Generac Power Systems Stationary emergency generator Owner's Manual page 118

1 0H30830ST03 1
2 0F2608 1
3 0E3256 1
4 046526 5
(1) 5 059981 4
6 0A5259A 2
7 0F5050A 1
(3) 8 0H2844 2 (REF)
9 0F2573 1
10 0F4011 1
11 0H20620ST03 1
(1) 12 0H2051 1
13 0F2862 1
14 0F2560 1
15 022131 4
16 0E2507 1
0H1827 1
17 035685 2
18 0F2561 1
19 0C8145 8
20 052250 2
21 0C7043 12
22 080713 1
23 022473 8
(1) 24 0C8146 4
25 022097 16
26 076749 1
(2) 27 048031C 2(REF)
28 031971 1
29 0H0696 1
(1) 30 042911 1
31 0F2872 1
32 022304 1
WELDMENT RADIATOR SUPPORT C2
RADIATOR 598 X 568 X 49 CPL RH
V-BELT A58 (60IN O.C.) DDC S60
WASHER LOCK M10
SCREW HHC M10-1.5 X 30 G10.9
HOSE 2"ID X 3.0"LG
SHIELD RADIATOR C4
BEARING SLEEVE 1/2/ X 3/4 X 1
PULLEY FAN V-GROOVE 9"
FAN COOL 22" DIA 10 BLADE LH
ARM BELT TENSIONER
SHOULDER BOLT 1/2 X 2-1/4"
SPRING TENSION CPL
PULLEY V-BELT 4" FLANGED
WASHER FLAT 3/8-M10 ZINC
PROBE COOLANT LEVEL 3/8 NPTF
PROBE COOLANT LEVEL 3/8-18NPTF
CLAMP HOSE #28 1.32-2.25
HUB FLEX PLATE
WASHER FLEX (THIN)
TAPE FOAM 1 X 1 (26.75" LG)
DISK FLEX
BRACKET COOLANT TANK
WASHER FLAT 1/4-M6 ZINC
SCREW HHC 5/16-24 X 1.124
WASHER LOCK M6-1/4
TANK COOLANT RECOVERY
CLAMP HOSE BAND 1/4
BEARING #6205 2NSE C3 E SRI2 S
PULLEY 7.5" DIA MACHINED
SCREW HHC M10-1.5 X 30 G8.8
SCREW HHC 1/2-13 X 2" G8
WASHER FLAT 1/2 ZINC
33 022195 1
34 022196 1
35 0F8651 8
36 052677 1
37 0F9867 1
38 0F2461 1
39 022145 13
40 022129 9
(1) 41 039287 1
42 082774 1
43 0G0795 1
44 0G0816 1
0H1546 1
45 049813 8
46 052644 1
47 0C8566 16
48 0C2454 4
49 090283 1
50 0G53150AL0R 1
51 0C2454B 4
52 0G3989 1
53 039253 2
54 0H0750 1
55 049820 2
56 0H30880ST03 1
57 099502 2
58 0C8165 2
59 029032 1
60 0G3762 1
61 0G1285C 8
62 071296A 2
(4) 63 0H1851 1
64 029333A 9
WASHER LOCK 1/2
NUT HEX 1/2-13 STEEL
SCREW HHFC M8-1.25 X 20 W/M6
WASHER NYLON .50 X .87 X .06
SHAFT FAN DRIVE
RETAINER BEARING
WASHER FLAT 5/16-M8 ZINC
WASHER LOCK M8-5/16
SCREW HHC M8-1.25 X 45 C8.8
KEY WOODRUFF 4 X 19D
HOSE LOWER RADIATOR G2
HOSE UPPER RADIATOR G2 (USED WITH MANFLD
P/N 0G0707)
HOSE UPPER RADIATOR G2 (USED WITH MANFLD
P/N 0G8488)
NUT HEX M6 X 1.0 G8 YEL CHR
SPACER .5 X 1.5 X .25 STL/ZINC
SCREW HHFC M6-1.0 X 20 G8.8
SCREW THF M6-1 X 16 N WA Z/JS
CAP RADIATOR 13 PSI
SPACER CPL COOLING FAN 1/8"
SCREW THF M6-1 X 30 N WA DELTA
TUBE CAC OUT G2 TURBO
SCREW HHC M8-1.25 X 20 C8.8
TUBE CAC IN
NUT HEX LOCK M8-1.25 NY INS
BRACKET TENSIONER SPRING
CLAMP HOSE #24 B1.06-2.00
NUT HEX LOCK 5/16-24 NY INS
HOSE 9/32 ID (36"LG)
CAC 504W X 152H X 50D 2.4L G2
CLAMP CNST TENSION 1.75-2.625
HOSE 2"ID X 3.0"LG
ASSY PCB LCL SENSOR (USE WITH I/N 16, P/N
0H1827 ONLY)
TIE WRAP UL 7.4" X .19" BLK (NOT SHOWN)
BEARING PRESS NOTE:
APPLY LOCTITE 620 BEARING RETAINMENT
COMPOUND TO BEARING SURFACE ON ITEM 37
PRIOR TO PRESSING ITEM 28 ONTO ITEM 37.
ALSO APPLY LOCTITE 620 BEARING RETAINMENT
COMPOUND TO THE OUTSIDE OF 28 PRIOR TO
INSTALLING ITEM 28 INTO ITEM 38.
(1) APPLY MEDIUM STRENGTH BLUE THREAD
LOCKING FLUID TO THREADS.
(2) INCLUDED WITH I/N 26.
(3) ITEM 8 IS INCLUDED WITH ITEM 1.
(4) USE WITH R-200 CONTROL PANEL ONLY.
