- Page 1 Product Manual Momentus 7200.1 SATA ST910021AS ST980825AS ST96023AS ST94015AS 100320528 Rev. B August 2007...
- Page 2 SeaBOARD, SeaFONE, SeaTDD, and SeaTools are either trademarks or registered trade- marks of Seagate Technology LLC or one of its affiliated companies in the United States and/ or other countries. All other trademarks or registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Seagate Technology support services ........ - Page 4 Momentus 7200.1 SATA Product Manual, Rev. B...
- Page 5 Mounting dimensions—top, side and end view ........21 Momentus 7200.1 SATA Product Manual, Rev. B...
-
Page 7: Introduction
Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate ® Momentus 7200.1 SATA model drives: • ST910021AS • ST980825AS • ST96023AS • ST94015AS These drives provide the following key features: • 7,200 RPM spindle speed •... -
Page 8: About The Serial Ata (Sata) Interface
Shadow Register Block. All Serial ATA devices behave like Device 0 devices. For addi- tional information about how Serial ATA emulates parallel ATA, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. The specification can be downloaded from http://www.serialata.com. Momentus 7200.1 SATA Product Manual, Rev. B... -
Page 9: Drive Specifications
100.5 +/- 1.6 mm (3.957 +/- 0.063 inches) Weight (typical) 115 grams (0.254 lb) Average latency (msec) 4.2 msec Power-on to ready (typical) 4 seconds Standby to ready (typical) 3 seconds Startup current (typical) +5V (peak) 1.28 amps Momentus 7200.1 SATA Product Manual, Rev. B... - Page 10 600,000 software-controlled power on/off cycles 20,000 hard power on/off cycles 32°C, 80% relative humidity 100,000 software-controlled power on/off cycles 5°C, 80% relative humidity 20,000 hard power on/off cycles 5°C, 10% relative humidity 55°C, 16% relative humidity Momentus 7200.1 SATA Product Manual, Rev. B...
-
Page 11: Formatted Capacity
Sectors per track 16,383 LBA mode When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the number of guaranteed sectors as defined above. Momentus 7200.1 SATA Product Manual, Rev. B... -
Page 12: Physical Organization
Physical characteristics Drive specification Height (mm) 9.5 +/-0.2 (inches) 0.374 +/-0.0078 Width (mm) 69.85 +/-0.25 (inches) 2.75 +/-0.0098 Length (mm) 100.5+/-1.6 (inches) 3.957 +/- 0.063 Typical weight (grams) 115 grams (pounds) (0.254 lb) Momentus 7200.1 SATA Product Manual, Rev. B... -
Page 13: Seek Time
However, due to the manner in which these drives are formatted, benchmark tests that include command overhead or measure logical seeks may produce results that vary from these specifications. Start/stop times Time to ready Typical Power-on to Ready (sec) Standby to Ready (sec) Momentus 7200.1 SATA Product Manual, Rev. B... -
Page 14: Power Specifications
Idle, low power mode* 0.95 Standby 0.28 Sleep 0.28 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Momentus 7200.1 SATA Product Manual, Rev. B... -
Page 15: Deferred Spinup
This feature does not impact time-to-ready in typical desktop systems. To accommodate the deferred spinup of multiple disc drives in an enclosure, Momentus 7200.1 SATA disc drives will spin up only after power is applied to the drive and after successful PHY (Physical layer) initializa- tion. -
Page 16: Conducted Noise
Self Refresh Low Power mode, the heads are parked and the spindle is at rest. The drive leaves Sleep mode after it receives a Hard Reset or Soft Reset from the host. After receiving a reset, the drive exits Sleep mode and enters Standby mode with all current translation parameters intact. Momentus 7200.1 SATA Product Manual, Rev. B... -
Page 17: Environmental Specifications
Wet bulb temperature Operating 30°C (86°F max) Nonoperating 40°C (104°F max) 2.10.4 Altitude Operating –304.8 m to 3,048 m (–1,000 ft to 10,000+ ft) Nonoperating –304.8 m to 12,192 m (–1,000 ft to 40,000+ ft) Momentus 7200.1 SATA Product Manual, Rev. B... -
Page 18: Shock
The maximum nonoperating vibration levels that the drive may experience without incurring physical damage or degrada- tion in performance when subsequently put into operation are specified below 5–500 Hz: 5.0 Gs (0 to peak). Max displacement may apply below 22 Hz. Momentus 7200.1 SATA Product Manual, Rev. B... -
Page 19: Acoustics
150 kHz to 80 MHz, 3 Vrms, 80% AM with EN 61000-4-6: 97 1 kHz sine Voltage dips, interrupts 0% open, 5 seconds EN 61000-4-11: 94 0% short, 5 seconds 40%, 0.10 seconds 70%, 0.01 seconds Momentus 7200.1 SATA Product Manual, Rev. B... -
Page 20: Reliability
Information Technology Equipment (ITE). Emission levels are defined by EN 55022, Class B and the immunity levels are defined by EN 55024. Seagate uses an independent laboratory to confirm compliance with the EC directives specified in the previous paragraph. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives. -
Page 21: Fcc Verification
As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate Technology LLC has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disc drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. -
Page 22: Environmental Protection
Lead (Pb), in electronic products effective July 2006. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the rep- resentations of our suppliers regarding the presence of RoHS substances in these parts and materials. Our... -
Page 23: Corrosive Environment
The sil- ver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. - Page 24 Momentus 7200.1 SATA Product Manual, Rev. B...
-
Page 25: Configuring And Mounting The Drive
• Do not remove the factory-installed labels from the drive or cover them with additional labels. Removal voids the warranty. Some factory-installed labels contain information needed to service the drive. Other labels are used to seal out dirt and contamination. Momentus 7200.1 SATA Product Manual, Rev. B... -
Page 26: Configuring The Drive
For installations which require cables, you can connect the drive as illustrated in Figure 3. Signal connector Power connector Signal cable Power cable Figure 3. Attaching SATA cabling Each cable is keyed to ensure correct orientation. Momentus 7200.1 SATA Product Manual, Rev. B... -
Page 27: Drive Mounting
(9.5 +/- .2) 2X .118 Both sides 3.567 (90.60) 4X M3 X 0.5-6H .551 Mounting holes (13.99) .10 min. full thread 2.430 (61.722) .160 (4.06) Figure 4. Mounting dimensions—top, side and end view Momentus 7200.1 SATA Product Manual, Rev. B... - Page 28 Momentus 7200.1 SATA Product Manual, Rev. B...
-
Page 29: Serial Ata (Sata) Interface
Attachment” specification. Hot-Plug compatibility Momentus 7200.1 SATA drives incorporate connectors which enable you to hot plug these drives in accor- dance with the Serial ATA: High Speed Serialized AT Attachment specification revision 2.0. This specification can be downloaded from http://www.serialata.com. - Page 30 3. There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate backplane configuration. 4. All used voltage pins (V ) must be terminated. Momentus 7200.1 SATA Product Manual, Rev. B...
-
Page 31: Supported Ata Commands
Read Native Max Address Read Native Max Address Extended Read Sectors Read Sectors Extended Read Sectors without Retries Read Verify Sectors Read Verify Sectors Extended Read Verify Sectors without Retries Seek Set Features Set Max Address Momentus 7200.1 SATA Product Manual, Rev. B... - Page 32 Write Sectors Extended ATA-standard power-management commands Check Power Mode 98h or E5h Idle 97h or E3h Idle Immediate 95h or E1h Sleep 99h or E6h Standby 96h or E2h Standby Immediate 94h or E0h Momentus 7200.1 SATA Product Manual, Rev. B...
- Page 33 Command name Command code (in hex) ATA-standard security commands Security Set Password Security Unlock Security Erase Prepare Security Erase Unit Security Freeze Lock Security Disable Password Momentus 7200.1 SATA Product Manual, Rev. B...
-
Page 34: Identify Device Command
PIO data-transfer cycle timing mode 0200 Retired 0200 Words 54–58, 64–70 and 88 are valid 0007 Number of current logical cylinders xxxx Number of current logical heads xxxx Number of current logical sectors per logical track xxxx Momentus 7200.1 SATA Product Manual, Rev. B... - Page 35 Security erase time 0000 Enhanced security erase time 0000 Master password revision code FFFE Hardware reset value xxxx (see description following this table) Auto acoustic management setting xxxx 95–99 ATA-reserved 0000 Momentus 7200.1 SATA Product Manual, Rev. B...
- Page 36 Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Word 93 1 = 80-conductor cable detected, CBLID above V 0 = 40-conductor cable detected, CBLID below V Momentus 7200.1 SATA Product Manual, Rev. B...
-
Page 37: Set Features Command
Disable write cache Enable read look-ahead (read cache) feature (default). Report full capacity available Note. At power-on, or after a hardware or software reset, the default values of the features are as indi- cated above. Momentus 7200.1 SATA Product Manual, Rev. B... -
Page 38: S.m.a.r.t. Commands
S.M.A.R.T. Enable Operations S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status Note. If an appropriate code is not written to the Features Register, the command is aborted and 0x 04 (abort) is written to the Error register. Momentus 7200.1 SATA Product Manual, Rev. B... -
Page 39: Seagate Technology Support Services
Seagate Service Centers Presales Support Our Presales Support staff can help you determine which Seagate products are best suited for your specific application or computer system, as well as product availability and compatibility. Technical Support Seagate technical support is available to assist you online at support.seagate.com... - Page 40 Seagate Customer Service Operations (CSO) representative for warranty- related issues. Resellers or end users of drive products should contact their place of purchase or Seagate warranty service for assistance. Have your serial number and model or part number available.
- Page 41 Conducted RF immunity 13 Formatted capacity 5 Configuring the drive 19 Formatted Gbytes 3 connectors 20 Freeze Lock 25 corrosive environment 17 CSA C22.2 (950) 14 current 3 Gbytes 5 cycles 14 geometry 5 Cylinders 5 Momentus 7200.1 SATA Product Manual, Rev. B...
- Page 42 2 Read Multiple 25 Max Address 25 Read Multiple Extended 25 maximum temperature 11 Read Native Max Address 25 Microcode 25 Read Native Max Address Extended 25 mounting 21 Read Sectors 25 Momentus 7200.1 SATA Product Manual, Rev. B...
- Page 43 Set Multiple Mode 26 Write Long with Retries 26 Shock 12 Write Long without Retries 26 Shock, nonoperating 4 Write Multiple 26 Shock, operating 4 Write Sectors 26 single-track seeks 7 Sleep 8 Sleep mode 4 Momentus 7200.1 SATA Product Manual, Rev. B...
- Page 44 Momentus 7200.1 SATA Product Manual, Rev. B...
- Page 46 Seagate Technology LLC 920 Disc Drive, Scotts Valley, California 95066-4544, USA Publication Number: 100320528, Rev. B, Printed in USA...
