Summary of Contents for Volvo C30

  • Page 1: Owners Manual

    VOLVO C30 Owners Manual Web Edition...
  • Page 3 DEAR VOLVO OWNER THANK YOU FOR CHOOSING VOLVO We hope you will enjoy many years of driving pleasure in your Volvo. In order to increase your enjoyment of the car, we recommend that The car has been designed for the safety and comfort of you and your you familiarise yourself with the equipment, instructions and mainte- passengers.
  • Page 4: Table Of Contents

    01 Safety 02 Instruments and controls Important information....... 10 Seatbelts........... 18 Overview, left-hand drive cars....46 Volvo and the environment....... 14 Airbag system........... 21 Overview, right-hand drive cars....48 Airbags............22 Driver's door control panel....... 50 Activating/deactivating the airbag*... 24 Combined instrument panel......
  • Page 5 Table of contents 03 Climate control 04 Interior 05 Locks and alarm General information on climate control..90 Front seats..........106 Remote control key with key blade..126 Manual climate control, AC....... 92 Interior lighting........111 Active locks..........129 Electronic climate control, ECC*....95 Storage spaces in the passenger com- Keyless drive*..........
  • Page 6 Table of contents 06 Starting and driving 07 Wheels and tyres 08 Car care General............ 142 General............ 194 Cleaning..........210 Refuelling..........144 Tyre pressure.......... 198 Touching up paintwork......214 Alcoguard*..........148 Warning triangle* and spare wheel * ..199 Rustproofing........... 215 Starting the engine........
  • Page 7 Table of contents 09 Maintenance and service 10 Infotainment system 11 Specifications Volvo service........... 218 General............ 250 Type designation........284 Self-maintenance........219 Audio functions........252 Dimensions and weights......286 Bonnet and engine compartment... 220 Radio functions........257 Engine specifications......289 Oils and fluids.........
  • Page 8 Table of contents 12 Alphabetical Index Alphabetical Index........308...
  • Page 9 Table of contents...
  • Page 10: Introduction

    Important information Reading the Owner's Manual In the event of uncertainty over what is stand- lighted in the owner's manual by means of the ard or an option/accessory, contact a Volvo text being slightly larger and printed in grey. Introduction dealer.
  • Page 11 Introduction Important information warning is ignored, may result in serious per- Information Procedure lists sonal injury or fatality. Procedures where action must be taken in a certain sequence are numbered in the owner's Risk of property damage manual. When there is a series of illustrations for step-by-step instructions each step is numbered in the same way as the corres- ponding illustration.
  • Page 12 If the car has Volvo On Call and there is a or others who may assert a legal right to have so that Volvo can fulfil legal requirements and change of owner, it is very important that these access to it.
  • Page 13 Introduction Important information Information on the Internet At www.volvocars.com there is further infor- mation concerning your car.
  • Page 14: Volvo And The Environment

    Introduction Volvo and the environment Volvo Cars' environmental philosophy Environmental care is one of Volvo Car Corpo- Fuel consumption many cases the exhaust emissions are well ration's core values which influence all opera- below the applicable standards. Volvo cars have competitive fuel consumption tions.
  • Page 15 Interior • If the car is equipped with an engine block The interior of a Volvo is designed to be plea- The owner's manual and the heater*, use it before starting from cold - it sant and comfortable, even for people with...
  • Page 16 Seatbelts....................18 Airbag system..................21 Airbags....................22 Activating/deactivating the airbag*............24 Side airbags (SIPS bags)................ 26 Inflatable Curtain (IC)................28 WHIPS..................... 29 When the systems deploy............... 31 Crash mode.................... 32 Child safety..................... 33 Option/accessory, for more information, see Introduction.
  • Page 17 S A F E T Y...
  • Page 18: 01 Safety

    WARNING The seatbelt locks and cannot be with- drawn: Never modify or repair the seatbelt yourself. Volvo recommends that you contact an • if it is pulled out too quickly authorised Volvo workshop. If the seatbelt •...
  • Page 19 01 Safety Seatbelts Seatbelts and pregnancy such that they can easily maintain control of the Child seats are not covered by the seatbelt vehicle as they drive (which means that they reminder system. must be able to easily operate the foot pedals Rear seat and steering wheel).
  • Page 20 01 Safety Seatbelts Seatbelt tensioner Seatbelt guide All the seatbelts are equipped with seatbelt tensioners. A mechanism in the seatbelt ten- sioner tightens the seatbelt in the event of a sufficiently violent collision. The seatbelt then provides more effective restraint for occu- pants.
  • Page 21: Airbag System

    The symbol indi- cates a fault in the seatbelt tensioner sys- The warning symbol in the combined instru- tem, SIPS, SRS or the IC system. Volvo rec- ment panel illuminates when the remote con- ommends that you contact an authorised trol key is turned to key position I, II or III.
  • Page 22: Airbags

    01 Safety Airbags Airbag system WARNING NOTE Volvo recommends that you contact an The sensors react differently depending on authorised Volvo workshop for repair. the course of the collision and whether or Defective work in the airbag system could not the seatbelts on the driver's side and cause malfunction and result in serious per- passenger side are used.
  • Page 23 01 Safety Airbags Airbag on the driver's side WARNING The car has an airbag to supplement the pro- Never place a child in a child seat or on a tection afforded by the seatbelt on the driver's booster cushion in the front seat if the airbag side.
  • Page 24: Activating/Deactivating The Airbag

    Check that the switch is in the required posi- Switch location recommends that you visit an authorised tion. Volvo recommends that the key blade is Volvo workshop as soon as possible. The airbag is activated. With the switch in used to change position.
  • Page 25 01 Safety Activating/deactivating the airbag* A text message and a symbol in the roof panel WARNING NOTE indicate that the airbag for the front passenger Activated airbag (passenger seat): When the remote control key is turned to seat is deactivated (see preceding illustration). key position II or III the warning symbol for Never place a child in a child seat or on a the airbag is displayed on the combined...
  • Page 26: Side Airbags (Sips Bags)

    • Volvo recommends the use only of car seat covers approved by Volvo. Other seat covers may impede the operation of the side airbags.
  • Page 27 01 Safety Side airbags (SIPS bags) Front passenger seat, left-hand drive. The SIPS bag system consists of side airbags and sensors. A sufficiently violent collision trips the sensors and the side airbags are inflated. The airbag inflates between the occupant and the door panel and thereby cushions the initial impact.
  • Page 28: Inflatable Curtain (Ic)

    This could compromise the intended pro- on the inside of the car during a collision. WARNING tection. Volvo recommends that you only ever use Volvo genuine parts that are The inflatable curtain is a supplement to the approved for placement in these areas. seatbelts.
  • Page 29: Whips

    Never modify or repair the seat or WHIPS the seat with as little space as possible system yourself. Volvo recommends that The WHIPS system is a supplement to the between the head and the head restraint. seatbelts. Always use a seatbelt. you contact an authorised Volvo workshop.
  • Page 30 WARNING If a seat has been subjected to extreme forces, such as due to a rear-end collision, the WHIPS system must be checked. Volvo recommends that it is checked by an authorised Volvo workshop. Part of the WHIPS system's protective capacity may have been lost even if the seats appear to be undamaged.
  • Page 31: When The Systems Deploy

    Do not • Always contact a doctor. attempt to start the car since the airbags may deploy. Recovering the car. Volvo rec- ommends that you have it conveyed to an authorised Volvo workshop.
  • Page 32: Crash Mode

    If the car is in crash mode it must not be towed. It must be transported from its loca- Moving the car tion. Volvo recommends that you have it NORMAL MODE is shown after CRASH conveyed to an authorised Volvo workshop.
  • Page 33: Child Safety

    In the event of questions when fitting child beams under the seat. Sharp edges can dam- Volvo recommends that children travel in rear- safety products, contact the manufacturer age the straps. facing child seats until as late an age as pos- for clearer instructions.
  • Page 34 01 Safety Child safety Label Airbag WARNING WARNING Never place a child in a child seat or on a Booster cushions/child seats with steel booster cushion in the front seat if the airbag braces or some other design that could rest on the seatbelt buckle's opening button is activated must not be used, as they could cause the...
  • Page 35 Rear seat Front seat Group 0 Volvo infant seat (Volvo Infant Seat) - rear-facing child seat, Volvo infant seat (Volvo Infant Seat) - rear-facing child seat, secured with the ISOFIX fixture system. This fitting requires an secured with the ISOFIX fixture system.
  • Page 36 Rear seat Front seat Group 1 Volvo rear-facing/turnable child seat (Volvo Convertible Child Volvo rear-facing/turnable child seat (Volvo Convertible Child Seat) - rear-facing child seat, secured with the car's seatbelt Seat) - rear-facing child seat, secured with the car's seatbelt 9 –...
  • Page 37 Rear seat Front seat Group 2 Volvo rear-facing/turnable child seat (Volvo Convertible Child Volvo rear-facing/turnable child seat (Volvo Convertible Child Seat) - rear-facing child seat, secured with the car's seatbelt Seat) - rear-facing child seat, secured with the car's seatbelt 15-25 kg and straps.
  • Page 38 UF: Suitable for front-facing universally approved child seats in this weight class. For information on activated/deactivated airbag, see page 24. To install a rear-facing child seat in the rear seat, Volvo recommends that you contact an authorised Volvo dealer to have the mounting points installed. WARNING...
  • Page 39 Volvo recommends that you contact an seat illustration above). authorised Volvo dealer for recommenda- Press the seat cushion down to access the tions about which ISOFIX child seats Volvo Reduced size, rear-facing mounting points. recommends. child seat Always follow the manufacturer's installation...
  • Page 40 01 Safety Child safety Types of ISOFIX child seat Type of child seat Weight Size class Passenger seats for ISOFIX installation of child seats Front seat Outer rear seat Infant seat transverse max. 10 kg Infant seat, rear-facing max. 10 kg (IL) Infant seat, rear-facing max.
  • Page 41 IUF: Suitable for front-facing ISOFIX child seats that are universally approved in this weight class. In order to be able to fit the infant/child seat in the rear seat, the front passenger seat has been adjusted to a location in front of centre position. Volvo recommends rear-facing child seats for this group.
  • Page 42 Volvo recommends that small children should ment point. sit in rear-facing child seats to as late an age as possible.
  • Page 43 01 Safety...
  • Page 44 Overview, left-hand drive cars..............46 Overview, right-hand drive cars.............. 48 Driver's door control panel..............50 Combined instrument panel..............51 Indicator and warning symbols............... 52 Information display.................. 56 Electrical socket..................58 Lighting panel..................60 Left-hand stalk switch................63 Right-hand stalk switch................66 Cruise control*..................
  • Page 45 I N S T R U M E N T S A N D C O N T R O L S...
  • Page 46: 02 Instruments And Controls

    02 Instruments and controls Overview, left-hand drive cars...
  • Page 47 02 Instruments and controls Overview, left-hand drive cars Steering wheel adjustment Reading lamp, right-hand side Bonnet release Seatbelt reminder and passenger seat air- bag indicator Control panel Interior rearview mirror Direction indicators, main beam, trip com- Display for climate control and infotain- puter ment system Lighting, fuel filler flap opener...
  • Page 48: Overview, Right-Hand Drive Cars

    02 Instruments and controls Overview, right-hand drive cars...
  • Page 49 02 Instruments and controls Overview, right-hand drive cars Electrical socket, cigarette lighter Reading lamp, right-hand side Blind Spot Information System, BLIS No function Switch, optional equipment No function Parking brake Sunroof controls Control panel Ignition switch Glovebox Windscreen wipers and washers, head- lamp washers Door handle Cruise control...
  • Page 50: Driver's Door Control Panel

    02 Instruments and controls Driver's door control panel Driver's door control panel Power windows Door mirror, left-hand side Door mirrors, setting Door mirror, right-hand side...
  • Page 51: Combined Instrument Panel

    02 Instruments and controls Combined instrument panel Speedometer. Tachometer – Indicates engine speed in Button for trip meter – Used to measure thousands of revolutions per minute (rpm). short distances. Short presses on the but- Direction indicators, left. ton switches between the two trip meters Indicator and warning symbols.
  • Page 52: Indicator And Warning Symbols

    02 Instruments and controls Indicator and warning symbols Functionality check, symbols Symbols in the centre of the instrument When the symbol illuminates: panel All indicator and warning symbols illuminate 1. Stop in a safe manner. Do not drive the car when the remote control key is turned to posi- further.
  • Page 53 ABS fault 3. Drive to a workshop to have the ABS sys- tem checked if the symbol remains lit. Rear fog lamp Volvo recommends that you seek assis- Stability system DSTC tance from an authorised Volvo workshop. No function Rear fog lamp...
  • Page 54 If the faulty. symbol illuminates and the oil level is normal Volvo recommends that you contact an author- Parking brake applied ised Volvo workshop. The symbol illuminates when the parking brake is applied.
  • Page 55 02 Instruments and controls Indicator and warning symbols ± Stop the car in a safe place and check the have the brake system checked. Volvo rec- High speed level in the brake fluid reservoir, see ommends that you seek assistance from If the car is moving faster than page 227.
  • Page 56: Information Display

    Specification Message Specification STOP SAFELY Stop the car in a safe TIME FOR REGU- Time for regular manner and turn off service. Volvo rec- LAR SERVICE the engine. Serious ommends that an risk of damage. authorised Volvo workshop carries SERVICE Volvo recommends out the service.
  • Page 57 161. run the engine at information on idling speed until the If shown repeatedly checking the oil message clears. For then Volvo recom- level, see page 223. more information, mends that an see page 161. authorised Volvo SOOT FILTER...
  • Page 58: 12 V Electrical Socket

    02 Instruments and controls Electrical socket 12 V electrical socket Electrical socket in the rear seat WARNING Always leave the plug in the socket when the socket is not in use. NOTE Optional equipment and accessories - e.g. TV screens, music players and mobile phones - which are connected to one of the passenger compartment's 12V electrical sockets, could be activated by the climate...
  • Page 59 02 Instruments and controls Electrical socket WARNING Always leave the plug in the socket when the socket is not in use.
  • Page 60: Lighting Panel

    Thumbwheel for headlamp levelling centre position. If necessary, the automatic the height of the beam. dipped beam can be deactivated. Volvo rec- Light switches 1. Turn the remote control key to position II. ommends that this is performed by an author- Thumbwheel for adjusting display and ised Volvo workshop.
  • Page 61 02 Instruments and controls Lighting panel The lamps are switched off automatically when Fog lamps Fuel filler flap the remote control key is turned to position I or Press button (5) to open the fuel filler flap when NOTE the car is unlocked, see page 134. Regulations for use of fog lamps vary from Instrument lighting country to country.
  • Page 62 02 Instruments and controls Lighting panel event of a malfunction. The function is only Daytime running lights - DRL* NOTE active in twilight or darkness and only when the To save fuel, daytime running lights (Daytime To achieve minimal energy consumption, car is moving.
  • Page 63: Left-Hand Stalk Switch

    02 Instruments and controls Left-hand stalk switch Stalk switch positions Direction indicators Switching, main and dipped beam The remote control key must be in position II Continuous flash sequence and the headlamp control in end position, see ± Move the stalk switch up or down to page 60, for main beam to be switched on.
  • Page 64 02 Instruments and controls Left-hand stalk switch Trip computer* car is stationary, " --.- " appears on the display. NOTE During the period for regeneration fuel con- If a warning message interrupts while you sumption may increase, see page 146. are using the trip computer, this message AVERAGE must be acknowledged.
  • Page 65 02 Instruments and controls Left-hand stalk switch MPH ACTUAL SPEED. Current speed is displayed in mph. Resetting 1. Select --- KM/H AVERAGE SPEED --.- L/100 KM AVERAGE 2. Reset with one press on the RESET but- ton. Press and hold the RESET button for at least five seconds to reset the average speed and average consumption at the same time.
  • Page 66: Right-Hand Stalk Switch

    02 Instruments and controls Right-hand stalk switch Windscreen wipers Single sweep Windscreen/headlamp washer Raise the stalk switch to make a Move the stalk switch toward the steering single sweep. wheel to start the windscreen and headlamp washers. The wipers will make several more sweeps once the stalk switch is released.
  • Page 67 If the rear window wiper is already on at normal speed, no change is made. The function for intermittent wiping for reverse can be deactivated. Volvo recommends that Move the stalk switch forward to start rear win- The rain sensor automatically activates the you contact an authorised Volvo workshop.
  • Page 68 02 Instruments and controls Right-hand stalk switch Activating the rain sensor: selected, or the sensitivity to rain when the rain sensor is selected. ± Press the button (B), see page 66. A display symbol shows that the rain sensor is active.
  • Page 69: Cruise Control

    02 Instruments and controls Cruise control* Activating Increasing or decreasing speed NOTE A temporary increase in speed (less than one minute) using the accelerator, such as while overtaking, does not affect the cruise control setting. When you release the accel- erator, the car will return to the programmed speed.
  • Page 70 02 Instruments and controls Cruise control* Return to the set speed – Press this button to resume the previously set speed. CRUISE appears on the combined instrument panel. Disengaging ± Press CRUISE to disengage the cruise control. CRUISE ON clears on the com- bined instrument panel.
  • Page 71: Keypad In The Steering Wheel

    02 Instruments and controls Keypad in the steering wheel* Button functions in order to enable control of the phone system with the arrow keys. To return to Audio only, press EXIT.. To return to the phone menu, press EXIT once again. With the ENTER button you can select, acti- vate and deactivate options in menus.
  • Page 72: Steering Wheel Adjustment, Hazard Warning Flashers

    02 Instruments and controls Steering wheel adjustment, hazard warning flashers Steering wheel adjustment WARNING NOTE Adjust the steering wheel before driving off, Regulations regarding the use of hazard never while driving. Before driving, check warning flashers vary from country to coun- that the steering wheel is fixed in position.
  • Page 73: Parking Brake

    02 Instruments and controls Parking brake Handbrake > The instrument panel's warning symbol Disengaging the parking brake is illuminated. 1. Press the foot brake pedal down firmly. 2. Pull the parking brake lever up slightly, NOTE press the button, lower the parking brake lever and release the button.
  • Page 74: Power Windows

    02 Instruments and controls Power windows Operation Driver's door obstructed by an object, the movement will stop. The power windows are operated using the controls in the doors. The ignition key must be WARNING in position I or II for the power windows to operate.
  • Page 75 02 Instruments and controls Power windows Passenger seat Passenger seat. The control in the front passenger door oper- ates that window only.
  • Page 76: Windows, Rearview And Door Mirrors

    02 Instruments and controls Windows, rearview and door mirrors Interior rearview mirror Interior rearview mirror with compass* Calibrating the compass The earth is divided into 15 magnetic zones. Bright light from behind could be reflected in The upper right-hand corner of the rearview The compass is set for the geographical area the rearview mirror and dazzle the driver.
  • Page 77 02 Instruments and controls Windows, rearview and door mirrors 4. Press the button (1) repeatedly until the 1– number for the required magnetic zone ( ) is shown, refer to the map of magnetic zones for the compass. 5. Wait until the display returns to showing the character 6.
  • Page 78 02 Instruments and controls Windows, rearview and door mirrors Door mirrors Retractable power door mirrors* NOTE The mirrors can be retracted for parking/driving The door mirrors will not be extended auto- in narrow spaces. This can be carried out in matically during unlocking if they were ignition position I and II.
  • Page 79 02 Instruments and controls Windows, rearview and door mirrors Blind Spot Information System, BLIS* BLIS is an information system that under cer- tain conditions can help to draw the driver's attention to vehicles moving in the same direc- tion in the so-called "blind spot", see page 173.
  • Page 80: Power Sunroof

    02 Instruments and controls Power sunroof* Open positions Ventilation position WARNING Open: If there are children in the car: ± Press the rear edge of the control (5) Switch off the supply to the power sunroof upward. by removing the remote control key if the driver leaves the car.
  • Page 81 02 Instruments and controls Power sunroof* closed position as long as the button is If you need to interrupt closing: Wind deflector kept depressed. ± Press the lock button again. WARNING WARNING The sunroof's pinch-protection function Make sure that children or other passengers only operates during automatic closing, not are not in danger of becoming trapped in manual closing.
  • Page 82: Personal Preferences

    02 Instruments and controls Personal preferences Possible settings Display Clock, adjustment Personal preferences can be set for some of The hour and minute are each adjusted sepa- MENU the car's functions. This applies to locks, cli- rately. mate control and audio functions. For audio EXIT 1.
  • Page 83 02 Instruments and controls Personal preferences ± Select On/Off depending on whether or not Lock confirm. light door handle button on cars with the keyless you wish the recirculation timer to be system: The hazard warning flashers can provide feed- active.
  • Page 84 02 Instruments and controls Personal preferences • 30 seconds • 60 seconds • 90 seconds Information • VIN number… - (Vehicle Identification Number) is the car's unique identity num- ber. • Number of keys… - The number of keys registered for the car is shown.
  • Page 85: Homelink

    02 Instruments and controls HomeLink * General NOTE WARNING HomeLink is designed not to work if the car If HomeLink is used to operate a garage is locked from the outside. door or gate, ensure that nobody is in the vicinity of the door or gate while it is in Save the original remote controls for future motion.
  • Page 86 02 Instruments and controls HomeLink * The particular distance that is required ess is repeated for approx. 20 seconds Programming individual buttons and indicates that the device has a "roll- between the original remote control and To reprogram an individual button, proceed in ing code".
  • Page 87 02 Instruments and controls HomeLink * • Constant glow: The indicator lamp illu- 7. Depress the programmed button on minates with a constant glow when the HomeLink , while the "programming but- button is kept depressed, this indicates ton" is still flashing, keep it depressed for that the programming is complete.
  • Page 88 General information on climate control........... 90 Manual climate control, AC..............92 Electronic climate control, ECC*............. 95 Air distribution..................98 Fuel-driven engine block heater and passenger compartment heater*............. 99 Fuel-driven auxiliary heater* (diesel)............. 102 Option/accessory, for more information, see Introduction.
  • Page 89 C L I M A T E C O N T R O L...
  • Page 90: 03 Climate Control

    Fault tracing and repair Display The climate control system cools or heats as Volvo recommends that you only entrust fault There is a display above the climate control well as dehumidifies the air in the passenger tracing and repair of the climate control system panel.
  • Page 91: Climate Control

    03 Climate control General information on climate control Air vents in the dashboard ECC* Side windows and sunroof To ensure that the air conditioning works sat- Actual temperature isfactorily, close all side windows and the sun- The temperature you select corresponds to the roof (if fitted).
  • Page 92: Manual Climate Control, Ac

    03 Climate control Manual climate control, AC Control panel Functions 2. Recirculation Recirculation can be used to 1. Fan Recirculation shut out bad air, exhaust Increase or decrease the fan fumes, etc. from the passen- Defroster speed by turning the knob. ger compartment.
  • Page 93 03 Climate control Manual climate control, AC Timer 4. Air distribution 6. and 7. Heated front seats* The timer function reduces the risk of icing, The airflow can be distributed misting and bad air (if recirculation is selected). to the windows, dashboard See page 82, for activating/deactivating the vents or floor by pressing the function.
  • Page 94 03 Climate control Manual climate control, AC on the button. Automatic switching off discon- nects the rear window and door mirrors after 12 – 20 minutes depending on outside tem- perature. During cold weather the defrosting* also con- tinues after 20 minutes in order to keep the rear window and door mirrors free of ice and mist.
  • Page 95: Electronic Climate Control, Ecc

    03 Climate control Electronic climate control, ECC* Control panel AUTO Functions 2. Fan Turn the knob to increase or 1. AUTO decrease fan speed. If AUTO The AUTO function automat- is selected then fan speed is Recirculation/Air quality system ically regulates climate con- regulated automatically.
  • Page 96 03 Climate control Electronic climate control, ECC* • 3. Recirculation The air quality system consists of a multi-filter The defroster functions for the front, side and rear windows can be used to demist and a sensor. The filter separates gases and The function is selected to the windows.
  • Page 97 03 Climate control Electronic climate control, ECC* A symbol on the display above the climate con- 7 and 8. Heated front seats* on the button. Automatic switching off discon- trol panel and an illuminated light in the relevant nects the rear window and door mirrors after To activate front seat heating: button indicate which function has been 12 –...
  • Page 98: Air Distribution

    03 Climate control Air distribution Air distribution Use: Air distribution Use: Air to windows. Some air to remove ice and Air to the floor and windows. to ensure comfortable flows from the air vents. The misting quickly. Some air flows from the dash- conditions and good air is not recirculated.
  • Page 99: Fuel-Driven Engine Block Heater And Passenger Compartment Heater

    03 Climate control Fuel-driven engine block heater and passenger compartment heater* General information about heaters Refuelling Battery and fuel If the battery has insufficient charge or the fuel The parking heater heats the engine and pas- level is too low, the parking heater is switched senger compartment and can be started off automatically and a message appears on directly or with the timer.
  • Page 100 03 Climate control Fuel-driven engine block heater and passenger compartment heater* Activating the heater Symbols and display messages Display Specification When one of the timer's settings or HEATER STOP- The heater has been Direct start is activated, the infor- stopped by the car's PED LOW BAT- mation symbol in the combined electronics in order...
  • Page 101 03 Climate control Fuel-driven engine block heater and passenger compartment heater* Heating of the passenger compartment will After setting TIMER 1 a second start time can NOTE begin as soon as the engine coolant has be programmed with TIMER 2 by scrolling with All timer programming will be cleared if the reached the correct temperature.
  • Page 102: Fuel-Driven Auxiliary Heater* (Diesel)

    03 Climate control Fuel-driven auxiliary heater* (diesel) Auxiliary heater (diesel) In diesel-engined cars the auxiliary heater may be required for achieving the correct tempera- ture in the engine and passenger compartment during cold weather. The heater starts automatically when extra heat is required when the engine is running.
  • Page 103 03 Climate control...
  • Page 104 Front seats.................... 106 Interior lighting..................111 Storage spaces in the passenger compartment ........114 Rear seat....................118 Cargo area.................... 120...
  • Page 105 I N T E R I O R...
  • Page 106: 04 Interior

    04 Interior Front seats Seating position, manual seat Backrest rake: turn the wheel. Seating position, power seat* Control panel for power seat*. Lever (2) is not available on all seat models. WARNING Adjust the position of the driver's seat and adjust the seatbelt, see page 18, before set- ting off, never while driving.
  • Page 107 04 Interior Front seats An overload protection is deployed if one of the Emergency stop Entry to rear seat, manual seat seats is blocked. If this happens, turn off the If the seat accidentally begins to move, press ignition and wait a short time before adjusting any of the buttons to stop the function.
  • Page 108 04 Interior Front seats Push the seat forward Push the seat backward: Lift the handle Release the seatbelt from the seatbelt Lift the handle and fold back the backrest. Fold the backrest forward to the locked guide, see also page 20. position.
  • Page 109 04 Interior Front seats 3. Continue to lift of the handle, and push the seat forward to the desired position and release the handle. Entry to rear seat, power seat Push the seat forward Lift the handle. Hold down the front section of the button. If the seat is set in a higher position - then Fold the backrest forward to the locked it will be lowered automatically to avoid the...
  • Page 110 The belt on the front passenger side must be in the belt guide during driving, even when there is no passenger sitting in the seat. Inlaid mats* Volvo supplies inlay mats which are especially produced for your car. WARNING Before setting off check that the inlaid mat Lift the handle and fold back the backrest.
  • Page 111: Interior Lighting

    04 Interior Interior lighting Reading lamps and interior lighting Roof lighting Glovebox lighting The reading lamps are switched on or off by Glovebox lighting is switched on and off pressing the relevant button in the roof con- respectively when the lid is opened or closed. sole.
  • Page 112 04 Interior Interior lighting Automatic lighting Passenger compartment lighting comes on and remains on for 5 minutes if one of the doors Using the switch (2), see page 111, three posi- is open. tions can be selected for the lighting the pas- senger compartment: If any lighting is switched on manually and the car is locked then it will be switched off auto-...
  • Page 113 04 Interior Interior lighting...
  • Page 114: Storage Spaces In The Passenger Compartment

    04 Interior Storage spaces in the passenger compartment Storage spaces...
  • Page 115 04 Interior Storage spaces in the passenger compartment Storage compartment in door panel. Glovebox Coat hanger Storage pocket on front edge of front seat cushions (trim dependent). Ticket clip Coat hanger, only for light garments. Glovebox Storage compartment (e.g. for CD discs and cup holder, *) and storage compart- ment behind the centre console.
  • Page 116 04 Interior Storage spaces in the passenger compartment Storage under the front armrest Cup holder in centre console In the deeper compartment there is space for 10 normal CD cases. The cases must be stored There is a storage space under the armrest. There is space for a double cup holder under vertically on the top edge for all 10 to have There is also a smaller storage space in the...
  • Page 117 04 Interior Storage spaces in the passenger compartment Storage compartment behind the gear Bottle holder* Ashtray* lever A bottle holder for larger bottles is located on An ashtray is located towards the rear of the the rear of the tunnel console. tunnel console.
  • Page 118: Rear Seat

    04 Interior Rear seat Head restraint, rear Lowering the rear seat backrest shows that the backrest is no longer locked in place. IMPORTANT 2. Fold the backrest forward. There must be no objects on the rear seat Raising the backrest when the backrest is to be folded down.
  • Page 119 04 Interior Rear seat long load. The armrest folds down when one of WARNING the backrests is folded down. Place the belt straps over the backrests For securing loads, see page 189. before folding them back to their secured positions. NOTE When the backrest has been raised, the red indicator (A) should no longer be showing.
  • Page 120: Cargo Area

    04 Interior Cargo area Soft cargo cover* Hanging up the cargo cover when not in Hard cargo cover* 1. Unhook the hooks from the rear load retaining eyelets (D). 2. Press the rail together and remove it from the rear bracket (C). Place the rail at the front of the cargo area floor.
  • Page 121 04 Interior Cargo area The cargo cover hatch can be raised during Raising the floor hatch loading. NOTE The cargo cover has no load-securing func- tion. Never load anything on top of the cargo cover. For securing loads, see page 189. Removing the cargo cover 1.
  • Page 122 04 Interior Cargo area Safety net* Removing the safety net Load retaining eyelets* 1. Slacken the tension from the straps. 2. Undo the hooks from the eyes at the seat- belt floor mounting on both sides. 3. Detach the net from the mounting points in the roof panels.
  • Page 123 04 Interior...
  • Page 124 Remote control key with key blade............126 Active locks................... 129 Keyless drive*..................130 Battery in remote control key..............133 Locking and unlocking................134 Alarm*....................137 Option/accessory, for more information, see Introduction.
  • Page 125 L O C K S A N D A L A R M...
  • Page 126: 05 Locks And Alarm

    The car is supplied with 2 remote control keys. If you lose a remote control key, take the car and the other remote control keys to a Volvo The remote control keys contain detachable workshop - an authorised Volvo workshop is metal key blades for mechanical locking/ recommended.
  • Page 127 05 Locks and alarm Remote control key with key blade • Unlocking – Unlocks the doors and the the driver's door can be opened manually IMPORTANT if central locking cannot be activated with tailgate. Press and hold (at least 4 seconds) The narrow section of the remote control the remote control key, see page 131.
  • Page 128 05 Locks and alarm Remote control key with key blade 1. Insert the key blade in the driver's door The glovebox can only be locked/unlocked keyhole. using the remote control key's detachable key blade. (For information on the key blade, see 2.
  • Page 129: Active Locks

    05 Locks and alarm Active locks Active locks for remote control key with key blade. Active locks for remote control key with- out key blade.
  • Page 130: Keyless Drive

    05 Locks and alarm Keyless drive* • Keyless lock and ignition system Remote control key max. 1.5 m from the the READ button has been pressed. Never leave any remote control key in the In order to open a door or the tailgate, a remote control key must be no more than approx.
  • Page 131 05 Locks and alarm Keyless drive* Locking Unlocking doors with the key blade NOTE On cars with the keyless drive system and automatic transmission the gear selector must be moved to the P position and the ignition dial turned to the 0 position. Other- wise the car cannot be locked or alarmed.
  • Page 132 05 Locks and alarm Keyless drive* Centre console, under the rear section NOTE Door handle, right-hand rear When the driver's door is unlocked using the key blade and is opened, the alarm is trig- Centre console, under the front section gered.
  • Page 133: Battery In Remote Control Key

    05 Locks and alarm Battery in remote control key Low battery in remote control key 1. Place the remote control key with the key- pad downward and prize up the cover When the battery runs down and full function- using a small screwdriver. ality cannot be guaranteed, the information symbol and display show...
  • Page 134: Locking And Unlocking

    05 Locks and alarm Locking and unlocking Locking/unlocking the car from Automatic relocking WARNING outside If none of the doors or the tailgate is opened Be aware of the risk of being locked in the within 2 minutes of unlocking, all are locked For cars with the Keyless system, see car when it is locked from the outside using page 130.
  • Page 135 05 Locks and alarm Locking and unlocking Global opening Automatic locking WARNING ± Press the upper section of the central lock- When the speed of the car exceeds 7 km/h the Do not allow anyone to remain in the car ing button doors and tailgate are locked automatically.
  • Page 136 05 Locks and alarm Locking and unlocking Deactivation is carried out as follows: The next time the remote control key is turned to key position II the system is reset to zero and 1. Access the menu system under the instrument panel display shows the mes- SETTINGS (for a detailed description of sage...
  • Page 137: Alarm

    – the alarm has been triggered. If there is a fault in the alarm system, a message appears on the display. At which point you should contact a workshop - an authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
  • Page 138 05 Locks and alarm Alarm* Automatic re-arming of the alarm Remote control key not working Alarm signals This function prevents the car being left with When the alarm is triggered, the following hap- the alarm disarmed unintentionally. pens: • If the car is unlocked with the remote control A siren sounds for 25 seconds or until the alarm is deactivated.
  • Page 139 05 Locks and alarm Alarm* 4. Test the movement detector by lifting out 4. Open the bonnet with the handle under the a bag from a seat for example. dashboard. > A siren should sound and all direction > A siren should sound and all direction indicators should flash.
  • Page 140 General....................142 Refuelling....................144 Alcoguard*.................... 148 Starting the engine................152 Starting the engine – Flexifuel............... 154 Keyless drive*..................156 Manual gearbox..................157 Automatic gearbox................158 DRIVe Start-Stop*................. 163 Brake system..................167 DSTC – Stability and traction control system*........169 Park Assist*................... 171 BLIS* –...
  • Page 141 S T A R T I N G A N D D R I V I N G...
  • Page 142: 06 Starting And Driving

    06 Starting and driving General Economical driving For more information and further advice, see brake linings wet resulting in delayed brake the pages 15 and 295. function. Driving economically means driving smoothly while thinking ahead and adjusting your driving • Clean the electric contacts of the electric WARNING style and speed to the prevailing conditions.
  • Page 143 Do not use functions one of a greater capacity than the standard which use a lot of power when the engine is model. Check with your nearest Volvo dealer switched off. Examples of such functions are: regarding the options for your car.
  • Page 144: Refuelling

    06 Starting and driving Refuelling Opening the fuel filler flap 3. Take out the cap. General information on fuel 4. Hang up the cap on the inside of the fuel WARNING filler flap. Always avoid inhaling fuel vapour and get- NOTE ting fuel splashes in the eyes.
  • Page 145 Mixing different types of fuel or the use of adjusted. These adjustments create optimal nents, and do not replace components with fuel not recommended invalidates Volvo's conditions for efficient combustion of harmful parts that are not specifically designed for use...
  • Page 146 IMPORTANT specified in the Service and Warranty Booklet damage that is not covered by the Volvo or if you suspect that the car has been filled warranty. The sulphur content must be a maximum of with contaminated fuel.
  • Page 147 06 Starting and driving Refuelling called "regeneration" is started in order to burn way. The car should then be driven for approx- away the particles and empty the filter. This imately 20 minutes more. requires the engine to have reached normal NOTE operating temperature.
  • Page 148: Alcoguard

    06 Starting and driving Alcoguard* General information on the Alcolock Functions Operation The function of the Alcolock is to prevent the Battery car from being driven by individuals under the Alcolock indicator lamp (4) shows battery sta- influence of alcohol. Before the engine can be tus: started the driver must take a breath test that verifies that he/she is not under the influence...
  • Page 149 30 minutes within these 30 days then normal engine star- without a new breath test. ting will be blocked - only starting with the An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
  • Page 150 This setting can be nect the power supply cable from the glovebox changed afterwards at a workshop and wait until indicator lamp (6) is green. An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
  • Page 151 Test failed - take a INVALID TEST new breath test. ALCOGUARD Blowing too short - blow for longer. BLOW LONGER ALCOGUARD Blowing too hard - blow more gently. BLOW SOFTER An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
  • Page 152: Starting The Engine

    06 Starting and driving Starting the engine ± Before starting the engine Turn the ignition key to the start position NOTE III and just release it - the starter motor ± Apply the parking brake. The idling speed can be noticeably higher then works automatically until the engine than normal for certain engine types during Note that if the car is equipped with an alcolock...
  • Page 153 06 Starting and driving Starting the engine II – Driving position 2. Hold the steering wheel in this position. Reinsert the key and make a new attempt The remote control key's to start the car. position when driving. The whole electrical system is engaged.
  • Page 154: Starting The Engine - Flexifuel

    III. connections must only be carried out by a 3. When the engine has started, ease the workshop - an authorised Volvo workshop accelerator pedal gradually as the engine is recommended. speed increases.
  • Page 155 06 Starting and driving Starting the engine – Flexifuel NOTE IMPORTANT Points to remember for carrying reserve After the fuel mixture in the tank has been fuel: changed an adaptation should be made by driving at an even speed for about 15 •...
  • Page 156: Keyless Drive

    06 Starting and driving Keyless drive* General Starting the car Starting with the remote control key ± Depress the clutch pedal (cars with manual gearbox) or brake pedal (cars with auto- matic gearbox). Petrol engine ± Press in and turn the ignition dial to key position III.
  • Page 157: Manual Gearbox

    06 Starting and driving Manual gearbox Gear positions Gear shift indicator - GSI* GSI - Gear Shift Indicator - advises the driver of the opti- mum time to change gear. The indication is given with an arrow for up and down shift- ing respectively in the lower information display of the combined instrument panel, see page 51.
  • Page 158: Automatic Gearbox

    06 Starting and driving Automatic gearbox Geartronic automatic gear positions Geartronic manual gear positions (+/-) NOTE The driver can also change gear manually The brake pedal must be depressed in order using the Geartronic automatic gearbox. The to be able to disengage the gear lever from car engine-brakes when the accelerator pedal the P position.
  • Page 159 06 Starting and driving Automatic gearbox Kick-down Mechanical gear selector inhibitor Automatic gear selector inhibitor When the accelerator pedal is pressed all the Cars with an automatic gearbox have special way to the floor (beyond the position normally safety systems: regarded as full acceleration) a lower gear is Keylock immediately engaged.
  • Page 160 06 Starting and driving Automatic gearbox Disengaging the gear selector inhibitor Cold start Automatic gearbox, Powershift* When starting in low temperatures, the gear changes can sometimes feel hard. This is due to the gearbox oil's viscosity at low tempera- tures. To reduce engine emissions, the gear- box shifts up later than normal when the engine is started at low temperatures.
  • Page 161 06 Starting and driving Automatic gearbox In the event of uncertainty as to whether or not message. The transmission can also overheat For important information regarding Powershift the car is equipped with Powershift transmis- during slow driving in queues (10 km/h or transmission and towing - see page 176.
  • Page 162 06 Starting and driving Automatic gearbox Symbol Display Driving characteristics Action TRANSM. OVERHEAT BRAKE TO Difficulty in maintaining even speed at con- Gearbox overheated. Keep the car station- stant engine speed. HOLD ary using the foot brake TRANSM. OVERHEAT PARK SAFELY Significant pulling in the car's traction.
  • Page 163: Drive Start-Stop

    Adapted power steering Another DRIVe function is that the power steer- Environmental care is one of Volvo Car Corpo- ing's energy take-off is adapted according to ration's core values and it influences all of our requirements.
  • Page 164 06 Starting and driving DRIVe Start-Stop* • Function and operation All of the car's normal systems such as lighting, Release the foot brake and let the car roll faster than normal walking pace - the radio, etc. work as normal even with an auto- engine starts.
  • Page 165 06 Starting and driving DRIVe Start-Stop* Deactivating the Start/Stop function Limitations In the following cases the engine auto-starts even if the driver has not depressed the clutch The engine does not auto-stop pedal in order to engage a gear: Even if the Start/Stop function is activated, the •...
  • Page 166 If a message does not go out following com- Message opened - a display text prompts the driver pletion of the action then a workshop should to start the engine normally. be contacted - an authorised Volvo workshop AUTO START- Illuminates for is recommended. •...
  • Page 167: Brake System

    06 Starting and driving Brake system Brake servo Dampness can affect braking Bear in mind that driving with a trailer puts an additional load on the car's brakes. characteristics If the car is rolling or is being towed with the Brake components become wet when the car engine turned off, the brake pedal must be is driven in heavy rain, through pools of water...
  • Page 168 - an author- 10 km/h the brake light returns from flashing to ised Volvo workshop is recommended. the normal constant glow - while at the same time the hazard warning flashers are activated,...
  • Page 169: Dstc - Stability And Traction Control System

    06 Starting and driving DSTC – Stability and traction control system* General Reduced operation Operation 1. Turn the thumbwheel until the DSTC menu The stability and traction control system, DSTC appears. (Dynamic Stability and Traction Control) helps the driver to avoid skidding and improves the DSTC ON means that the system function car's traction.
  • Page 170 DSTC system. > If the message remains when the engine is restarted, drive to a workshop. An authorised Volvo workshop is recom- mended. Symbols in the combined instrument panel DSTC system Information Option/accessory, for more information, see Introduction.
  • Page 171: Park Assist

    Rear parking assistance is deactivated then this is automatically lowered. automatically when towing a trailer if a Volvo The tone becomes constant at a distance of genuine trailer cable is used. about 30 cm. If there are obstacles within this...
  • Page 172 Front parking assistance is active at speeds attention, contact a workshop - an authorised below 15 km/h. The system is deactivated at Volvo workshop is recommended. higher speeds. When the speed is below 10 km/h the system is reactivated. IMPORTANT...
  • Page 173: Blis* - Blind Spot Information System

    06 Starting and driving BLIS* – Blind Spot Information System General BLIS is an information system that under cer- Blind spots tain conditions can help to draw the driver's attention to vehicles moving in the same direc- tion in the so-called "blind spot". The system is designed to work most effec- tively when driving in dense traffic on multi-lane highways.
  • Page 174 06 Starting and driving BLIS* – Blind Spot Information System Activate/deactivate ton to clear the text message. For more infor- WARNING mation on messages, see page 56. BLIS does not work in sharp bends. BLIS system message BLIS does not work when the car is revers- ing.
  • Page 175 BLIS SERVICE must only be performed by a workshop - an REQUIRED authorised Volvo workshop is recom- mended. Here are several examples of situations where the BLIS indicator lamp may illuminate even if Low sun in the camera.
  • Page 176: Towing And Recovery

    06 Starting and driving Towing and recovery ± Start assistance Move the gear selector to position N and WARNING release the parking brake. Use a donor battery if the battery is discharged The steering lock remains in the position it and the engine does not start.
  • Page 177 06 Starting and driving Towing and recovery IMPORTANT Avoid towing. • However, the car can be towed for a short distance at low speed to move it from a dangerous position - not further than 10 km and not faster than 10 km/h.
  • Page 178 06 Starting and driving Towing and recovery Towing eye turning it outwards. Then turn out the The towing eye is screwed into a threaded Finish by refitting the cover onto the cover completely and remove it. socket behind a cover on the right-hand side bumper.
  • Page 179 06 Starting and driving Towing and recovery NOTE On certain cars with fitted towbar the towing eye cannot be secured in the rear mounting. In which case, secure the tow rope in the towbar. For this reason it is advisable to store the towbar's towball in the car, see page 183.
  • Page 180: Start Assistance

    06 Starting and driving Start assistance Starting with a donor battery 4. Connect one of the red jump lead's clamps IMPORTANT to the donor battery's positive terminal (1). Do not touch the crocodile clips during the start procedure. There is a risk of sparks IMPORTANT forming.
  • Page 181: Driving With A Trailer

    • Avoid driving with a trailer on inclines of If the towing bracket is fitted by an authorised more than 12%. Volvo workshop, then the car is delivered with Overheating • For safety reasons, the maximum permit- the necessary equipment for driving with a...
  • Page 182 06 Starting and driving Driving with a trailer Automatic gearbox hitched trailer. Always use the parking brake. Overheating • Block the wheels with chocks when park- When driving with a trailer in hilly terrain in a hot ing a car with hitched trailer on a hill. climate there may be a risk of overheating.
  • Page 183: Towing Equipment

    If the car is equipped with a detachable towbar, the installation instructions for the loose sec- tion must be followed carefully, see page 185. WARNING If the car is fitted with a Volvo detachable towbar: • Follow the installation instructions care- fully.
  • Page 184 06 Starting and driving Towing equipment* Specifications Dimensions for mounting points (mm) Option/accessory, for more information, see Introduction.
  • Page 185: Detachable Towbar

    06 Starting and driving Detachable towbar* Fitting the towbar 2. Ensure that the mechanism is in the 3. Check that the indicator window (3) shows unlocked position by turning the key clock- red. If the window does not show red, 1.
  • Page 186 06 Starting and driving Detachable towbar* 5. Check that the indicator window shows green. 4. Insert the towbar until you hear a click. 7. Check that the towbar is secure by pulling it up, down and back. WARNING 6. Turn the key anticlockwise to locked posi- tion.
  • Page 187 06 Starting and driving Detachable towbar* Removing the towbar 8. Safety cable. 2. Push in the locking wheel and turn it 1. Insert the key and turn it clockwise to the anticlockwise until you hear a click. WARNING unlocked position. Be sure to attach the trailer's safety cable to the correct place.
  • Page 188 06 Starting and driving Detachable towbar* 3. Turn the locking wheel down fully, until it 4. Push on the protective cover. comes to a stop. Hold it in this position while pulling the towbar rearward and upward. WARNING Secure the towbar safely if it is stored in the car, see page 183.
  • Page 189: Loading

    For more detailed infor- for your car by Volvo. surface of the tailgate. mation on weights, see page 287. Carefully follow the mounting instructions sup- •...
  • Page 190: Adjusting Headlamp Pattern

    On cars with Xenon headlamps, the dazzling oncoming motorists. replacement of Xenon lamps must be car- ried out at a workshop - an authorised Volvo The correct pattern will also better illuminate workshop is recommended. Working with the verge.
  • Page 191 06 Starting and driving...
  • Page 192 General....................194 Tyre pressure..................198 Warning triangle* and spare wheel * ............ 199 Changing wheels................... 201 Emergency puncture repair* ..............203 Option/accessory, for more information, see Introduction.
  • Page 193 W H E E L S A N D T Y R E S...
  • Page 194: 07 Wheels And Tyres

    07 Wheels and tyres General Driving characteristics and tyres Speed ratings New tyres The tyres greatly affect the car's driving cha- The car is approved as a whole, which means racteristics. The type of tyre, dimensions, tyre that dimensions and speed ratings must not pressure and speed rating are important for differ from those specified on the vehicle reg- how the car performs.
  • Page 195 A suitable dis- cially the studs, a longer service life. tance for the first change is approx. 5000 km and then at 10 000 km intervals. Volvo recom- NOTE mends that you contact an authorised Volvo Tread wear indicators.
  • Page 196 1. Tighten the wheel nuts of model (1) to 110 washer. Only use wheel rims that are tested and Nm. Tighten the wheel nuts of model (2) to approved by Volvo and which are included in 130 Nm. NOTE the Volvo genuine accessories range.
  • Page 197 The spare wheel (Temporary spare) is only Volvo recommends that you contact an author- intended for use temporarily and must be ised Volvo workshop for checking if you are replaced by an ordinary wheel as soon as pos- uncertain about tread depth.
  • Page 198: Tyre Pressure

    07 Wheels and tyres Tyre pressure Recommended tyre pressure DRIVe* NOTE An important detail in connection with environ- Tyre pressure decreases over time, this is a mentally-conscious driving is to use the right natural phenomenon. Tyre pressure also type of tyres and to drive with the correct air varies depending on ambient temperature.
  • Page 199: Warning Triangle* And Spare Wheel

    Spare wheel* and jack * NOTE triangle*. Place the warning triangle in a suita- Volvo recommends only using the jack* that The car's original jack* ble place with regard to the traffic. belongs to the car model in question, which The original jack* must only be used for chang- 1.
  • Page 200 07 Wheels and tyres Warning triangle* and spare wheel * Putting the spare wheel* and jack* into the cargo area Wheel wrench*. Jack* and handle, secured with a tension- ing strap. The spare wheel is bolted down with the rim side down using the through-bolt. Tools - returning into place Tools and jack* must be returned into place in the correct manner after use.
  • Page 201: Changing Wheels

    07 Wheels and tyres Changing wheels Removing wheels NOTE Volvo recommends only using the jack* that belongs to the car model in question, which is indicated on the jack's label. The label also indicates the jack's maximum lift capacity at a specified minimum lifting height.
  • Page 202 07 Wheels and tyres Changing wheels Fitting the wheel 1. Clean the contact surfaces between wheel and hub. 2. Put on the wheel. Tighten the wheel nuts. 3. Lower the car so that the wheel cannot rotate. 4. Tighten the wheel nuts crosswise. It is important that the wheel nuts are tightened properly.
  • Page 203: Emergency Puncture Repair

    It consists of a compressor used. Volvo recommends that you visit an and a bottle with sealing fluid. The kit works as authorised Volvo workshop for inspection of 1.
  • Page 204 07 Wheels and tyres Emergency puncture repair* Overview Sealing punctured tyres 3. Check that the switch is in position 0 and locate the cable and the air hose. NOTE Do not break the bottle's seal before use. The seal is broken automatically when the bottle is screwed in.
  • Page 205 8. Flick the switch to position I. gauge. to the cargo area. 3. If it is below 1.3 bar then the tyre is insuf- 7. Volvo recommends that you drive to the IMPORTANT ficiently sealed. The journey should not be nearest authorised Volvo workshop for the Risk of overheating.
  • Page 206 07 Wheels and tyres Emergency puncture repair* Inflating the tyres IMPORTANT NOTE The car's original tyres can be inflated by the Risk of overheating. The compressor must Leave the container at a collection point for compressor. not run for more than 10 minutes. storing dangerous waste.
  • Page 207 07 Wheels and tyres...
  • Page 208 Cleaning....................210 Touching up paintwork................. 214 Rustproofing..................215...
  • Page 209 C A R C A R E...
  • Page 210: 08 Car Care

    08 Car care Cleaning Washing the car Chromed wheels NOTE Wash the car as soon as it becomes dirty. Use Outside lighting such as headlamps, fog IMPORTANT car shampoo. Dirt and road salt can lead to lamps and rear lamps may temporarily have corrosion.
  • Page 211 Only paint treatment recommended by When using a pressure washer: Make sure rubber. Volvo should be used. Other treatment such that the nozzle of the pressure washer is not as preserving, sealing, protection, lustre When using degreasant on plastic and rub- closer than 30 cm to the bodywork.
  • Page 212 (or more if A special fabric cleaning agent, available from cream on the felted cloth and massage in necessary). The Volvo Leather Care kit is avail- authorised Volvo dealers, is recommended to a thin layer of cream with gentle circular able from your Volvo dealer.
  • Page 213 Use water and a synthetic detergent. A special • textile cleaning agent is available from your Remove dirt and dust with a soft pre-mois- Volvo dealer. Make sure the seatbelt is dry tened sponge and neutral soap. before allowing it to retract. •...
  • Page 214: Touching Up Paintwork

    08 Car care Touching up paintwork Paintwork Stone chips and scratches If the stone chip has penetrated to the bare metal Paint is an important part of the car's rust- 1. Apply a piece of masking tape over the proofing and should therefore be checked reg- damaged surface.
  • Page 215: Rustproofing

    The car's rustproofing does not normally require treatment for approximately 12 years. After this period, it should be treated at three- year intervals. If the car needs further treat- ment, Volvo recommends that you engage an authorised Volvo workshop for assistance.
  • Page 216 Volvo service..................218 Self-maintenance.................. 219 Bonnet and engine compartment............220 Oils and fluids..................222 Wiper blades..................228 Battery....................230 Replacing bulbs..................234 Fuses..................... 240...
  • Page 217 M A I N T E N A N C E A N D S E R V I C E...
  • Page 218: 09 Maintenance And Service

    It was checked again in accord- ance with Volvo Car Corporation regulations before it was handed over to you. To keep your Volvo as safe and reliable as pos- sible, follow the Volvo service programme specified in the Service and Warranty Booklet.
  • Page 219: Self-Maintenance

    NOTE filled. Use washer antifreeze at tempera- High output from the ignition system. The Volvo recommends only using the jack that voltage in the ignition system is highly dan- tures around freezing. belongs to the car model in question. If a gerous.
  • Page 220: Bonnet And Engine Compartment

    09 Maintenance and service Bonnet and engine compartment Opening the bonnet The illustration shows a left-hand drive car. 1. Pull the handle on the far left under the Engine oil dipstick WARNING instrument panel. (In right-hand drive cars Radiator Check that the bonnet locks properly when the handle is on the far right.) You will hear closed.
  • Page 221 09 Maintenance and service Bonnet and engine compartment Battery Relay and fuse box, engine compartment Air filter Engines with electronic oil level sensor have no dipstick (5-cyl. diesel).
  • Page 222: Oils And Fluids

    Using oil of a higher than specified grade is permitted. If the car is driven in adverse con- ditions, Volvo recommends using an oil of a higher grade than that specified on the decal, see page 290.
  • Page 223: Maintenance And Service

    The 1. Ensure that the car is level. After switching ried out at a workshop - an authorised Volvo dipstick will indicate that the level is too low off the engine it is important to wait workshop is recommended.
  • Page 224 09 Maintenance and service Oils and fluids 5. If the level is close to MIN then 0.5 litres For engines with electronic oil level should be added. If the level is significantly sensor below, then an additional amount is required. 6.
  • Page 225 09 Maintenance and service Oils and fluids Measuring the oil level Washer fluid, topping up IMPORTANT If the oil level needs to be checked then it Engine oil In the event of the message should be carried out in accordance with the level Fill with 0.5 l oil , only fill with 0.5 litres.
  • Page 226 • Mix the coolant with approved quality overpressure. tap water. In the event of any doubt about water quality, used ready-mixed coolant in accordance with Volvo rec- NOTE ommendations. The engine must only be run with a well- • When changing coolant/replacing cool- filled cooling system.
  • Page 227 09 Maintenance and service Oils and fluids Checking and topping up the brake and WARNING clutch fluid If the brake fluid is under the MIN level in the brake fluid reservoir, do not drive further before topping up the brake fluid. The reason for the loss of brake fluid must be investigated.
  • Page 228: Wiper Blades

    09 Maintenance and service Wiper blades Wiper blades Replacing the wiper blades, windscreen 1. Turn up the wiper arm. 2. Press the button located on the wiper blade mounting and pull straight out (1), parallel with the wiper arm. 3. Slide in (2) the new wiper blade until a "click"...
  • Page 229 09 Maintenance and service Wiper blades > Check that it is firmly installed and fold back the wiper arm.
  • Page 230: Battery

    09 Maintenance and service Battery Operation Symbols on the battery NOTE The service life and function of the battery is Use protective goggles. The life of the battery is shortened if it influenced by factors such as the number of becomes discharged repeatedly.
  • Page 231 09 Maintenance and service Battery Changing the battery 2. Tighten the clamp that holds the battery. Avoid sparks and naked flames. 3. Connect the ventilation hose. Removal > Check that it is correctly connected to 1. Remove the remote control key from the both battery and outlet in the body.
  • Page 232 A workshop should be contacted in fallen below the lowest permissible level the event of questions or problems - an author- then the Start/Stop function is disen- ised Volvo workshop is recommended. gaged. Temporarily reduced Start/Stop function due to high current take-off means: Auto-start can only take place if the gear lever is in neutral position.
  • Page 233 09 Maintenance and service Battery NOTE If the battery has become so discharged that everything is "black" and in principle the car does not have all the normal electri- cal functions and the engine is subsequently started using an external battery or battery charger, then the Start/Stop function will be activated.
  • Page 234: Replacing Bulbs

    On cars with Xenon headlamps, the replacement of Xenon lamps must be car- Removing the lamp housing ried out at a workshop - an authorised Volvo 5. Lift out the lamp housing and place it on a 1. Remove the remote control key and turn workshop is recommended.
  • Page 235 09 Maintenance and service Replacing bulbs on or the remote control key inserted into the Main beam ignition switch. Dipped beam Fitting a new bulb 1. Remove the entire lamp housing. 1. Fit the new bulb. It can only fit in one posi- tion.
  • Page 236 09 Maintenance and service Replacing bulbs Position/parking lamps Direction indicators Side marker lamps 1. Twist the bulb holder anticlockwise and 1. Twist the bulb holder anticlockwise and 1. Twist the bulb holder anticlockwise and withdraw it. Replace the bulb. remove it. withdraw it.
  • Page 237 (A or B). NOTE If an error message remains after the broken bulb has been replaced then we recom- mend that you visit an authorised Volvo 1. Switch off all lights and turn the remote workshop. control key to position 0.
  • Page 238 09 Maintenance and service Replacing bulbs Location of bulbs in the rear bulb Cargo area NOTE holder The rear fog lamp only illuminates in the left rear light cluster on a left-hand drive car and in the right on a right-hand drive. Number plate lighting 1.
  • Page 239 09 Maintenance and service Replacing bulbs Passenger compartment lighting in Vanity mirror lighting* Fitting the mirror glass cargo area 1. First, press the three lugs at top edge of mirror glass back into position. 2. Then press the three lower lugs back into position.
  • Page 240: Fuses

    Each fuse box has space for several spare fuses. If the same fuse fails repeatedly then there is a fault in the component. In which case, Volvo recommends that you visit an authorised Volvo workshop for this to be checked.
  • Page 241 • Fuses 19-36 are of the "Mini Fuse" type. and fitting of fuses. • Fuses 7-18 are of the "JCASE" type and should be replaced by a workshop. An authorised Volvo workshop is recommended.
  • Page 242 09 Maintenance and service Fuses Cooling fan 50 A ABS valves 20 A Infotainment system 30 A Power steering 80 A Engine functions 30 A Windscreen wipers 30 A Supply to passenger com- Ventilation fan 40 A Supply to passenger com- partment fuse box 60 A partment fuse box...
  • Page 243 09 Maintenance and service Fuses Engine control module (5-cyl. Injectors (5-cyl. petrol), Turbo Relay coil, relay, climate con- petrol), Transmission control control valve (5-cyl. diesel), trol system, PTC element, oil module (5-cyl.) 10 A Oil level sensor (5-cyl. diesel) trap (5-cyl. petrol), Mass air flow sensor (5-cyl.
  • Page 244 09 Maintenance and service Fuses DRIVe Start/Stop* For more information on DRIVe Start/Stop - see page 163. Location of fuses for the Start/Stop function. Component 11M/1 Engine compartment, electrical distribution unit 11M/2 Sensor, battery monitor- Central electronic mod- ule (CEM) (Reference voltage standby bat- tery), diesel engine Option/accessory, for more information, see Introduction.
  • Page 245 09 Maintenance and service Fuses Relay/Fuse box in the passenger compartment The fuse box has 50 fuse positions. The fuses completely. The fuse box can be fully are located under the glovebox. The box also unhooked. provides space for several spare fuses. Tools 4.
  • Page 246 09 Maintenance and service Fuses Telematics*, Audio sys- Washer, rear window 15 A Parking assistance*, tem, RTI*, Bluetooth* 15 A Xenon* 10 A SRS system 10 A SRS system, Engine con- Control module Keyless* 20 A Reserve – trol module (5-cyl, DRIVe) 10 A Remote control receiver, PTC element, air pre-...
  • Page 247 09 Maintenance and service Fuses Seat heating (driver's Sunroof*, Overhead con- Power seat, driver 25 A side) 15 A sole for interior lighting, Interior lighting, cargo Seatbelt reminder, rear, Seat heating (passenger area lighting, power Dimming, interior rear- side) 15 A seats, fuel level display view mirror* (2.0F)
  • Page 248 General....................250 Audio functions..................252 Radio functions..................257 CD functions..................262 Menu structure – audio system............. 265 Phone functions*................... 266 Menu structure – phone*............... 273 Bluetooth handsfree*................276 Option/accessory, for more information, see Introduction.
  • Page 249 I N F O T A I N M E N T S Y S T E M...
  • Page 250: 10 Infotainment System

    10 Infotainment system General • Infotainment system system can be easily operated using the con- EXIT (6) leads back one step in the menu structure. A long press on EXIT will exit the trol panel or the steering wheel keypad*, see menu system.
  • Page 251: Infotainment System

    10 Infotainment system General Dolby Surround Pro Logic II Dolby Surround Pro Logic II distributes the two stereo audio channels to left, centre, right and rear speakers. This provides a more real- istic sound quality than that provided by stand- ard two-channel stereo.
  • Page 252: Audio Functions

    10 Infotainment system Audio functions Audio controls ume adjusts automatically depending on vehi- External audio sources cle speed, see page 255. AUX, USB* Audio source selection General Repeatedly pressing AM/FM switches between FM1, FM2 and AM. Repeatedly pressing MODE changes between CD, USB, AUX and BT.
  • Page 253 10 Infotainment system Audio functions Use the MODE button to select the external iPod NOTE audio source you wish to use. An iPod is charged and supplied with power The system supports the playback of music by the USB connection via the player's con- 1.
  • Page 254 Bluetooth function in the car's audio sys- free* and a mobile phone is connected then the the following options. Adjust by turning tem. Volvo recommends that you contact an audio system can wirelessly play back stream- TUNING. authorised Volvo dealer or visit ing audio files from the mobile phone.
  • Page 255 10 Infotainment system Audio functions Surround Equalizer front/rear Automatic volume control Surround settings govern the spatial The equalizer can be used to adjust different The auto volume control function allows the perception of the sound. Settings frequency bands separately. audio volume to increase as the speed of the and activating/deactivating are sep- car increases.
  • Page 256 10 Infotainment system Audio functions There is a also a dynamic calibration that takes into account the position of the volume control, radio reception and vehicle speed. The controls explained in these operating instructions, e.g. bass, treble and equalizer* are only intended for the user to be able to adapt the sound reproduction according to personal taste.
  • Page 257: Radio Functions

    10 Infotainment system Radio functions Radio controls Tuning Storing stations Ten station presets can be stored per wave- Automatic tuning length. FM has two memories for presets: 1. Select wavelength using AM/FM (1). . Preset stations are selected 2. Give a brief press on using the preset buttons (2) or the steering wheel keypad.
  • Page 258 10 Infotainment system Radio functions Selecting an auto-stored preset Scanning RDS functions Allowing the radio to remain in Auto mode pro- SCAN (4) automatically searches through a Radio Data System - RDS links FM transmitters vides access to the autostored presets. wavelength for strong stations.
  • Page 259 10 Infotainment system Radio functions gramme types ( ) interrupt one another in TP from current station/all stations News order of priority, where alarm has the highest The radio can interrupt with traffic information This function allows news broad- priority and programme types has the lowest. from only the set (current) station or from all casts within a set station's stations.
  • Page 260 10 Infotainment system Radio functions Programme types – PTY 4. Scroll to Search PTY and press ENTER. Automatic frequency update – AF The PTY function can be used to The AF function selects one of the strongest If the radio finds any of the selected pro- select different programme types, transmitters for a set station.
  • Page 261 10 Infotainment system Radio functions Enhanced Other Networks – EON Resetting RDS functions The EON function is especially useful in urban Resets all radio settings to the original factory areas with many regional radio stations. It settings. allows the distance between the car and the 1.
  • Page 262: Cd Functions

    10 Infotainment system CD functions CD function controls automatically. Otherwise, load a disc and Pause change to CD mode by pressing MODE. If the volume is turned down completely, the CD player is stopped. The player is restarted Start playback (CD changer*) when volume is increased.
  • Page 263 10 Infotainment system CD functions cally when all files in the current folder have Activating/deactivating, random (CD NOTE been played back. changer) It is only possible to scroll between random If a normal music CD is being played: Press left/right on the navigation button if the CD tracks on the current disc.
  • Page 264 10 Infotainment system CD functions Using low quality CD discs could result in poor or non-existent sound. IMPORTANT Only use standard discs (12 cm in diameter). Do not use CD discs with adhesive disc labels. The heat in the CD player may cause the label to come off, damaging the CD player.
  • Page 265: Menu Structure - Audio System

    10 Infotainment system Menu structure – audio system Overview News AUX MENU FM MENU AUX input volume… News Disc text News Audio settings… PTY… CD MENU Audio settings… Radio text For CD changer* with CD disc USB MENU* selected. Advanced radio settings… Playlist Random…...
  • Page 266: Phone Functions

    10 Infotainment system Phone functions* Phone system components. Option/accessory, for more information, see Introduction.
  • Page 267 SIM card. • Volvo recommends that an authorised delayed 5 seconds before they are diverted. If Volvo workshop carries out phone system the current traffic situation still requires a high NOTE servicing. level of attention from the driver then the The built-in phone cannot read 3G type SIM incoming call is diverted to the voice mail.
  • Page 268 10 Infotainment system Phone functions* Extra SIM card Phone controls Steering wheel keypad Many network operators offer two SIM cards for the same phone number. The extra SIM card can be used in the car. Inserting the SIM card 1. Switch off the phone and open the glove- box.
  • Page 269 10 Infotainment system Phone functions* On/Off Activating from standby mode 2. Scroll to Hold Resume and press ± ENTER. Press PHONE. A handset appears in the display when the phone system is active or in standby mode Dialling a third party (standby).
  • Page 270 If the phone book contains a live caller's con- see menu 6.4.3, on page 273. This function tact information then this is shown in the dis- only applies to the Volvo integrated phone sys- play. Contact information can be stored on the tem.
  • Page 271 10 Infotainment system Phone functions* 6. Scroll to SIM card Phone memory 4. Enter the first few letters of the item and 6. Enter the first few letters of the item and press ENTER, or simply press ENTER. press ENTER, or simply press ENTER. press ENTER.
  • Page 272 10 Infotainment system Phone functions* SMS - Short Message Service IMEI number NOTE To block the phone, you must provide your Press ENTER to dial. Reading SMS network operator with the phone's IMEI num- 1. Press MENU. ber. This is a 15 digit serial number that is pro- NOTE 2.
  • Page 273: Menu Structure - Phone

    10 Infotainment system Menu structure – phone* Phone menu 2.4. Speed dial… 4.6.2. When busy Call register… 2.4.1. Active 4.6.3. Not answered 1.1. Last 10 missed calls 2.4.2. Select numbers 4.6.4. Not reachable 1.2. Last 10 received calls 2.5. Erase SIM 4.6.5.
  • Page 274 10 Infotainment system Menu structure – phone* 6.2.3. Automatic 1.4.1. All calls 2.4. Speed dial A number stored in the phone book can be 6.3. Edit PIN code 1.4.2. Missed calls stored as a speed dial number. 6.4. Sounds and volume… 1.4.3.
  • Page 275 10 Infotainment system Menu structure – phone* operator for information on message settings. 4.6.2 When busy 6.1.2. Manual select Normally, these settings should not be altered. 4.6.3. Not answered 6.2. SIM security 3.3.1. SMSC number Select if the PIN code should be on, off or if the 4.6.4.
  • Page 276: Bluetooth Handsfree

    Volvo recommends that you seek assis- Connect mobile phone tance from an authorised Volvo dealer or A mobile phone is connected in different ways visit www.volvocars.com for information on depending on whether or not it has been con- compatible phones.
  • Page 277 The call is interrupted with EXIT. the mobile phone's manual. Auto answer Disconnecting the mobile phone 3. Select My Volvo Car in the list of units The automatic answer function means that Automatic disconnection takes place if the detected in your mobile phone.
  • Page 278 10 Infotainment system Bluetooth handsfree* Ring volume More on registering and connecting NOTE Go to Phone Menu… Phone settings… A maximum of three mobile phones can be With certain mobile phones the connection registered. Registration is performed once per Sounds and volume… Ring volume is terminated when the privacy function is phone.
  • Page 279 List is empty compatible with the voice recognition func- tion. Volvo recommends that you contact an shown when copying is finished. tion is made under Phone Menu… authorised Volvo dealer or visit Bluetooth…...
  • Page 280 10 Infotainment system Bluetooth handsfree* twice for the second etc. Continue pressing for Bluetooth… Menu structure - Bluetooth more characters, see the table on page 270. handsfree with built-in phone 3.1. Change phone Call register… A short press on EXIT deletes an input char- 3.1.1.
  • Page 281 10 Infotainment system Bluetooth handsfree* Phone settings… 6.1. Sounds and volume… 6.1.1. Ring volume 6.1.2. Ring signals… 6.1.3. Mute radio 6.2. Synchronise phone book Option/accessory, for more information, see Introduction.
  • Page 282 Type designation................... 284 Dimensions and weights............... 286 Engine specifications................289 Engine oil....................290 Fluids and lubricants................292 Fuel....................... 295 Wheel and tyres, dimensions and pressure ......... 298 Electrical system................... 301 Type approval..................303 Symbols in the display................304...
  • Page 283 S P E C I F I C A T I O N S...
  • Page 284: 11 Specifications

    11 Specifications Type designation...
  • Page 285 S40 and V50: The label is visible when the right rear door is opened. C30 and C70: The label is visible when the right door is opened. Label for parking heater.
  • Page 286: Dimensions And Weights

    11 Specifications Dimensions and weights Dimensions Dimensions Dimensions Dimensions Wheelbase 2640 Front track Width including door 2039 1548 mirrors 1535 Length 4266 Width including folded- 1871 Rear track 1544 Load length, floor, 1486 in door mirrors folded seat 1531 with 15" wheel Load length, floor with 16"...
  • Page 287 11 Specifications Dimensions and weights Weights WARNING Kerb weight includes the driver, the fuel tank The car's driving characteristics change 90% full and all fluids. depending on how heavily it is loaded and how the load is distributed. The weight of passengers and accessories, and towball load (when a trailer is hitched, see table) influences the payload and is not included in the kerb weight.
  • Page 288 11 Specifications Dimensions and weights Towing capacity and towball load Engine Maximum weight, braked trailer (kg) Maximum towball load (kg) 1200 DRIVe 1300 1300 2.0F 1350 1350 others 1500 Engine Maximum weight, unbraked trailer (kg) Maximum towball load (kg) 2.0, D2 and DRIVe others...
  • Page 289: Engine Specifications

    11 Specifications Engine specifications Overview NOTE Not all engines are available in all markets. Engine Engine Output Output Torque (Nm/ No. of Bore Stroke Swept Com- (kW/rpm) (hp/rpm) rpm) cylinders (mm) (mm) volume pression code (litres) ratio B4164S3 74/6000 100/6000 150/4000 81.4 1.596...
  • Page 290: Engine Oil

    Volvo Car Corporation disclaims all war- tances at low temperatures. ranty liability if engine oil of the prescribed grade and viscosity is not used. Volvo recommends that oil changes are car- ried out at a workshop - an authorised Volvo workshop is recommended.
  • Page 291 11 Specifications Engine oil Engine oil grade Engine Engine code Recommended oil grade Volume, incl. oil filter (litres) B4164S3 Oil grade: ACEA A5/B5 approx. 4.0 Viscosity: SAE 5W–30 2.0F B4204S4 approx. 4.3 B4204S3 approx. 4.3 DRIVe D4162T approx. 3.8 D4162T approx.
  • Page 292: Fluids And Lubricants

    Do not mix with any other transmission fluid. If the transmission is topped up with a dif- ferent fluid, contact a workshop nearby for servicing. Volvo recommends that you con- tact an authorised Volvo workshop. Gearbox oil Manual gearbox...
  • Page 293 Brake system DOT 4+ Power Power steering 0.8 – 0.9 WSS M2C204-A2 or equivalent product with same specifications. steering fluid Washer fluid 4-cyl. Petrol/Die- Use a washer antifreeze recommended by Volvo, mixed with water for temperatures below freezing. 5-cyl. Petrol/Die-...
  • Page 294: Fluids And Lubricants

    62 Diesel: D2 and approx. 52 Diesel: see page 146 DRIVe Diesel: D3 and approx. 60 Water quality must fulfil the standard STD 1285.1. Refrigerant quantity varies depending on engine variant. Contact an authorised Volvo workshop for the correct information.
  • Page 295: Fuel

    11 Specifications Fuel emissions and fuel consumption 2.0F 254 (242 10.9 (14.8 137 (135 5.9 (8.2 180 (174 7.7 (10.6 10.8 12.6 13.5 DRIVe...
  • Page 296 11 Specifications Fuel • The car's weight may increase depending on Fuel quality, road and traffic conditions, : gram/km weather and the condition of the car. equipment. This, as well as how heavily the car is loaded, increases fuel consumption and car- Even a combination of the above-mentioned : litre/100 km bon dioxide emissions.
  • Page 297 11 Specifications Fuel To bear in mind Tips that the driver can use in order to reduce consumption: • Drive gently and avoid unnecessary accel- eration as well as braking too hard. • Drive with the correct air pressure in the tyres and check this regularly - select ECO tyre pressure for best results, see the tyre pressure table on page 299.
  • Page 298: Wheel And Tyres, Dimensions And Pressure

    11 Specifications Wheel and tyres, dimensions and pressure Approved dimensions shows all approved combinations of wheel drive (AWD) and the type of transmission is rims and tyres, and the lowest permitted load needed to read the table. For information with In certain countries not all approved dimen- index (LI) and speed rating (SS).
  • Page 299 11 Specifications Wheel and tyres, dimensions and pressure Approved tyre pressures Engine Tyre size Speed (km/h) Load, 1 - 3 persons Max. load Rear (kPa) Front (kPa) Rear (kPa) Front (kPa) ECO pressure 0–160 195/65 R15 160+ 0–160 205/55 R16 DRIVe 160+ 0–160...
  • Page 300 11 Specifications Wheel and tyres, dimensions and pressure Engine Tyre size Speed (km/h) Load, 1 - 3 persons Max. load Rear (kPa) Front (kPa) Rear (kPa) Front (kPa) ECO pressure 0–160 205/55 R16 160+ 205/50 R17 0–160 215/45 R18 160+ Temporary Spare Tyre 0–80 In certain countries there is the "bar"...
  • Page 301: Electrical System

    11 Specifications Electrical system General The battery capacity is dependent upon the capacity as the original battery (see the label equipment level in the vehicle. If the starter on the battery). The car has a voltage-regulated AC alternator. battery is replaced, therefore, you must ensure The electrical system is single-pole and uses that you switch to a battery with the same the chassis and engine casing as a conductor.
  • Page 302 11 Specifications Electrical system Lighting Output (W) Type Side marker lamps, front WY5W LL Fog lamps Side direction indicators, door mirrors WY5W LL Front courtesy lighting T10 Socket W2.1x9.5d Glovebox lighting T10 Socket W2.1x9.5d Vanity mirror lighting* Socket SV5.5 Length 35 mm Cargo area lighting Socket SV8.5 Length 38 mm Number plate lighting...
  • Page 303: Type Approval

    11 Specifications Type approval Remote control key system Certification of the Keyless Drive system Country and Siemens VDO Automotive A.G. hereby certifies region that this equipment type 5WK4 8952, 5WK48956, 5WK48812 conforms to the A, B, CY, CZ, D, DK, essential characteristic requirements and other E, EST, F, FIN, GB, Delphi hereby...
  • Page 304: Symbols In The Display

    11 Specifications Symbols in the display General Symbols in the display Symbol Meaning Page There are a variety of different symbols in the Indicator and warning symbols in the Stability sys- 53, 169, 170 display in the car. The symbols are divided into combined instrument panel tem, DSTC* warning, indicator and information symbols.
  • Page 305 11 Specifications Symbols in the display Information symbols in the centre Symbol Meaning Page Symbol Meaning Page console display Low oil pres- 52, 54 Left direction Symbol Meaning Page sure indicators Surround sound (only Premium Sound) Seatbelt 18, 54 Right direc- reminder tion indicators News...
  • Page 306 11 Specifications Symbols in the display Information symbols in the roof console display Symbol Meaning Page Seatbelt reminder Airbag, passenger 24, 25 seat, activated Airbag, passenger seat, deactivated...
  • Page 307 11 Specifications...
  • Page 308 12 Alphabetical Index Air quality system, ECC......96 AUTO storing stations........257 Air vents............. 91 Auto climate..........95 Alarm............137 electronic climate control..... 97 alarm indicator........137 Automatic car washes......210 manual climate control....92, 93 alarm signals........138 Automatic gearbox ABS fault..........
  • Page 309 12 Alphabetical Index specifications........301 Brake system........... 167 Catalytic converter........145 start assistance........180 recovery..........176 Bulb holder symbols on the battery....... 230 removal..........237 CD discs warning symbols......... 230 storage compartment......116 Bulbs Bioethanol E85........145 changing..........234 CD functions..........262 Blind spot (BLIS)........
  • Page 310 12 Alphabetical Index seatbelts..........213 Cruise control..........69 Driving upholstery........... 211 cooling system........142 economical......... 142 Climate control in water..........142 general..........90 slippery driving conditions....143 personal preferences......82 with trailer........... 181 Deadlock Climate control settings deactivation........135 Driving in water........142 auto............
  • Page 311 12 Alphabetical Index Electrical system........301 Error messages in BLIS......174 Fold down the rear seat backrest ... 118 Emergency calls........267 Expectant mothers, seatbelt...... 19 Frequency update, automatic....260 Emergency equipment External dimensions........ 286 Front seats, heated........93 warning triangle........199 Extra mats..........
  • Page 312 12 Alphabetical Index Heating Instrument overview front seats........93, 97 left-hand drive........46 Gearbox rearview and door mirrors....93, 97 right-hand drive........48 manual..........157 rear window........93, 97 Interior lighting, see Lighting....111 Gear selector assistance (GSI - Gear shift High-pressure headlamp washing.....
  • Page 313 12 Alphabetical Index Keyless entry..........83 main/dipped beam......60, 63 Locking/unlocking........134 position/parking lamps......60 inside..........134 Keyless start (keyless drive)..... 130 reading lamps........111 outside..........134 Keypad in the steering wheel..69, 71, 268 rear fog lamp........61 Locks Key positions...........
  • Page 314 12 Alphabetical Index Menus Parking heater audio system........250 battery and fuel........99 News............259 general..........99 Menu structure.......... 82 parking on a hill........99 media player........265 symbols and display messages..100 phone, menu options......274 time setting......... 101 phone, overview.........
  • Page 315 12 Alphabetical Index making calls........277 Recirculation on/off..........269 A/C............92 one-key dial........271 Radio ECC............96 phone book......... 279 EON............ 261 Recommended child seats ....... 33 phone book, shortcut......279 frequency update........ 260 Reduced guard receiving a call........277 news...........
  • Page 316 12 Alphabetical Index Reverse gear inhibitor......157 Securing loads ........122 Starting the engine........152 keyless drive....... 130, 156 Rims Service programme......... 218 cleaning..........210 Steering lock..........152 Side airbags..........26 Roof load, max. weight ......287 Steering wheel Side airbag SIPS........26 cruise control........
  • Page 317 12 Alphabetical Index Symbols and display messages Towing capacity........287 tread wear indicators......195 parking heater........100 winter tyres......... 197 Towing equipment........183 installation........... 185 removing..........187 specifications........184 Towing eye..........178 Tailgate Unlocking......... 131, 134 TP – Traffic information......259 driving with open tailgate....
  • Page 318 12 Alphabetical Index Warning triangle........199 Wiper blades..........228 cleaning..........228 Washer fluid, filling........225 replacing, rear window....... 228 Washers replacing, windscreen......228 headlamps..........66 rear window.......... 67 washer fluid, filling......225 windscreen........... 66 Waxing............. 211 Weights kerb weight......... 287 Wheels changing..........
  • Page 320 Kdakd 8Vg 8dgedgVi^dc ©...

Table of Contents
