Product features may vary from the picture above.
Please read this manual and save it with your original sales receipt.
Tools needed for assembly: Phillips Screwdriver, Hammer, Pliers
and Safety Scissors (tools not included).
Use only with a Power Wheels
®
12 Volt Lead-Acid Rechargeable Battery and Power Wheels
®
12 Volt Charger with Type "12V" Connector (included).
JEEP and the Jeep grille design are registered trademarks of DaimlerChrysler
Corporation and are used under license. ©DaimlerChrysler Corporation 2003.
www.powerwheels.com
Goodyear (and winged foot design) and Wrangler (for tires) are trademarks of
The Goodyear Tire & Rubber Company, used with permission.
Owner's Manual
with Assembly Instructions
For Model C2390
Advertisement
Table of Contents
Related Manuals for Fisher-Price Power Wheels C2390
Summary of Contents for Fisher-Price Power Wheels C2390
- Page 1 JEEP and the Jeep grille design are registered trademarks of DaimlerChrysler Corporation and are used under license. ©DaimlerChrysler Corporation 2003. www.powerwheels.com Goodyear (and winged foot design) and Wrangler (for tires) are trademarks of The Goodyear Tire & Rubber Company, used with permission. Owner's Manual with Assembly Instructions For Model C2390...
-
Page 2: Table Of Contents
- only two (2) riders at a time. • Use this vehicle ONLY outdoors. Most interior floor- ing can be damaged by riding this vehicle indoors. Fisher-Price will not be responsible for damage to ® the floor if the vehicle is used indoors. -
Page 3: Warnings And Cautions
ELECTRICAL HAZARD • Battery can fall out and injure a child if vehicle tips over. Always use battery clamp. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. - Use of the wrong type battery or charger could cause a fire or explosion resulting in serious injury. -
Page 4: Parts
• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. - Page 5 Parts #8 x 4" Screw – 2 Key Assembly #10 x 1" Screw – 7 #10 x " Screw – 8 #8 x 1" Screw – 7 #8 - 32 x 1.625" Screw – 2 #8 Lock Nut – 2 Hood Latch –...
-
Page 6: Parts Diagram
Note: Some parts shown are assembled on both sides of the vehicle. No. Part Quantity No. Part Vehicle Body Steering Column .354 Cap Nut Hood Latch 12 Volt Battery Battery Clamp Unit Key Assembly Taillight Lens Taillight Housing #8 x 1" Screw Dash Parts Diagram #10 x 1"... -
Page 7: Battery Charging
ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery clamp. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. -
Page 8: Assembly
Battery Charging Battery • Plug the charger connector into the battery • Plug the charger into a standard wall outlet Note: If power flow to the wall outlet is controlled by a switch, make sure the switch is “ON”. • Before first-time use, charge the battery for at least 18 hours. - Page 9 Battery Clamp Unit • Insert two #10 x 1" screws through the holes in the battery clamp unit and into the pegs in the dash. • Tighten the screws with a Phillips screwdriver. Do not over-tighten. Battery Clamp • Position the dash on the vehicle body. •...
- Page 10 Dash Key Assembly Dash View • Insert and “snap” the key assembly into the opening in the dash, as shown. Steering Column Bottom View • Wipe the steering column with a paper towel to remove any excess lubricant. • Turn the vehicle on its side. •...
- Page 11 Steering Wheel Steering Column “UP” • Turn the vehicle upright. • Position the steering wheel so that the spokes form a “Y” as shown. The tab on the steering wheel stem should face up. • Fit the steering wheel onto the steering column. •...
- Page 12 Hood Latch Slot • Insert a hood latch into one of the slots in the vehicle body, near the hood area. • Twist the base of the hood latch the vehicle body. • Repeat this procedure on the other side of the hood area to attach the other hood latch to the vehicle body.
- Page 13 Spacers Grille Brush Guard • Fit two spacers between the grille and the back of the brush guard, as shown. • Insert two #8 x 4" screws through the brush guard, the spacers and into the holes in the grille. •...
- Page 14 Dash View • Insert a #8 x 1" screw into the rear of seat, as shown. • Tighten the screw with a Phillips screwdriver. Do not over-tighten. • Fit a support to one side of the sport bar. • Insert a #8 - 32 x 1.625 " screw through the support, the sport bar and out through the support.
- Page 15 Sport Bar Support PUSH HERE Side Fender PULL HERE • Fit the sport bar into the holes in the vehicle body. • Push down firmly on a sport bar support while pulling up on the side fender to fit the sport bar into the vehicle body.
-
Page 16: Label Decoration
Label Decoration Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •... - Page 17 Label Decoration Right Side View Left Side View...
-
Page 18: Battery Installation
IMPORTANT! Use only a Power Wheels Use of any other battery will damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels ® 12 volt charger before operating your vehicle for the first time. Charge the battery for at least 14 hours after each use of the vehicle. -
Page 19: Battery Care And Disposal
Care If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. Please refer to the information on this page for proper disposal. If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician. -
Page 20: Rules For Safe Driving
RIDING HAZARD WARNING Prevent Injuries and Deaths • Direct Adult Supervision Required. • Keep Children Within Safe Riding Areas These areas must be: - away from swimming pools and other bodies of water to prevent drownings. - generally level to prevent tipovers. - away from steps, driveways, cars, roads and alleys. -
Page 21: How To Operate Your Vehicle
Beginner Use - Low Speed Drive As assembled, your vehicle is ready to roll in low speed mph, maximum). It has been pre-set so it will only operate in low speed. After your child has mastered the basic skills of driving and understands the rules for safe driving, it’s time to remove the high speed lock-out screw to allow the vehicle to operate in low or high speed. -
Page 22: Caring For Your Vehicle
How to Operate Your Vehicle Advanced Use - High Speed Drive Disconnecting the High Speed Lock-Out Shifter Lock-Out Screw • Before you disconnect the high speed lock-out, make sure your child knows how to steer, how to start and stop the vehicle and knows the rules for safe driving. When the high speed lock-out is disconnected, the vehicle can be driven forward in low speed (2 maximum) or high speed (5 mph, maximum). -
Page 23: Problems And Solutions Guide
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels at www.powerwheels.com. - Page 24 Problems and Solutions Guide Problem Short run time (Less than Undercharged battery 1 - 3 hours per charge) Overcharged battery Battery is old and will not accept full charge Tripped thermal fuse Vehicle runs sluggishly Undercharged battery Battery needs charging Battery is old and will not accept full charge Vehicle is overloaded...
- Page 25 Problems and Solutions Guide Problem Vehicle runs in low speed, but High speed lock-out not disconnected does not run in high speed Please Note: The vehicle is designed to operate in low speed only in reverse When the foot pedal is pressed Operation of vehicle in low speed only one rear wheel spins Sometimes the vehicle doesn’t...
-
Page 26: Limited Warranty
Bumper-to-Bumper* Limited Warranty *One year limited warranty from the date of purchase on the Power Wheels ® vehicle. Six month limited warranty on the 12 volt battery. For the original purchaser, this one year limited warranty covers the Power Wheels ®... - Page 28 Fisher-Price, Power Wheels, and Power Wheels by Fisher-Price, Power Lock and Power Stick are U.S. trademarks of Mattel, Inc. ©2003 Mattel, Inc. All Rights Reserved. ® and ™ are registered trademarks of Mattel Inc. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A.
