About this document This manual should be retained for future reference. The information in this manual was current when published. The manufacturer reserves the right to revise and improve its products. All specifications are therefore subject to change without notice. Terms and Trademark Ethernet, Internet Explorer, Linux, Microsoft, Windows, WWW are registered trademarks of the respective holders.
TABLE OF CONTENTS 1. INTRODUCTION………………………………………………………………..4 2. FEATURES……………………………………………………………………….4 3. SYSTEM REQUIREMENTS…………………………………………………….6 3.1 Minimum System requirements………………………………………………6 3.2 Recommended System requirements…………………………………………6 3.3 Notes about using CMS………………………………………………………7 4. MAIN WINDOW MENU TREE…………………………………………………8 5. SETTING UP……………………………………………………………………..9 5.1 Log in………………………………………………………………………….9 5.2 Live Monitor………………………………………………………………….10 5.3 System………………………………………………………………………..14 5.3.1 Authority……………………………………………………………….15 5.3.2 E-Map…………………………………………………………………..23 5.4 Video Surveillance……………………………………………………………28 5.4.1 DVR……………………………………………………………………28...
It also features an advanced E-map function that allows users to visualize all devices on a geographic region at different zoom levels. Working with the included EverFocus TV Wall software, it can control a monitor wall (local or remote) containing multiple video displays. With powerful and flexible function sets, the ECMS software delivers the most comprehensive remote video management applications to meet your surveillance needs.
Page 5
1. Support multiple concurrent video and audio playback from DVR 2. Searching can be queried based on channel; date and time and event type 3. Support several playback speeds in fast forward and fast reverse playback. 4. Support multiple video and audio archive E-Map 1.
3. SYSTEM REQUIREMENTS 3.1 Minimum System requirements • No existing SQL server system installed • Intel Pentium 4 531 3.0 GHz, 1 MB Cache, 800 MHz FSB • Microsoft Windows XP Professional SP2, Microsoft Windows Vista. Window7 • Microsoft Internet Explorer Version 7.0. •...
b) When more than 64 channels are enabled in live view and playback mode together, it is recommended that the client PC meets below system requirements for optimal performance. • Intel Core2 Quad Q9400 2.66 GHz or higher, 6 MB Cache, 1333 MHz FSB •...
5. SETTING UP 5.1 Log in Enter the IP address and you will see the login page. 1. Language: select the language 2. Login name: type in Login name. (Default Login name: Admin) 3. Password: type in the password. (Default Password: 11111111) 4.
5.2 Live Monitor The default login page is Live Monitor. The Live Monitor configuration page contains the following tabs: The CMS-DVR contains three sections: Live Monitor, System and Video Surveillance. In live monitor, the main page is divided into 7 sections: 1.
Page 11
3. Mapview list: all the maps will be shown. 4. Status/Logout: displays user, current date and time. Click “Logout” button to logout of the system. 5. Display Terminals: When you click on one of displays Device show on the bar of Displays terminal, it will term in the screen as follow.
Page 12
Display terminal is a client PC. After this Display terminal has installed Everfocus Wall AP, ECMS can control it and show the view via this Display terminal. Everfocus Wall AP can support max. 4 monitors for each Display terminal client PC.
Page 13
Using the Navigation Controls The navigation controls you see at maps.google.com are shown on the left. Navigation controls include: 1. Arrows - Click the appropriate arrow buttons to move the view north, south, east or west. 2. Zoom - Click + to zoom in on the center of the map. Click - to zoom out.
5.3 System This section describes the functions of the System. In “System”, there are two main sections: “Authorities” and “E-Map”. In Authority, there are 3 sub-sections: My Account, User Groups and User List.
5.3.1 Authority Authority => My Account => User Setting In this section, user can configure user’s settings. User List is displayed at left panel. The icon with 2 persons means a group, and the icon with only 1 person means a user. Group User 1.
Page 16
10. Mobile: Enter user’s mobile number. 11. Select a hint question and enter the answer. System will check the answer first, if it is correct, the password will be reset to default value “11111111”. Click button to apply changes. Click button to reset settings.
Page 17
System=> Authorities=> User Groups The User Group configuration page contains the following sections Authorities Setting: This section is used to edit group’s authority. There are two default groups: Administrator Group and Guest Group. Users in the same group share the same Authorities, Device Permission and Map Permission.
Page 18
System In system, select system’s authority setting that the group is allowed to do by ticking the item. To select all the items, tick “System”. CCTV In CCTV, select CCTV’s authority setting that the group is allowed to do by ticking the item.
Page 19
Map Permission Select a group first. To create a new group, click “ ” button; to delete a group, click “ ” button. Click “ ” button to print out the page. All the maps will be listed, tick the checkbox to select which map user is allowed to configure.
Page 20
System=> Authorities=> Users list Show all users. Click button to delete a selected user. Click button to add a new user and “add a new user” window pops up.
Page 21
1. User name: Enter user name. It is case sensitive. (Required!) 2. Login name: Enter login name. This name must be unique; the same login name can only be used once. (Required!) 3. User group: Select the group to which user belongs to. (Required!) 4.
Page 22
1. User name: Enter user name. It is case sensitive. (Required!) 2. Login name: Enter login name. This name must be unique. The same login name can only be used once. (Required!). 3. User group: Select the group to which user belongs to. (Required!) 4.
5.3.2 E-Map E-Map=>E-Map Edit In “E-Map Edit”, user will be able to edit the map, delete the map and set a child map. : allows user to change the current map (google map or E-map). Click button to edit the current map. “Edit Current Map” window pops Select Map from Database or File by clicking “Select”...
Page 24
: allows user to delete the current map. : allows user to insert a child map. First, select the area to insert a child map by left clicking the mouse to draw lines. Every click is an end point of the line. When the area is formed, double click the mouse to have all the lines connected.
Page 25
“Edit Child Map” window pops up. Select Map from Database or File by clicking “Select” button to locate the file. Assign a name to the map and change the map scale if necessary. Map preview will be displayed at lower part of window. Click “Apply”...
Page 26
Right click on the device icon to select the DVR. A “Select Device” window pops up. Select one DVR from the device list by clicking on that DVR. The selected DVR will be highlighted and DVR information will be displayed at the upper part of the window.
Page 27
In “E-Map View”, user will be able to view the map. Click button to go to Home map. Click button to go to e-map’s upper level. Click button to go to previous step. Click button to go to next step.
5.4 Video Surveillance 5.4.1 CCTV=> DVR=> Device List Device Group To add a device group: 1. Click button. 2. Key-in device group name. 3. To apply all settings in this page, click button. To delete a device group: 1. Select device group name. 2.
Page 29
Device List Click to add a device to the device group and “Add a new device” window pops up. Basic 1. Device Group: Select the device group. 2. Device Type: Select the device type. 3. Device Name: Enter the device name. Network IP address/name: Enter IP address or DNS name of the device.
Page 30
Click button to edit device list and “Edit Device” window pops up. Select a device to edit first. Basic 4. Device Group: Select the device group. 5. Device Type: Select the device type. 6. Device Name: Enter the device name. Network IP address/name: Enter IP address or DNS name of the device.
Page 31
Click button to print out the current page. Click to delete a selected device from the device group. CCTV=> DVR=> Edit Device By clicking “Edit Device”, the system will lead you to the remote page of the selected DVR. Double click left tree node to enter the DVR edit page.
5.4.2 Search & Playback The Search & Playback configuration page contains the following tabs: Time Search Time Period: Click to select a date to be searched. Go to current month Close the window Go to previous month Go to next month button to select time to be searched.
Page 33
Record Period: Start Time: Starting recording time will be shown. End Time: Ending recording time will be shown. When a selected DVR had been found after query, start/end recording period will be shown here. Device: Model: Select device model. Group: Select device group. Name: Input name of device to be searched.
Page 34
1. Audio: Speaker out on / off. 2. Device information: displays DVR name and its IP address. 3. DVR Layout: Select DVR display layout from full screen, 4-displays, 9-displays and 16-displays. Playback control keys: Playback speed Playback Fast Rewind Pause Play reverse Fast Forward...
Page 35
CCTV=> DVR=> Event Search Time Period Click to select start/end date to be searched. Go to current month Close the window Go to previous month Go to next month button to select start/end time to be searched. Click Up/Down arrows to decrease/increase value. Click Left/Right arrows to switch between hour/minute/seconds.
Page 36
Device Model: Select device’s model. Group: Select device’s group. Name: Enter device’s name. Click button to search the device. Click button to search all devices. Click button to start search the event.
Page 37
CCTV=> DVR=> Archive Disk Recording Time Start Time and End Time of the recorded data in disk. (Not selectable) Time Period Click to select start/end date to be archived. Go to current month Close the window Go to previous month Go to next month button to select start/end time to be archived.
Page 38
Camera Select the camera for the data to be archived. Device Model: Select device’s model. Group: Select device’s group. Name: Enter device’s name. Click button to search the device. Click button to search all events. Click button to start archiving.
5.3.3 Display & Live CCTV=>Display & Live => Live View Click “Live View” for Live View of the DVR. 1. Audio: Speaker out on / off 2. Device List: Select device group first, all the devices will be shown under device group.
Page 40
Focus Far/Focus Near Zoom Out/Zoom In Iris Close/Iris Open Pattern/Tour Auto Pan Set Preset Pan Speed (Faster, Fast, Normal, Slow, Slower) 5. Remove One: Click to remove one DVR from the view layout. 6. Remove All: Click to remove all DVR from the view layout. 7.
Page 41
CCTV=>Display Live=>View Layouts Click button to remove one view. Click button to remove all views. Click button to view layout live image. Select view layout by clicking for full screen mode (1-DVR view) or for 4-displays view (4-DVR view). To add a view layout: 1.
Page 42
view layout will be saved to view list. To delete a view layout: 1. Select view name. 2. Click button. CCTV=> Display Live=> Display Terminal Terminal information is displayed. 1. Display Terminal Type 2. Display Terminal Name 3. IP Address/Name: Enter IP Address or DNS name. 4.
