Rosen DP-1001 User Manual

Multimedia navigation system
Hide thumbs Also See for DP-1001:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owenrs Manual, Owner's Manual
E
N
T
E
R T A
I
N
M
E
N
T
S
Y
S
T
E
M
S
Multimedia Navigation System

System Features

Ultra High Resolution LCD Display
Integrated Touch Screen Controls
AM/FM Stereo Tuner with 24 Presets
Satellite Radio Ready with 24 Presets
Made for iPod Accessory Ready
CD and MP3 Audio Disc Playback
Plays DVD Movie to Front and Rear Seat Zones
Supports Integrated Rear Seat Monitors
Integrated MP3 Virtual 6 Disc Recorder/Player
Built in Bluetooth Hands-Free Interface
Aux Input to Play External Sources
Supports Dolby 5.1 Surround Sound
Supports Full Subwoofer Control
Voice and Visual 3D Turn-By-Turn Navigation
3D Maps with City Realistic Graphics
Millions of POI Navigation Library
Integrated Backup Camera ready
Integrated Backup Sensor ready
Copyright 2009 Rosen Entertainment Systems
DP-1001 Rev J

Advertisement

Table of Contents
loading

Related Manuals for Rosen DP-1001

Summary of Contents for Rosen DP-1001

  • Page 1: System Features

    Supports Dolby 5.1 Surround Sound Supports Full Subwoofer Control Voice and Visual 3D Turn-By-Turn Navigation 3D Maps with City Realistic Graphics Millions of POI Navigation Library Integrated Backup Camera ready Integrated Backup Sensor ready Copyright 2009 Rosen Entertainment Systems DP-1001 Rev J...
  • Page 2 COPYRIGHT Copyright © 2009 by Rosen Entertainment Systems. All rights reserved. Except as permitted under the Copyright Act of 1976, no part of this publication may be reproduced or distributed in any form or by any means, or stored in a database or retrieval system, without the prior written permission of Rosen Entertainment Systems.
  • Page 3 SAFETY NOTICE NOTICE OF INTENDED USE Some features of Rosen Entertainment Systems are not intended for viewing by the driver when the vehicle is in motion, such as movie playback. When using navigation, minimize the amount of time spent viewing the screen and use voice prompts as much as possible.

  • Page 4: Table Of Contents

    CONTENTS 1. Control Organization....................2. Basic Operation......................2.1 RADIO Operation.................... 2.1.1 RDS Operation..................2.2 SAT RADIO Operation..................2.3 iPod Operation....................2.4 CD Operation....................2.5 DVD Operation....................2.5.1 VCD Playback..................2.5.2 SD Card Playback.................. 2.5.3 JPEG Playback..................5.5.4 USB Hard Drive Playback..............2.6 MP3 Operation....................
  • Page 5 CONTENTS 4. Navigation........................ 4.1 Touch Screen Calibration................. 4.2 Map and POI Updates..................5. Precautions/System Reset..................

  • Page 6: Control Organization

    1. CONTROL ORGANIZATION Controls Your system (while it may not look like the figure), is equipped with various push buttons and rotary knobs in some cases. You can use these to access selected functions directly. Touch Controls Your system is equipped with a touch sensitive screen.
  • Page 7 Spectrum Display If the spectrum is turned on, it will display after several seconds of no operation while in Radio or DVD T-1 00:12 Satellite Radio mode. After the spectrum screen appears, touch switch among several different spectrum display options (as figure shows). Spectrum can be enabled/disabled from the settings screen.

  • Page 8: Basic Operation

    2. BASIC OPERATION 2.1 RADIO Operation Enter/Exit Touch to enter radio interface. Touch any other Tab Button to exit this screen. If the spectrum is turned on, it will display after a few seconds if there is no operation. When spectrum is showing, touch the screen to return to the radio mode.
  • Page 9 Setting Preset Buttons Select the radio station, and then press and hold one of the preset buttons to set the station. 18 radio stations can be stored for FM (6 stations for each of FM1, FM2 and FM3), 6 stations can be stored for AM. Play a Selected Radio Station Using a short press of a preset button or the tuning knob on equipped radios, you can select...

  • Page 10: Rds Operation

    2.1.1 RDS Operation To enable/disable the RDS (Radio Data System) feature touch the RDS icon on the top menu bar. When an RDS function is enabled the RDS icon will remain colored. PTY Operation Touch to enable the PTY (Program Type) function.

  • Page 11: Sat Radio Operation

    2.2 SATELLITE RADIO Operation Enter/Exit If your system contains the optional Satellite Radio feature, touch to enter SAT radio interface. Touch any other Tab Button to exit this screen. If the spectrum is turned on, it will display after a few seconds if there is no operation.
  • Page 12 Setting Preset Buttons Select the SAT radio station, and then press and hold one of the preset buttons to set the station. 18 stations can be stored for SAT (6 stations for each of SAT1, SAT2 and SAT3). Play a Selected SAT Radio Station Using a short press of a preset button you can select the desired station from SAT1, SAT2, or SAT3.

  • Page 13: Ipod Operation

    2.3 iPod Operation When the unit is equipped with the optional iPod connector and external iPod player, the audio and video files (on compatible iPod models) stored in an iPod player can be played through the car system. Due to changes in design and firmware by Apple, not all iPod models are compatible with the Rosen system.
  • Page 14 Main Menu Touch to go up one level in the menu structure. To Play A Song To play a song from the menu, touch the song name. Touch to play the previous/next song. Touch to Pause or resume Playback. Display Song Information Touch the EQ button once and the play information will be displayed in the box on the right (as shown).
  • Page 15 Numeric Keypad Touch to enter the numeric keypad interface. Touch the numbers on the keypad to select the desired song choice, then touch Enter to confirm. Your selection will then be played. Video Playing Touch to access the main menu of the iPod. Select Video from the menu list as shown.

  • Page 16: Cd Operation

    2.4 CD Operation CD Disc Playing Touch the tab to enter the main CD interface. Touch any other Tab Button to exit this screen. Inserting a CD will automatically start audio playback. Discs should be inserted with the label facing upwards. A CD can be inserted at any time and the system will automatically switch to CD mode (except in Navigation mode).

  • Page 17: Dvd Operation

    2 5 DVD Operation This unit plays discs in formats such as DVD/VCD/CD/MP3/JPEG/MPEG4/ CD-R , etc. However, some user produced disc may not play or may cause unpredictable operation. Disc which are not the proper region will not play in this system and the disc size is limited to the standard 12cm diameter type only.
  • Page 18 9.¾µÍ·¹¦ÄܲÙ×÷ 9.¾µÍ·¹¦ÄܲÙ×÷ 9.¾µÍ·¹¦ÄܲÙ×÷ 9.¾µÍ·¹¦ÄܲÙ×÷ 9.¾µÍ·¹¦ÄܲÙ×÷ 9.¾µÍ·¹¦ÄܲÙ×÷ 9.¾µÍ·¹¦ÄܲÙ×÷ 9.¾µÍ·¹¦ÄܲÙ×÷ DVD Control Panel Description While in DVD mode, long press the screen to show the DVD control panel. Touch the screen or tab to exit the control panel and return the DVD to full screen or after several seconds of no operation , the DVD screen will return to full screen mode.

  • Page 19: Vcd Playback

    2.5.1 VCD Disc Playing If the VCD has no menu, the system will automatically read the disc and play directly. If Normal the disc has a menu , touch the menu item to play Select song Touch on the DVD setting page, to return to main menu of the disc. While playing a disc, touch the upper right part of DVD T-01 02:16 play the screen to display the play information.

  • Page 20: Sd Card Playback

    2.5.2 SD Card Playing If the unit is equipped with the optional multi-media SD card port, this operation is available Inserting /Removing SD Card Insert the SD card, with media information into the SD card slot directly until the card is locked. To remove the SD card, exit from SD card playback mode first, and then press the SD card slightly to cancel the locking status and the SD card will eject automatically.

  • Page 21: Jpeg Playback

    2.5.3 JPEG Disc Playing Play Status: Insert a JPEG disc into the DVD player. The disc will play the first file automatically. To exit, touch the screen to bring up the main menu Tab Buttons. Thumbnail View£º While playing, touch to return to thumbnail view.

  • Page 22: Usb Hard Drive Playback

    2.5.4 Play USB Hard Disc Inserting / Removing USB To use the USB input, insert USB directly into the unit or though the USB adaptor cable included with the system. To remove the USB, exit from USB mode first. Access to USB Mode 00:15 3:42 Touch...

  • Page 23: Mp3 Operation

    2.6 MP3 Operation Your system may contain an optional built in MP3 storage feature. Touch the tab to enter the optional MP3 interface. Touch any other Tab Button to exit from the MP3 interface. Touch any button where MP3 music has been recorded to start playback.

  • Page 24: Bluetooth Operation

    2 7 Bluetooth Handsfree The system can provide bluetooth hands free communication function. If your mobile phone is bluetooth enabled, it can establish a point-to-point connection with the system, providing telephone dial up, call answering, and bluetooth music play. Note: This system requires a Bluetooth enabled phone.
  • Page 25 “Pairing” will be displayed on the screen. After the connection succeeds, your cell phone will display (Rosen). Connect to the device by entering the pass code (1234). The system will indicate “Linking” and then “Connected.” When your phone is connected its name will be displayed on the unit.
  • Page 26 To make a call from the touch screen, enter the desired number and press 1-888-555-1212 If the wrong number has been entered, press 1-888-555-1212 Touch to transfer the call between car 1-888-555-1212 speakers and handset. To end the call, press 1-888-555-1212 Touch to call the last number dialed from...
  • Page 27 Answer A Call While in any mode, if there is an incoming cal, the Bluetooth handsfree system is automatically activated. 1-888-555-1212 Press to answer or to reject the call. If Auto Answer is selected, the incoming call will be automatically connected after three rings. Any time during the call press to switch between audio over the car speakers or mobile phone...
  • Page 28 To Add/Edit/Delete an entry, long touch the name/number on the screen and this will open the full keyboard as shown. Select the name or number button to edit the entry. After your entry is correct press the button. To return to the previous screen, select the icon.

  • Page 29: System Setup

    3. SYSTEM SETTINGS MENU 3.1.1 Settings Menu Enter/Exit Touch to enter the main menu interface. Touch to enter the system settings menu. Touch icon to exit. System Settings Touch to enable/disable the clock display on the menu bar. 12:00 Touch to enable/disable the reverse function.

  • Page 30: Touch Screen Calibration

    Time Setup From the main menu, touch to enter the system settings interface. Touch the clock display directly to make changes to the time. 12:00 When the selected item (hour and minute) flashes, touch the + and - buttons to make the changes. After the time has been set, touch .
  • Page 31 Touch Screen Calibration To re-calibrate the touch screen settings follow the steps below. To ensure accuracy please use the stylus provided with your system and be sure to touch the center point of the cross as close as possible otherwise the precision of the touch calibration will be affected.

  • Page 32: Extras

    3.1.3 Extras Your system may be equipped with various extra features. Enter/Exit Touch to enter the main menu interface. Touch to open the available Extras. Touch to exit from the main menu. If no extras are available the extras page will not open.

  • Page 33: Rear Seat Source

    3.1.4 Rear Seat Source The system offers a rear seat source function. The driver can enjoy music while the passenger can watch a DVD through an option display for rear seat passengers. Enter/Exit From any screen touch the icon to open the main menu.

  • Page 34: Reverse Camera/Sensor

    3.1.5 Reverse Camera/Sensor Operation When the system is connected with an optional rear camera or sensors you can view the image from the rear camera on the unit or use the backup warning system. When the camera is installed and the backup setting enabled, the rear camera view will automatically open when the vehicle is shifted into reverse.

  • Page 35: Display Adjustments

    3.1.6 Audio Setup From the main menu touch to enter the audio settings interface. Touch any of the Treble, Mid Range, Bass or Speaker buttons to adjust the balance of the audio settings. Select the + and - icons on the top menu bar to adjust the levels for the audio and speaker settings.

  • Page 36: Aux Input

    3.1.8 AUX Operation If you have an external video source connected to your system you can access the source through the Auxiliary Input function (AUX). Touch to enter the main menu interface. Touch to access the external video source. The AUX source will be displayed in full screen mode Touch the screen to bring up the top menu bar.

  • Page 37: Dvd Setup

    3.1.9 DVD System Setup NOTICE: Use caution when making changes to the DVD Settings. Incorrect settings can prevent the system from operating properly such as loss of audio or video. Enter/Exit System Setup Touch tab to enter the DVD interface. While in DVD mode, touch the screen to show the main DVD Control Panel.
  • Page 38 General Setup Page Screen Normal/Ps Images will be displayed in panoramic format Normal/LB Images will be displayed in message box format Images will be displayed in wide screen (16:9) format Wide Angle Mark On/Off Select to display or hide the angle mark. Osd Lang English Chinese/Francais/French/Italiano/Svenska/pyccknn Select the DVD system interface language...
  • Page 39 Audio Setup Page CAUTION: Selecting certain audio settings may disable the audio if your system does not have optional equipment. SPEAKER SETUP DOWNMIX Dolby stereo, distributes the sound from the middle and the surround channels LT/RT to the left and right speakers. Stereo Audio output to left and right channel signal.
  • Page 40 SPDIF Setup Page SPDIF Output Meaning that the output signal is an analog signal, which is the normal setting. Output/Off SPIDF/ALL/PCM If you have a 5.1 surround sound system it may support a SPDIF input. LPCM Output It is available to convert 96 K LPCM digital audio into 48K LPCM output when selecting LPCM as 48 K.
  • Page 41 Channel Delay To adjust the sound configuration use the cursor to scroll up/down; to adjust the sound delay distance use the cursor to scroll left/right. The Sound Delay Distance is used to select different sound transmission effects in - - Audio Setup Page- - Speaker Setup different spaces.
  • Page 42 Reverb Mode Off/Concert /Living/Room/Hall/bathroom/Cave/Arena/Church Select to obtain different reverb effects. HDCD Setup Page Digital Filter Off/ / 1X 2X This option is used to select the sampling frequency for the digital wave filter. The higher the frequency the clearer the quality. The default setting is 1X (which displays CD).To play HDCD, please set it to the default setting or 2X.
  • Page 43 Subtitle English/French/Italian/Swedish/Spaish/Chinese/Japanese/Korean/Russian/Thai Select to choose the available subtitle language options. Disc Menu English/French/Italian/Swedish/Spaish/Chinese/Japanese/Korean/Russian/Thai Select to choose the available disc menu language options. Parental 1 KID SAF/2 G/3 PG/ 4 PG 13/5 PGR/6 R/ 7 NC17/8 ADULT Select to set the parental controls of your system. Default Reset Select to reset your system to the default settings.
  • Page 44 If the password has been set, enter the original password to cancel the original password first before canceling the password setting. As the figure shows, use remote number **** Password key or touch the number pad of the touch screen to enter correct password and confirm.

  • Page 45: Navigation

    4. NAVIGATION OPERATION 4. NAV Operation NOTE: While in NAV, the touch screen functions are limited to Navigation Functions only. Enter/Exit Press the NAV button on the perimeter of the unit to enter the navigation interface. Press the NAV button or any other source button on the unit to exit navigation. To access any other functions, you must first exit the navigation interface.

  • Page 46: Touch Screen Calibration

    4.1 NAV Touch Screen Calibration The Navigation Calibration Screen is only available for a short time, after the vehicle is switched ON. To access the Navigation Calibration Screen, select NAV as soon as the System Self Test has finished. Step 1: Start the Rosen Unit and wait for the Step 2: Select NA V after the Self Test has Self Test to complete.

  • Page 47: Precautions/System Reset

    5. PRECAUTIONS/SYSTEM RESET Hazards -Never use excessive force on the Touch Panel in the System, as this may cause glass breakage and result in sharp edges. -Never place foreign objects into the unit Disc slot, USB, or SD card slot as this will damage the unit and could result in electrical shock or fire.
  • Page 48 Installation -Never modify the System unless instructed by the installation manual. Rosen Entertainment Systems will not be held liable for property damage, injury or death which are the result of improper installation or modification. This system should be installed by a qualified service technician.
  • Page 49 TRADEMARKS/CERTIFICATIONS Manufactured under license from Dolby Laboratories; “Dolby” and the “Double-D” symbol are trademarks of Dolby Laboratories. iPod and Made For iPod is a trademark of Apple Inc., registered in the U.S. and other countries. “Made for iPod” means that an electronic accessory has been designed to connect specifically to iPod and has been certified by the developer to meet Apple performance standards.
