Introduction
In this manual the installation of the controller and the software programs are explained. It is a server-client system,
which requires to install a part of the software on a server PC and the other parts on work stations.
Installation of RW-470 PLOTBASE has to be done on the server PC. The programs RW-470 SCANTOOL and RW-470
PLOTCLIENT WEB with Apache Web Server are also installed on the server PC automatically. This installation and
necessary settings are described in the following chapter.
Other RW-470 CLIENTS then are installed on the work stations. The description of this software installation you can
find in the section „Installation of " from page 11. The following illustration makes clear, which programs should be
installed on the different PCs:
RW-470 PLOTBASE
Server PC
MS Windows 2000 ®
with Controller Board
Client PC
Windows 9x/ME Windows NT/2000
I.

Package list

The delivery includes
•
Installation sheet,
• the Controller Board Type 470,
• one CD with Software and PDF-Manuals,
•
one 3,5 inch disc with RSP-License files.
II.

Installations and settings on the server PC

This chapter explains,
•
What system requirements must be fulfilled for the server,
• How to install the drivers and the program and
• What adjustments you have to make to the operating system settings.
Attention: Adjustment of the settings in the operating system and installation of the program should only be
carried out by a user with administrator rights.
Note: The setting of the language is only applied to installation procedure itself. If you want to change the
language for the complete RW-470 software, you have to do so in the "Regional Options" of the "Control
Panel" of your Windows operating system. Instructions you will find in the Reference Manuals of Windows.
SERVER site
CLIENT site
Client PC Client PC
UNIX/LINUX
Software to install on server:
RW-470 PLOTBASE with
- RW-470 SCANCLIENT
- RW-470 PLOTCLIENT WEB
RW-470 WINPRINT
RW-470 Kernel Driver (Device Driver)
optionally AutoCAD 2000
( for use with RW-470 PLOTCLIENT HDI/ADI )
( AutoCAD 2000i required for file format DWG )
Software to install or set up on clients:
RW-470 PLOTCLIENT WIN
RW-470 PLOTCLIENT HDI/ADI
RW-470 PLOTCLIENT MAC
RW-470 PLOTCLIENT LPR/FTP
RW-470 WINPRINT
Client PC
( not to install, only as shared printer )
Macintosh
MS Internet Explorer 5.5 ®
( for use with RW-470 PLOTCLIENT WEB )
INTRODUCTION
RW-470 PLOTBASE Installation 5
