- Page 1 • Please read this manual and save it with your original sales receipt. • Tool needed for assembly: Phillips screwdriver (not included). • Use only with the Power Wheels 12 Volt Lead-Acid Rechargeable Orange Battery with Built-in Thermal Fuse and the Power Wheels® 12 Volt Charger (both included).
-
Page 2: Electrical Hazard
IMPORTANT INFORMATION ELECTRICAL HAZARD • To prevent electric shock, do not immerse in water; wipe clean with a damp cloth. • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - Never modify the electrical system. - Page 3 Use this vehicle ONLY outdoors. Most interior fl ooring can be damaged by riding this vehicle indoors. Fisher-Price® will not be responsible for damage to the fl oor if the vehicle is used indoors. • You must charge your battery for 18-30 hours you use your vehicle for the fi...
- Page 4 • If you experience a problem with this product, please call us at to a store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. • Metal parts have been coated with a lubricant to protect them during shipment.
- Page 5 ASSEMBLED PARTS Note: Fasteners not shown. T5407pr-0920...
-
Page 6: Battery Charging
ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fi re resulting in serious injury and could also ruin the electrical system. -
Page 7: Bottom View
WARNING Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle. -
Page 8: Front View
Dash Assembly BACK VIEW • At an angle, fi t the tabs on the dash assembly into the slots in the vehicle. • Insert two screws into the dash assembly. Tighten the screws. Steering Wheel Assembly • Fit the steering column assembly down through the opening in the dash. -
Page 9: Top View
Screws TOP VIEW • Insert three screws into the holes in the seat back and tighten. Roll Bar FRONT VIEW • Fit the tabs on the roll bar onto the seat back and vehicle, as shown. ASSEMBLY • Insert four screws into the holes in the roll bar and tighten. -
Page 10: Back View
• Wipe the vehicle with a clean, dry cloth to remove any oils before applying labels. • Apply labels exactly as shown in the illustrations. For best results, avoid repositioning the label after it has been applied. • Starting at the center of a label rub fi rmly with a dry cloth, and smooth towards the outer edges to remove air bubbles. BACK VIEW T5407pr-0920 DECORATION... -
Page 11: Inside View
DECORATION km/h INSIDE VIEW LEFT VIEW Hint: Labels 32 and 34 are designed to overlap. RIGHT VIEW Hint: Labels 31 and 33 are designed to overlap. T5407pr-0920... -
Page 12: Battery Installation
BATTERY INSTALLATION IMPORTANT! Use only a Power Wheels® 12 volt lead-acid rechargeable orange battery. Use of any other battery will damage your vehicle. Seat Bottom • While pulling the tabs on the front of the seat bottom, lift to remove the seat bottom. Motor Harness Connector •... -
Page 13: Safe Driving Rules
RIDING HAZARD WARNING • Prevent Injuries and Deaths • Direct Adult Supervision Required. • Never Ride at Night. • Keep Children Within Safe Riding Areas. These areas must be: Away from swimming pools and other bodies of water to prevent drownings. -
Page 14: Vehicle Operation
Help your child practice steering to learn how far and how quickly to turn the steering wheel when driving, and automatically knows how to stop. Beginner Use – Low Speed • As assembled, your vehicle is ready to roll in low speed (2½... -
Page 15: Battery Care
BATTERY CARE If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See next section for proper disposal. If acid comes in contact with skin or eyes, fl ush with cool water for at least 15 minutes and call a physician. -
Page 16: Limited Warranty
LIMITED WARRANTY Bumper-to-Bumper* Limited Warranty *One year limited warranty from the date of purchase on the Power Wheels ® vehicle. Six month limited warranty on the 12 volt battery. For the original purchaser, this one year limited warranty covers the Power Wheels ®... -
Page 17: Problems And Solutions Guide
PROBLEMS AND SOLUTIONS GUIDE IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels Or, contact your local Power Wheels at www.powerwheels.com, or call 1-800-348-0751. POSSIBLE PROBLEM Vehicle does not run... - Page 18 PROBLEMS AND SOLUTIONS GUIDE POSSIBLE PROBLEM Vehicle was running but Loose wires or loose suddenly stopped connectors Tripped thermal fuse Short run time (Less than Undercharged battery 1 - 3 hours per charge) Overcharged battery Battery is old and will not accept full charge Tripped thermal fuse T5407pr-0920...
