Owner's Manual
Digital
Digital
Thermostat
Thermostat
Control up to 2 Heat &
2 Cool Stages
Single Day Programmable
4 Settings/Day
Auto Changeover
5 minute Built-In
Compressor Protection
Self-Prompting Programming
Display Either F or C
Use with most Air Conditioning & Heating Systems including: 1 or 2 Stage
Electric Cooling & 2 Stage Gas Heating, Heat Pump, Electric or Hydronic Heat.
INSTALLATION
INSTALLATION
INSTRUCTIONS
INSTRUCTIONS
residential
THERMOSTAT
T1
Single Day
Single Day
PROGRAMMABLE
PROGRAMMABLE
up to
2-heat
up to
2-heat
& 2-cool
& 2-cool
HEAT
COOL
Mounts Flush with the Wall
Back-Lit display
One For All Works with
Virtually All Equipment
Non-Volatile memory
Keypad lockout
Single or Dual setpoint
with Adjustable Deadband
'O' or 'B' Terminal
Optional: Outdoor Sensor
Venstar Inc. 08/07
000FS
HEAT
PUMP
Advertisement
Related Manuals for Venstar T1000FS
Summary of Contents for Venstar T1000FS
- Page 1 Display Either F or C Optional: Outdoor Sensor Use with most Air Conditioning & Heating Systems including: 1 or 2 Stage Electric Cooling & 2 Stage Gas Heating, Heat Pump, Electric or Hydronic Heat. INSTALLATION INSTALLATION INSTRUCTIONS INSTRUCTIONS Venstar Inc. 08/07...
-
