Fortinet FortiAnalyzer 1000B Quick Start Manual

LED State
Green
Ports 1 to 4 Left LED
Flashing
Green
Ports 1 to 4 Right LED
Yellow
Off
Visit these links for more information and documentation for your Fortinet product.
• Technical Documentation - http://docs.forticare.com
• Fortinet Knowledge Center - http://kc.forticare.com
• Fortinet Technical Support - http://support.fortinet.com
Package Contents
Connector
Ports 1 to 4
CONSOLE
USB
For future
Connecting
Connect the following to the FortiAnalyzer unit. Ensure the FortiAnalyzer unit is placed on a stable surface or install in a standard 19 inch rack. See
the FortiAnalyzer-1000B Rack Install Guide for details.
• Insert a network cable to port 1.
• Connect the other end of network cable to the network hub or switch.
• Connect the AC Power Cord to the Power Supply.
• Connect the Power Cord to a surge protected
power bar or power supply.
Configuration Tools
Web-based manager
The FortiAnalyzer web-based manager is an easy to use management tool.
Use it to configure the administrator password, the interface and default gateway addresses,
add Fortinet devices and configure reports.
Requirements:
• An Ethernet connection between the FortiAnalyzer unit and management computer.
• A web browser such as FireFox or Internet Explorer on the management computer.
Description
The correct cable is connected to the copper
10/100/1000 interface and the connected equip-
ment has power.
Network activity at this interface.
The interface is connected at 1000 Mbps.
The interface is connected at 100 Mbps.
The interface is connected at 10 Mbps.
Type Speed
RJ-45 10/100/1000
Base-T
DB9 9600 8/N/1
USB
1000B
Ethernet ports
use
Console
connection
2 Mounting Slide Rails
Power Cable
Straight-through
Ethernet cable
QuickStart Guide
© Copyright 2008 Fortinet Incorporated. All rights reserved.
Products mentioned in this document are trademarks or registered trademarks
of their respective holders.
Regulatory Compliance
FCC Class B Part 15 CSA/CUS
30 September 2008
Protocol Description
Ethernet Copper gigabit connection to 10/100/1000 copper networks.
RS-232 serial Optional connection to the management computer. Provides access to
the command line interface (CLI).
USB Optional connection to a USB key for firmware backup and installation.
Ethernet
USB
ports
Tools and Documenation
Null-Modem Cable
(RS-232)
Ethernet cables connect to
the internal network and to
the Internet (public switch
or router)
Null modem
cable connects to serial
port on management
computer
Command Line Interface (CLI)
The CLI is a full-featured management tool. Use it to configure the administrator password,
the interface addresses, the default gateway address, and the DNS server addresses. To
configure advanced settings, see the Tools and Documentation CD included with the
FortiAnalyzer unit.
Requirements:
• The DB9 serial connection between the FortiAnalyzer unit and management computer.
• A terminal emulation application (HyperTerminal for Windows) on the management
computer.
1000B
R
Power supply
QuickStart Guide
FortiGate-30B
1000B
R
Copyright 2008 Fortinet Incorporated. All rights reserved.
Trademarks
Products mentioned in this document are trademarks.
Welcome | Bienvenue | Willkommen | ?迎 | 歓迎 | Bienvenido | Benvenuto
Ethernet cables connect to
the internal network and to
the Internet (public switch
or router)
FortiAnalyzer-1000B
R
05-30006-0480-20080930
Power cable
connects to
power supply
