  • Page 1 Please read this manual and save it Please read this manual and save it with your original sales receipt. with your original sales receipt. Tools needed for assembly: Phillips Tools needed for assembly: Phillips Screwdriver, Slotted Screwdriver and Screwdriver, Slotted Screwdriver and Hammer (all not included).

  • Page 2: Table Of Contents

    12 - 36 months of age. • Use this vehicle ONLY outdoors. Most interior flooring can be damaged by riding this vehicle indoors. Fisher-Price be responsible for damage to the floor if the vehicle is used indoors.

  • Page 3: Warnings And Cautions

    WARNINGS AND CAUTIONS ELECTRICAL HAZARD To prevent electric shock, do not immerse in water; wipe clean with a damp cloth. • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - Never modify the electrical system.

  • Page 4: Parts

    • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.

  • Page 5: Parts Picture

    Steering Wheel Cap Lock Nut - 2 Steering Wheel Turn Signal Dash R2510pr-0920 PARTS PICTURE Steering Column Handle Battery Retainer Vehicle 6 Volt Battery Steering Column Cover Seat Belt - 2 6 Volt Charger Seat Not Shown Label Sheet #8 x ¾ " Screw - 2...

  • Page 6: Battery Charging

    ELECTRICAL HAZARD ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fi re resulting in serious injury and could also ruin the electrical system.

  • Page 7: Assembly

    BATTERY CHARGING Charger Connector • Plug the battery connector into the charger connector. • Plug the charger into a standard wall outlet. Notes: - The power indicator on the charger does not indicate the charge status of your battery. The power indicator allows you to see that there is power from the wall outlet.
  • Page 8 Dash SIDE VIEW • Locate the wire connector inside the front end of the vehicle. • While feeding the wire connector through the hole in the dash, fit the tabs on the dash onto the front end of the vehicle. ASSEMBLY Wire Connector DASH VIEW...
  • Page 9 Lock Nut End of Steering Column Steering Linkage • Fit the end of the steering column through the hole in the steering linkage. • Fit a lock nut onto the end of the steering column. • Tighten the lock nut with the assembly tool. Steering Column Cover •...
  • Page 10 End of Steering Column • Fit the remaining lock nut onto the end of the steering column. • Tighten the lock nut with the assembly tool. • “Snap” the steering wheel cap into the center of the steering wheel. ASSEMBLY T-Loops Lock Nut •...

  • Page 11: Vehicle Care

    ASSEMBLY LOCKED • Using a slotted screwdriver, turn both lock fasteners ¼ turn to the locked position Handle Latch Note: Be sure the end of the handle is clean and free from debris before inserting. • Make sure the front wheels are not turned. •...

  • Page 12: Decoration

    Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •...

  • Page 13: Battery Installation

    BATTERY INSTALLATION IMPORTANT! Use only a Power Wheels battery and built-in thermal fuse. Use of any other battery will damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels (4.0 Amp/Hr.) charger before operating your vehicle for the first time.

  • Page 14: Battery Care And Disposal

    BATTERY CARE AND DISPOSAL Care If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See information below for proper disposal. If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician.

  • Page 15: Safe Driving Rules

    SAFE DRIVING RULES RIDING HAZARD WARNING • Prevent Injuries and Deaths • Direct Adult Supervision Required. • Never Ride At Night. • Keep Children Within Safe Riding Areas. These areas must be: - away from swimming pools and other bodies of water to prevent drownings - generally level to prevent tipovers - away from steps, steep inclines, cars, roads and alleys.

  • Page 16: Vehicle Operation

    IMPORTANT! Use this vehicle ONLY outdoors. Most interior floor-ing can be damaged by riding this vehicle indoors. Fisher-Price ® will not be responsible for damage to the floor if the vehicle is used indoors. Stage 1 - Parent Assisted • Make sure the handle is installed (see Assembly step 17).

  • Page 17: Problems And Solutions Guide

    PROBLEMS AND SOLUTIONS GUIDE IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels Monday through Friday and 11 AM - 5 PM (EST) Saturday. Or, contact your local Power Wheels location nearest you, please visit us on-line at www.powerwheels.com.
  • Page 18 PROBLEMS AND SOLUTIONS GUIDE PROBLEM Vehicle was running but suddenly stopped Short run time (Less than 1 - 3 hours per charge) POSSIBLE CAUSE Loose wires or loose connectors Tripped thermal fuse Undercharged battery Overcharged battery Battery is old and will not accept full charge Tripped thermal fuse SOLUTION...
  • Page 19 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE Vehicle runs sluggishly Undercharged battery Battery needs charging Battery is old and will not accept full charge Vehicle is overloaded Driving conditions are too stressful Sometimes the vehicle doesn’t Loose wire or connector run, but other times it does Motor or electrical switch damage When the button is pressed,...
  • Page 20 For the location nearest you, visit us on-line at www.powerwheels.com. © Disney Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2009 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc., unless otherwise indicated.
