartronic)
2002 VOLVO V70 Kickdown Automatic shift to a lower gear (kickdown) is achieved by depressing the accelerator pedal fully and briskly. An upshift will occur when approaching the top speed for a particular gear or by releasing the accelerator pedal slightly. Kickdown can be used for maximum acceleration or when passing at highway speeds.
Page 134 2002 VOLVO V70 WARNING! Never leave the car unattended when the engine is running. If, by mistake, the gear selector is moved from P, the car may start moving. R (Reverse) Never engage R while the car is moving forward.
Page 135 2002 VOLVO V70 Automatic transmission -shift gate positions You can move the gear selector freely between the (MAN)ual and (D)rive positions while driving. Depress the button on the front of the gear selector knob to move between the R, N, D, and P positions.
Page 136: Driving Economy
2002 VOLVO V70 If you slow down to a very low speed, the transmission will automatically shift down. When starting in the (MAN)ual position, 3rd gear is the highest gear that may be selected. NOTE: Kickdown (see previous page) does not function when the transmission is in the manual shift (geartronic) mode.
Page 137 2002 VOLVO V70 Avoid carrying unnecessary items (extra load) in the car. Maintain correct tire pressure. Check tire pressure regularly (when tires are cold). Remove snow tires when threat of snow or ice has ended. Note that roof racks, ski racks, etc., increase air resistance and also fuel consumption.
Page 138: Points To Remember
2002 VOLVO V70 pg. 90 Points to remember Cooling system The risk for engine overheating is greatest, especially in hot weather, when: Towing a trailer up steep inclines for prolonged periods at wide open throttle and low engine rpm. Stopping the engine suddenly after high speed driving (so-called "after-boiling" can occur).
Page 139: Roof Racks/Load Carriers
91 Roof racks/Load carriers Load carriers (accessory) Load carriers are available as Volvo accessories. Observe the following points when in use: To avoid damaging your car and to achieve maximum safety when driving, we recommend using the load carriers that Volvo has developed especially for your car.
Page 140 2002 VOLVO V70 Place heavier cargo at the bottom of the load. Anchor the cargo correctly with appropriate tie-down equipment. Check periodically that the load carriers and load are properly secured. Remember that the car's center of gravity and handling change when you carry a load on the roof.
Page 141 2002 VOLVO V70 8 Press down the covers. Check periodically that the load carriers and load are properly secured. pg. 92 Load carriers (models with rails) Position of load carriers Make sure that the wing-shaped load carriers are installed on the roof rails with the rounded edge forward (see the inset illustration above).
Page 142 2002 VOLVO V70 Load carrier cover The car's ignition key or the stud on the edge of the supplied torque wrench can be used to undo or tighten the cover. Turn a quarter turn (90 degrees). See illustration. Contents Top of Page...
Page 143: Emergency Towing
2002 VOLVO V70 pg. 93 Emergency towing Emergency towing The towing eyelet is located in the tool kit, under the floor of the cargo area, with the spare tire. This eyelet must be screwed into the positions provided on the right sides of either the front or rear bumper (see illustration).
Page 144: Vehicle Towing Information
2002 VOLVO V70 Precautions when the car is in tow The steering wheel must be unlocked. Turn the ignition key to position I or II. The gear selector must be in position N. Maximum speed: 50 mph (80 km/h) Maximum distance with front wheels on ground: 50 miles (80 km).
Page 145 Towing cars with front wheel drive Volvo recommends the use of flat bed equipment. If wheel lift equipment must be used, please use extreme caution to help avoid damage to the car. In this case, the car should be towed with the rear wheels on the ground if at all possible.
Page 146: Towing A Trailer
95 Towing a trailer When preparing for trailer towing, observe the following: Volvo recommends the use of Volvo trailer hitches which are specially designed for the car. Maximum trailer weight recommended by Volvo is: Trailers without brakes: 1100 lbs (500 kg) Trailers with brakes: 3300 lbs (1,500 kg), Observe the legal requirements of the state/province in which the vehicles are registered.
Page 147 2002 VOLVO V70 Volvo recommends the use of synthetic engine oil when towing a trailer over long distances or in mountainous areas. WARNING! Bumper-attached trailer hitches must not be used on Volvo's, nor should safety chains be attached to the bumper.
Page 148 2002 VOLVO V70 pg. 97 Detachable trailer hitch - removing file:///K|/ownersdocs/2002/2002_V70/02v70_06b.htm (6 of 11)12/30/2006 3:59:10 PM...
Page 149: Jump Starting
2002 VOLVO V70 pg. 98 Jump starting Jump starting Follow these instructions to jump start your car's dead battery or to jump start another car's dead battery using your car. Although your car's battery is located under the floor of the cargo area, jumper cables should be connected in the engine compartment, to the points shown in the illustrations.
Page 150 2002 VOLVO V70 auxiliary battery to be used is in another car, check that the cars are not touching to prevent premature completion of a negative circuit. Be sure to follow jump starting instructions provided for the other vehicle. To jump start your car: Switch off the ignition.
Page 151: Winter Driving
It is therefore advisable to check the state of charge more frequently and spray an anti-rust oil on the battery posts. Volvo recommends the use of snow tires on all four wheels for winter driving - see section "Wheels and tires".
Page 152: Before A Long Distance Trip
Check all lights, including high beams. Reflective warning triangles are legal requirement in some countries. Have a word with your Volvo retailer if you intend to drive in countries where it may be difficult to obtain the correct fuel. Consider your destination. If you will be driving through an area where snow or ice are likely to occur, consider snow tires.
Page 153 2002 VOLVO V70 Three-way catalytic converter cautions Keep your engine properly tuned. Certain engine malfunctions, particularly involving the electrical, fuel or distributor ignition systems, may cause unusually high three-way catalytic converter temperatures. Do not continue to operate your vehicle if you detect engine misfire, noticeable loss of power or other unusual operating conditions, such as engine overheating or backfiring.
Page 154: General Information
2002 VOLVO V70 2 0 0 2 VOLVO Chapter 7 - Wheels and tires pg.103 Wheels and tires General information, Wear indicator, Tire economy, Flat spots Wheels and tires - All Wheel Drive vehicles 105 Snow chains, Snow tires/studded tires 106...
Page 155 Unbalanced wheels impair tire economy and driving comfort. Volvo does not recommend rotating the tires. However, if tires are rotated, they must be kept on the same side of the car so that they revolve in the same direction as before rotation.
Page 156: Tire Replacement
Tire Replacement When tire replacement is necessary, Volvo strongly recommends replacing all four tires at the same time with identical tires as explained above. Failure to do so can result in a circumference difference that may damage the transmission and all-wheel-drive system.
Page 157: Temporary Spare
Snow chains can be used on your Volvo with the following restrictions: Snow chains should be installed on front wheels only. Use only Volvo approved snow chains. Special snow chains must be mounted on 215/55 R16. Consult your Volvo retailer.
Page 158 Failure to do so could reduce traction to an unsafe level or adversely affect handling. Volvo does not recommend tire rotation. However, as with any other radial tires, if rotated, the tires must be kept on the same side of the car so that they revolve in the same direction as before rotation.
Page 159: Vehicle Loading
Vehicle loading The tires on your Volvo should perform to specifications at all normal loads when inflated as recommended on the tire informa-tion label. The label is located on the inside of the fuel filler door. The label lists both tire and vehicle design limits.
Page 160: Uniform Tire Quality Grading
2002 VOLVO V70 In the event of damage to this tire, a new one can be purchased from your Volvo retailer. WARNING! Current legislation prohibits the use of the "Temporary Spare" tire other than as a temporary replacement for a punctured tire. It must be replaced as soon as possible by a standard tire. Road holding and handling may be affected with the "Temporary Spare"...
Page 161 2002 VOLVO V70 characteristics and climate. TRACTION The traction grades, from highest to lowest, are AA, A, B, and C, as measured under controlled conditions on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction performance.
Page 162: Changing Wheels
2002 VOLVO V70 Changing wheels The spare wheel is located under the carpet on the cargo area floor. The jack and crank are secured in the wheel recess. There are two jack attachment points on each side of the car.
Page 163 2002 VOLVO V70 Raise the vehicle until the wheel to be changed is lifted off the ground. Unscrew the wheel bolts completely and carefully remove the wheel so as not to damage the thread on the studs. NOTE: See also...
Page 164 2002 VOLVO V70 CAUTION: The car must not be driven with wheels of different dimensions or with a spare tire other than the one that came with the car. The use of different size wheels can seriously damage your car's transmission.
Page 165: Fuses
2002 VOLVO V70 2 0 0 2 VOLVO Chapter 8 - Maintenance/Servicing pg. 111 Maintenance/Servicing Fuses 112 Replacing bulbs 116 Paint touch up 122 Washing the car 123 Cleaning the upholstery 124 Maintenance service, Warranty 125 Fuel/emissions systems 126 Drive belt, Air pump system, Coolant 127...
Page 166: Replacing Fuses
If so, put in a new fuse of the same color and amperage (written on the fuse). Spare fuses are stored in the fuse box in the passenger compartment. If fuses burn out repeatedly, have the electrical system inspected by an authorized Volvo retailer. WARNING! Never use fuses with higher amperage that those stated on the following pages.
Page 167 2002 VOLVO V70 Relays/fuses in the engine compartment When replacing fuses, be sure to replace a blown fuse with a new one of the same color and amperage (written on the fuse). Fuse amperage is also indicated on the inside of the fuse box cover.
Page 168 2002 VOLVO V70 17 Low beam, right 18 Low beam, left 19 ABS 20 High beam, left 21 High beam, right 22 Starter motor 23 Engine control module 24 - pg. 114 Fuses in the passenger compartment Fuse box in the passenger compartment This fuse box is located at the far left side of the instrument panel.
Page 169 2002 VOLVO V70 9 ABS 10 - 11 - 12 Headlight wipers 13 Electric socket 12 V 14 Power passenger's seat, seat belt buckle switches, SRS 15 Audio system 16 Audio system 17 Radio amplifier 18 Front fog lights 19 VNS display (option)
Page 170 2002 VOLVO V70 pg. 115 Fuses in the cargo area Fuses in the cargo area The fuses in the cargo area are located on the trim on the left-hand side. When replacing a blown fuse, be sure to replace it with a new one of the same color and amperage (written on the fuse).
Page 171: Replacing Bulbs
2002 VOLVO V70 15 Trailer (15 supply) 16 - 17 - 18 - pg. 116 Replacing bulbs Replacing high/low beam headlight bulbs The headlight bulbs must be replaced from the engine compartment. CAUTION: Do not touch the glass on halogen bulbs with your fingers. Grease, oil or any other impurities can be carbonized onto the bulb and cause damage to the reflector.
Page 172 2002 VOLVO V70 To remove a defective low beam bulb: Switch off all lights and turn the ignition switch to position 0. Open the hood. Remove the plastic cover over the bulb (1) by turning it counterclockwise. Remove the connector (2).
Page 173 2002 VOLVO V70 NOTE: If the vertical aim of your headlights needs to be adjusted for any reason (e.g., towing a trailer for extended periods), this should be done by an authorized Volvo retailer. pg. 117 Replacing bulbs To remove and install a high beam bulb (HB3): Switch off all lights and turn the ignition switch to position 0.
Page 174 2002 VOLVO V70 Switch off all lights and turn ignition key to position 0. Remove the low beam cover by twisting counterclockwise. Pull out the bulb and its socket. Replace bulb. Press the bulb and its socket back into place.
Page 175 2002 VOLVO V70 Replacement of rear turn signal and brake light bulbs Switch off all lights and turn the ignition switch to position 0. Using a screwdriver, carefully pry off the speaker grille. Pull out the red tab in the speaker.
Page 176 2002 VOLVO V70 Front fog lights (option) CAUTION: Avoid touching the glass on the bulb with your fingers. Switch off all lights and turn the ignition key to position 0. Turn the bulb holder slightly counter-clockwise to release it. Replace the bulb. The shape of the base of the bulb corresponds to the shape of the bulb holder.
Page 177: License Plate Lights
2002 VOLVO V70 Remove the defective bulb by pulling it straight out. Insert a new bulb. Reinsert the bulb holder in the lens and press the entire unit back into place on the fender. pg. 120 Replacing bulbs License plate lights Switch off the ignition.
Page 178: Vanity Mirror Lights
2002 VOLVO V70 The door step courtesy lights are located under the dash on the driver's and passenger's sides. To replace a bulb: Carefully insert a screwdriver and pry out the lens. Replace the defective bulb. Reinstall the lens. Vanity mirror lights Carefully insert a screwdriver and pry out the lens.
Page 179: Paint Touch Up
These bulbs may be difficult for you to replace yourself. We recommend that you let an authorized Volvo retailer replace these bulbs if necessary. NOTE: Other bulbs may be difficult for you to replace yourself. Let an authorized Volvo retailer replace these bulbs if necessary.
Page 180 2002 VOLVO V70 Minor stone chips and scratches Material: Primer - can Paint - touch-up bottle Brush Masking tape NOTE: When touching up the car, it should be clean and dry. The surface temperature should be above 60° F (15° C).
Page 181: Washing The Car
2002 VOLVO V70 several thin paint coats and let dry after each application. 3. If there is a longer scratch, you may want to protect surrounding paint by masking it off. pg. 123 Washing the car Washing the car The car should be washed at regular intervals since dirt, dust, insects and tar spots adhere to the paint and may cause damage.
Page 182: Polishing And Waxing
2002 VOLVO V70 WARNING! When the car is driven immediately after being washed, apply the brakes several times in order to remove any moisture from the brake linings. Engine cleaning agents should not be used when the engine is warm. This constitutes a fire risk.
Page 183: Maintenance Service, Warranty
The maintenance services contain several checks which require special instruments and tools and therefore must be performed by a qualified technician. To keep your Volvo in top condition, specify time-tested and proven Genuine Volvo Parts and Accessories.
Page 184: Specifications
2002 VOLVO V70 Maintenance services Your Volvo has passed several major inspections before being delivered to you, according to Volvo specifications. The maintenance services outlined in this book should be performed as indicated. The extended maintenance service intervals make it even more advisable to follow this program. Inspection and service should also be performed any time a malfunction is observed or suspected.
Page 185: Fuel/Emissions Systems
2002 VOLVO V70 pg. 126 Fuel/emissions systems Fuel system The fuel system continually compensates for variation in engine load, speed and temperature. A mass air flow sensor continuously measures the inducted air and makes rapid adjustments for changes in air temperature and density, to balance fuel economy, emissions, and engine power requirements.
Page 186: Check Coolant Level
2002 VOLVO V70 NOTE: Overfilling the fuel tank can cause damage to the evaporative control system. If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Malfunction Indicator Lamp may indicate a fault.
Page 187: Emissions Maintenance
2002 VOLVO V70 Changing coolant Normally, the coolant does not need to be changed. If the system must be drained, consult your Volvo retailer. NOTE: Do not top off with water only. This reduces the rust-protective and antifreeze qualities of the coolant and has a lower boiling point.
Page 188 NOTE: If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Check Engine light ("Malfunction indicator") may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. Timing belt For proper functioning of the vehicle and its emission control systems, the timing belt and belt tensioner must be replaced every 105,000 miles (168,000 km).
Page 189: Washer Fluid Reservoir
2002 VOLVO V70 Washer fluid reservoir The washer fluid reservoir is located in the engine compartment and holds approx. 4.7 US qts. (4.5 liters). During cold weather, the reservoir should be filled with windshield washer solvent containing antifreeze. Hoisting the car If a garage jack is used to lift the car, the two jack attachments points should be used.
Page 190: Opening The Hood, Engine Compartment
2002 VOLVO V70 pg. 130 Opening the hood, Engine compartment Opening the hood Pull the lever located under the left side of the dash to release the hood lock. Lift the hood slightly. Press up the release control located under the front edge of the hood (at the center) and lift.
Page 191: Engine Compartment
Conserving. Your Volvo V70 has been certified to standards using ILSAC oil specification GF-2 5W/30. Volvo recommends use of oil with a quality rating equal to or higher than ILSAC GF-2. Equivalent and better oils include ACEA A1, API SJ, SJ/CF, and SJ/Energy conserving. Lower quality oils may not offer the same fuel economy, engine performance, or engine protection.
Page 192 Oil and oil filter changes should be made at 7,500 mile (12,000 km) intervals. Extra oil additives must not be used unless advised by an authorized Volvo retailer. Synthetic oil is not used when the oil is changed at the normal maintenance service intervals.
Page 193: Checking The Oil Level
2002 VOLVO V70 Break-in Period Although some oil consumption occurs during normal engine operation, more oil is consumed when the engine is new as the internal parts generate higher friction while wearing-in each other. From the time the engine is new until the first service is performed, the oil consumption could be higher than normal.
Page 194: Adding Oil
2002 VOLVO V70 WARNING! Do not allow oil to spill onto or come into contact with hot exhaust pipe surfaces. Adding oil Add oil of the same kind as already used. Capacity (including oil filter): 6.1 US qts. (5.8 liters) Capacity (including oil filter and oil cooler): 7.1 US qts.
Page 195: Brake Fluid
Replace: Every second year or 30,000 miles (48,000 km). The fluid should be replaced once a year or every 15,000 miles (24,000 km) when driving under extremely hard conditions (mountain driving, etc.) Always entrust brake fluid changing to an authorized Volvo retailer. pg. 134 Battery maintenance Battery maintenance The battery in your car is located under the floor of the cargo area.
Page 196 2002 VOLVO V70 The battery should be disconnected from the vehicle when a battery charger is used directly on the battery. However, if the battery is being charged via the connecting points in the engine compartment (see page 98), the battery must be connected.
Page 197: Replacing The Battery
2002 VOLVO V70 Replacing the battery Switch off the ignition. Unscrew the cover over the battery. Wait at least 10 minutes after switching off the ignition before disconnecting the battery so that all information in the car's electrical system can be stored in the control modules.
Page 198: Replacing Wiper Blades
(see illustration). Be sure the ventilation hose is free of debris. Only use replacement batteries equipped with a ventilation hose. Consult your Volvo retailer. pg. 136 Replacing wiper blades Windshield wiper blades Lift the wiper arm off the windshield and hold the blade at a 45°...
Page 199 2002 VOLVO V70 Pull the old blade free of the wiper arm. Install the new blade (installation is the reverse of removal) and make sure that it is properly attached to the wiper arm. NOTE: For reasons of safety, you should change the windshield wiper blades as soon as they start to leave marks on the windshield or fail to wipe efficiently and cleanly.
Page 200 2002 VOLVO V70 wiper blade into place. The long section of the blade should point toward the grille. Check that the new blade is properly attached to the wiper arm. Contents Top of Page file:///K|/ownersdocs/2002/2002_V70/02v70_08b.htm (16 of 16)12/30/2006 3:59:17 PM...
Page 201 138 Label information B<>1 Vehicle Emission Control Information Your Volvo is designed to meet all applicable emission standards, as evi-denced by the certification label on the underside of the hood. For further informa-tion regarding these regulations, please consult your Volvo retailer.
Page 202 6 Federal Motor Vehicle Safety Stan-dards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the facing side of the driver's door. For further informa-tion regarding these regulations, please consult your Volvo retailer.
Page 203: Dimensions And Weights
Width 70.9 in. (180 cm), Cross Country - 73.2 in. (186 cm) Height 57.5 in. (146 cm), V70 AWD - 58.7 in. (149 cm), Cross Country - 61.4 in. 156 cm) Wheelbase 108.7 in. (276 cm), Cross Country - 108.7 in. (276 cm) Track, front 61.4 in.
Page 204: Engine/Transmission Specifications
** The max permissible axle loads or the gross vehicle weight must not be exceeded. pg. 140 Engine/transmission specifications Engine specifications Designation: Volvo B 5234 T3 Output 247 hp at 5200 rpm (184 kW/87 rps) Max. torque 243 ft. lbs. at 2400-5200 rpm (330 Nm/42-87 rps) Number of cylinders 5 Bore 3.19"...
Page 205 3rd gear 1.19:1 4th gear 0.87:1 5th gear 0.70:1 Reverse 3.30:1 Designation: Volvo B 5244 T3 Output 197 hp at 6000 rpm (147 kW/100 rps) Max. torque 210 ft. lbs. at 1800-5000 rpm (285 Nm/30-83 rps) Number of cylinders 5 Bore 3.27"...
Page 206: Oil/Fluid Specifications And Volumes
Engine Oil Meeting or exceeding ILSAC specification GF-2, including ACEA A1, API SJ, SJ/CF, and SJ/Energy Conserving. Oil additives must not be used unless advised by an authorized Volvo retailer. Volume: Capacity (including oil filter): 6.1 US qts. (5.8 liters) Capacity (including oil filter and oil cooler): 7.1 US qts.
Page 207: Fuel System, Distributor Ignition System, Suspension
Washer fluid reservoir Volume: 4.7 US qts (4.5 liters) * 18.5 US gals (70 liters) on V70 AWD, Cross Country and V70 with non-turbo engine. All specifications are subject to change without prior notice. pg. 142 Fuel system, Distributor ignition system, Suspension Fuel system The engine is equipped with a multiport fuel injection system.
Page 208: Electrical System
Voltage: 12 Volt, capacity: 600 A/115 min reserve capacity. The battery contains corrosive and poisonous acids. It is of the utmost importance that old batteries are disposed of correctly. Your Volvo retailer can assist you in this matter. Generator Rated output: max. current: 120 A...
Page 209: Volvo On Call
SV 8.5 Cargo area lights SV 8.5 Glove compartment light BA 9s Vanity mirror lights W 2.1x9.5d Instrument lighting 2.1x9.5d All specifications are subject to change without prior notice. pg. 144 Volvo On Call file:///K|/ownersdocs/2002/2002_V70/02v70_09.htm (9 of 10)12/30/2006 3:59:19 PM...
Page 210 2002 VOLVO V70 Your new Volvo comes with a four year ON CALL road assistance. Additional information, features, and benefits are described in a separate information package in your glove compartment. If you have misplaced your package, dial: In the U.S.A.
Page 211: Audio Systems
2002 VOLVO V70 2 0 0 2 VOLVO Chapter 10 - Audio systems pg. 145 Audio systems HU-413 overview 146 HU-613 overview 147 HU-803 overview 148 Functions 149 Specifications 160 General information pg. 146 Audio system HU-413 - overview file:///K|/ownersdocs/2002/2002_V70/02v70_10a.htm (1 of 11)12/30/2006 3:59:21 PM...
Page 212 2002 VOLVO V70 1. Display 2. Radio - Manual station selection Cassette - Fast winding forward/backward CD - Fast forward/backward. 3. Radio - Station seek up/down Cassette - selecting next/previous track CD - Selecting next/previous track 4. Fader - press and turn Balance - press, pull and turn 5.
Page 213 2002 VOLVO V70 1. On/off - press Volume - turn 2. Selector knob for: Stored radio frequencies CD changer - selecting disc 3. Selector knob: Radio Cassette CD changer TV (option on certain models) 4. Fader - press and turn Balance - press, pull and turn 5.
Page 214 2002 VOLVO V70 16. Cassette opening 17. Cassette eject 18. Display pg. 148 Audio system HU-803 - overview 1. On/off - press Volume - turn 2. Bass - press and turn Treble - press, pull and turn 3. Fader - press and turn Balance - press, pull and turn 4.
Page 215: Volume Control
2002 VOLVO V70 10. Dolby Pro Logic - switching on 11. 2 channel stereo 12 3 channel stereo 13. CD slot 14. CD random play 15. Program type 16. News 17. Traffic information 18. Automatic presetting of radio stations 19. Display pg.
Page 216 2002 VOLVO V70 Bass Adjust the bass by pressing the button to ex-tend the control and turning it to the left (less bass) or to the right (more bass). A "detent" indicates "equalized" bass. Press the button back in when you have made the adjustment.
Page 217 2002 VOLVO V70 Fader - Balance front/rear Adjust front/rear speaker balance by pressing the button to extend the control and turning it to the left (more sound from the rear speakers) or to the right (more sound from the front speakers). A "detent"...
Page 218 2002 VOLVO V70 Station seek up/down If you have a key pad in the steering wheel press the right or left arrow to switch between preset stations. Scan function Press the SCAN button (HU-613) or the SOURCE button (HU-803) to start the station scan function.
Page 219 The RDS or Radio Data System operates in the FM band only, and the information transmitted is supplied exclusively by participating broadcasters. Volvo has no control over the accuracy of the data or information. Please refer to the following pages regarding specific descriptions and operation of these functions.
Page 220 2002 VOLVO V70 will find the radio in your car is equipped to take advantage of this system. pg. 152 Audio systems HU-803 - radio Traffic information (TP) -HU- 803 only This feature may not be apply in your area and only functions with FM broadcasts. (See previous page) Push the "TP"...
Page 221 2002 VOLVO V70 News on/off - HU-803 only This feature may not apply in your area and only functions with FM broadcasts. (See previous page) Press the "NEWS" button to activate the news function. The text NEWS is displayed. Press the "NEWS"...
Page 222 2002 VOLVO V70 pg. 153 Audio systems HU-803 - radio Program types (HU-803 only) Program type Text displayed News News Information Inform Sports Sports Talk Talk Rock Rock Classic rock Cls_Rock Adult hits Adlt_Hit Soft rock Soft_Rck Top 40 Top_40...
Page 223 2002 VOLVO V70 Program type - HU-803 only The PTY function enables you to select specific types of programs. To search for a particular program type: 1. Press "PTY" button to initiate the function. The currently tuned station's program type is displayed.
Page 224 2002 VOLVO V70 If you change the volume when the TP, PTY or NEWS function is active, the new volume setting will be stored automatically. pg. 154 AUM (Advanced User Mode) - certain models AUM (Advanced User Mode) With the radio switched off, press and hold the volume wheel down for at least 5 seconds to start the AUM function.
Page 225 2002 VOLVO V70 The following functions are available on the HU-803 only: AF SWITCHING ON/OFF (automatic frequency update) - The AF function ensures that the strongest available transmitter for a program is selected. REGIONAL ON/OFF (regional radio program) - This function makes it possible to continue to listen to a regional transmitter, even if the signal is weak.
Page 226 2002 VOLVO V70 CD eject HU-613: If you press this button the CD stops playing and the disc is ejected. HU-803: The CD currently playing will be ejected. If more than one CD has been inserted, turn the "1- 20/DISC" to display the number of the CD you would like to eject and press the CD eject button.
Page 227: Playing A Cd
2002 VOLVO V70 Press "RND" to connect the random function. The unit plays tracks from the disc in random order. "RND" (random) is displayed as long as the function is activated. pg. 156 Audio system HU-413/HU-613/HU-803 - CD changer (option) CD changer The optional CD changer, mounted in the cargo area, can accommodate 10 discs.
Page 228 2002 VOLVO V70 Selecting a disc Turn the "1-20/DISC" knob. The number of the disc and track is displayed. Fast winding Press " " or " " to seek within a track. Next/previous track Press " " to skip to the next track or "...
Page 229 2002 VOLVO V70 Slide a cassette into the slot with the tape to the right (side 1 or A upwards). The ignition key must be in position I or II before a cassette can be inserted. "TAPE A" or "TAPE B" is displayed. When one side has finished playing the unit will automatically begin playing the other side.
Page 230 2002 VOLVO V70 The tape can be wound forward with " " and backwards with " ". During fast winding "FF" (forward) respectively "REW" (backward) is displayed. Fast winding is interrupted if you press the button again. Next/Previous track If you press "...
Page 231 2002 VOLVO V70 pg. 159 Dolby Surround Pro Logic HU-803 (option) 3 channel stereo To select 3 channel stereo press "3-CH". "3 ch" is displayed. Press "OFF" to return to 2 channel stereo. Center speaker volume Set the center speaker volume by pressing the button to extend the control and turning it to the left (quieter) or to the right (louder).
Page 232 2002 VOLVO V70 Set the power output of the rear channels by pressing the button to extend the control, pulling it out as far as possible and turning it left or right. A "detent" indicates "normal" power output. Press the button back after setting (Dolby Surround Pro Logic only).
Page 233 Take up slack using a pen or a pencil before inserting a cassette in the cassette slot. Cassette cleaning We recommend the use of the Volvo Cleaning Cassette available as a genuine Volvo accessory. Regular use improves sound quality, cleans vital parts and prevents tape tangle.
Page 234 2002 VOLVO V70 Volume control - Subwoofer Turn the knob clockwise to increase volume. Turn the knob counterclockwise to lower volume or switch off the subwoofer. Contents Top of Page file:///K|/ownersdocs/2002/2002_V70/02v70_10b.htm (13 of 13)12/30/2006 3:59:23 PM...
Page 235 2002 VOLVO V70 2 0 0 2 VOLVO HomeLink® Universal Transceiver (option) pg. 162 HomeLink® Universal Transceiver (option) HomeLink® Universal Transceiver HomeLink® is an advanced system that can be programmed to learn the codes of three different remote controlled-devices (e.g., garage door openers, remote lighting, entry door lock). HomeLink®'s sun visor- mounted transceiver, powered by your car's electrical system, may then be used in place of your hand- held remote controls.
Page 236 2002 VOLVO V70 2. Begin by erasing all 3 factory default channels. Hold down the two outside buttons (buttons 1 and 3 in the illustration) on the HomeLink® Universal Transceiver for about 20 seconds, until HomeLink®'s indicator light begins to flash. Then release the buttons.
Page 237 2002 VOLVO V70 Determining if your garage door uses a rolling code Determine, in one of the following ways, if your garage door uses a rolling code system and is manufactured after 1996: Refer to the garage door opener owner's manual for verification.
Page 238 2002 VOLVO V70 Erasing programmed buttons Individual buttons cannot be erased. To erase all three programmed buttons: 1. Turn the ignition key to the "accessory" position (II). 2. Hold down the two outside buttons on the HomeLink® Universal Transceiver for about 20 seconds, until HomeLink®'s indicator light begins to flash.
Page 239 2002 VOLVO V70 Contents Top of Page file:///K|/ownersdocs/2002/2002_V70/02v70_11.htm (5 of 5)12/30/2006 3:59:24 PM...
Page 240 2002 VOLVO V70 2 0 0 2 VOLVO INDEX pg. 178 - 181 Index ABS - warning light Accessory lights Adjusting the steering wheel Advanced User Mode (AUM) - radio 44 - 47 Air conditioning Air filter - engine Air pump system...
Page 241 2002 VOLVO V70 Ashtray Audio systems cassette deck CD player HU-413 - overview HU-613 - overview HU-803 - overview specifications AUM (Advanced User Mode) - radio Automatic car washing Automatic Locking Retractor (ALR) Automatic transmission 87, 88 Geartronic 86, 87...
Page 242: Child Safety
2002 VOLVO V70 Cargo eyelets Cargo net Catalytic converters - three-way Center armrest - 3-section rear seat Center backrest (3-section rear seat) Center console - switches Center head restraint - 3-section rear seat Center head restraint - rear seat Center seat head restraint...
Page 243 2002 VOLVO V70 Detachable trailer hitch - installing Detachable trailer hitch - removing Dimensions Direction indicators Distributor ignition system Door step courtesy lights - replacing Doors and locks Drive belt Driver's seat and remote keyless entry system Driving economy Driving mode indicator...
Page 244 2002 VOLVO V70 Engine air filter Engine compartment 131, 132 Engine oil Extension of cargo compartment Exterior courtesy lights Exterior features - overview Extra seat Fog light - rear Fog lights - front Folding passenger's seat backrest Foldtable Four wheel drive - towing...
Page 245 2002 VOLVO V70 Gas cap Gasoline Gear indicator 87, 88 Geartronic (automatic transmission) Generator Generator warning light Hand brake Handgrip - Cross Country Handling Hazard warning flashers Head restraint (center) - 3-section rear seat Head restraint - center rear Headlight bulbs - replacing...
Page 246 Additionally, your authorized Volvo retailer knows where accessories may and may not be safely installed in your Volvo. In all cases, please consult your authorized Volvo retailer before installing any accessory in or on your car.
Page 247 2002 VOLVO V70 driving safely. Distraction can lead to a serious accident. In addition to this general warning, we offer the following guidance regarding specific newer features that may be found in your vehicles: Never use a hand-held cellular telephone while driving. Some jurisdictions prohibit cellular telephone use by a driver while the vehicle is moving.
Page 248 2002 VOLVO V70 4 Engine oil level should be between the dipstick marks. The distance between the marks represents approx. 1.6 US qts (1.5 liters). See page 132. 5 Brake fluid - check, without removing the cap, that the level is above the MIN mark. Use brake fluid DOT 4+.
Page 249 2002 VOLVO V70 55 W 5 W W 2.1x9.5d 1157NA 21/4 BA 15d BA 15s Contents Top of Page Bulbs Power Socket US no. file:///K|/ownersdocs/2002/2002_V70/02v70_13.htm (4 of 4)12/30/2006 3:59:28 PM...
