- Page 1 Open All ™ Electric Can Opener Instruction Booklet CA2800 Please read these instructions carefully and retain for future reference.
-
Page 2: Table Of Contents
Contents Sunbeam’s Safety Precautions Safety Precautions for your Open All Features of your Open All Using your Sunbeam Open All Care and Cleaning of your Open All Important instructions – retain for future use. -
Page 3: Sunbeam's Safety Precautions
• Do not place any part of this appliance in SUNBEAM OPEN ALL. a dishwasher. • Keep fingers well away from blade when in use. • Use extreme care when handling off-cuts. • Use extreme care when handling blades. Sunbeam is very safety conscious when • Do not use an appliance for any purpose designing and manufacturing consumer products, other than its intended use. but it is essential that the product user also • Do not place an appliance on or near a hot gas exercise care when using an electrical appliance. -
Page 4: Features Of Your Open All
Features of your Open All Release Button Cutting Assembly Support Bar Drive Wheel Knife Sharpener Built in ceramic knife sharpener will ensure that your knives remain sharp at all times. Cord Storage Handy cord storage keeps the benchtop tidy by storing unwanted cord. - Page 5 Lever Blade Magnetic Lid Holder Stainless steel blade cutting action Stainless steel blade allows for a smoother cutting action. Magnetic lid holder Holds the lid in place during and after the can is fully opened. Removable lever For easy cleaning, slide the release button and remove the cutting assembly/lever. Automatic operation Simply lift the lever and position the blade inside the rim of the can. Press the lever down and the Open All can opener will ™ automatically stop when the can is fully opened.
-
Page 6: Using Your Sunbeam Open All
Using your Sunbeam Open All 1. E nsure that the Cutting Assembly is correctly positioned. (See figure 1.) Support Lever Release Button Drive Wheel Keyhole Figure 2 Drive Wheel Figure 1 4. F irmly press the Lever down. This action will bring the blade down and pierce The Cutting Assembly fits into the the lid of the can and start operating keyhole opening at the top of the Open the motor to turn the can. Ensure the can opener, above the Drive Wheel. Magnetic Lid Holder is in contact with ™ the lid of the can. (See figure 3.) Slide the Release Button to the right as the Cutting Assembly is inserted, it will “click” into position, with the release button returning to its original position. 2. I nsert the plug into a 230-240 volt power outlet and turn the power on. 3. H old the Lever in the upright position. - Page 7 7. T o remove the can, support the can with one hand and lift the Lever with the other. The lid will remain attached to the Magnetic Lid Holder. (See figure 4.) Figure 4 CAUTION: Be careful when removing the lid from the magnet as the cut edge is sharp. Opening dented/damaged cans: Occasionally, badly dented cans will cause the Open All can opener to stall. If this ™ happens, grasp the dented can and guide it through the cutting action manually until the damaged areas are opened. Jammed cans: To continue opening a can that has become jammed, raise the Lever and release the can. Begin the cutting action again in a new position on the can lip. Sharpening knives: Support the Open All ™...
-
Page 8: Care And Cleaning Of Your Open All
Care and Cleaning Turn the power off and unplug the cord from Drive Wheel: the power outlet before cleaning. The Cutting Wipe with a damp cloth to thoroughly clean, Assembly is easily removed for thorough use a small brush to remove accumulated cleaning. (See figure 5.) dirt. Motor Housing: Release Button Wipe over with a damp cloth. Keyhole Do not use harsh abrasives or cleaners to clean any parts of your Open All can opener, ™ as these may scratch the parts. Do not wash any parts in an automatic dishwasher, as the hot water temperatures and harsh detergents may ultimately warp Drive Wheel and scratch these parts. Figure 5 Warning: NEVER IMMERSE THE OPEN ALL IN Removing the Cutting Assembly: WATER OR ANY OTHER LIQUID. Raise the Cutting Assembly to its most upright position. Slide the Release Button to the right and slide out the Cutting Assembly. - Page 9 Notes...
- Page 10 Notes...
- Page 11 12 months of purchase (3 months commercial use) due to faulty materials or manufacture, we will replace it for you free of charge. Should you experience any difficulties with In Australia you are entitled to a your appliance, please phone our customer replacement or refund for a major failure and service line for advice on 1300 881 861 in for compensation for any other reasonably Australia, or 0800 786 232 in New Zealand. foreseeable loss or damage. You are also Alternatively, you can send a written claim entitled to have the goods repaired or to Sunbeam at the address listed below. replaced if the goods fail to be of acceptable On receipt of your claim, Sunbeam will quality and the failure does not amount to seek to resolve your difficulties or, if the a major failure. appliance is defective, advise you on how Should your appliance require repair or to obtain a replacement or refund. service after the guarantee period, contact Your Sunbeam 12 Month Replacement your nearest Sunbeam service centre. Guarantee naturally does not cover misuse For a complete list of Sunbeam’s authorised...
- Page 12 Sunbeam Corporation Limited 2011. ABN 45 000 006 771 Units 5 & 6, 13 Lord Street Botany NSW 2019 Australia Unit 3, Building D 26 Vestey Drive Mt Wellington Auckland New Zealand Sunbeam Corporation is a division of GUD Holdings Ltd. 07/11...
