Fluke DSP-100 User Manual

Lan cablemeter/cable analyzer
Hide thumbs
Table of Contents

Advertisement

Quick Links

®
DSP-100/2000
LAN CableMeter
®
/Cable Analyzer

Users Manual

PN 642964
January 1997
© 1997 Fluke Corporation. All rights reserved. Printed in U.S.A.
All product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading

Related Manuals for Fluke DSP-100

Summary of Contents for Fluke DSP-100

  • Page 1: Users Manual

    ® DSP-100/2000 LAN CableMeter ® /Cable Analyzer Users Manual PN 642964 January 1997 © 1997 Fluke Corporation. All rights reserved. Printed in U.S.A. All product names are trademarks of their respective companies.
  • Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.

  • Page 3: Table Of Contents

    Chapter Introduction ... 1-1 Overview of Features ... 1-1 Standard Accessories ... 1-3 Using This Manual ... 1-5 Getting Started ... 2-1 W Safety and Operational Information ... 2-1 Quick Start... 2-3 Quick Configuration... 2-4 Results within Accuracy Range ... 2-6 Autotest on Twisted Pair Cable ...
  • Page 4 DSP-100/2000 Users Manual Autotest on Coaxial Cable ... 3-19 Autotest Results for Coaxial Cable ... 3-21 Saving Autotest Results... 3-23 The Autotest Report... 3-25 Running Individual Tests ... 4-1 Single Tests for Twisted Pair Cable ... 4-1 Scanning Function ... 4-2 When to Use a Remote Unit ...
  • Page 5 Appendices Using DSP-LINK ... A-1 Glossary... B-1 Tests Run per Test Standard During an Autotest... C-1 Index Contents (continued)
  • Page 6 DSP-100/2000 Users Manual...

  • Page 7: List Of Tables

    Table 2-1. International Electrical Symbols... 2-1 2-2. Key Functions for the Menu System ... 2-3 2-3. Quick Configuration Settings ... 2-4 2-4. Main Unit Features ... 2-13 2-5. Remote Connectors and Features ... 2-15 2-6. Status Indications from Remotes ... 2-29 2-7.
  • Page 8 DSP-100/2000 Users Manual 8-6. Distance Specifications for TDR Test... 8-11 8-7. PC Interface Cable Connections... 8-13 8-8. 9-to 25-pin Adapter ... 8-13 8-9. Certifications ... 8-16 A-1. Summary of DSP-LINK Functions ... A-5 A-2. Special Terms Used in DSP-LINK... A-6 A-3.

  • Page 9: List Of Figures

    Figure 1-1. Standard Accessories ... 1-4 2-1. The Asterisk and Test Tool Accuracy ... 2-6 2-2. Autotest Connections for Twisted Pair Cable (Channel) ... 2-8 2-3. Autotest Connections for Coaxial Cable ... 2-11 2-4. Main Unit Features ... 2-12 2-5. Standard and Smart Remote Features ...
  • Page 10 DSP-100/2000 Users Manual 7-6. A TDX Analyzer Plot... 7-10 7-7. Split Pair Wiring... 7-12 7-8. How NVP is Calculated ... 7-14 7-9. Signals Reflected from an Open, Shorted, and Terminated Cable... 7-16 7-10. Example of a TDR Plot ... 7-18 7-11.

  • Page 11: Introduction

    A guide to using this manual. Overview of Features The Fluke DSP-100 LAN CableMeter ® and DSP-2000 LAN Cable Analyzer test tools (hereafter referred to collectively as “the test tool”) are hand-held instruments used to certify cable and to test and troubleshoot coaxial and twisted pair cable in local area network (LAN) installations.
  • Page 12 Sends stored test reports to a host computer or directly to a serial printer. Flash EPROM accepts test standard and software upgrades. Tests fiber optic cable when used with a Fluke DSP Fiber Optic Meter. Model DSP-2000 includes the following additional features: Monitors 100BaseTX network traffic.

  • Page 13: Standard Accessories

    1 3.5” DSP-LINK utility diskette 1 Users manual (not shown) 1 Warranty registration card (not shown) 1 Soft carrying case for Model DSP-100 (2 with smart remote package, not shown. Discard loose foam pieces.) 1 Smart remote unit with Model DSP-2000 (not shown)
  • Page 14 Users Manual RJ45 Straight Through Patch 15 cm (1) RS-232 Cable 2m (2) Strap AC Adapter/Charger Figure 1-1. Standard Accessories Coaxial Cable RJ45 to BNC Adapter (DSP-2000 Only) DSP-Link Software 3.5-Inch Floppy Disk BP7217 Nickel-Cadmium Battery Pack gc01f.eps...

  • Page 15: Using This Manual

    Using This Manual Before using the test tool, carefully read "Safety and Operational Information" at the beginning of Chapter 2. If you are familiar with the general features, functions, and operation of LAN cable testers and want to start testing cables immediately, proceed as follows: 1.
  • Page 16 Users Manual If you have never used a LAN cable tester and want to learn about cable testing and troubleshooting before you use the test tool, proceed as follows: 1. Read Chapter 7, “Basic Cable Testing,” to learn the basics of LAN cable characteristics, testing, and interpreting test results.

  • Page 17: Getting Started

    Chapter 2 provides the following information: Safety and cautions to observe when using the test tool. Instructions for getting started quickly with the test tool. Detailed information on the test tool’s features. Detailed instructions on configuring the test tool. Safety and Operational Information The international electrical symbols used on the instrument or in this manual are described in Table 2-1.
  • Page 18 Users Manual To avoid possible fire or electric shock when charging the battery or powering the test tool with ac power, use only the ac adapter/charger provided with the test tool. Never connect the test tool to telephone lines of any type, including ISDN lines.

  • Page 19: Quick Start

    Quick Start This section is for users who want to start using the test tool immediately with minimal instruction. For suggestions on additional reading that may be helpful to you, see “Using this Manual” in Chapter 1. Powering the Test Tool Before powering the test tool or smart remote with the NiCad battery pack, charge the battery for about 3 hours.

  • Page 20: Quick Configuration

    Select the test standard and cable type you are using. Your selection Cable Type determines which test specifications are used and which tests are run during cable testing. Fiber optic cable testing requires a Fluke DSP Fiber Optic Meter. Average Cable...
  • Page 21 To change any of the settings shown in Table 2-3, proceed as follows: 1. Turn the rotary switch to SETUP. 2. If the setting you want to change is not on the first Setup screen, press to see additional Setup screens. 3.

  • Page 22: Results Within Accuracy Range

    Users Manual Results within Accuracy Range An asterisk following a test result value indicates that the value is within the test tool’s range of accuracy, as shown in Figure 2-1. All tests except the wire map test may produce results with an asterisk when the asterisk is required by the selected test standard.

  • Page 23: Autotest On Twisted Pair Cable

    Some test standards require a NEXT measurement from both ends of the cable. If you are using another main unit (Model DSP-100 only) or a smart remote as the remote unit, and you enable remote end testing on the main unit, the Autotest runs the REMOTE tests supported by the test tool if those tests apply to the selected test standard.
  • Page 24 Users Manual 2 Meters DSP-2000 CABLE ANALYZER Test Tool TEST SAVE FAULT INFO EXIT ENTER WAKE UP MONITOR SINGLE SETUP TEST AUTO PRINT TEST SPECIAL FUNCTIONS SMART REMOTE Figure 2-2. Autotest Connections for Twisted Pair Cable (Channel Configuration and Model Horizontal Cross Connect Blocks RJ45...
  • Page 25 1. If you are using a DSP-100 main unit as the remote, turn the remote unit’s rotary switch to SMART REMOTE. If you are using a smart remote unit, turn its rotary switch to ON. 2. Use a 2m patch cable of the correct impedance to connect the remote to the far end of the cable link.

  • Page 26: Autotest On Coaxial Cable

    Users Manual Autotest on Coaxial Cable The following tests are run during an Autotest on coaxial cable: Impedance Resistance Length Anomaly detection (Results shown only if anomalies are detected.) To run an Autotest on coaxial cable, refer to Figure 2-3 and proceed as follows: 1.
  • Page 27 BNC “T” Connector Figure 2-3. Autotest Connections for Coaxial Cable (Model DSP-2000 Shown) Autotest on Coaxial Cable DSP-2000 CABLE ANALYZER TEST SAVE FAULT INFO ENTER EXIT MONITOR SINGLE SETUP TEST Test Tool AUTO PRINT TEST SPECIAL FUNCTIONS SMART REMOTE For Length Test, remove far-end Terminator gc04f.epc...

  • Page 28: Main Unit Features

    Users Manual Main Unit Features Figure 2-4 shows the features on the main unit and Table 2-4 explains their functions. Features shown in light gray are found on Model DSP-100 only. DSP-100 DSP-2000 TEST FAULT INFO EXIT SINGLE TEST AUTO...
  • Page 29 Model DSP-2000, this jack is labeled CABLE TEST. Model DSP-2000 has an additional RJ45 jack labeled MONITOR, which is used for 10/100BaseTX traffic and hub tests. BNC connector Model DSP-100 only. A connector for coaxial cable. Table 2-4. Main Unit Features Description Main Unit Features...

  • Page 30: Remote Features

    Users Manual Remote Features Figure 2-5 shows the features on the standard and smart remote units. Table 2-5 explains the functions of these items. Standard Remote Figure 2-5. Standard and Smart Remote Features 2-14 Smart Remote DSP-2000SR SMART REMOTE PASS TESTING FAIL LOW BATTERY...
  • Page 31 Table 2-5. Remote Connectors and Features Item Feature RS-232C serial A DB9P connector for loading software updates. port AC adapter/ Connection for the ac adapter/charger supplied with the test tool. charger jack AC power LED Style 1: A green LED that turns on when the test tool is powered indicator with the ac adapter/charger.

  • Page 32: Strap And Bail

    Users Manual Strap and Bail The test tool and the smart remote have a strap and a bail. Figure 2-6 shows how to attach the strap and open the bail. Figure 2-6. Attaching the Strap and Opening the Bail Rotary Switch The following paragraphs summarize the modes you can select with the rotary switch on the main unit.
  • Page 33 Autotest Autotest is the most frequently used function in LAN cable testing. Autotest performs all of the tests necessary to qualify the cable you are testing. When the Autotest is complete, the tests that were run are listed with the overall result for each test.

  • Page 34: Single Test

    Users Manual The following tests apply to coaxial cable: Impedance: Measures the impedance of the cable. Resistance: Measures the loop resistance of the cable, shield, and terminator. Length: Measures the length of unterminated cables. Anomaly Detection: During a coaxial cable test, the test tool also detects and reports the position of the largest impedance anomaly (if any are present) on the cable.
  • Page 35 Getting Started Rotary Switch Setup Allows you to do the following: Select a test standard and cable type. Select an average cable temperature when temperature is required by the selected test standard. Set the test tool to test cable installed in conduit when a conduit setting is required by the selected test standard.

  • Page 36: Turning On The Test Tool

    Calibrate the test tool to work with a new remote unit. Run a self-test to verify proper operation of the test tool and the remote. Smart Remote (Model DSP-100) The SMART REMOTE mode causes the test tool to function as a smart remote. In the SMART REMOTE mode, when remote testing is enabled on the main unit, the remote unit sends results from REMOTE tests to the main unit.
  • Page 37 Selecting a Language for Displays and Reports The test tool displays results and prints reports in English, German, French, Spanish, and Italian. To select a language for displays and reports, proceed as follows: 1. Turn the rotary switch to SETUP. 2.

  • Page 38: Configuring The Test Tool

    Users Manual Overvoltage Test The test tool periodically checks for dc voltages on the cable connected to the RJ45 jack. A dc voltage means that the test tool is connected to an active telephone cable or other power source. If voltage is detected, the following message appears: Voltage on the cable can damage the test tool or cause errors in measurements.

  • Page 39: Adjusting The Display Contrast

    When the backlight time-out is enabled, the backlight timer starts counting down after all tests are complete or after the last key entry or movement of the rotary switch. To restart the backlight timer while the backlight is on, press any key (except the backlight key) or turn the rotary switch to a new mode.
  • Page 40 Users Manual Selecting a Test Standard and Cable Type The test standard and cable type you select determine which standards are used and which tests are run during cable testing. The test tool is equipped with information for all the common test standards and cable types. Several of the test standards for twisted pair cable are defined for both a channel and a basic link configuration.
  • Page 41 An increase in cable temperature causes an increase in attenuation. To compensate for this increase, the test tool uses the temperature you select to modify the attenuation test limits. To avoid passing faulty cables or failing good cables, select the temperature that is closest to the cable’s average temperature. To select an average cable temperature, proceed as follows: 1.
  • Page 42 Users Manual Selecting a Length Unit The test tool displays length measurements in meters or feet. To change the unit of measurement, proceed as follows: 1. Turn the rotary switch to SETUP. 2. Press 3. Press 4. Use to highlight the desired unit. 5.

  • Page 43: Setting The Date And Time

    Setting the Date and Time The test tool has a clock that records the date and time for saved test results. To change the date or time or the format for the date or time, proceed as follows: 1. Turn the rotary switch to SETUP. 2.
  • Page 44 Users Manual Setting the Power-Down Timer To extend battery life, you can set the power-down timer to automatically switch the test tool to a low-power mode after a selected period of inactivity. You can also disable the power-down timer. When the test tool switches to low-power mode, the display goes blank. To reactivate the display, press To set the power-down timer or enable/disable the timer, proceed as follows: 1.

  • Page 45: Remote Lights, Messages, And Audible Tones

    Remote Lights, Messages, and Audible Tones The standard and smart remotes indicate various states by flashing light-emitting diodes (LEDs) and emitting audible tones, as described in Table 2-6. Table 2-6. Status Indications from Remotes Status Power on self-test passed. Power on self-test failed. Main unit is running a test.

  • Page 46: Remote End Testing

    3. Press 4. Use to highlight If you use a DSP-100 unit as a remote, the remote unit displays the following status messages: start a test. just completed. This message is displayed for about 3 seconds after a test is completed.

  • Page 47: Remote Communication Error

    For a smart remote or second main unit, connect the ac adapter/charger. Replace the alkaline battery in standard remote. Charge the NiCad battery in a second main unit or smart remote. Have the lithium battery replaced at a Fluke Service Center. . This 2-31...
  • Page 48 Users Manual Battery Status Display To see the charge level of the main unit’s NiCad battery, turn the rotary switch to SPECIAL FUNCTIONS; then select level of the smart remote’s battery, connect the smart remote to the main unit (use the CABLE TEST jack on Model DSP-2000);...

  • Page 49: Autotest

    Chapter 3 provides the following information: Instructions and test result descriptions for an Autotest on twisted pair cable. Instructions and test result descriptions for an Autotest on coaxial cable. Instructions for saving Autotest results. Autotest Softkeys The following softkey functions are active on the Autotest screens noted. The PSNEXT screen is available on Model DSP-2000 only.

  • Page 50: Autotest On Twisted Pair Cable

    Users Manual Autotest on Twisted Pair Cable The procedures for an Autotest on shielded and unshielded twisted pair cable are the same. When shielded cable is selected, the test tool performs an additional test for shield continuity if the shield test is enabled in SETUP. To run the Autotest on twisted pair cable, refer to Figure 3-1 and proceed as follows: RJ45...
  • Page 51 The REMOTE tests will run only if the remote is a smart remote or a DSP-100 with the SMART REMOTE mode selected. 1. If you are using a DSP-100 main unit as the remote, turn the remote unit’s rotary switch to SMART REMOTE. If you are using a smart remote unit, turn its rotary switch to ON.

  • Page 52: Link Performance Grade Result (Headroom)

    Users Manual Link Performance Grade Result (Headroom) When an Autotest is complete, the display shows the overall result (pass or fail) and the worst-case NEXT margin, or headroom. Headroom is the smallest difference found between the measured NEXT value and the limit. This number serves as a figure of merit that reflects the overall performance of the link.
  • Page 53 Autotest Automatic Diagnostics (Model DSP-2000) gc09c.eps Figure 3-2. Examples of Automatic Diagnostics Displays...

  • Page 54: Autotest Results For Twisted Pair Cable

    Users Manual Autotest Results for Twisted Pair Cable To see detailed results from a test, use Autotest menu; then press The tests run during an Autotest on twisted pair cable depend on the test standard selected. Tests not applicable to the selected test standard are not run or displayed.
  • Page 55 Table 3-1. Wire Map Displays (continued) Wire Map Display Condition Crossed wires Reversed pairs Crossed pairs Short Open Split pair Autotest Results for Twisted Pair Cable Schematic (only affected pairs shown) gc44i.eps gc45i.eps gc46i.eps gc47i.eps gc48i.eps gc49i.eps gc50i.eps gc51i.eps gc52i.eps gc53i.eps gc54i.eps gc55i.eps...
  • Page 56 Users Manual Resistance The resistance test measures the dc loop resistance for each cable pair. The resistance results screen displays the resistance, limit, and pass/fail result for each cable pair. A limit. A result means that the measured resistance exceeds the limit. Length The length test measures the length of each cable pair tested.
  • Page 57 Propagation Delay and Delay Skew Propagation delays are the times taken in nanoseconds for a test pulse to travel the length of each cable pair. Delay skews are the differences in propagation delays between the shortest delay, which is displayed as 0 ns, and the delays of the other cable pairs. The propagation delay and delay skew results show a limit if the test is required by the selected test standard.
  • Page 58 Users Manual Attenuation Incorrect conduit or temperature settings can cause false attenuation results. You can change these settings in the SETUP mode, as described in “Configuring the Test Tool” in Chapter 2. The attenuation test measures the loss of signal strength over the length of the cable.
  • Page 59 Pressing shows an example of the screen and Table 3-3 describes the items on the screen. Figure 3-3. The Attenuation Plot Screen Table 3-3. Items on the Attenuation Plot Screen Item The cable pair relevant to the plot. Frequency range in MHz of the attenuation test. Margin is the difference between the limit and measured values plotted at the cursor’s position.
  • Page 60 Users Manual NEXT Test The NEXT test measures the crosstalk between cable pairs. This crosstalk value is expressed as the difference in amplitude (in dB) between the test signal and the crosstalk signal. NEXT is measured from the main-unit end of the cable over a frequency range defined by the selected test standard.
  • Page 61 Pressing an example of the screen and Table 3-5 describes the items on the screen. Figure 3-4. The NEXT Plot Screen Table 3-5. Items on the NEXT Plot Screen Item The cable pairs relevant to the plot. Frequency range in MHz of the NEXT test. Margin is the difference between the limit and measured values plotted at the cursor’s position.
  • Page 62 Users Manual NEXT@REMOTE Results The NEXT@REMOTE test and its results are identical to the NEXT test described above, except that the NEXT@REMOTE measurements are taken from the remote end of the cable and sent to the main unit. The ACR test calculates the ratio of attenuation to crosstalk (ACR) for each combination of cable pairs.
  • Page 63 Autotest Autotest Results for Twisted Pair Cable Table 3-6. Items on the ACR Results Screen Item Description The pairs that produced the crosstalk value used in calculating the ACR result. The pair that produced the attenuation value used in calculating the ACR result. The overall result for the ACR test.
  • Page 64 Users Manual Pressing example of the screen and Table 3-7 describes the items on the screen. Item The cable pairs relevant to the plot. Frequency range in MHz of the ACR test. Margin is the difference between the limit and measured values plotted at the cursor’s position.
  • Page 65 ACR@REMOTE The ACR@REMOTE test is identical to the ACR test, except that the ACR values are calculated using NEXT@REMOTE values. Return Loss (RL) The RL test measures the difference between a test signal’s amplitude and the amplitude of signal reflections returned by the cable. The results of the RL test indicate how well the cable’s characteristic impedance matches its rated impedance over a range of frequencies.
  • Page 66 Users Manual Pressing example of the screen and Table 3-9 describes the items on the screen. Item The cable pair relevant to the plot. Frequency range in MHz of the RL test. Margin is the difference between the limit and measured values plotted at the cursor’s position.

  • Page 67: Autotest On Coaxial Cable

    PSNEXT (Power Sum NEXT; Model DSP-2000) The PSNEXT results show how much each cable pair is affected by the combined NEXT from the other pairs. PSNEXT is expressed as the difference in amplitude (in dB) between the crosstalk received on a cable pair and a test signal transmitted on the other pairs.
  • Page 68 Users Manual Figure 3-7. Autotest Connections for Coaxial Cable (Model DSP-2000 Shown) 3-20 BNC “T” Connector DSP-2000 CABLE ANALYZER TEST FAULT INFO ENTER EXIT MONITOR SINGLE TEST Test Tool AUTO TEST For Length Test, remove far-end Terminator SAVE SETUP PRINT SPECIAL FUNCTIONS SMART...

  • Page 69: Autotest Results For Coaxial Cable

    4. Verify that the test standard and cable type displayed are correct. You can change these settings in the SETUP mode. 5. On Model DSP-100, remove any cable connected to the test tool’s RJ45 connector. 6. Remove the terminator from the near end of the coaxial cable and connect the cable to the BNC connector on the test tool.
  • Page 70 Users Manual Resistance The resistance test measures the loop resistance of the cable and the terminator. If a terminator is not connected or if the cable is open, the resistance value is reported as reported as near 0 . Resistance values over 400 are reported as Length Because a cable terminator eliminates signal reflections in coaxial cable, the test tool cannot measure the length of a terminated...

  • Page 71: Saving Autotest Results

    Saving Autotest Results The test tool’s memory can store the results of 500 or more Autotests, depending on the software version and test standard used. You can save the results from an Autotest anytime after the Autotest is complete, but before another Autotest or a Single Test is started.
  • Page 72 The default name assigned to the results from the most recently completed test. Softkey for moving the cursor to edit characters in the middle of the cable identification. On Model DSP-100 with software versions 3.0 and earlier, use the softkey to move the cursor back to the right. On Model DSP-2000, press until the cursor wraps back to the right.

  • Page 73: The Autotest Report

    Automatically Incrementing the Cable Identification Name The test tool’s auto increment function increments the last alphanumeric character of the cable identification name each time you save Autotest results. To enable or disable the auto increment function, proceed as follows: 1. Turn the rotary switch to SETUP. 2.
  • Page 74 Appendix C shows which test standards can produce a warning result for these tests. Mukilteo Cable Co. SITE: Westshore Business Park OPERATOR: Kim Nguyen NVP: 69.0% FAULT ANOMALY THRESHOLD: 15% FLUKE DSP-2000 S/N: 6680915 HEADROOM: -20.4 Wire Map FAIL Split pairs detected: Patch Cable BAD or Patch Cable too short Pair...
  • Page 75 Mukilteo Cable Co. SITE: World Technology Ctr. OPERATOR: Mike Marshall NVP: 80.0% FAULT ANOMALY THRESHOLD: 10% FLUKE DSP-2000 S/N: 6680915 Impedance (ohms), Limit 42-58 Length (ft), Limit 607 Prop. Delay (ns) Resistance (ohms), Limit 48.0-65.0 Figure 3-10. Autotest Report for Coaxial Cable...
  • Page 76 DSP-100/2000 Users Manual 3-28...

  • Page 77: Running Individual Tests

    Chapter 4 provides the following information: Descriptions of the test results produced by the TDX test. Instructions for running Single Tests on twisted pair cable. Instructions for running Single Tests on coaxial cable. Instructions for using the tests available in the MONITOR mode. Instructions for using the tone generator (Model DSP-2000).

  • Page 78: Scanning Function

    Press the selected test. Model DSP-2000 is compatible only with Model DSP-2000SR units. Model DSP-100 is not compatible with Model DSP-2000SR units. softkey. The scanning function runs the test repeatedly Note Note...
  • Page 79 NEXT Required. Supported by all remotes. NEXT@REMOTE Required. Supported by smart remotes and DSP-100 main units used as remotes. With a standard remote, results can be obtained by switching the positions of the remote and main unit and retesting. Length Optional.
  • Page 80 Users Manual Running a Single Test on Twisted Pair Cable To run a test as a Single Test, refer to Figure 4-1 and proceed as follows: RJ45 Jack DSP-2000 CABLE ANALYZER TEST SAVE FAULT INFO EXIT ENTER WAKE UP MONITOR SINGLE SETUP TEST...
  • Page 81 1. If you are using a DSP-100 main unit as the remote, turn the remote unit’s rotary switch to SMART REMOTE. If you are using a smart remote unit, turn its rotary switch to ON. 2. Use a 2m patch cable of the correct impedance to connect the remote to the far end of the cable link.

  • Page 82: The Tdx Analyzer

    1. Turn off any PCs connected to the link you are testing. 2. If you are using a DSP-100 main unit as a remote, turn the remote unit’s rotary switch to SMART REMOTE. If you are using a smart remote unit, turn its rotary switch to ON.
  • Page 83 If the test tool does not detect a remote, the following message appears: restart the analyzer and scan for the remote again, press Single Test screen, press TDX Analyzer Results When the TDX analyzer test is complete, the TDX analyzer results screen appears.
  • Page 84 Users Manual TDX Analyzer Plot To view a TDX analyzer plot for a set of cable pairs, use pairs, then press 4-2 shows an example of a TDX analyzer plot and Table 4-3 describes the items on the screen. Figure 4-2. Example of a TDX Analyzer Plot for a Good Twisted Pair Cable Run Item The cable pairs relevant to the results.

  • Page 85: The Tdr Test

    The TDR Test The TDR (Time Domain Reflectometry) test helps you locate impedance anomalies on a cable by reporting the locations of signal reflections caused by the anomalies. The test locates anomalies caused by problems such as shorts, opens, poor connections, and mismatches in cable types.
  • Page 86 1. Disconnect any PCs from the link you are testing. 2. If you are using a DSP-100 main unit as a remote, turn the remote unit’s rotary switch to SMART REMOTE. If you are using a smart remote unit, turn its rotary switch to ON.
  • Page 87 TDR Results Screen When the TDR test is complete, the TDR results screen appears. Table 4-5 describes the items on the screen. Table 4-5. Items on a TDR Results Screen (Twisted Pair Results) Item The cable pair relevant to the results. Not shown for coaxial cable results. The first distance is the measured distance from the test tool to the end of the cable.

  • Page 88: Single Test Results For Twisted Pair Cable

    Users Manual Figure 4-3. Example of a TDR Plot (Twisted Pair Results) Table 4-6. Items on a TDR Plot (Twisted Pair Results) Item The cable pair relevant to the results. The peak value as reported on the results screen. The distance along the cable under test. The 0 at the left of the scale represents the location of the main test tool.
  • Page 89 The NEXT test and results are identical to the Autotest version. See “NEXT” in Chapter 3 for details. The NEXT@REMOTE test is available only when using a second main DSP-100 unit or a smart remote as a remote unit. Remote end testing must be enabled on the main unit.

  • Page 90: Single Tests For Coaxial Cable

    Users Manual Return Loss (RL) and RL@REMOTE The RL test is identical to the Autotest version. See “Return Loss” in Chapter 3 for details. The RL@REMOTE test is available only when using a DSP-2000 with a DSP- 2000 smart remote. Remote end testing must be enabled on the main unit. See "RL@REMOTE"...
  • Page 91 BNC “T” Connector Figure 4-4. Single Test Connections for Coaxial Cable (Model DSP-2000 Shown) Single Tests for Coaxial Cable DSP-2000 CABLE ANALYZER TEST SAVE FAULT INFO EXIT ENTER MONITOR SINGLE SETUP TEST Test Tool AUTO PRINT TEST SPECIAL FUNCTIONS SMART REMOTE For Length Test, remove far-end...

  • Page 92: Monitoring Network Activity

    This feature allows you to identify active cables and provides some information on network activity. If you want to troubleshoot active networks, contact your Fluke representative for information on LAN diagnostic tools. When connected to a network, the test tool automatically generates link pulses to activate the hub.
  • Page 93 When using a coaxial T-connector to connect the test tool to a network, never allow the T-connector to touch a conductive surface. Such contact could disrupt network operation by creating a ground loop. To extend battery life, use the ac adapter/charger when monitoring network traffic for extended periods.
  • Page 94 Users Manual 1. Turn the rotary switch to MONITOR. 2. Use to highlight either 3. Remove any cable connected to the test tool’s unused test connector. 4. Use a patch cable of the correct impedance to connect the test tool to the network as shown in Figure 4-5.
  • Page 95 Table 4-7. Items on the Traffic Monitor Screen Item Percentage of the network’s transmission bandwidth used over the last 1 second. Utilization includes correct frames, collisions, and jabber. The percentage indicates the current traffic density. The average of all the 1-second utilization percentages since the start of the test.

  • Page 96: Identifying Hub Port Connections

    The locator sends a link pulse to the hub, causing the port’s LED to blink. To identify a hub port connection, proceed as follows: 1. On Model DSP-100, remove any cable connected to the test tool’s BNC connector. 2. Use a patch cable of the correct impedance to connect the test tool to the network connection.
  • Page 97 Running the Impulse Noise Test The connector type for the noise test is always RJ45. The noise test is not valid for coaxial cable because the level of noise on coaxial cable is negligible. To monitor impulse noise, refer to Figure 4-6 and proceed as follows: RJ45 Jack DSP-2000...
  • Page 98 2. Use a 2m patch cable of the correct impedance to connect the remote to the far end of the cable link. 3. On Model DSP-100, remove any cable connected to the test tool’s BNC connector. 4. Turn the rotary switch to MONITOR.

  • Page 99: Determining Hub Port Capabilities (Model Dsp-2000)

    Noise Test Results As the noise test runs, the displayed test results are updated every second after the first 10-second sample period. Table 4-8 describes the items on the screen. Table 4-8. Items on the Noise Monitor Screen Item The minimum level of noise that is considered to be a noise hit. The default threshold is 270 mV.

  • Page 100: Using The Tone Generator (Model Dsp-2000)

    Users Manual Using the Tone Generator (Model DSP-2000) If you have an inductive pickup device, you can use the test tool’s tone generator to identify cable runs and connections. The tone generator produces a signal on the cable under test. You can hear the signal as an audible tone when you place an inductive pickup device near the cable or one of the cable’s connectors.

  • Page 101: Viewing And Printing Saved Reports

    Viewing and Printing Saved Reports Chapter 5 provides the following information: Instructions for sending saved test reports to a serial printer. Instructions for editing the report identification information. Instructions for viewing, deleting, and renaming test reports saved in the test tool’s memory.

  • Page 102: Configuring The Serial Port

    The pin configuration for the cable provided and for Fluke’s 9-to 25-pin adapter is given in “Specifications” in Chapter 8. Refer to your printer’s manual for specifications on your printer’s serial port.
  • Page 103 Test Tool Figure 5-1. Connections for Printing Test Reports 1. Remove any cables connected to the connectors at the top of the test tool. 2. Configure the test tool’s serial port, as described in the previous section. 3. Use an appropriate cable to connect the test tool to the printer. 4.
  • Page 104 Users Manual AUTOTEST REPORTS screen where you can select the reports you want to print, as follows: 1. Use # report label. 2. Press E to select the highlighted report. An asterisk appears on the label to show that the report is selected for printing. To select several consecutive reports, hold down E.
  • Page 105 4. To delete characters in the name, press $ character to the name, use L R and D U to highlight a character in the list; then press E. 5. To store the name, press S. 6. When printing is complete, the test tool displays the following message: reports from memory, press # printed reports, press $ If the Printer Does Not Respond...

  • Page 106: Viewing, Renaming, And Deleting Test Reports

    Users Manual Viewing, Renaming, and Deleting Test Reports To view, rename, or delete test reports, proceed as follows: 1. Turn the rotary switch to SPECIAL FUNCTIONS. 2. Press E to select VIEW/DELETE TEST REPORTS screen appears showing the first screen of test record labels.

  • Page 107: Calibrations And Custom Test Standards

    Calibrations and Custom Test Chapter 6 provides the following information: Instructions for calibrating the test tool. Instructions for determining a cable’s NVP value. Instructions for defining a custom test standard. Calibrating the Test Tool Before shipment, each test tool is calibrated to work with the remote unit shipped in the same package.
  • Page 108 1. Turn the rotary switch to SPECIAL FUNCTIONS. 2. Use D to highlight 3. Press E. 4. On Model DSP-100, remove any cable connected to the test tool’s BNC connector. 5. Connect the test tool to the remote as directed by the displayed messages. On Model DSP-2000, connect the cable to the CABLE TEST jack.

  • Page 109: Nvp Calibration

    NVP Calibration The Determine Cable NVP function allows you to determine the NVP (nominal velocity of propagation) for a known length of cable and save the value for additional measurements of unknown lengths of the same type of cable. The calibrated NVP value applies only to the selected test standard.

  • Page 110: Configuring A Custom Cable

    Users Manual Configuring a Custom Cable The Configure Custom Cable function allows you to define custom test standards for up to four custom cables. You can change the following parameters for your custom configuration: Baseline standard for cable definition NVP (Nominal Velocity of Propagation) Maximum cable length Fault threshold for impedance anomalies Active pair assignments for cable pairs...
  • Page 111 To configure a custom cable, proceed as follows: 1. Turn the rotary switch to SETUP. 2. Press $ 3. Highlight the custom cable configuration; then press E to see the menu of custom cable names. The default cable names are change the cable name after configuring the test parameters.
  • Page 112 DSP-100/2000 Users Manual...

  • Page 113: Basic Cable Testing

    Chapter 7 provides the following information: A description of LAN cable construction. Definitions and explanations of attenuation, noise, characteristic impedance, crosstalk, near-end crosstalk (NEXT), NVP, ACR, and RL. Explanations of the TDR and TDX Basic troubleshooting procedures for LAN cable. LAN Cable Construction LAN cables have a number of characteristics in common with other types of electrical cables.
  • Page 114 Users Manual Cables are designed to perform best in specific applications. For example, power cables are designed to minimize power losses at frequencies of 50 or 60 Hz. LAN cables are designed to minimize signal distortion at higher frequencies. Two types of cables are designed for use with LAN systems: twisted pair cable and coaxial cable.
  • Page 115 Pin 1 Pin 2 Pin 3 Pair 3 Pin 1 Pin 2 Pin 3 Pair 2 Figure 7-2. EIA/TIA RJ45 Connections LAN Cable Construction 568A Pin 4 Pin 5 Pin 6 Pin 7 Pair 1 Pair 2 568B Pin 4 Pin 5 Pin 6 Pin 7...
  • Page 116 Users Manual Coaxial Cable Coaxial cable consists of a conductor surrounded first by an insulating material, then by a braided conductive sheath, as shown in Figure 7-3. In LAN applications, the sheath is electrically grounded and serves as a shield that protects the inner conductor from electrical noise.

  • Page 117: Attenuation

    Basic Cable Testing Attenuation Attenuation Attenuation is a decrease in the strength of a signal over the length of a cable, as shown in Figure 7-4. Cable Signal Signal Receiver Source Loss gc30f.eps Figure 7-4. Attenuation of a Signal Attenuation is caused by a loss of electrical energy in the resistance of the cable wire and by leakage of energy through the cable’s insulating material.

  • Page 118: Noise

    Users Manual Noise Electrical noise is unwanted electrical signals that alter the shape of the signals transmitted on a LAN cable. Figure 7-5 shows an example of how noise affects the shape of an electrical signal known as a sine wave. Signals that are severely distorted by noise can cause communication errors in a LAN.

  • Page 119: Characteristic Impedance

    Basic Cable Testing Characteristic Impedance LAN cables act as antennas that can pick up noise from fluorescent lights, electric motors, electric heaters, photocopiers, refrigerators, elevators, and other electronic devices. Coaxial cable is far less susceptible to noise than twisted pair cable because it is shielded by a conductive sheath.
  • Page 120 Users Manual Minimizing Impedance Discontinuities Characteristic impedance is usually altered slightly by cable connections and terminations. Sharp bands or kinks in LAN cable can also alter the cable’s characteristic impedance. Networks can operate with small discontinuities because the resulting signal reflections are small and are attenuated in the cable. Larger impedance discontinuities can interfere with data transmission.

  • Page 121: Crosstalk And Near-End Crosstalk (Next)

    Crosstalk and Near-End Crosstalk (NEXT) Crosstalk is undesirable signal transmission from one cable pair to another nearby pair. Like electrical noise from outside sources, crosstalk can cause communication problems in networks. Of all the characteristics of LAN cable operation, crosstalk has the greatest effect on network performance. The test tool measures crosstalk by applying a test signal to one cable pair and measuring the amplitude of the crosstalk signals received by the other cable pairs.
  • Page 122 Users Manual The plot’s horizontal scale represents the distance along the cable under test. In the above example, the cursor is placed at a small crosstalk source caused by a connector 77 ft (23.5m) from the test tool. The vertical scale represents the magnitude of the crosstalk detected. The crosstalk levels shown on the plot are adjusted to compensate for cable attenuation.
  • Page 123 Basic Cable Testing Crosstalk and Near-End Crosstalk (NEXT) The scale of the vertical scale increases logarithmically. The scale units are arbitrary. A level of 50 represents a crosstalk magnitude that is close to causing a cable failure. The level of 100 is approximately 20 times greater than the level of 50.
  • Page 124 Users Manual Split Pairs and NEXT A split pair occurs when one wire from a cable pair is twisted together with a wire from a different cable pair. Split pairs most frequently result from miswires at punchdown blocks and cable connectors. Figure 7-7 shows an example of split pair wiring.
  • Page 125 Minimizing Crosstalk Crosstalk problems are minimized by twisting together the two wires in each cable pair. Twisting the two wires together causes the electromagnetic fields around the wires to cancel out, leaving virtually no external field to transmit signals to nearby cable pairs.

  • Page 126: Nominal Velocity Of Propagation (Nvp)

    Users Manual Nominal Velocity of Propagation (NVP) NVP is the speed of a signal through a cable relative to the speed of light. In a vacuum, electrical signals travel at the speed of light. In a cable, signals travel slower than the speed of light. Typically, the speed of an electrical signal in a cable is between 60% and 80% of the speed of light.

  • Page 127: Time Domain Reflectometry (Tdr)

    NVP Calibration The NVP values specified for standard cables are included in the cable specifications stored in the test tool. These values are accurate enough for most length measurements. However, the actual NVP for one cable type can vary up to 20% between batches because of variations in the manufacturing process.
  • Page 128 Users Manual Reflections from Opens An open, or break, in the cable represents an abrupt increase in the cable’s impedance. The impedance of an open is nearly infinite. In an open cable, a signal’s energy is not dissipated by a terminating impedance, so the signal bounces back towards the source.
  • Page 129 Reflections from Shorts A short represents an abrupt decrease in the impedance between the two conductors in a cable. A short is caused when the insulation surrounding a cable’s wires is damaged, allowing the wires to touch each other. The result is a near-zero impedance connection between the conductors.

  • Page 130: Cable Termination

    Users Manual Cable Termination Because signal reflections can distort the shape of communication signals, the unused ends of cable segments must be terminated to prevent reflections. The terminating device is a resistor with a value equal to the cable’s characteristic impedance.

  • Page 131: Acr

    Basic Cable Testing A negative reflection percentage indicates that the polarity of the reflection is the opposite of the original signal. Negative reflections are caused by abrupt decreases in the cable’s impedance, such as those caused by mismatches in cable types or shorts on the cable.
  • Page 132 Users Manual Figure 7-11 shows a plot of NEXT and attenuation limits, along with the resulting ACR plot. Notice that the ACR is lower where NEXT and attenuation values are near each other. 70.0 60.0 50.0 40.0 30.0 GOOD 20.0 10.0 Figure 7-11.

  • Page 133: Troubleshooting Basics

    Troubleshooting Basics Troubleshooting LAN cable installations is most often required during cable installation or modification. When cable is handled carefully and installed correctly, it usually operates trouble-free for years. Finding Cable Faults A general rule for finding cable faults is as follows: With very few exceptions, faults occur at cable connections.
  • Page 134 Users Manual Test Failure Wire map: open Wire map: split pair Wire map: reversed pairs Wire map: crossed pairs 7-22 Table 7-1. Identifying Cable Faults Likely Causes of Failure Wires connected to wrong pins at connector or punchdown blo cks. Faulty connections.
  • Page 135 Table 7-1. Identifying Cable Faults (continued) Examples of Test Displays and Plots gc52i.eps Wire map display showing an open on pair 1,2. gc59i.eps Wire map display showing a split pair on pairs 1,2 and 3,6. gc61i.eps Wire map display showing reversed pair on pair 1,2.
  • Page 136 Users Manual Table 7-1. Identifying Cable Faults (continued) Test Failure Wire map: short NEXT Impedance anomaly detected 7-24 Likely Causes of Failure Wires connected to wrong pins at connector or punchdown blo cks. Conductive material stuck between pins at a connection. Damage to cable insulation.
  • Page 137 Table 7-1. Identifying Cable Faults (continued) Examples of Test Displays and Plots gc63i.eps Wire map display showing short between pins 1 and 2. NEXT test fails. Impedance anomaly is detected. gc64i.eps TDR results showing short 78 ft from test tool. TDX plot showing NEXT caused by excessive untwisting of cable pair at far-end connector.
  • Page 138 DSP-100/2000 Users Manual 7-26...

  • Page 139: Maintenance And Specifications

    Maintenance and Specifications Chapter 8 provides the following information: Instructions for cleaning and storing the test tool. Instructions for replacing batteries. A troubleshooting guide to use when the test tool is not operating correctly. Instructions for returning the unit for repair. A list of replacement parts.
  • Page 140 Figure 8-2 shows how to remove the battery pack. This instrument contains a Nickel-Cadmium battery. Used batteries should be disposed of by a qualified recycler or hazardous materials handler. Contact your authorized Fluke Service Center for recycling information. Note...
  • Page 141 Figure 8-2. Removing the NiCad Battery Pack The ac adapter/charger will not power the test tool when the battery pack is removed. Internal Lithium Backup Battery A lithium battery maintains the test tool’s memory contents when you remove the NiCad battery pack. The memory contents maintained are the stored Autotest reports, all SETUP settings, self-calibration and NVP calibration data, custom cable configurations, and the report identification information.

  • Page 142: If The Test Tool Fails

    Users Manual When the lithium battery voltage is low, have the battery replaced at a Fluke Service Center. See the later section “Service Center Repair” for shipping and warranty information. If the Test Tool Fails If the test tool does not operate properly, refer to Table 8-1 on the next page for troubleshooting procedures.
  • Page 143 Note any error number displayed. Turn the unit off, then turn it on again. Stored data may be lost. If the error occurs again, contact a Fluke Service Center for assistance. Symptom 5: Test tool does not operate with ac adapter/charger connected.

  • Page 144: Replacement Parts

    Replacement Parts Table 8-2 lists the replacement parts for the test tool, the standard remote, and the smart remote. To order replacement parts in the USA and Canada, call Fluke Service Parts at 1-800-526-4731. Outside the USA and Canada, call 1-206-356- 5500.

  • Page 145: Specifications

    Compatibility with Remote Units Model DSP-100 is compatible with DSP-R and DSP-SR units and with other DSP-100 test tools set to the SMART REMOTE mode. It can store calibration data for eight different remotes. Model DSP-2000 is compatible with DSP-2000SR units. It can store calibration data for two different smart remotes.
  • Page 146 Users Manual Cable Types Tested Unshielded twisted pair LAN cables of all categories (UTP category 3, category 4, and category 5). Foil-screened twisted pair cables (ScTP): category 3, category 4, and category 5. Shielded twisted pair cables (STP) (IBM Type 1, 6, and 9; adapter required). Coaxial cables: Thicknet (10Base5;...
  • Page 147 Length Test Table 8-4 shows the specifications for the length test. Table 8-4. Length Test Specifications Twisted Pair cable Range 0 to 328 ft (100m) Resolution Accuracy ± (1 ft (.3m) + 2% of reading) Range 328 to 2500 ft (762m) Resolution Accuracy ±...
  • Page 148 Users Manual DC Loop Resistance Range: 0 to 400 DSP-100 accuracy: ±(500 m +1% of reading) DSP-2000 accuracy: ±(2 +2% of reading) Resolution: 0.1 Overload recovery time: Less than 10 minutes to rated accuracy following an overvoltage. Self-calibration is required after repeated or prolonged overvoltage.

  • Page 149: Return Loss

    Random Noise Floor: Better than 65 dB at 100 MHz. Typically better than 75 dB at 100 MHz. Output Signal Balance: Better than 37 dB at 100 MHz. Common Mode Rejection: Better than 37 dB at 100 MHz. Measurement Accuracy (calculated from above parameters): Better than 1.5 dB from 1 MHz to 100 MHz.

  • Page 150: Serial Interface

    270 mV. Monitors either polarity of noise on pair 3, 6. Minimum detectable impulse width: 10 ns Model DSP-100 LAN Traffic Monitors 10 Mb/s Ethernet only; UTP or coaxial cable. Monitors pair 3, 6 for either polarity of data. Generates a positive polarity link pulse on pair 1, 2.
  • Page 151 Transmit Data Data Terminal Ready (always true) Signal Ground Not connected Request To Send (used only with hardware flow control) Clear To Send Not connected Table 8-8. 9-to 25-pin Adapter (available from Fluke) 9-pin Connector Direction <----- <----- -----> -----> <---->...
  • Page 152 Power Main unit and smart remote: NiCad battery pack, 7.2V, 1700 mA hr Typical NiCad battery life for DSP-100: 10 to 12 hours Typical NiCad battery life for DSP-2000: 8 to 11 hours AC adapter/charger, USA version: Linear power supply; 108 to 132V ac input;...
  • Page 153 Figure 8-3. Operating Environment Specifications Input Ratings Models DSP-100 and DSP-2000 are designed to measure unpowered cables. The inputs are protected against continuous, current-limited telco voltages (<100 mA). Model DSP-2000 can withstand occasional overvoltages of less than 30V rms (42V peak, 60V dc).
  • Page 154 Description Conforms to relevant European Union directives. Safety listed by UL. The control number of the Fluke Corporation is 950Z. This instrument meets the requirements of Telecommunications Industry Association (TIA) Technical System Bulletin (TSB) 67 Accuracy Level II performance for both basic link and channel test configurations.

  • Page 155: Rj45 Connector

    Display Type: Graphic bit-mapped LCD with backlight and adjustable contrast. Size and resolution: 2.8” x 2.4” (7.1 cm x 6.1 cm), 15 lines, 30 characters per line, 240 x 200 bits. RJ45 Connector Typical life: > 5000 cycles Warranty One year from date of purchase. Specifications 8-17...
  • Page 156 DSP-100/2000 Users Manual 8-18...

  • Page 157: A B C

    Appendix Using DSP-LINK ... A-1 Glossary... B-1 Tests Run per Test Standard During an Autotest... C-1 Appendices Page...

  • Page 159: Using Dsp-Link

    Introduction DSP-LINK is a Windows Configure a PC’s serial port for communication with the test tool. Transfer saved Autotest reports and report summaries from the test tool to a View and print saved Autotest reports and summaries. Transfer test data in CSV format from the test tool to a PC. View and print plots from the last test run.

  • Page 160: Connecting To A Pc

    To connect the test tool to a PC, use the 9-pin serial interface cable provided with the test tool. Refer to Figure A-1. If your PC has a 25-pin serial port, you can use a Fluke 25-pin adapter, Fluke P/N 929187. To verify the pin assignments for a different 25-pin adapter or a different cable, refer to the pin assignments for the serial interface cable given in “Specifications”...

  • Page 161: Configuring The Serial Ports

    Figure A-1. Connecting the Test Tool to a PC Configuring the Serial Ports Transferring data requires the serial ports on the test tool and the PC to have the same interface configurations. You can view or change the test tool’s serial port configuration in the SETUP mode.
  • Page 162 Users Manual To use DSP-LINK to configure a PC’s serial port and establish communications, proceed as follows: 1. Use the serial interface cable provided to connect the test tool to the PC. 2. Start the DSP-LINK program on the PC. 3.
  • Page 163 CSV data for plots. * Fluke Cable Manager software lets you organize, sort, edit, print, and save Autotest reports generated by a DSP-100 or DSP-2000 test tool. To purchase Cable Manager, contact your local Fluke distributor. DSP-LINK Functions What You Can View...
  • Page 164 Users Manual DSP-LINK Function Autotest Reports Summary Data: Summary data are the cable identification name, date and time of the test, cable length, test result summary (pass, fail, or warning), total Detailed Test Data length, and site name for the selected summaries, as shown in the Autotest Reports window.
  • Page 165 Table A-2. Special Terms Used in DSP-LINK (continued) DSP-LINK Function Quick Plot Using a Mouse to Control the Cursor: When the pointing hand is shown on the plot, you can move the cursor by sliding the mouse from side to side. To freeze the cursor at a point on the line, click the mouse.
  • Page 166 Users Manual Getting Software Updates from Fluke The Fluke bulletin board system (BBS) and the LAN Products web site give you access to new versions of software and test standards for your test tool. Using the BBS requires a modem and a communication software package.
  • Page 167 Downloading New Test Standards When new test standards are available, you can download the standards from Fluke’s LAN Products BBS or web site to your PC, then use DSP-LINK to download the standards to your test tool. Downloading new test standards erases all test result data stored in the test tool’s memory.
  • Page 168 Downloading New Software When a software update becomes available from Fluke, you can download the software from Fluke’s LAN Products BBS or web site to your PC, then use DSP- LINK to download the software to your test tool. Downloading new software overwrites the existing test software in your test tool.

  • Page 169: Glossary

    Appendix B Glossary 10Base2 An IEEE Standard for Thin Coax Ethernet networks: 10 Mb/s transmission, baseband signaling, 185 meters per coax segment. Also known as Thinlan, Thinnet, or Cheapernet. 10BaseT An IEEE Standard for unshielded twisted pair Ethernet networks: 10 Mb/s transmission, baseband signaling, unshielded twisted pair cable.
  • Page 170 Users Manual Attenuation A reduction in the strength of a signal. Attenuation is usually expressed in decibels. Auto-Negotiation The ability of a network device to determine the capabilities of a far end device, then select settings for optimal communication. Bandwidth A measure of the information capacity of a transmission medium.

  • Page 171: Crossed Pair

    Glossary Capacitance Capacitance A measurement of the capacity to store electrical charge across conductive elements that are separated by an insulating material (dielectric). Undesirable capacitance that occurs between conducting wires in a network cable results in capacitive coupling, which causes crosstalk between cable pairs.

  • Page 172: Flash Memory

    Users Manual Crosstalk Unwanted signal transfer between adjacent cable pairs. Crosstalk occurs because electrical signals passing through a cable pair create an electromagnetic field that transmits the signal to nearby pairs. CSV Data Abbreviation for comma-separated variable. A list of data separated by commas. When CSV data is loaded into a spreadsheet application, the application puts each comma- separated value into a separate cell.

  • Page 173: Hardware Flow Control

    Glossary Hardware Flow Control Hardware Flow Control A hardware method of controlling data flow between two devices. The receiving device tells the sending device to start or stop data transmission by sending control signals on a cable wire that is dedicated to flow control signals. Horizontal Cabling The cabling between a telecommunications outlet and a horizontal cross-connect.
  • Page 174 Users Manual Link Pulse A single-bit, 100 ns test pulse that is transmitted at least every 50 ms during idle periods on 10BaseT link segments to verify link integrity. Near-End Crosstalk (NEXT) The amount of coupling loss (in decibels) occurring when a signal sent on one cable pair is received as crosstalk by another cable pair.

  • Page 175: Reversed Pair

    Glossary Reversed Pair Reversed Pair A wiring error in twisted pair cabling where the pins on a cable pair are reversed between connectors on each end of the cable. RJ45 An 8-pin modular connector used with twisted pair cable. The RJ45 connector resembles a telephone connector (RJ11).

  • Page 176: Split Pair

    Time domain crosstalk. The TDX analyzer locates sources of NEXT along a cable. This measurement technique is patented by Fluke corporation. Terminator A resistor connected to the end of a coaxial cable. The terminator, which is intended to match the characteristic impedance of the cable, eliminates signal reflections by dissipating signals in the cable.
  • Page 177 Glossary XON/XOFF Flow Control XON/XOFF Flow Control Transmitter ON/transmitter OFF. A software method of controlling data flow between two devices. The receiving device tells the sending device to start or stop data transmission by sending commands over the data transmission line.
  • Page 178 DSP-100/2000 Users Manual B-10...

  • Page 179: Tests Run Per Test Standard During An Autotest

    Appendix C Tests Run per Test Standard During an Autotest...
  • Page 180 Users Manual Table C-1. Tests Run per Test Standard During an Autotest Test Standard TIA Cat 5 Channel TIA Cat 5 Basic Link TIA Cat 4 Channel TIA Cat 4 Basic Link TIA Cat 3 Channel TIA Cat 3 Basic Link Fiber Optic ISO11801 EN50173 Class A ISO11801 EN50173 Class B...
  • Page 181 Table C-1. Tests Run per Test Standard During an Autotest (continued) Test Standard Attenuation TIA Cat 5 Channel TIA Cat 5 Basic Link TIA Cat 4 Channel TIA Cat 4 Basic Link TIA Cat 3 Channel TIA Cat 3 Basic Link Fiber Optic ISO11801 EN50173 Class A ISO11801 EN50173 Class B...
  • Page 182 Users Manual Table C-1. Tests Run per Test Standard During an Autotest (continued) Test Standard Coax Cables IEEE 10BaseT 100BaseTX 100BaseT4 IEEE 802.12 4-UTP IEEE 802.12 STP TokenRing, 4 Mb/s TokenRing, 16 Mb/s, Passive TokenRing, 16 Mb/s, Active TP-PMD Twin-Ax: RJ45 pins 4,5,S ARCnet Aus/NZ Class C Channel Aus/NZ Class D Channel...
  • Page 183 Table C-1. Tests Run per Test Standard During an Autotest (continued) Test Standard Coax Cables IEEE 10BaseT 100BaseTX 100BaseT4 IEEE 802.12 4-UTP IEEE 802.12 STP TokenRing, 4 Mb/s TokenRing,16 Mb/s, Passive TokenRing,16 Mb/s, Active TP-PMD Twin-Ax: RJ45 pins 4, 5, S ARCnet Aus/NZ Class C Channel Aus/NZ Class D Channel...
  • Page 184 DSP-100/2000 Users Manual...

  • Page 185: Index

    —A— AC adapter/charger, 2-3 Accessories standard accessories, 1-3 Accuracy range, 2-6 ACR@Remote test, 3-17 explanation of ACR, 7-19 plot description, 3-16 results screen items, 3-15 test for twisted pair, 3-14 Anomaly. See Impedance anomaly Asterisk in test results, 2-6 on custom configurations, 6-5 on selected report, 5-4 Attenuation explanation of attenuation, 7-5...
  • Page 186 8-17 DSP-LINK hardware requirements, A-1 installing, A-2 summary of functions, A-5 —E— Email address for Fluke, A-8 —F— False test results, 8-5 Fault anomaly threshold (twisted pair), 3-9 Fault info key, 3-4 Fiber optic cable testing, 2-4 Frequency, 155 MHz, 2-24...
  • Page 187 —K— Keys for moving around screens, 2-3 functions, 2-13 —L— Language selecting a language, 2-21 selecting, quick start, 2-4 LED functions, 2-15, 2-29 Length test for coaxial cable, 3-22 test for twisted pair, 3-8 variations between cable pairs, 3-8 variations between measured and actual, 7- Length units selecting, 2-26 selecting, quick start, 2-4...
  • Page 188 DSP-100/2000 Users Manual —R— Reflection causes of reflections, 7-15 length test result message, 3-22 Remote calibrating for a new remote, 6-1 communication error, 2-31 compatibility between models, 8-7 effects on TDR test, 4-9 lights, messages, and audible tones, 2-29 messages displayed on remote, 2-30...
  • Page 189 3-3 unable to save test results, 3-25 warning in test results, 4-12 Web site address for Fluke, A-8 Wire map description of test, 3-6 displays, 3-6 pin connections for 568 standard, 7-3...
  • Page 190 DSP-100/2000 Users Manual...
  • Page 191 DSP-100,DSP-2000 Users Supplement Issue: Part Number: 642964 Print Date: January 1997 Revision/Date: This supplement contains information necessary to ensure the accuracy of the above manual. © 2000 Fluke Corporation. All rights reserved. Printed in the U.S.A. Issue Date: 7/00 Page Count:...
  • Page 192 DSP-100,DSP-2000 Users Change #1 On page 6-1, under Calibrating the Test Tool, add the following note after the first paragraph: Allow a 1 minute warm-up time prior to performing self-calibration (see Chapter 6). Self-calibration should be performed only after the test tool and remote unit have warmed up to an ambient temperature between 10°C and 40°C (50 F and 104 F).
  • Page 193 3,6 pair. gc45i.eps Wires 1 and 2 are crossed. gc47i.eps The wire pair connected to pins 1 & 2 at one end is connected to pins 3 & 6 at the other end. gc49i.eps DSP-100,DSP2000 Users Description 7/00...
  • Page 194 DSP-100,DSP-2000 Users Table 3-1. Wire Map Displays (continued) Short Open Split pair On page 7-23, Table 7-1, replace the entire first column and the bottom two cells of the second column with the following: gc53i.eps Wire map display showing an open on pair 1, 2.
  • Page 195 Wire map display showing reversed pair on pair 1, 2. gc49i.eps Wire map display showing transposed pairs on 1, 2 and 3, 6. Inspect the color code at each connection/termination. Inspect the color codes of the wires at each connection/termination. DSP-100,DSP2000 Users 7/00...
  • Page 196 The test tool requires a traceable calibration once a year to make sure that it meets or exceeds the published accuracy specifications. Send it to an authorized Fluke service center for a complete traceable calibration once a year. On page 8-7, change Service Center Calibration Period,...
